Zeiss EXTARO 300 User manual

ZEISS EXTARO 300
Service Manual
Confidential and Proprietary
SM-30-0053
Version 01, 2017-03-10
Order No. 2215-710
General
Information
Checkout and
Preventive
Maintenance
Parts Removal /
Re
p
lacement
Adjustment and
Calibration
Troubleshooting /
Error codes
Diagrams
Parts
Appendices

ZEISS EXTARO 300
COPYRIGHT NOTE
The information contained in this document is subject to the copyright of Carl Zeiss Meditec AG and
must not be reproduced either in whole or in part without prior written consent by
Carl Zeiss Meditec AG. The content of this document is intended to provide the user with detailed
information required for the repair and maintenance of the delivered system and for spare part
orders. Although every effort has been made to ensure that the information contained in this
document is up to date and correct at the date of publication, no express or implicit guarantee can
be given for the accuracy and completeness of the information.
All trademarks, registered trademarks and brand names mentioned in this manual are the property of
the respective owners.
Copyright © 2017 by Carl Zeiss Meditec AG. All rights reserved.
Carl Zeiss Meditec AG
Goeschwitzer Strasse 51-52
07745 Jena
Germany
Service Manual Confidential and Proprietary SM-30-0053
Order No. 2215-710 ii Version 01, 2017-03-10

ZEISS EXTARO 300
REVISION CONTROL LIST
Document: Service Manual „ZEISS EXTARO 300”
Document No.: SM-30-0053
Order No.: 2215-710
Date of issue: 2017-03-10
Section Version Date of issue
1 – General Information 01 2017-03-10
2 – Checkout and Preventive Maintenance 01 2017-03-10
3 – Parts Removal / Replacement 01 2017-03-10
4 – Ad
j
ustment and Calibration 01 2017-03-10
5 – Troubleshootin
g
/ Error codes 01 2017-03-10
6 – Dia
g
rams 01 2017-03-10
7 – Parts 01 2017-03-10
8 – Appendices 01 2017-03-10
The order number (e.g. Order No. 2215-710) and the document number of the service manual
(e.g. SM-30-0053) as well as the version and the date of issue of the relevant section
(e.g. Version 01, 2017-03-10) are indicated at the bottom of each page.
Revised sections are marked with a new version number and new date of issue. The current status of
all versions of the sections is shown in the Revision Control List (see above).
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 iii Order No. 2215-710

ZEISS EXTARO 300
Service Manual Confidential and Proprietary SM-30-0053
Order No. 2215-710 iv Version 01, 2017-03-10

ZEISS EXTARO 300
Contents
Section 1 – General Information
Section 2 – Checkout and Preventive Maintenance
Section 3 – Parts Removal / Replacement
Section 4 – Adjustment and Calibration
Section 5 – Troubleshooting / Error codes
Section 6 – Diagrams
Section 7 – Parts
Section 8 – Appendices
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 v Order No. 2215-710

Section 1 – General Information
1.1 Update information ............................................................................................. 2
1.2 About This Manual............................................................................................... 3
1.2.1 General Notes .................................................................................................................. 3
1.2.2 Conventions..................................................................................................................... 4
1.3 Service bulletins ................................................................................................... 4
1.4 Service Strategy ................................................................................................... 5
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 1 - 1 Order No. 2215-710

General Information ZEISS EXTARO 300
1.1 Update information
Version Comments
01 2017-03-10: First Issue
Notes
Service Manual Confidential and Proprietary SM-30-0053
Order No. 2215-710 1 - 2 Version 01, 2017-03-10

