Zibro TP 025 User manual

2
6
5
3
4
FIN
GEBRAUCHSANWEISUNG
BRUGSANVISNING
INSTRUCCIONES DE USO
MANUEL D'UTILISATION
KÄYTTÖOHJE
OPERATING MANUAL
4
16
28
40
52
64
TP 025
man_TP025_1 30-01-2008 12:00 Pagina 1

2
2ALLGEMEINE SICHERHEIT
Aus Sicherheitsgründen bitten wir Sie, die Bedienungsanleitung vor Inbetriebnahme sorgfältig zu lesen!
Personen, die mit der Bedienungsanleitung nicht vertraut sind, dürfen das Gerät nicht bedienen.
6SIKKERHED GENERELT
Læs denne brugsanvisning grundigt igennem af hensyn til sikkerheden! Personer, som ikke er fortrolige med brugsanvisningens
indhold, må ikke anvende dette klimaanlæg. Vi anbefaler, at De gemmer denne brugsanvisning et sikkert sted med henblik på
senere brug.
5MEDIDAS DE SEGURIDAD
¡Consulte atentamente el modo de empleo y preste atención a las medidas de seguridad! Aquellos que no estén
familiarizados con estas medidas de seguridad, no deben utilizar este acondicionador de aire. Aconsejamos
guardar en sitio seguro este manual para poder consultar en caso necesario.
3SÉCURITÉ GÉNÉRALE
Par mesurede sécurité, consulter attentivement ce manuel d’instructions! Les personnes qui ne sont pas famili-
arisées avec ce manuel d’instructions, ne doivent pas utiliser ce climatiseur.Nous vous conseillons de ranger ce
manuel d’instructions à un endroit sûr pour pouvoir le consulter ultérieurement.
YLEINEN TURVALLISUUS
Lue tämä käyttöopas turvallisuussyistä huolellisesti ennen käyttöä. Henkilöt, jotka eivät ole perehtyneet käyttö-
oppaaseen, eivät saa käyttää ilmastointilaitetta. Suosittelemme käyttöoppaan säilyttämistä turvallisessa paikas-
sa myöhempää käyttöä varten.
4GENERAL SAFETY
For safety reasons, please read this manual carefully before operating. Persons who are not familiar with this
manual must not use this air conditioner. Westrongly recommend keeping this manual in a safe place for futu-
re reference.
A. Do not use a damaged cable.
B. Do not clamp or bend the cable.
C. Do not place unevenly.
D. Do not place in front of an open window.
E. Do not bring in contact with chemicals.
F. Do not place near a heat source.
G. Do not immerse in water.
H. Do not spill.
I. Do not insertanything.
J. Do not use an extension cord.
K. Keep out of the reach of children.
L. Do not repair.
A. Älä käytä vahingoittunutta johtoa.
B. Älä kiristä tai taivuta johtoa.
C. Älä aseta laitetta epätasaiselle pinnalle.
D. Älä aseta laitetta auki olevan ikkunan eteen.
E. Älä päästä laitetta kosketuksiin kemikaalien kanssa.
F. Älä aseta laitetta lämmönlähteen lähelle.
G. Älä upota laitetta veteen.
H. Älä läikytä nesteitä laitteen päälle.
I. Älä aseta mitään laitteen sisälle.
J. Älä käytä jatkojohtoa.
K. Pidä laite poissa lasten ulottuvilta.
L. Älä korjaa laitetta.
FIN
A. Ne pas utiliser de câble endommagé.
B. Ne pas serrer ou plier le câble.
C. Placer sur une surface plane.
D. Ne pas placer devant une fenêtre ouverte.
E. Ne pas mettre en contact avec des produits chimi-
ques.
F. Ne pas placer auprès d’une source de chaleur.
G. Ne pas immerger.
H. Ne pas renverser.
I. Ne rien introduire dans l’appareil.
J. Ne pas utiliser de câble de rallonge.
K. A tenir hors de portée des enfants.
L. Ne pas réparer soi-même.
A. No utilizar un cable deteriorado.
B. No averiar o doblar el cable.
C. Colocar en superficie llana
D. No colocar delante de ventana abierta.
E. No poner en contacto con productos químicos.
F. No poner en contacto con fuente de calor.
G. No sumergir en líquidos.
H. No verter líquidos.
I. No introducir objetos en el aparato.
J. No utilizar cable de extensión.
K. Poner fuera del alcance de los niños.
L. No hacer reparaciones.
A. Brug ikke beskadigede kabler.
B. Kabel må ikke sættes i klemme eller knækkes.
C. Anbringes på et plant gulv.
D. Må ikke anbringes ved et åbent vindue.
E. Må ikke komme i kontakt med kemikalier.
F. Må ikke anbringes ved en varmekilde.
G. Må ikke sænkes ned i vand.
H. Pas på med at spilde.
I. Der må ikke stikkes noget ind i apparatet.
J. Der må ikke bruges kabeltrommel.
K. Bruges uden for børns rækkevidde.
L. De må ikke selv reparere apparatet.
A. Kein beschädigtes Kabel verwenden.
B. Kabel nicht zusammendrücken oder knicken.
C. Unbedingt waagerecht aufstellen.
D. Nicht vor geöffneten Fenstern aufstellen.
E. Nicht mit Chemikalien in Kontakt bringen.
F. Nicht bei Wärmequellen aufstellen.
G. Nicht in Wasser eintauchen.
H. Kein Flüssigkeiten verschütten.
I. Keine Gegenstände in das Gerät stecken.
J. Kein Verlängerungskabel verwenden.
K. Außer Reichweite von Kindern halten.
L. Nicht selbst reparieren. A
B
C
D
E
F
man_TP025_1 30-01-2008 12:00 Pagina 2

