Z3 Technology Z3-DME-04 User manual

User Instructions
H.264 HD Multimedia System
Digital Media Encoder and Streamer
Model Name: Z3-DME-04
DOC-USR-0087-02
Manual Version 2.26.1.1
Software Version 2.26.1.1
February 2, 2016
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2016 Z3 Technology, LLC. All rights reserved. This document contains proprietary and confidential information of Z3 Technology, LLC
("Z3"). This document may not be used, reproduced, disclosed, or disseminated to anyone without the prior written approval of an authorized
representative of Z3.
Z3 Technology, LLC incorporates HDMI® technology. The terms of HDMI and HDMI High-Definition Multimedia Interface, and
the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
The Power of ZEUS™

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
2
REVISION HISTORY
Version
Date
Change Note
Author
2.26.1
08/12/2015
Original Document
RC/KA
2.26.1.1
02/02/2016
Updated per SW v2.26.1.1. Updated cover photo. Updated HW
warranty link. Corrected Doc # (formerly DOC-USR-0077-xx).
NC/TA

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
3
TABLE OF CONTENTS
1.0 GENERAL DESCRIPTION.................................................................................................6
2.0 QUICK START GUIDE ....................................................................................................7
If You Have Received a System from Z3 with the Software Preloaded .......................................72.1
If You Already Have a System from Z3 and Need to Update the Firmware ..................................72.2
3.0 INCLUDED PARTS LIST ..................................................................................................8
4.0 FEATURES ................................................................................................................9
Supported Input Resolutions - Encoder ...........................................................................94.1
5.0 OPERATING CONTROLS ............................................................................................... 10
6.0 RUNNING THE ENCODER ............................................................................................. 11
Set up the HD Source.............................................................................................. 116.1
Connect and Power Up the Z3-DME-04 ......................................................................... 116.2
Find the Z3-DME-04 Using ZFinder .............................................................................. 126.3
Configure Channel 1 and Encode ................................................................................ 136.4
Run VLC to View Stream .......................................................................................... 156.5
Streaming RTP...................................................................................................... 166.6
Changing the Bitrate Dynamically............................................................................... 176.7
Adjusting the UDP TS Rate........................................................................................ 196.8
Tuning for Latency................................................................................................. 226.9
Encoding from HDMI or Composite In.......................................................................... 236.10
Encoding Closed Caption Data.................................................................................. 266.11
Using the “Aux TS File” Option................................................................................. 286.12
7.0 STREAMING RTMP IN THREE DIFFERENT RESOLUTIONS .......................................................... 29
Connect the Encoder .............................................................................................. 297.1
Configure the Encoder for “Multiple Output from One Input” Mode....................................... 297.2
Configure CH1 for RTMP Streaming ............................................................................. 307.3
Configure CH2 for RTMP Streaming ............................................................................. 317.4
Configure CH3 for RTMP Streaming ............................................................................. 327.5
Set up the Wowza Server ......................................................................................... 337.6
Start the Encode ................................................................................................... 337.7
View the Content on Wowza ..................................................................................... 337.8
8.0 PERFORMING OTHER OPERATIONS WITH THE Z3-DME-04........................................................ 35
Saving Current Settings ........................................................................................... 358.1
Using a Static IP Address.......................................................................................... 368.2
Making a Firmware Update ....................................................................................... 408.3
Using the Password Feature ...................................................................................... 428.4

