Zeiss IOLMaster 700 User manual

IOLMaster®700
Service Manual
Confidential and Proprietary
SM-30-4060
Version 03, 2014-10-13
Order No. 2075-325
General
Information
Checkout and
Preventive
Maintenance
Parts Removal /
Replacement
Adjustment and
Calibration
Troubleshooting /
Error codes
Diagrams
Parts
Appendices

IOLMaster®700
COPYRIGHT NOTE
The information contained in this document is subject to the copyright of Carl Zeiss Meditec AG and
must not be reproduced either in whole or in part without prior written consent by
Carl Zeiss Meditec AG. The content of this document is intended to provide the user with detailed
information required for the repair and maintenance of the delivered system and for spare part
orders. Although every effort has been made to ensure that the information contained in this
document is up to date and correct at the date of publication, no express or implicit guarantee can
be given for the accuracy and completeness of the information.
All trademarks, registered trademarks and brand names mentioned in this manual are the property of
the respective owners.
Copyright © 2014 by Carl Zeiss Meditec AG. All rights reserved.
Carl Zeiss Meditec AG
Goeschwitzer Strasse 51-52
07745 Jena
Germany
Service Manual Confidential and Proprietary SM-30-4060
Order No. 2075-325 ii Version 03, 2014-10-13

IOLMaster®700
REVISION CONTROL LIST
Document: Service Manual „IOLMaster®700”
Document No.: SM-30-4060
Order No.: 2075-325
Date of issue: Version 03, 2014-10-13
Section
Version
Date of issue
1 – General Information
03
2014-10-13
2 – Checkout and Preventive Maintenance
03
2014-10-13
3 – Parts Removal / Replacement
03
2014-10-13
4 – Adjustment and Calibration
03
2014-10-13
5 – Troubleshooting / Error codes
03
2014-10-13
6 – Diagrams
03
2014-10-13
7 – Parts
03
2014-10-13
8 – Appendices
03
2014-10-13
The order number (e.g. Order No. 2075-325) and the document number of the service manual
(e.g. SM-30-4060) as well as the number of the section, the version and the date of issue of the
relevant section (e.g. Section 1, Version 03, 2014-10-13) are indicated at the bottom of each page.
Revised sections are marked with a new version number and new date of issue. The current status of
all versions of the sections is shown in the Revision Control List (see above).
SM-30-4060 Confidential and Proprietary Service Manual
Version 03, 2014-10-13 iii Order No. 2075-325

IOLMaster®700
Service Manual Confidential and Proprietary SM-30-4060
Order No. 2075-325 iv Version 03, 2014-10-13

Section 1 – General Information
1.1 Update information ................................................................................................. 2
1.2 About This Manual................................................................................................... 3
1.2.1 General Notes .......................................................................................................................3
1.2.2 Conventions..........................................................................................................................4
1.3 Service bulletins ....................................................................................................... 4
1.4 IOLMaster®700 Service Strategy ............................................................................. 5
1.4.1 General Safety Instructions....................................................................................................5
1.4.2 Laser Class ............................................................................................................................5
1.5 Disposal of the product within the EU..................................................................... 6
SM-30-4060 Confidential and Proprietary Service Manual
Version 03, 2014-10-13 1 - 1 Order No. 2075-325

General Information IOLMaster®700
1.1 Update information
Version Comments
01 2013-07-24 First issue
02 2014-08-15 Second issue (Gate 2)
03 2014-10-13 Third issue (Gate 3/4)
Notes
Service Manual Confidential and Proprietary SM-30-4060
Order No. 2075-325 1 - 2 Version 03, 2014-10-13

IOLMaster®700 General Information
1.2 About This Manual
1.2.1 General Notes
This manual is the field service reference for troubleshooting, repair, adjustment, and calibration of
the IOLMaster®700. The manual is intended for use by field service engineers who have completed
ZEISS specific service training on the IOLMaster®700.
The service manual is designed to support Level 1 of a two-level service strategy. Level 1 (on-site)
field service employs modular replacement of printed circuit boards and other assemblies that are
most effectively repaired on site. This is the service strategy used in field service, and presented in
ZEISS training classes. Level 2 (workshop repair) include procedures which are not possible on-site or
where on-site repair was not successful. See section 1.4, page 5for additional information regarding
the IOLMaster®700 service strategy.
The procedures in this manual assume that the reader is familiar with operation of the instrument.
Complete operating instructions are contained in the IOLMaster®700 User Manual. Information
presented in the user manual is not repeated in this service manual. The user manual can be ordered
separately as a standard ZEISS part.
Update revisions to this service manual will be issued by Service Bulletin, as required.
The general layout of the service manual is shown below. For greater detail, please refer to the Table
of Contents.
Service manual layout
Section 1 - General Information
Section 2 - Checkout and Preventive Maintenance
Section 3 - Parts Removal / Replacement
Section 4 - Adjustment and Calibration
Section 5 - Troubleshooting / Error codes
Section 6 - Diagrams
Section 7 - Parts
Section 8 - Appendices
SM-30-4060 Confidential and Proprietary Service Manual
Version 03, 2014-10-13 1 - 3 Order No. 2075-325