3
>SICUREZZA
Per motivi di sicurezza, si raccomanda di leggere attentamente il manuale prima di utilizzare l’apparecchio. Le
persone che non conoscono il funzionamento del climatizzatore non devono usarlo. Si raccomanda di riporre il
manuale in un luogo sicuro per future referenze.
uGENERELL SIKKERHET
Avsikkerhetshensyn ber vi deg lese denne håndboken nøye før drift. Personer som ikke har gjort seg kjent med
denne håndboken, må ikke bruke klimaanlegget. Vi anbefaler på det sterkeste at du tar vare på denne hånd-
boken, slik at du kan slå opp i den ved senere anledninger.
1VEILIGHEID ALGEMEEN
Bestudeer voor de veiligheid deze gebruiksaanwijzing zorgvuldig! Personen, die met de gebruiksaanwijzing niet
vertrouwd zijn, mogen deze airconditioner niet gebruiken. Wij raden u aan deze gebruiksaanwijzing op een vei-
lige plaats te bewaren voor latere raadpleging.
:OGóLNE ZASADY BEZPIECZEńTWA
Dla własnego bezpieczeństwa przeczytaj dokładnie treść instrukcji obsługi klimatyzatora! Osobom, które nie zapoz-
nały się z instrukcją obsługi niniejszego urządzenia, zabrania się z niego korzystać. Radzimy przechowywać instrukc-
ję obsługi w bezpiecznym miejscu, aby w razie potrzeby móc skorzystać z niej w przyszłości.
=ALLMÄN SÄKERHET
Av säkerhetsskäl, läs noga igenom denna bruksanvisning innan du använder enheten. Personer som inte har satt
sig in i denna bruksanvisning får inte använda denna luftkonditioneringsapparat. Vi rekommenderar starkt att
denna bruksanvisning förvaras på ett säkert ställe för framtida referens.
GENEL GÜVENL‹K
Güvenlik aç›dan çal›flt›rmaya bafllamadan önce lütfen kullanma talimat›n› dikkatlice okuyunuz!
Kullanma talimat›n› bilmeyen kiflilerin aleti kullanmas› yasakt›r.
ySPLOŠNI VARNOSTNI NASVETI
Zaradi varnosti pred uporabo naprave preberite ta varnostna navodila. Osebe, ki niso seznanjene s temi navo-
dili naj te naprave ne uporabljajo. Priporočamo, da navodila shranite.
A. Ne uporabljajte pokodovanega električnega vodnika.
B. Kabla ne prepogibajte in pazite, da ga ne priščipnete.
C. Naprava naj stjoi v vodoravnem položaju.
D. Ne postavljajte je pred odprto okno.
E. Ne izpostavljajte je kemikalijam.
F.Ne postavljajte v bližino izvora toplote.
G. Ne potapljajte naprave v vodo
H. Na napravo ne zlivajte vode.
I. V napravo ne vstavljajte predmetov.
J. Ne uporabljajte električnega podaljška.
K. Napravo hranite izven dosega otrok.
L. Naprave ne popravljate sami.
A. Hasar görmüfl kablo kullanmay›n›z.
B. Kabloyu ezmeyiniz ve katlamay›n›z.
C. Mutlaka yatay kurunuz.
D. Aç›k pencerelerin önüne kurmay›n›z.
E. Kimyasal maddelerle temas ettirmeyiniz.