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
4
9.0 SUMMARY OF OPTIONS ............................................................................................... 44
The System Setup Tab............................................................................................. 449.1
The User Presets Tab .............................................................................................. 459.2
The Status Tab...................................................................................................... 459.3
The MPTS Tab....................................................................................................... 469.4
The CH1/CH2/CH3 Tab............................................................................................ 479.5
Values Appearing at the Bottom of All Tabs .................................................................... 539.6
APPENDIX A: Configuring the Wowza Server for RTMP ............................................................... 54
APPENDIX B: Troubleshooting ............................................................................................ 56
LIST OF FIGURES
Figure 1 Z3-DME-04.........................................................................................................6
Figure 2 Parts Included with the Z3-DME-04............................................................................8
Figure 3 Z3-DME-04 Front View......................................................................................... 10
Figure 4 Z3-DME-04 Rear View.......................................................................................... 10
Figure 5 Connecting SDI In and Turning on the Z3-DME-04 ......................................................... 11
Figure 6 Connecting the Ethernet and Power on the Z3-DME-04 .................................................. 11
Figure 7 ZFinder with Z3-DME-04 Selected ........................................................................... 12
Figure 8 Z3-DME-04 Web GUI (System Setup Page) .................................................................. 13
Figure 9 Channel 1 Configuration Screen –UDP...................................................................... 14
Figure 10 VLC Open Network Screen for UDP ........................................................................ 15
Figure 11 Example of Z3 Video Streaming to VLC (UDP)............................................................ 15
Figure 12 Channel 1 Configuration Screen –RTP..................................................................... 16
Figure 13 VLC Open Network Stream Screen for RTP ............................................................... 16
Figure 14 Example of Z3 Video Streaming to VLC (RTP) ............................................................ 17
Figure 15 Viewing Bitrate in VLC ....................................................................................... 17
Figure 16 Changing the Bitrate Dynamically.......................................................................... 18
Figure 17 Drop in Bitrate after Dynamic Bitrate Change ........................................................... 18
Figure 18 Status Page Output Showing Lower Bitrate ............................................................... 19
Figure 19 Changing TS Rate ............................................................................................. 20
Figure 20 TS Rate and Lower Bitrate Reflected in VLC ............................................................. 21
Figure 21 Tuning for Various Use Cases................................................................................ 22
Figure 22 Clicking on / Creating the CH2 Tab ........................................................................ 23
Figure 23 Configuring HDMI Input on CH2............................................................................. 24
Figure 24 VLC Settings for Viewing the Multicast Stream........................................................... 25

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
5
Figure 25 Composite Adapter Cable ................................................................................... 25
Figure 26 Connections for Closed Caption Extraction ............................................................... 26
Figure 27 Sample Encoder Settings for Composite Closed Caption Extraction .................................. 26
Figure 28 Setting VLC to use the Extracted Closed Caption Data ................................................. 27
Figure 29 Using the Aux TS File Enable Option ....................................................................... 28
Figure 30 Changing to “Encode 1 to 3 Ch” Mode..................................................................... 29
Figure 31 Creating the CH3 Tab ........................................................................................ 29
Figure 32 3-Channel RTMP Encode –Channel 1 Settings ............................................................ 30
Figure 33 3-Channel RTMP Encode –Channel 2 Settings ............................................................ 31
Figure 34 3-Channel RTMP Encode –Channel 3 Settings ............................................................ 32
Figure 35 Getting to the Wowza Test Player.......................................................................... 33
Figure 36 Viewing DME-03 Content on Wowza........................................................................ 34
Figure 37 The User Presets Tab ......................................................................................... 35
Figure 38 Entering a User Preset Name ............................................................................... 35
Figure 39 Saving a User Preset.......................................................................................... 36
Figure 40 Setting a Static IP Address within a User Preset ......................................................... 37
Figure 41 Saving to a User Preset ...................................................................................... 37
Figure 42 Reboot Reminder for Changing IP Settings................................................................ 38
Figure 43 ZFinder with Z3-DME-04 DHCP Address.................................................................... 38
Figure 44 Selecting Z3-DME-04 w/ DHCP Address in ZFinder....................................................... 39
Figure 45 Web GUI Using DHCP Address ............................................................................... 39
Figure 46 Updating the Device Firmware from the Web Interface ................................................ 40
Figure 47 Updater Screen ............................................................................................... 41
Figure 48 File Selection Screen......................................................................................... 41
Figure 49 Selecting “Set Password”.................................................................................... 42
Figure 50 Changing the Password ...................................................................................... 42
Figure 51 Password Entry Screen....................................................................................... 43
Figure 52 Wowza Performance Settings ............................................................................... 54
Figure 53 Wowza Security Settings..................................................................................... 55

