Zeiss Stemi 508 User manual

Stereo microscope Stemi 508
Operating Manual

You have acquired a product made by ZEISS. Please read this
operating manual before using your instrument for the first time to
make sure that its quality is maintained and you can utilize your
instrument reliably for a long time.

COPYRIGHT Stereo microscope
ZEISS Stemi 508
4 435064-7044-001 01/2015
Knowledge of this manual is required for operation of the device. Would you therefore please familiarize
yourself with the contents of this manual and pay special attention to instructions concerning the safe
operation of the device.
We reserve the right to perform modifications in view of technical progress; this operating manual is not
subject to revision.
© Unless expressly authorized, forwarding and reproduction of this document as well as utilization
and communication of its contents are not permitted. Violations will entail an obligation to pay
compensation.
All rights reserved in the event of granting of patents or registration of a utility model.
Issued by: Carl Zeiss Microscopy GmbH
Carl-Zeiss-Promenade 10
D-07745 Jena, Germany
microscop[email protected]m
www.zeiss.com/microscopy
Carl Zeiss Microscopy GmbH
Königsallee 9-21
D-37081 Göttingen, Germany
SAP no.: 435064-7044-001
Date of issue (Version 3): 01/28/2015
authorised dealer:
Pulch + Lorenz GmbH
Am Untergrün 23, 79232 March
Tel.: [phone]
www.pulchlorenz.de

Stereo microscope CONTENTS
Stemi 508 ZEISS
01/2015 435064-7044-001 5
CONTENTS
Page
1INTRODUCTION ........................................................................................................... 7
1.1 General information....................................................................................................... 7
1.2 Notes on instrument safety ............................................................................................ 8
1.3 Warranty notes............................................................................................................ 11
2DESCRIPTION ............................................................................................................. 12
2.1 Indication for use ......................................................................................................... 12
2.2 Microscope system....................................................................................................... 12
2.3 Interfaces on the stereo microscope Stemi 508 doc (with photo output) ........................ 13
2.4 System overview .......................................................................................................... 14
2.5 Technical data.............................................................................................................. 20
3INSTALLATION........................................................................................................... 23
3.1 General information..................................................................................................... 23
3.2 Installing the stereo microscope.................................................................................... 23
3.3 Mounting optional components ................................................................................... 25
3.3.1 Mounting reflected-light illuminator ............................................................................. 25
3.4 Connecting stereo microscope to the power supply ...................................................... 28
3.5 Switching stereo microscope ON or OFF ....................................................................... 28
4OPERATION ............................................................................................................... 29
4.1 Adjusting the stereo microscope................................................................................... 29
4.2 Setting reflected-light illumination ................................................................................ 30
4.2.1 Spot illuminator ........................................................................................................... 30
4.2.2 Double spot illuminator................................................................................................ 30
4.2.3 Ring illuminator ........................................................................................................... 31
4.2.4 Controller K LED .......................................................................................................... 32
4.3 Transmitted-light illuminators ....................................................................................... 33
4.3.1 Transmitted-light module in stand K EDU...................................................................... 33
4.3.2 Transmitted-light unit in stand K LAB........................................................................... 34
5CARE, MAINTENANCE AND SERVICE ........................................................................ 35
5.1 Care ............................................................................................................................ 35
5.2 Maintenance ............................................................................................................... 36
5.2.1 Replacing the power unit ............................................................................................. 36
5.2.2 Opening the stand cover plate, stand K EDU................................................................. 37
5.2.3 Opening the stand cover plate, stand K LAB ................................................................. 38
5.2.4 Wearing parts.............................................................................................................. 39
5.3 Service......................................................................................................................... 39
5.4 Product disposal
........................................................................................................... 40

CONTENTS Stereo microscope
ZEISS Stemi 508
6 435064-7044-001 01/2015
6APPENDIX...................................................................................................................41
6.1 List of abbreviations......................................................................................................41
6.2Troubleshooting ...........................................................................................................42
6.3 List of illustrations.........................................................................................................43
6.4 Index............................................................................................................................44