F Is› kaynaklar›n bulundu¤u yerlere kurmay›n›z.
G. Suya bat›rmay›n›z.
H. Üzerine s›v› dökmeyiniz.
I. Aletin içine cisim sokmay›n›z.
J. Uzat›c› kablo kullanmay›n›z.
K. Çocuklar›n eriflemeyece¤i yerelerde muhafaza ediniz.
L. Kendiniz tamir etmeyiniz.
TR
A. Använd inte en trasig sladd.
B. Sladden får inte klämmas eller böjas.
C. Får ej placeras på ojämnt underlag.
D. Får ej placeras framför ett öppet fönster.
E. Får ej komma i kontakt med kemikalier.
F. Får ej placeras nära en värmekälla.
G. Får ej sänkas ner i vatten.
H. Spill inte vätska på enheten.
I. För inte in något i enheten.
J. Använd inte en förlängningssladd.
K. Förvaras utom räckhåll för barn.
L. Reparera inte enheten.
A. Nie używać uszkodzonego przewodu zasilającego.
B. Nie uciskać ani nie zginać przewodu.
C. Urządzenie umieścić na płaskim podłożu.
D. Nie umieszczać urządzenia przed otwartym oknem.
E. Nie stosować żadnych środków chemicznych.
F. Nie umieszczać w bezpośrednim sąsiedztwie źródeł
ciepła.
G. Nie zanurzać w wodzie.
H. Nie rozlewać cieczy.
I. Nie wtykać obcych przedmiotów do aparatu.
J. Nie używać przedłużacza.
K. Trzymać z daleka od dzieci.
L. Nie próbować naprawiać klimatyzatora samodzielnie.
A. Gebruik geen beschadigde kabel.
B. Kabel niet afklemmen of knikken.
C. Plaats op een vlakke ondergrond.
D. Niet voor een open raam plaatsen.
E. Niet met chemicaliën in contact brengen.
F. Niet bij een warmtebron plaatsen.
G. Niet onderdompelen.
H. Niets morsen.
I. Niets in het apparaat steken.
J. Geen verlengkabel gebruiken.
K. Buiten bereik van kinderen houden.
L. Niet zelf repareren.
A. Bruk ikke en skadet ledning.
B. Klem eller bøy ikke ledningen.
C. Plasser ikke apparatet på et ujevnt underlag.
D. Plasser ikke apparatet foran et åpent vindu.
E. La ikke kjemikalier komme i berøring med apparatet.
F. Plasser ikke apparatet i nærheten av varmekilder.
G. Legg aldri apparatet i vann.
H. Søl ikke væske på apparatet.
I. Før ikke noe inn i apparatet.
J. Bruk ikke skjøteledning.
K. Oppbevar apparatet utilgjengelig for barn.
L. Reparer ikke apparatet.
A. Non usare il cavo, se danneggiato.
B. Non bloccare o piegare il cavo.
C. Collocare l’apparecchio su una superficie piana.
D. Non collocare l’apparecchio davanti alla finestra
aperta.
E. Non porlo a contatto con prodotti chimici.
F. Non posizionarlo vicino ad una fonte di calore.
G. Non immergerlo nell’acqua.
H. Non versare liquidi sull’apparecchio.
I. Non inserire alcun oggetto nell’apparecchio.
J. Non usare prolunghe.
K. Tenere l’apparecchio lontano dalla portata dei
bambini.
L. Non cercare di riparare l’apparecchio.
G
H
I
J
K
L
man_TP025_1 30-01-2008 12:00 Pagina 3