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
6
1.0 GENERAL DESCRIPTION
The Z3-DME-04 is a cost-optimized, compact 157 x 122 mm system that allows encode of HD video (up to
1080p60) through SDI or HDMI input, and encode of SD video through a composite input. It allows users to
quickly take video from any of those three sources and stream them to the web or internal clients/PCs via
UDP, RTP, or RTMP. This solution is ideal for applications such as low-cost broadcast encoders, low-
bandwidth video security, satellite uplink, remote monitoring and industrial applications. The Z3-DME-04
provides immediate access to multi-format HD video, integrated system peripherals and production-
qualified codecs.
The Z3-DME-04 features HD performance, compact size, and low latency while still having less power
consumption than a PC-based encoder platform.
Figure 1 Z3-DME-04
33 mm
122 mm
157 mm

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
7
2.0 QUICK START GUIDE
If You Have Received a System from Z3 with the Software Preloaded2.1
To start working with the encoder, you can go straight to Section 6.0, “RUNNING THE ENCODER,” on
page 11. This section describes how to quickly generate a UDP or RTP stream to VLC, how to change
bitrate dynamically, how to adjust the UDP TS rate, how to tune for latency, and how to use DHCP.
Encoding from SDI is described. For encoding from HDMI or composite, a special step of creating a CH2
to encode from is needed. This is described in detail on page 23.
Details on streaming RTMP and also on using the “Encode 1 to 3 Ch” mode (which allows one source to
be encoded three different ways, as long as the total processing involved fits within the constraints of
the encoder’s performance) can be found in Section 7.0, “ STREAMING RTMP IN THREE DIFFERENT
RESOLUTIONS,” on page 28. There are additional notes on successfully configuring Wowza in “APPENDIX
A: Configuring the Wowza Server for RTMP,” on page 54.
If You Already Have a System from Z3 and Need to Update the Firmware2.2
You can update the firmware via the HTTP-based user interface (GUI) by following the instructions in
Section 8.3 “Making a Firmware Update”on page 40.
Please Note: Actual version numbers for your Z3 product may differ from those pictured in this document.

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
8
3.0 INCLUDED PARTS LIST
Z3-DME-04
5V Power Supply
BNC to BNC Cable
DB-9 Serial Cable
1 x Composite Adapter Cable
Note: The serial cable and gender changer are included for advanced troubleshooting purposes only
and are not needed by the typical user.
Figure 2 Parts Included with the Z3-DME-04

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
9
4.0 FEATURES
HD resolutions up to 1920x1080 including 1080i, 1080p60 and 720p
Standard Definition encoding for ISDB-T, DVB-H, and other standards
Video Inputs: 3G-SDI, HDMI, Composite
On-board video scaler provides full screen resizing with all resolutions
Outputs RTP, RTMP TSRTP, or MPEG-2 Transport Stream
DHCP and DNS support
Limited RTSP support
Supports fractional resolutions and frame rates
1x USB 2.0 Interface for local storage
HTTP-based configuration software for user-friendly configuration and control
RS-232 serial port for technical configuration and control
Operating Temp: 0 to 40 degrees C at 20-80% relative humidity (non-condensing)
Storage Temp: -10 to 65 degrees C at 20-80% relative humidity (non-condensing)
Measurements: 157 x 122 x 33 mm (6.19 x 4.81 x 1.31 in)
Weight: 513 g (1.13 lb)
Supported Input Resolutions - Encoder4.1
HDMI: 1080p60, 1080p50, 1080i30, 1080i29.97, 1080i25, 720p60, 720p59.94, 720p50, 576p50,
576i25, 480p60, 480i30, and 480i29.97
SDI: 1080p60, 1080p50, 1080i30, 1080i29.97, 1080i25, 720p60, 720p59.94, 720p50, 576p50,
576i25, 480p60, 480i30, and 480i29.97
Composite: 576i25, 480i29.97

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
10
5.0 OPERATING CONTROLS
FRONT VIEW
REAR VIEW
Figure 4 Z3-DME-04 Rear View
Power
Switch
HDMI
In
Composite
In
SDI
In
Figure 3 Z3-DME-04 Front View
Ethernet
Serial
Port
USB
5V
Power