Stereo microscope INTRODUCTION
Stemi 508 General information ZEISS
01/2015 435064-7044-001 7
1 INTRODUCTION
1.1 General information
The stereo microscope Stemi 508 has been designed, produced and tested in compliance with the
standards DIN EN 61010-1 (IEC 61010-1) and IEC 61010-2-101 "Safety Requirements for Electrical
Measuring, Control and Laboratory Equipment".
The device meets the requirements of the EC Directive 98/79/EC Annex 1 regarding ivd products and the
EC RoHS Directive 2011/65/EC and carries the mark.
This operating manual contains information and warnings to be observed by the operator.
The devices must be disposed of in compliance with the WEEE Directive 2012/19/EC.
In this operating manual, the following warning and information symbols are used:
CAUTION
This symbol indicates a possible hazard to the user.
CAUTION
LED risk group 2 acc. to DIN EN 62471:2009 Optical radiation is emitted.
Do not look into the beam. This may damage your eyes.
CAUTION: High-energy UV radiation!
Risk of damage to eyes and skin!
CAUTION
Hot surface!
CAUTION
Remove the power plug before any intervention in the instrument!
ATTENTION
This symbol indicates a possible hazard to the instrument or system.
NOTICE
This symbol indicates information which deserves special attention.

INTRODUCTION Stereo microscope
ZEISS Notes on instrument safety Stemi 508
8 435064-7044-001 01/2015
1.2 Notes on instrument safety
If it becomes apparent that the safety measures are no longer effective, the device must be
taken out of service and secured against being used again
unintentionally. Please contact a
ZEISS service agency or the Carl Zeiss Microscopy Service to have the instrument repaired.
The Stemi 508 Information regarding instrument safety and installation conditions 435063-
6044-008 and the Stemi 508 Short operating instructions 435063-8044-
000 as well as the
operating instructions regarding the light sources also must be observed.
Do not operate the devices included in the scope of supplies in a potentially explosive
atmosphere, in the presence of volatile ana
esthetics or flammable solvents such as alcohol,
gasoline or similar substances.
The devices may only be operated by instructed persons who have been informed about the
possible risks in conjunction with the use of microscopes and the fields of appli
cation in
question. The microscope is a high-precision device that may be impaired in its performance or
even destroyed if handled improperly.
Before commissioning the instrument, make sure that the existing power supply is suitable for
the instrument.
Make sure that the mains plug is removed from the socket before the device is opened.
The devices are not equipped with special equipment protecting them from corrosive,
potentially infectious, toxic and radioactive or other samples that may be hazardous to health. If
you handle such samples, be sure to observe all legal require
ments, in particular the relevant
national accident prevention regulations.
The LED reflected-light illuminators and the LED transmitted-light illuminators have been
classified as belonging to LED risk group 2 acc. to DIN EN 62471:2009. Avoid looking directly
into the LED light.
If the device is operated with an external cold light source (high-
energy light), never look
directly into the fibre optic output of the cold light source. Otherwise, there is a risk of dazzling
and blindness.
Never cover the open light guide socket or the fibre optic output. There is a fire hazard!
In all cases avoid covering the open light guide socket or the fibre optic output with your hand
or other parts of your body. There is a risk of burns!