IMPORTANT
COMPONENTS
Control panel
Air outlet
Handle
Casters
Filter set
Air filter
Exhaust air outlet
Rubber plug
Hose adapter
Exhaust hose
Window air outlet
Remote control
Power cord
Foam component
A
B
C
4
E
F
G
H
I
J
K
L
M
N
1. READ THE DIRECTIONS FOR USE FIRST.
2. IN CASE OF ANY DOUBT, CONTACT YOUR DEALER.
4
64
I
J K
ON/OFF MODE
FAN SPEED UP
TIMER DOWN
L
C
A
B
F
G
E
M
D
N
H
man_TP025_1 30-01-2008 12:00 Pagina 64

4
65
Dear Sir, Madam,
Congratulations on the purchase of your air conditioner. This air conditioner has three
functions in addition to cooling the air, namely, air dehumidification, circulation and
filtration. The mobile air conditioner is extremely easy to operate and move. You have
acquired a high quality product that will provide you with many years of pleasure, on
condition
that you use it responsibly.Reading these instructions for use beforeoperating your
air conditioner will optimise its life span. Wewish you coolness and comfort with your
air conditioner.
Yours sincerely,
PVG International B.V.
Customer service department
man_TP025_1 30-01-2008 12:00 Pagina 65

ASAFETY INSTRUCTIONS
Install the device only when it complies with local regulations, by-laws and
standards. The unit is only suitable for use in dry locations, indoors. Check the
mains voltage and frequency. This unit is only suitable for earthed sockets,
connection voltage 220-240 V. / 50 Hz.
Before connecting the unit, check the following:
•The voltage supply must correspond with the mains voltage stated on the
rating label.
• The socket and power supply must be suitable for the current stated on the
rating label.
• The plug on the cable of the device must fit into the wall socket.
• The device must be placed on a flat and stable surface.
The electricity supply to the device must be checked by a recognised professional
if you have any doubts regarding the compatibility.
•This device is manufactured according to CE safety standards. Nevertheless,
you must take care, as with any other electrical device.
• Do not cover the air inlet and outlet grill.
• Empty the water reservoir before moving the unit.
• Never allow the device to come into contact with chemicals.
• Never spray the unit with or submerge in water
• Do not insert objects into the openings of the unit.
• Always remove the plug from the electric power supply before cleaning or
replacing the unit or components of the unit.
• Never use an extension cable to connect the device to the electric power
supply. If there is no suitable, earthed wall socket available, have one
installed by a recognised electrician.
• For safety reasons take care when children are in the surrounding of the
device, as with any other electrical device.
• Have any repairs only carried out by a recognised service engineer or your
supplier. Follow the instructions for use and maintenance as indicated in the
user manual of this device.
• Always remove the plug of the unit from the wall socket when it is not in use.
• A damaged power cord or plug must always be replaced by a recognised
electrician or your supplier.
GIMPORTANT
The device MUST always have an earthed connection. If the power
supply is not earthed, you may not connect the unit. The plug must
always be easily accessible when the unit is connected. Read these
instructions carefully and follow the instructions.
4
66
man_TP025_1 30-01-2008 12:00 Pagina 66