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
11
6.0 RUNNING THE ENCODER
This section gives step-by-step instructions on using the Z3-DME-04 to stream 1080p or 1080i video to VLC
running on your PC. In addition to the Z3-DME-04, an HD source with SDI output and a PC with the VLC
media player are required. Encoding with an HDMI or a composite source is described later in Section 6.10.
Please Note: Actual version numbers for your Z3 product may differ from those pictured in this document.
Set up the HD Source6.1
Select an HD source with SDI output.(1)
-Power on the HD Source.
-Connect SDI to a monitor.
-Set the HD Source to 1080i output.
-Select content you would like to stream.
If you see playback on the monitor, you’ve confirmed the source works.
Connect and Power Up the Z3-DME-046.2
Connect the SDI source to “SDI In” on the front of the unit.(2)
Connect an Ethernet cable from “Ethernet” on the back of the Z3-DME-04 to a switch, router or(3)
other DHCP server on the same network as your Windows PC.
Connect the 5V power supply, and turn on the power switch. It will take 45-60 seconds to boot.(4)
Figure 5 Connecting SDI In and Turning on the Z3-DME-04
(1) Connect to
SDI Source
Figure 6 Connecting the Ethernet and Power on the Z3-DME-04
(2) Connect to
Ethernet
(3) Connect to
5V Power
(4) Turn on
Switch

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
12
Find the Z3-DME-04 Using ZFinder6.3
ZFinder is a PC Utility that allows you to find any Z3 Technology product on your network. If you have
not yet downloaded this to your computer, you can find it on the USB drive provided with your system.
Verify your PC is set to DHCP. If it is set to a static IP address, ZFinder will be unable to discover(5)
your encoder, or it will appear in red and you will be unable to proceed further.
Run the “ZFinder” PC Utility on your Windows PC. The ZFinder window appears. ZFinder does a scan(6)
of the network and lists the location of all Z3 systems connected to the network. In this case, the
Z3-DME-04 appears.
Click on the Z3-DME-04 entry in the window to select it. This will cause the “Edit Device”, “Open (7)
Device” and “Flash LEDs” boxes to activate.
Figure 7 ZFinder with Z3-DME-04 Selected
*Note:Selecting “Edit Device” allows for manual changes to network settings. Selecting “Flash
LED’s” is not applicable to the Z3-DME-04 as there are no LEDs.
Click on “Open Device.” An Internet browser window is opened (for best results, we recommend(8)
using Firefox or Chrome) and the HTTP-based graphical user interface (GUI) appears at the System
Setup tab.

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
13
Click on the “CH1” tab.(9)
Configure Channel 1 and Encode6.4
At the CH1 tab, change Video Resolution to “1920x1080”.(10)
Set “Output Format” to UDP.(11)
You can set the “Dest Address” to:(12)
(a) the IP address of your PC that will be running the VLC media player (in the pictured
example, 192.168.0.6)
(b) or to a multicast address (An example multicast address would be “225.1.2.3”. If you are
on a shared network, check with your Network Administrator.)
Make note of the value of “Dest Port” (This will be “5004”by default).(13)
Figure 8 Z3-DME-04 Web GUI (System Setup Page)

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
14
The encoder may have already started (after 20 seconds, the encoder will automatically try to(14)
start). If it has, click on “stop” near the bottom of the screen. The status will then change to
“STOPPED”. Then click on “start”. Once you do this, the status will change to “RUNNING.” If the
encoder hadn’t started already, simply click on “start” and observe the status change.
*Note:If you want to encode 1080p60, you must first change “Operating Mode” at the bottom
right from “Encode Interlaced/Progressive” to “Encode Single CH No Scale.” Note that, in
“Encode Single CH No Scale” mode, only CH1 can be used.
Figure 9 Channel 1 Configuration Screen –UDP
(2) Change
to UDP
(3) Change to IP
address of your
PC or multicast
address
(4) Note “Dest Port”
value
(1) Change to
“1920x1080” or
“Follow input”
(5) If necessary, click “stop”
(6) Click “start”