Stereo microscope INTRODUCTION
Stemi 508 Notes on instrument safety ZEISS
01/2015 435064-7044-001 9
Safe disconnection from the power supply is ensured exclusively by removing the mains plug.
The switch on the microscope only switches into standby mode.
Do not
replace detachable mains cables by inadequately designed mains cables. Only the
specified power supply lines may be used.
The microscope and the controller K LED are equipped with a desktop power unit each
allowing line voltages in the range from 100 to 240 V ±10 %, 50 / 60 Hz, without the need for
changing the voltage setting on the device.
The desktop power unit meets the
requirements of protection class II (with protective
insulation). If its casing is damaged, put the power unit out of operation. The microscope may
only be operated with the desktop power unit supplied with the instrument.
Changing the lamps on the col
d light source is only admissible in accordance with the
manufacturer's operating manual. If the appropriate instructions are not complied with, there is
a risk of burns and explosion when changing the lamp.
Defective devices should not be disposed of with house
hold waste; dispose of them in
compliance with the statutory provisions.
Samples must also be disposed of appropriately in accordance with the applicable statutory
provisions and internal work instructions.
The stereo microscope Stemi 5
08 incl. its original accessories may only be used for the
applications described in this oper
ating manual. The manufacturer cannot assume any liability
for other applications, including those of individual
modules or single components.
Changes to and ma
intenance on this device and on devices which are operated together with
the microscope may only be performed by our service or by authorized persons. The
manufacturer of the devices does not accept any liability for damage due to unauthorized
interventions in the device. Moreover, such interventions invalidate all guarantee / warranty
claims.
Dirt and dust may impair the performance of the device. The device must therefore be
protected from such influences to the greatest possible extent and covered with the dust cover
when not in use. Before covering the device, always make sure that it is definitely switched OFF.
Considerable temperature fluctuations, direct exposure to sunlight and vibrations should be
avoided.
Blocking or covering ventilation louvers may result in heat accumulation which may damage the
device and in extreme cases even cause fire. Always keep venti
lation louvers free and do not
insert or allow any objects to fall into them. All electrical components and parts must be located
at a distance of min. 15 cm from flammable objects and walls.

INTRODUCTION Stereo microscope
ZEISS Notes on instrument safety Stemi 508
10 435064-7044-001 01/2015
If it is intended to operate the Stemi 508 with an external fibre optical cold light source, please
refer to the appropriate operating instructions incl. the safety provisions contained in them
before commissioning the light source.
The desktop power unit must not get into contact with moisture.
For transport over an extended distance, the device must be dismantled partially and
transported in its original packaging.
To transport the device over an extended distance, use the original packaging or the transport
case Stemi 305/508.
To connect the LED illuminators of the Stemi 305 system, six-pin modular connectors are used
which are known from telecommunications (type: RJ 12).
Only the LED illuminators pertaining to the Stemi 305 may be connected to the RJ 12 sockets in
the microscope body and in the stands of the Stemi
305. Only the connection cables supplied
with the device may be used.
The use of commercially available cables with RJ 12 connectors or the connection of fax units,
modems or other telecommunication equipment to the RJ 12 sockets of the Stemi
305 is
prohibited.
Fig. 1 Warning and information labels on the device

Stereo microscope INTRODUCTION
Stemi 508 Warranty notes ZEISS
01/2015 435064-7044-001 11
1LED aperture, transmitted-light illuminators
2LED aperture, spot illuminator K LED
3LED aperture, ring illuminator K LED, segmentable
4LED aperture, double spot illuminator K LED
Fig. 2 Apertures for LED radiation
1.3 Warranty notes
The manufacturer guarantees that the device is free from material or manufacturing defects when
delivered. Any defects which may have occurred must be reported to us immediately and steps be taken
to minimize damage. If notified of such a defect, the device manufacturer is obligated to rectify it at his
discretion, either by repairing the instrument or by delivering an intact replacement. No guarantee is
provided for defects caused by natural wear (wearing parts in particular) and improper use.
The instrument manufacturer shall not be liable for damage caused by faulty operation, negligence or
any other tampering with the device, particularly the removal or replacement of instrument components,
or the use of accessories from other manufacturers. Such actions will render all warranty claims invalid.
No maintenance or repair work may be performed on the microscopes which exceed the activities
specified in this operating manual. Repair may only be performed by ZEISS Service or by persons
specifically authorized by it. Should any malfunctions occur on the device, please first contact the
Carl Zeiss Microscopy Service or, abroad, the ZEISS representative in your area.