ZEISS EXTARO 300 General Information
1.2 About This Manual
1.2.1 General Notes
This manual is the field service reference for troubleshooting, repair, adjustment, and calibration of
the ZEISS EXTARO 300. The manual is intended for use by field service engineers who have
completed specific service training on the ZEISS EXTARO 300.
This service manual describes the full scope of activities that can be performed on site by service staff
who have completed appropriate training. More extensive activities require that the system be
returned to ZEISS for factory repair.
The procedures described in this manual assume that the reader is familiar with the operation of the
system. A user manual with complete operating instructions is contained in the delivery package of
every system. Information presented in the user manual is not repeated in this service manual.
Update revisions to this service manual will be issued as required.
The general layout of the service manual is shown below. For greater detail, please refer to the table
of contents.
Service manual layout
Section 1 - General Information
Section 2 - Checkout and Preventive Maintenance
Section 3 - Parts Removal / Replacement
Section 4 - Adjustment and Calibration
Section 5 - Troubleshooting / Error codes
Section 6 - Diagrams
Section 7 - Parts
Section 8 - Appendices
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 1 - 3 Order No. 2215-710

General Information ZEISS EXTARO 300
1.2.2 Conventions
The following conventions apply in this manual:
Unless otherwise specified, front and back of the system are as viewed from the front (patient
side) of the system.
Unless otherwise specified, all tool dimensions for screws and nuts are metric values.
1.3 Service bulletins
Service bulletins are a vital element of service support. Bulletins are used to quickly convey technical
information on a variety of field service topics, including:
Changes in system design Service manual revisions
Technical problems and corrections New calibration and adjustment procedures
Software updates Upgrade announcements and procedures
New troubleshooting procedures System checkout - checklist
Problem alerts Service disclaimers
Your service bulletins should be filed where easily accessible for quick reference.
NOTE
Service bulletins are confidential and proprietary documents for the sole use of personnel
employed by ZEISS.
As a ZEISS employee, subsidiary or distributor you are required to handle your service
bulletins as appropriate for proprietary and confidential information.
Service Manual Confidential and Proprietary SM-30-0053
Order No. 2215-710 1 - 4 Version 01, 2017-03-10

ZEISS EXTARO 300 General Information
1.4 Service Strategy
The service strategy for the ZEISS EXTARO 300 stipulates that only a limited scope of work may be
performed in field service. This scope is appropriately marked in this service manual and is dealt with
in detail during the service training for this product.
Spare parts and procedures marked Factory repair only must be handled exclusively by the factory
repair department of ZEISS or by appropriately equipped workshops authorized by ZEISS.
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 1 - 5 Order No. 2215-710

Section 2 – Checkout and Preventive
Maintenance
ZEISS EXTARO 300 on Floor Stand Installation Instruction........................... SM-30-0053-A01
ZEISS EXTARO 300 on Ceiling Mount Installation Instruction....................... SM-30-0053-A02
ZEISS EXTARO 300 on Wall Mount Installation Instruction .......................... SM-30-0053-A03
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 2 - 1 Order No. 2215-710

Checkout and Preventive Maintenance ZEISS EXTARO 300
Notes
Service Manual Confidential and Proprietary SM-30-0053
Order No. 2215-710 2 - 2 Version 01, 2017-03-10

Section 3 – Parts Removal / Replacement
3.1 Update information ............................................................................................. 2
3.2 General information............................................................................................. 3
3.2.1 Tools required ...............................................................................................................3
3.2.2 Lubricants and thread locker .........................................................................................3
3.2.3 Screw torque specification............................................................................................. 3
3.2.4 Documents required...................................................................................................... 3
3.3 ZEISS EXTARO 300............................................................................................... 4
3.3.1 Removing OPMI from Yoke ........................................................................................... 4
3.3.2 Removing the rear OPMI cover with cable cover ............................................................ 5
3.3.3 Removing the illumination module ................................................................................ 6
3.3.4 Removing the varioscope...............................................................................................9
3.3.5 Removing the OPMI PCBA........................................................................................... 11
3.3.6 Removing the filter wheel module (option) .................................................................. 12
3.3.7 Changing the filter wheel motor.................................................................................. 13
3.3.8 Changing the magnification changer ........................................................................... 14
3.3.9 Changing the multiple function knob........................................................................... 16
3.3.10 Changing the LED Indicator PCB .................................................................................. 19
3.4 Floor Stand ........................................................................................................ 21
3.4.1 Changing the upper covers of suspension arm............................................................. 21
3.4.2 Changing the lower cover of suspension arm............................................................... 21
3.4.3 Changing carrier arm cover ......................................................................................... 22
3.4.4 Changing the gas spring.............................................................................................. 23
3.4.5 Changing the limit switch ............................................................................................26
3.4.6 Changing the suspension arm...................................................................................... 27
3.4.7 Changing the carrier arm.............................................................................................28
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 3 - 1 Order No. 2215-710