4
67
BINSTALLATION
This unit is portable and can easily be moved from one room to another. In doing
so keep this in mind:
Ensurethat the unit is positioned upright and on a level surface.
Do not operate the unit inside the bathroom, shower,or in any other very
humid environment.
Please keep a distance of 50 cm between the unit and the wall or other
objects to ensure proper air circulation.
Insert both ends of the air exhaust hose Jin the round connectors 9.Fasten
the connectors by turning them clockwise onto the hose.
Insert one round connector 9in the backside of the unit 7.Fasten the other
connector 9to the window air outlet K.
Ensure that the window air outlet Khas a free flow outside. Close the
window or door as much as possible to prevent outside air from entering the
room.
GIMPORTANT
The flexible exhaust hose should be less than 1m during operation,
which provides the best performance. This length has been designed
especially according to the specifications of the air conditioner. Do not
use an extension or exchange for a different hose as that may lead to
malfunctioning. The exhaust air must flow freely,any blockage can lead
to overheating of the air conditioner. Take careto prevent any bow or
bend in the exhaust hose.
6
5
4
3
2
1
GWARNING
Beforeusing the air conditioner it should be left in an upright position
for at least 2 hours.
GATTENTION!
• Never use the device with a damaged power cord, plug, cabinet or
control panel. Never trap the power cord or allow it to come into
contact with sharp edges.
• Never seal the room - where this device will be used - completely
airtight. This will prevent under pressure in this room. Under
pressure can disrupt the safe operation of geysers, ventilation
systems, ovens, etc.
• Failing to follow the instructions may lead to nullification of the
guarantee on this device.
man_TP025_1 30-01-2008 12:00 Pagina 67

COPERATION
Insert the plug into the wall outlet.
Press the -button to switch on the air conditioner.
With -button you can change the operating mode of the unit.
By pressing the -button the following modes appear:
Cooling, the green light lits.
Dehumidifying, the orange light lits.
Air circulation, the yellow light lits.
COOLING
When the unit is in the cooling mode, the following functions apply:
• The fan speed can be adjusted by pressing the -button
Maximum setting.
Medium setting.
Lowest setting.
•The temperaturecan be set by pressing the and buttons, anywhere
between 16°C en 32°C. The display will show the set temperature for 15
seconds and the “set temp” will light up. Fifteen seconds after setting the
required temperature, the display will show the room temperature.
DEHUMIDIFYING
When the unit is primarily used as a dehumidifier, then please follow these
instructions: Do not connect the air exhaust hose and let the warm air go
back into the room. Connect a drainage hose onto the permanent drain
connector on the back of the unit (refer to Chapter G). You must connect a
drain tube to the water outlet 8(refer to Chapter G).
When the unit is in the dehumidifying mode, the fan speed cannot be
adjusted when the temperature is below 25ºC. The fanspeed will be
automatically set on ‘Medium setting’. Adjusting of the temperature setting
does not have any effect when in dehumidifying mode.
GIt depends on the environment whether the required temperature will
be reached. It is not a malfunction of the air conditioner if the room
temperature remains above the “set temp”.
3
2
1
4
68
man_TP025_1 30-01-2008 12:00 Pagina 68

4
69
AIR CIRCULATION
In this mode the unit only circulates air; the unit will not cool or dehumidify.
The air entering the unit is not cooled or dehumidified, but is filtered.
When the unit is in this mode, the following functions apply:
•The fan speed can be adjusted by pressing the -button
Maximum setting.
Medium setting.
Lowest setting.
When the unit is switched off the most recent setting will be stored in
memory.
The timer function allows you to switch the unit on or off at a certain time.
TO SWITCH ON THE UNIT AT A CERTAIN TIME
• Ensure that the unit is set in the required operating mode , of .
•Switch off the unit by pressing the -button. Ensure that the plug is
properly inserted into the wall outlet.
• Press the -button. The light “Timer set” will flash.
• Use the and buttons to set a time between 1 and 12 hours.
• When the set time has expired the unit will switch on.
TO SWITCH OFF THE UNIT AT A CERTAIN TIME
•When the unit is operating in the required mode press the -button.
The light "Timer set” will flash.
• Use the and buttons to set a time between 1 and 12 hours.
• When the set time has expired the unit will switch off.
GNOTE!
The compressor has been set so that it starts functioning three minutes
after the (re)start of the air conditioner.
The cooling will switch off when the room temperature is lower than
the set one. Air circulation will however continue to work on the set
level. When the room temperature rises above the selected value, the
cooling will work again.
5
4
man_TP025_1 30-01-2008 12:00 Pagina 69

