Zip ZIP-B User manual

Reverse Osmosis

Please keep this manual, including service and guarantees sections, to provide
better after-sales service. If you have any questions about the set up, operation,
or maintenance of this equipment, please contact your local customer service
center for technical assistance.
DIRECT ACCESS
Easy maintenance.
CLICK
Secure connections.
ELECTRONIC ADAPTOR
High yield stability.
NSF CONNECTORS
High quality and trusted.
FT QUICK CHANGE FILTERS
Time and effort saving.
ZERO INSTALLATION
Ready to use.
ECO FRIENDLY - ZERO WASTE WATER
Filtration water recovery design.
Plug & Play
Easy instant operation.
ENCAPSULATED MEMBRANE
Maximum hygiene, minimum contact.

Contents
Introduction
Specifications
Parts description
4 Stage filtration & booster pump
What is natural osmosis and reverse osmosis, (RO)?
How does the membrane work?
Contaminants removed by reverse osmosis
Operating conditions and cautions
Effect of TDS concentration in the inlet water
Startup and operating
Push button control - user interface
Treatment cycle time
Changing water in supply pitcher
Filter initialization
Cleaning pure water reservour
Filter replacement
Prefilter replacement
Postfilter replacement
How quick connectors work
RO membrane replacement
Reset procedure
Troubleshooting
Filter change and maintenance record
4
4
5
5
6
7
8
9
9
10
12
13
14
14
15
16
16
17
18
19
22
23
24
DIRECT ACCESS
Easy maintenance.
CLICK
Secure connections.
ELECTRONIC ADAPTOR
High yield stability.
NSF CONNECTORS
High quality and trusted.
FT QUICK CHANGE FILTERS
Time and effort saving.
ZERO INSTALLATION
Ready to use.
ECO FRIENDLY - ZERO WASTE WATER
Filtration water recovery design.
Plug & Play
Easy instant operation.
ENCAPSULATED MEMBRANE
Maximum hygiene, minimum contact.

4\ INTRODUCTION
Thank you and congratulations on selecting the ZIP RO Water Purifier.
ZIP-RO purifiers are among the best appliances you can find on the market to
improve water taste and quality.
With the water quality of our environment worsening, we have been prompted
to design and manufacture the ZIP compact, domestic RO purifier to meet
these challenges with the highest quality solutions.
Your ZIP RO purifier will provide many benefits and advantages:
t ZIP is a physical system that does not use or add chemicals to the water.
t Provides high quality water.
t Ensures high production.
t Low maintenance costs.
t Compact innovative design and concept.
t No installation or water connections.
t No water waste. All water can be used.
t Saves time on set up and maintenance.
With the ZIP you will enjoy the improved taste of water for drinking, coffee,
juice and ice cubes and any other drinking water use. RO water also enhances
the flavor of food when cooking. Enjoy healthier water for your whole family.
TECHNICAL SPECIFICATIONS
Model: ZIP-B
Dimensions: (HxWxD) 415 x 250 x 380 mm
Weight: 25 lbs. (11.3 Kg)
Temperature Range (max/min): 45°C/5°C (113°F/41°F)
Inlet TDS (Maximum): 800ppm
Hardness (Maximum): 25 grain
RO Membrane: Type 1×1812 75 GPD
Production: 75 gallons per day
Electrical operation: 24VDC, 24 W
Electrical adaptor: 100-240 V 50 / 60Hz. 24VDC
Treated water reservoir capacity: ½gallon (2 liters)
Supply water pitcher capacity: 1 gallon (4 liters)

B
C
E
F
A
D
PARTS DESCRIPTION /5
A. Pure water reservoir cover.
B. Pure water reservoir.
C. Push button control.
D. Front panel cover.
E. Dispenser.
F. Supply pitcher.
G. Back cover.
H. Prefilter PP5 micron.
I. Prefilter Carbon.
J. Carbon postfilter and pH adjuster.
K. RO membrane.
L. Power socket.
M. Electrical transformer.
4 STAGE FILTRATION & BOOSTER PUMP
Stage 1. Prefilter
PP5 micron This stage removes particles suspended in inlet water.
Stage 2. Prefilter
Carbon
Removes free chlorine, odor, organic contaminants,
pesticides and chemicals that contribute
to undesirable taste and odor.
Stage 3. 75GPD RO
membrane
This is the heart of the ZIP Purifier, and removes
contaminants down to a molecular level.
(see page 6 for an explanation of “What is Reverse Osmosis” )
Stage 4. Post filter Removes any remaining odors and tastes, and adds
beneficial minerals to the drinking water.
Pump
UP-7000
UP-7000 Pump provides top quality, quiet,
efficient operation for pressure for RO process.
PARTS DESCRIPTION
G
H
I
J
K
L
M