General Information IOLMaster®700
1.2.2 Conventions
The following conventions apply in this manual:
Unless otherwise specified, front and back of the system are as viewed from the patient side of
the system (front).
Unless otherwise specified, right and left of the system are as viewed from the patient side of the
system (front).
Unless otherwise specified, all tool dimensions for screws and nuts are metric values.
1.3 Service bulletins
Service bulletins are a vital element of service support. Bulletins are used to quickly convey technical
information on a variety of field service topics, including:
Changes in system design Service manual revisions
Technical problems and corrections New calibration and adjustment procedures
Software updates Upgrade announcements and procedures
New troubleshooting procedures System checkout - checklist
Problem alerts Service disclaimers
Your service bulletins should be filed where easily accessible for quick reference.
NOTE
Service bulletins are confidential and proprietary documents for the sole use of personnel
employed by ZEISS.
As a ZEISS employee, subsidiary or distributor you are required to handle your service
bulletins as appropriate for proprietary and confidential information.
Service Manual Confidential and Proprietary SM-30-4060
Order No. 2075-325 1 - 4 Version 03, 2014-10-13

IOLMaster®700 General Information
1.4 IOLMaster®700 Service Strategy
The service strategy for IOLMaster®700 envisages that field service must only be performed by
appropriately trained technicians authorized by ZEISS. These activities are described in this service
manual and are dealt with in detail during the service training for this product.
Only original spare parts must be used.
For maintenance and repair adequate ESD protection measures must be taken. Only tools specified in
the tools list must be used (see section 7).
1.4.1 General Safety Instructions
If you need to gain access to the interior electronics of the IOLMaster®700, especially the computer
base, always disconnect the instrument from any and all power sources first.
For maintenance and repair adequate ESD protection measures must be taken. Only tools specified in
the tools list may be used (see section 7).
Only original spare parts listed in section 7 and the official CZM spare part price list must be used.
Do not use or install software which is not approved and tested by CZM. Other procedures than
described in this manual are not allowed to be performed by the field service engineer.
After any kind of manipulation or changes perform a System Checkout in accordance with the
instrument checklist and initiate a technical safety check according to section 2, especially after the
service of electronic parts directly connected to the main power, e.g. power supply, main switch and
power entry module.
1.4.2 Laser Class
Based on the IEC 60825-1 laser class specification the following laser classes can be found within the
IOLMaster®700.
Class 1
Normal Use with Measurement Head covers in place
Class 1M
Service Activity with Measurement Head covers removed.
WARNING RISK OF OPTICAL RADIATION
Once the Glass Fiber is disconnected, do not look directly or via any optical tool, such
as mirrors, magnification lenses or microscopes into the Laser, in order to prevent
potential damage to the Eye.
SM-30-4060 Confidential and Proprietary Service Manual
Version 03, 2014-10-13 1 - 5 Order No. 2075-325

General Information IOLMaster®700
1.5 Disposal of the product within the EU
EU directives and national regulations currently in force at the time of marketing prohibit the disposal
of the product specified on the delivery note in domestic waste or by municipal waste disposal
companies.
For more information on disposal of the product, please contact your local dealer, the manufacturer
or their legal successors. Please also take note of the manufacturer’s current online information.
If the product or its components are resold, the seller has the duty to notify the buyer that the
product must be disposed of in accordance with currently valid national regulations.
Service Manual Confidential and Proprietary SM-30-4060
Order No. 2075-325 1 - 6 Version 03, 2014-10-13

Section 2 – Checkout and Preventive
Maintenance
2.1 Update information ................................................................................................. 2
2.2 Checkout and Maintenance ..................................................................................... 3
2.3 Technical and Electrical Safety Check ...................................................................... 3
2.3.1 General Information ..............................................................................................................3
2.3.2 Procedure of the technical safety check.................................................................................3
Checking the electrical safety ................................................................................................3
1. Measuring protective ground resistance ............................................................................4
2.Measuring the leakage current ..........................................................................................4
3. Measuring the insulation resistance...................................................................................4
2.3.3 Reading points ......................................................................................................................5
SM-30-4060 Confidential and Proprietary Service Manual
Version 03, 2014-10-13 2 - 1 Order No. 2075-325
IOLMaster 700 Checklist & Maintenance Report ............................................. SM-30-4060-A01