DESCRIPTION Stereo microscope
ZEISS Indication for use Stemi 508
12 435064-7044-001 01/2015
2 DESCRIPTION
2.1 Indication for use
The stereo microscopes Stemi 508 are microscopes for magnifying spatial observation of small objects.
They have been designed and manufactured for use in biological and medical laboratories, in industrial
manufacture and quality assurance. They are, moreover, used for training purposes in schools, universities
and natural science institutes.
Stemi 508 is envisaged for applications in biology and in medicine for the analysis of blood and/or tissue
samples from the human body. Applications in the field of diagnostic medicine are explicitly excluded,
except for the field of medical research.
2.2 Microscope system
1Eyepiece in eyepiece tube (eyepiece 10x/23)
2Microscope body (trinocular)
3Interface 60N with camera adapter for cameras with
C-mount connector
4Zoom button to adjust the magnification
5Handle
6Stand (model K EDU)
7Focusing drive to focus the specimen
8Rotary/push-button for switching ON and OFF the
reflected-light illumination and for adjusting the
illumination intensity
9Rotary/push-button for switching ON and OFF the
transmitted-light illumination and for adjusting the
illumination intensity
10 Reflected-light illumination (spot illuminator K LED)
11 Lever for adjusting the transmitted-light illuminator –
bright field or dark field on the stand K EDU
12 Insert plate for placing the specimen
Fig. 3 Microscope system Stemi 508
The illustrated microscope equipment shows an example and may differ from the ones actually
existing!

Stereo microscope DESCRIPTION
Stemi 508 Interfaces on the stereo microscope Stemi 508 doc (with photo output) ZEISS
01/2015 435064-7044-001 13
2.3 Interfaces on the stereo microscope
Stemi 508 doc (with photo output)
1
Optional mount for eyepiece plates
∅26 mm
2
Eyepiece tube
∅
30 mm to replace the
eyepieces
3
Exchangeable camera adapter 0.5x with
interface 60N and C-mount connector for
cameras up to 2/3"
4
Internal thread M50x0.75 to accommodate
the front optics
5
Internal thread M49x0.75 to accommodate
optical filters and analyzer for pol.
6
Mount
∅
53 mm holding ring A53 for
adaptation of ring illuminators with mount
∅66 mm
7
Mount
∅
76 mm for microscope body
8
Mount
∅
84 mm for tables, insert plates
9
Guide for mounting secondary illumination
10
M8 thread to mount holding frame (only
stand K)
Thanks to the interface ∅76 mm, the Stemi 508 can also be used in conjunction with other stands of the
modular kit of the Stereo system – and other ZEISS stereo microscopes such as e.g. the Stemi 305, may
also be inserted in the stand K LED.
Front optics for Stemi 508
− External thread M50x0.75 for fastening in the
zoom body Stemi 508
− Internal thread M49x0.75 to accommodate
optical filters and analyzer for pol.
− Before screw-fastening the front optics 5 in the
microscope body Stemi 508
remove the dust protection glass.
Fig. 4 Interfaces on the Stemi 508
with stand K (schematic diagram)
Fig. 5 Front optics, Stemi 508 (example)

DESCRIPTION Stereo microscope
ZEISS System overview Stemi 508
14 435064-7044-001 01/2015
2.4 System overview

Stereo microscope DESCRIPTION
Stemi 508 System overview ZEISS
01/2015 435064-7044-001 15

DESCRIPTION Stereo microscope
ZEISS System overview Stemi 508
16 435064-7044-001 01/2015

Stereo microscope DESCRIPTION
Stemi 508 System overview ZEISS
01/2015 435064-7044-001 17

DESCRIPTION Stereo microscope
ZEISS System overview Stemi 508
18 435064-7044-001 01/2015

Stereo microscope DESCRIPTION
Stemi 508 System overview ZEISS
01/2015 435064-7044-001 19

DESCRIPTION Stereo microscope
ZEISS Technical data Stemi 508
20 435064-7044-001 01/2015
2.5 Technical data
Microscope system Stemi 508 EDU
Dimensions
Weight
Stemi 508 in stand K EDU.................................4.6 kg
Microscope system Stemi 508 LAB
Dimensions
Weight
Stemi 508 in stand K LAB .................................6.2 kg