REMOTE CONTROL
a. Power on/off button
b.Timer and thermostat setting buttons
c. Mode button (select A/C, Fan or Dehumidifier)
d. A/C Fan Speed button (High, Medium, Low)
e. Timer ON / OFF button
The remote control works in combination with the control panel. Aim the front
end of the remote control at the red window. The maximum operating distance
from the air conditioner is approximately 5 metres. Place AAA Batteries before
use.
TIMER PROGRAMMING
Press the button on the remote or the “Timer Setting” button on the
control panel to turn on the Timer Function.
Press the or buttons on the remote or the or buttons on the
control panel to set the desired shut-off period.
The unit will shut off when the set time elapses.
DEHUMIDIFACATION OPERATION
Press the button on the remote or the MODE button on the control panel to
select the dehumidifier mode. The fan will operate on medium speed.
The dehumidifier indicator light will illuminate and stay solid while the unit is
dehumidifying. When the humidity in the room is 50% or lower, the compressor
will not run, the unit will not dehumidify, and the dehumidifier light will blink.
Remember, the exhaust hose does not need to be used in dehumidifier mode.
3
2
1
4
70
ON/OFF MODE
FAN SPEED UP
TIMER DOWN
c
db
b
e
a
man_TP025_1 30-01-2008 12:00 Pagina 70

4
71
DFILTER
The airconditioner is fitted with a screen filter 5to purify the circulating air. For
optimum results the screen filter must be cleaned once or twice per week when
the machine is in normal use with a vacuum cleaner and/or water in order to
prevent blockage of the airflow.
Switch the airconditioner off and pull the plug out of the socket.
Slide the filter out of the airconditioner.
Dry the filter and replace it. Always ensure that the filter is completely dry.
Insert the plug into the socket.
The airconditioner is again ready for use
EAIR FLOW
Move the air vent directly to adjust the air flow direction of the horizontal
louvres.
FEMPTY INTERNAL WATER CONTAINER
Under extreme (environmental) circumstances it may be necessary to empty the
internal water container regularly. When the internal water container is full the
light will flash and the unit will beep continously. The unit will switch off
automatically. To empty the water container do the following:
Do not move the unit. Drastic movements can cause water leakage.
Switch offthe unit and remove the plug from the wall outlet.
Place a pan or appropriate tray on the floor underneath the permanent drain
tube.
Remove the rubber plug 8from the drain tube and let the water run out. (±
0.5 litres).
Replace the rubber plug 8,put the plug into the wall outlet, and switch on
the unit. The warning light should be off.
5
4
3
2
1
GNever use the machine without a filter.
5
4
3
2
1
man_TP025_1 30-01-2008 12:00 Pagina 71

GCONTINUOUS DRAINAGE
Switch off the unit and remove the plug from the mains.
Place a pan or appropriate tray on the floor underneath the permanent drain
tube to collect any water draining away.
Remove the rubber plug 8.
Connect a drain tube (ø 15 mm) into the water outlet and extend with extra
water tube as needed.
Place the other end of the drain tube at a location suitable for the purpose (a
drain hole, for instance). In doing so, take care to ensure that the tube is not
twisted and is free of kinks. The tube must be placed so as to be declining
along its entirelength.
DEHUMIDIFICATION
If the unit will be used mainly as dehumidifier,do not connect the exhaust hose
and let the warmair returnin the room. Continuous drainage is then necessary
and moreefficient. You must, however, use a water drain tube (ø 0.5 inch internal
diameter), placing its discharge end at a suitable drainage point.
HCLEANING
Clean the housing with a soft, damp cloth. Never use aggressive chemicals, petrol,
detergents or other cleansing solutions. For maintenance of the filters, refer to
Chapter D “Air Filter”.
GNOTE!
Never use the air conditioner without screenfilter.
GWARNING!
Switch offthe unit and remove the plug from the mains beforecleaning
the appliance or filter,or before replacing the filters.
5
4
3
2
1
GNOTE!
When the air conditioner is in use, under normal circumstances the
condensed water will be drained through the air outlet-tube.
4
72
man_TP025_1 30-01-2008 12:00 Pagina 72