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
15
Run VLC to View Stream
6.5
Run VLC on your PC (version used in testing at Z3: 2.1.5)(15)
Select Media –Open Network Stream. In the box, type “udp://@192.168.0.6:5004”, where (16)
“192.168.0.6” matches the values of the computer IP address or multicast address entered for
“Dest Address” in step 6.4(12), and 5004 is the value of “Dest Port” noted in step 6.4(13).
Press “Enter.” (17)
You should now see video streaming to VLC:(18)
Figure 11 Example of Z3 Video Streaming to VLC (UDP)
Figure 10 VLC Open Network Screen for UDP

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
16
Streaming RTP
6.6
Once you have UDP streaming, it is relatively simple to change to RTP streaming. One parameter
change is all that is needed. To stream using RTP, complete the following steps:
In the CH1 configuration tab, click on “stop” to stop the current encoding session.(19)
Change “Output Format” from “UDP” to “RTP.”(20)
Click on “start” to start the RTP encoding session. At this point your settings should look like the(21)
following:
Open VLC. Select “Media – Open Network Stream”.(22)
In the “Open Media” box, type “rtsp://{IP Address}/z3-{ch #}{m}.mp4”, where {IP Address} is the (23)
IP address of the Z3-DME-04, {ch #} is 1 for CH1, 2 for CH2, and 3 for CH3, and {m} is added if a
multicast address is being streamed. For example, if the IP address of the Z3-DME-04 is
192.168.1.3, encode is being done from CH1, and unicast streaming is being done, the user would
type in “rtsp://192.168.1.3/z3-1.mp4”:
.
*Note: VLC version 2.1.5 or later is needed for RTSP support.
Figure 13 VLC Open Network Stream Screen for RTP
(1) Change to “RTP”
Figure 12 Channel 1 Configuration Screen –RTP

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
17
You will then see RTP video streaming on VLC:(24)
Changing the Bitrate Dynamically6.7
The Z3-DME-04 includes an “Update” button which allows you to change the bitrate and/or frame rate
without stopping and restarting the encoder. To use this feature, complete the following steps:
In VLC, click on “Tools” and select “Codec Information.” This brings up a window with four tabs.(25)
Select the “Statistics” tab. In this tab, you can see the current video + audio bitrate:
Video + Audio bitrate
Figure 15 Viewing Bitrate in VLC
Figure 14 Example of Z3 Video Streaming to VLC (RTP)

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
18
In the CH1 screen, change the bit rate from “8000K” to “2000K” and click “update”:
(26)
You will see the quality of the picture in VLC change and the video bitrate drop:(27)
Figure 16 Changing the Bitrate Dynamically
(1) Change bitrate to 2000K
(2) Click “update”
Figure 17 Drop in Bitrate after Dynamic Bitrate Change
Lower video + audio bitrate

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
19
If you click on the status page and click “Refresh,” you will also see the updated bitrate reflected:
(28)
The parameter “Frame Rate Divider” can also be updated dynamically using the “update”
button. All other parameters require a stop and then start to change.
Adjusting the UDP TS Rate6.8
The Z3-DME-04 includes a parameter to adjust the TS rate independent of the video bitrate. This can
be found just below “PMT PID” when “UDP” is selected as the output format.
Normally, this value is set to 25% to 33% above the sum of the video and audio bitrate. For example,
the default value out of the factory is a value of 10Mbps, corresponding to 8Mbps for the video.
There are times, however, when it is desirable to make this value higher. For example, if the encoder
bitrate is very low (below 1Mbps), it is advisable to allow more leeway in the event there are some
challenging scenes to encode. An example follows:
Return to the “CH1” tab. In this tab, click “stop”. Then change “Video Resolution” to “720x480”,(29)
“Video Bitrate” to “512K”, and “Output Format” to “UDP” (steps 1-4 in the figure below):
Figure 18 Status Page Output Showing Lower Bitrate
Lower bitrate

DOC-USR-0087-02
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
20
Once you select UDP, “TS RATE” should appear with the default value of 10000K. Change this to(30)
1000K.
Click on “start” to start encoding).(31)
Open VLC to view your UDP stream (Section 6.5) and view the “Status” tab (Section 6.7). You will(32)
see a lower value for the overall input rate and for the “content” rate:
(4) Change to
UDP
(1) Click stop
(6) Click start
(2) Change to
“720x480”
(3) Change to
512K
(5) Change to
1000K
Figure 19 Changing TS Rate