Checkout and Preventive Maintenance IOLMaster®700
2.1 Update information
Version Comments
01 2013-07-24 First issue
02 2014-08-15 Second issue (Gate 2)
03 2014-10-13 Third issue (Gate 3/4)
Notes
Service Manual Confidential and Proprietary SM-30-4060
Order No.2075-325 2 - 2 Version 03, 2014-10-13

IOLMaster®700 Checkout and Preventive Maintenance
2.2 Checkout and Maintenance
Procedure
Please follow the instructions of the Checkout and Maintenance form (see Section 8 Appendices) as
accurate as possible. For any nonconformity please perform the necessary adjustments and
alignments
2.3 Technical and Electrical Safety Check
2.3.1 General Information
The detailed description of the technical safety check procedure can be found in
Service Manual SM-30-8005-116 (Medical Electrical Equipment in Field Service) This Manual is for all
Carl Zeiss Meditec AG medical products applicable and equates the latest international rules for
electrical safety. Additionally, this service manual also describes the most important procedures
inclusive instrument specific procedures e.g. the reading points for the different tests.
NOTE
If you have national rules for electrical safety, Service Manual SM-30-8005-116 is in force
only analogous. In this case you have to fulfil the values of your national standards (e.g.
NFPA 99, AAMI ES-1).
Only qualified technicians shall perform these tests. Qualification shall include training on the subject,
knowledge, experience, and acquaintance with the relevant technologies and regulations. The
technician shall be able to assess safety and shall be able to recognize possible consequences and
hazards arising from non-conforming equipment.
2.3.2 Procedure of the technical safety check
Complete the following points in line with the test procedures of the Instrument
Checklist:
Check that the housing (in particular the ventilation slots) is undamaged and free from
contamination.
Check all cables (in particular the insulation) for damage.
Check that all notes and labels are complete and correctly positioned using the user manual.
Checking the electrical safety
(This test must be performed as part of the installation procedure, the annual maintenance service
and technical safety check, or after repairs affecting safety-relevant components).
During the technical safety check, the device must be tested for electrical safety.
Perform the measurements in accordance with IEC 62353:2007 and DIN EN 62353:2008.
The measuring results must be documented in the technical safety check report.
Refer Service Manual SM-30-8005-116.
SM-30-4060 Confidential and Proprietary Service Manual
Version 03, 2014-10-13 2 - 3 Order No. 2075-325

Checkout and Preventive Maintenance IOLMaster®700
Procedure:
1. Measuring protective ground resistance
A maximum test voltage of 24V and a test current of 10A AC are recommended for measurement.
1) Connect the device with its connecting cable to the power socket of the safety tester
(e.g. RIGEL 288).
2) Firmly press the test probe against a screw head on the housing of the IOLMaster (see Fig. 2)
3) Start the measurement and note down the measured value.
4) If the IOLMaster is powered via the power socket of the IT table, repeat the measurement for the
table. The same applies if the system is operated via a multiple socket. Include the multiple socket
into the measurement in this case.
5) Note down the highest value measured.
Note
The limit value that must not be exceeded is 0.3 Ohms for devices with a power cord
and 0.5 Ohms for systems with a multiple socket.
2. Measuring the leakage current
We recommend using the differential current method, where the device is measured during
operation and both phase directions are taken into account. The IOLMaster connected and operated
via the safety tester.
1) When using the RIGEL 288 tester, select IEC 62353, differential measurement and semi automatic
mode (to boot and shut down the computer manually during reversal of polarity).
2) Please note the risk of a computer damage using safety testers with fully automatic reversal of
polarity!
3) Switch on the instrument at the main switch.
4) Firmly press the test probe against a screw head on the housing of the IOLMaster (see Fig. 1 and
Fig. 2) and start measurement. The tester automatically performs a reversal of polarity.
5) Note down the highest value measured.
Note
The limit value of 0.5 mA must not be exceeded in any of the measurements.
3. Measuring the insulation resistance
Perform this measurement at 500V DC.
1) Connect the power cord of the IOLMaster to the power socket of the safety tester.
2) Switch on the instrument at the main switch.
3) Start the measurement.
4) Note down the measured value.
Note
The measured value must not be less than the limit value of 2 MOhm.
If the IOLMaster is operated via the power socket of the instrument table and/or via a multiple
socket, repeat the measurements accordingly.
Service Manual Confidential and Proprietary SM-30-4060
Order No.2075-325 2 - 4 Version 03, 2014-10-13

IOLMaster®700 Checkout and Preventive Maintenance
2.3.3 Reading points
According to Service Manual SM-30-8005-116 following tests are necessary:
Measuring of protective earth impedance
Measuring of leakage currents
Measuring of insulation resistance
For all measurements and tests during the electrical safety check please use the two points according
to Fig. 1 and Fig. 2
Fig. 1: Measuring point base Fig. 2: Measuring point PI
SM-30-4060 Confidential and Proprietary Service Manual
Version 03, 2014-10-13 2 - 5 Order No. 2075-325