4
73
ISTORAGE
Empty the internal water container (refer to Chapter F)
Clean and replace the mesh filter (see also chapter D).
Put the unit in air circulation mode for a couple of hours to ensure that the
inside becomes completely dry.
Store cable as shown, protect the unit against dust and store in a dry place
not accessible to children.
JTROUBLE SHOOTING
Never try to repair or dismantle the air conditioner yourself. Incompetent repairs
result in loss of warranty and can endanger the user.
Problem Cause Solution
No power supply
Connect to a functioning outlet
and switch on
Water tank indicator is on
Empty the internal water
container (refer to Chapter F)
In direct sunlight Close curtains
Windows or doors open, many
people or heat source in room
Close doors and windows, or
place an extra air conditioner
Dirty filter Clean or replace filter
Air inlet or air outlet blocked Remove blockage
Room temperature lower than
selected value
Change temperature selection
The unit is noisy Unit stands uneven
Place on even surface (less
vibrations)
The compressor
does not work
Overheat protection probably
activated
Wait 3 minutes until the
temperature has decreased, and
turn on the unit again
Distance too great
Remote control signal not
detected by control panel
Batteries empty Replace the batteries
The unit does
not seem to
perform
The unit does
not function
Remote control
does not
function
Make sure the remote control is
correctly aimed at the control
panel
4
3
2
1
man_TP025_1 30-01-2008 12:00 Pagina 73

KGUARANTEE CONDITIONS
The air conditioner is supplied with a 24-month guarantee, commencing on the
date of purchase. All material and manufacturing defects will be repaired or
replaced free of charge within this period. The following rules apply:
1. We expressly refuse all further damage claims, including claims for collateral
damage.
2. Repairs to or replacement of components within the guarantee period will
not result in an extension of the guarantee.
3. The guarantee is invalidated if any modifications have been made, non
genuine parts are fitted or repairs are carried out by third parties.
4. Components subject to normal wear, such as the filter, are not covered by the
guarantee.
5. The guarantee is valid only when you present the original, dated purchase
invoice and if no modifications have been made.
6. The guarantee is invalid for damage caused by neglect or by actions that
deviate from those in this instruction booklet.
7. Transportation costs and the risks involved during the transportation of the
air conditioner or air conditioner components shall always be for the account
of the purchaser.
8. Damage caused by not using suitable filters is not covered by the guarantee.
To prevent unnecessary expense, we recommend that you always first carefully
consult the instructions for use. Take the air conditioner to your dealer for repairs
if these instructions do not provide a solution.
4
74
man_TP025_1 30-01-2008 12:00 Pagina 74

4
75
LTECHNICAL DATA
To be used as indication, subject to modifications
* Conform EN 14511-2004
** Moisture removal at 32°C, 80% RH
Environmental information: This equipment contains fluorinated greenhouse
gases covered by the Kyoto Protocol. It should only be serviced or dismantled by
professional trained personnel.
This equipment contains R410A refrigerant in the amount as stated in the table
above. Do not vent R410A into atmosphere: R410A, is a fluorinated greenhouse
gas with a Global Warming Potential (GWP) = 1975.
Waste electrical products should not be disposed with household waste. Please
recycle where facilities exist. Check with your local authority or retailer for
recycling advice.
Model
TP 025
Cooling capacity* W2500
A
2.61
Power consumption
kW 0.96
Current nom.
A4.5
Mains V/Hz/PH
220 - 240 / 50 / 1
Air delivery max.
m3/h 300
Dehumidification max. **
L/24h 28
Room size
m360 - 85
rotary
Refrigerant
type/gr R-410A / 650
Thermostat range
°C 16 - 32
3
Noise level
dB(A) 52
Dimensions (w x h x d)
mm 435 x 785 x 390
Weight
kg 30
IP 20
yes
T3.15A, 250V
Fuse rating
Remote control
Unit protection
EE Class*
EER*
Compressor type
Fan speeds
man_TP025_1 30-01-2008 12:00 Pagina 75