Parts Removal / Replacement ZEISS EXTARO 300
3.1 Update information
Version Comments
01 2017-03-10: First Issue
Notes
Service Manual Confidential and Proprietary SM-30-0053
Order No. 2215-710 3 - 2 Version 01, 2017-03-10

ZEISS EXTARO 300 Parts Removal / Replacement
3.2 General information
Repair and maintenance work must only be performed by authorized service staff.
Ensure that the stand is always switched off during repair or maintenance work.
The relevant ESD protection measures must be observed when working on electrical components.
Fasten cable ties and additional components after dismantling.
3.2.1 Tools required
Standard tool kit
ESD service kit
Torx screwdriver set
Multimeter
T30 Torx Screw Driver
Cable Tie
3.2.2 Lubricants and thread locker
Grease TF 30 000000-0117-921
Grease GF 50 000000-0117-939
Grease GF 100 000000-0117-938
Thread locker
3.2.3 Screw torque specification
Recommended screw torque specification tolerance ± 5 %
Size Kgf*cm Nm
M2 5.0 0.5
M2.5 7.0 0.7
M3 13.9 1.4
M4 31.2 3.1
3.2.4 Documents required
Service Manual for ZEISS EXTARO 300 SM-30-0053
Technical Safety Check SM-30-8005-115
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 3 - 3 Order No. 2215-710

Parts Removal / Replacement ZEISS EXTARO 300
3.3 ZEISS EXTARO 300
3.3.1 Removing OPMI from Yoke
1) Unscrew the cover (1) and remove it.
Fig. 1: Removing the cover
2) Remove the screw (2) M6x20 ISO 14579
-A2-70 with T30 Torx screw driver.
3) Remove the OPMI body from the Yoke.
Fig. 2: Removing the screw
1
2
Service Manual Confidential and Proprietary SM-30-0053
Order No. 2215-710 3 - 4 Version 01, 2017-03-10

ZEISS EXTARO 300 Parts Removal / Replacement
3.3.2 Removing the rear OPMI cover with cable cover
1) Remove the two screws (1) M3x8
ISO 14579 -A2-70.
2) Remove the screw (2) M3x12 ISO 10642
-A2-70 with the manual filter driver.
Fi
g
. 3: Removin
g
the rear OPMI cover
3) Take out the rear OPMI cover with cable
cover.
Fig. 4: Taking out the rear OPMI cover
1
2
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 3 - 5 Order No. 2215-710

Parts Removal / Replacement ZEISS EXTARO 300
3.3.3 Removing the illumination module
Remove the rear OPMI cover with cable cover (see Section 3.3.2).
1) Unplug the light guide from the socket (1).
Fig. 5: Unplugging the light guide
2) Remove the four screws (2) M3x10
ISO 14580 –A2-70 from the bottom.
Caution
Make sure varioscope is not falling down.
Fi
g
. 6: Removin
g
f
our screws
2
1
Service Manual Confidential and Proprietary SM-30-0053
Order No. 2215-710 3 - 6 Version 01, 2017-03-10

ZEISS EXTARO 300 Parts Removal / Replacement
3) Take out the varioscope together with the
illumination module.
Fig. 7: Varioscope with illumination module
4) Undo the two screws (3) M2.5x6 ISO 14579 -
A2-70 and remove the cable bracket.
Fig. 8: Removing the cable bracket
3
SM-30-0053 Confidential and Proprietary Service Manual
Version 01, 2017-03-10 3 - 7 Order No. 2215-710

Parts Removal / Replacement ZEISS EXTARO 300
5) Remove the four screws (4) M3x8
(the other two screws are at the other side).
Fig. 9: Removing the four screws
6) Take out the illumination module.
Fig. 10: Illumination module
4
Service Manual Confidential and Proprietary SM-30-0053
Order No. 2215-710 3 - 8 Version 01, 2017-03-10