Section 3 – Parts Removal Replacement
3.1 Update information ............................................................................................. 2
3.2 Measurement Head.............................................................................................. 3
3.2.1 Measurement Head Side Covers ...................................................................................... 3
3.2.2 Measurement Head (complete)........................................................................................ 5
3.2.3 MH Cable........................................................................................................................ 8
3.2.4 Measurement Head Cooling Fan...................................................................................... 9
3.2.5 Dust Covers................................................................................................................... 10
3.2.6 Lens Drive (PCB & Cable) ............................................................................................... 11
3.2.7 Shutter (PCB & Cable).................................................................................................... 12
3.3 Computer Base................................................................................................... 13
3.3.1 Computer Base Covers .................................................................................................. 13
3.3.2 Computer Module & Cover Removal.............................................................................. 14
3.3.3 Computer Module Replacement .................................................................................... 15
3.3.4 Power Supply ................................................................................................................ 16
3.3.5 CMOS Battery ............................................................................................................... 17
3.3.6 Computer Module Cooling Fan...................................................................................... 18
3.3.7 mSATA (service drive) .................................................................................................... 18
3.3.8 Hard drives (HDD and/or SSD)........................................................................................ 19
3.3.9 PCIe Adapter PCB.......................................................................................................... 19
3.3.10 CIF (Central Interface).................................................................................................... 20
3.4 Instrument Base / Cross Stage ........................................................................... 21
3.4.1 Brake Cap ..................................................................................................................... 21
3.4.2 Cross Stage Covers........................................................................................................ 21
3.4.3 Joystick ......................................................................................................................... 22
3.4.4 Proximity Switch (OS/OD detector) ................................................................................ 23
3.4.5 X-Y Guideway, Gear Rack and Gears with Rollers .......................................................... 24
3.4.6 Cross Stage Brake.......................................................................................................... 25
3.5 PI (Patient Interface) .......................................................................................... 26
3.5.1 PI Removal .................................................................................................................... 26
3.5.2 PI Replacement ............................................................................................................. 27
3.5.3 PI Cable......................................................................................................................... 28
SM-30-4060 Confidential and Proprietary Service Manual
Version 03, 2014-10-13 3 - 1 Order No. 2075-325

Parts Removal Replacement IOLMaster 700
3.1 Update information
Version Comments
01 2013-07-24 First issue
02 2014-05-15 Second issue (GATE 2)
03 2014-10-13 Third issue (Gate 3/4)
Notes
Service Manual Confidential and Proprietary SM-30-4060
Order No. 2075-325 3 - 2 Version 03, 2014-10-13

IOLMaster 700 Parts Removal Replacement
3.2 Measurement Head
3.2.1 Measurement Head Side Covers
Precondition:
The instrument has been shut down and switched off.
Procedure:
1) Remove the front cover retaining ring by
turning in an anticlockwise direction.
See Fig. 1.
Fig. 1 – Front cover ring
2) To remove the left side cover (viewed from
patient side) insert a 2mm hex key into the
three apertures as shown in Fig. 2. Turn
anticlockwise to open the fastener
(DON’T OVERTURN – refer to Step 3 for
detailed information).
Fig. 2 - measurement head side covers
Apertures
SM-30-4060 Confidential and Proprietary Service Manual
Version 03, 2014-10-13 3 - 3 Order No. 2075-325

Parts Removal Replacement IOLMaster 700
3) There are two variations of fasteners installed
in the side cover.
Old – only a quarter turn, anticlockwise
See Fig. 3
New – several turns anticlockwise
See Fig. 4
Fig. 3 - Old fastener, quarter turn
Fig. 4 - New fastener, several turns
4) Remove the left side cover.
5) Remove the right side cover by loosening the
four holding screws (Torx 20 – 100mm) as
shown in Fig. 5.
Note
Care should be taken to avoid damaging
sensitive parts (lenses) whilst gaining
access to these screws.
Reassembly:
1) Reassemble in the reverse order;
Old – the fasteners on the right side cover
should be set to the closed position (Fig. 3)
before attaching.
New – the fasteners must be open (Fig. 4)
before attaching.
Fig. 5 - Right cover
Caution!
When performing service activities with
measurement head covers off. Particular
attention should be given to not damage
or move the polarisation paddles.
They can’t be re-adjusted in the field!
Fig. 6 - Polarisation paddles
Screws
Open
Closed
Closed
Open
Warning!
sensitive parts
Service Manual Confidential and Proprietary SM-30-4060
Order No. 2075-325 3 - 4 Version 03, 2014-10-13