DISTRIBUTED IN EUROPE BY PVG INTERNATIONAL B.V.
PVG Traffic rmo©080130 man_TP025_1
iÖSTERREICH
PVG Austria VertriebsgmbH
Salaberg 49
3350 HAAG
tel: [phone]
fax: [phone]
email: [email protected]
eBELGIË
PVG Belgium NV/SA
Industrielaan 55
2900 SCHOTEN
tel: [phone]
fax: [phone]
email: [email protected]
qSCHWEIZ
PVG Schweiz AG
Salinenstrasse 63
4133 PRATTELN
tel: [phone]
fax: [phone]
email: [email protected]
2DEUTSCHLAND
PVG Deutschland GmbH
Beiersdorfstraße 4
46446 EMMERICH
tel: [phone]
fax: [phone]
email: [email protected]
6DANMARK
Appliance A/S
Blovstroed Teglvaerksvej 3
DK-3450 ALLEROED
tel: [phone]
fax: [phone]
email: [email protected]
5ESPAÑA
PVG España S.A.
Pol. Ind. San José de Valderas II
Comunidad ”La Alameda”
C/ Aurora Boreal, 19
28918 LEGANÉS (Madrid)
tel: [phone]
fax: [phone]
email: [email protected]
3FRANCE
PVG France SARL
4, Rue Jean Sibélius
B.P.185
76410 SOTTEVILLE SOUS LE VAL
tel: [phone]
fax: [phone]
email: [email protected]
SUOMI
Appliance Finland Oy
Piispantilankuja 6C
02240 ESPOO
tel: [phone]
fax: [phone]
email: [email protected]
FFIINN
4UNITED KINGDOM
Lister Gases
Bridge Street
Holloway Bank, Wednesbury
West Midlands WS10 OAW
tel.: [phone]
fax: [phone]
email: [e-mail]
>ITALIA
PVG Italy SRL
Via Niccolò Copernico 5
50051 CASTELFIORENTINO (FI)
tel: [phone]
fax: [phone]
email: [email protected]
uNORGE
Appliance Norge AS
Vogellunden 31
1394 NESBRU
tel: [phone]
fax: [phone]
email: [email protected]
1NEDERLAND
PVG International B.V.
P.O. Box 96
5340 AB OSS
tel: [phone]
fax: [phone]
email: [email protected]
9PORTUGAL
Gardena, Lda
Recta da Granja do Marquês
ALGUEIRÃO
2725-596 MEM MARTINS
tel: + 35 21 92 28 530
fax: + 35 21 92 28 536
email: [email protected]
:POLSKA
PVG Polska Sp. z. o. o.
ul. Kościelnej 110
26-800 Białobrzegi
tel: [phone]
fax: [phone]
email: [email protected]
=SVERIGE
Appliance Sweden AB
Sjögatan 6
25225 HELSINGBORG
tel: [phone]
fax: [phone]
email: [email protected]
TURKEY
PVG Is›tma Klima So¤utma Ltd.fiti.
Tepekule is merkezi
Anadolu Cad. No: 40 K:3 D:306
35010 BAYRAKLI/IZMIR
tel: + 90 232 461 51 01
fax: + 90 232 461 51 85
email: [email protected]
TTRR
man_TP025_1 30-01-2008 12:00 Pagina 76