REVERSE OSMOSIS
6\
WHAT IS NATURAL OSMOSIS AND
REVERSE OSMOSIS?
Natural or direct osmosis is common in nature, found in places like the semi-
permeable membranes which are part of the vast majority of organisms (e.g.
plant roots, our own body organs, cell membranes, etc ...)
When two solutions of different concentrations of salts (TDS -Total dissolved
solids) are separated by a semi permeable membrane, it naturally produces a
flow of water from the less concentrated solution to the higher concentrated
solution. This flow continues until the concentrations on both sides of the
membrane are equal.
To overcome this tendency, and reverse the natural flow of the system, (in
order to obtain a flow of water from a higher salt concentration solution to a
lower salt concentration solution) pressure is applied to the water on the side of
the membrane with the higher concentration. Pure water is collected from the
lower pressure side of the membrane and this process is what is called reverse
osmosis. Today, reverse osmosis is one of the best methods for improving the
characteristics of water by a physical process (without using chemicals).
For ZIP video walkthroughs and online user guide, please visit:
https://puricomusa.com/guide/

RO MEMBRANE /7
HOW DOES THE MEMBRANE WORK?
Pressure is applied to the water on the inlet side of the semi permeable
membrane, so that part of it (RO water) will flow through the pores of
the membrane, while the rest of the water (water rejected with high salt
concentration) will be diverted back to the supply pitcher to recycle and
optimize performance.
Since the diameter of the pores of the membrane is less than 0.0001 microns,
only water molecules and a small amount of minerals (sodium, potassium,
calcium, magnesium, etc.) will pass through the membrane. Larger molecules
will be “rejected” from passing through the membrane.
Particle filter
5 µm
Particle filter
1 µm
Ultrafiltration
0.01 µm
Reverse
Osmosis
0.0001 µm
Bacteria
0.2 µm
Virus
0.02 µm

CONTAMINANT REDUCTION
8\
CONTAMINANTS AND OTHER SUBSTANCES REDUCED
BY REVERSE OSMOSIS MEMBRANE.
The chemical composition and concentration of salts and other substances in
the inlet water will affect the water produced. The reverse osmosis membrane
of the ZIP Purifier is able to reduce the concentration of elements and
compounds listed in the following tables and more.
Element / Compound
Sodium
Calcium
Magnesium
Aluminum
Copper
Nickel
Zinc
Barium
Carbonates
Chlorine
Bicarbonates
Nitrates
Phosphates
Fluoride
Cyanide
Mercury
Chromium
Arsenic
Reduction
90-95%
93-98%
93-98%
93-98%
93-98%
93-98%
93-98%
93-98%
93-98%
90-95%
90-95%
45-55%
93-98%
93-98%
90-95%
94-96%
94-96%
93-98%
INORGANICS
Element / CompoundÁCI-
Total Organic Compounds
Glucose
Acetone
Isopropanol
Ethyl benzene
Ethylphenol
Tetrachloroethylene
Urea
1,2,4 trichlorobenzene
1,1,1 trichloralethane
Reduction
98%
98-99%
70%
90%
71%
84%
68-80%
70%
96%
98%
ORGANICS

OPERATION /9
OPERATION CONDITIONS
t Do not use water above 113°F (45 °C)
t The ambient temperature must be between 40
and 104 °F (4 and 40 °C. )
t Keep the system from extreme temperatures,
like cooking surfaces, direct sunlight, and
extreme environmental conditions.
t Avoid external dripping on the purifier.
CAUTIONS
Do not use with water that is microbiologically unsafe, of unknown quality, or
without adequate disinfection before or after the system. If the water being used
is from a public supply, it will comply with requirements for water to be used for
the ZIP purifier and your ZIP will substantially improve the water quality.
In the event that the water to be treated is not from a public water supply,
or is of unknown origin, in order to ensure proper purification, contact your
distributor to advise you on the most appropriate physical, chemical and
bacteriological water treatment to use with your ZIP system.
t Unplug the unit before repair, inspection or filter replacement.
EFFECT OF TDS CONCENTRATION
IN THE INLET WATER
Production rate will vary depending on the TDS content (Total Dissolved Solids)
and temperature of water to be treated. Water with a lower temperature and
higher TDS will be filtered slower than water which is warmer or of a lower TDS.
t It is recommended to use water with a maximum hardness of 25 grains in
order to obtain optimum performance.
t If the inlet water is of hardness greater than 25 grains, or contains high
concentrations of iron or manganese, or hyper chlorination, there may be a
reduction in membrane life and performance of certain components of the purifier.
ZIP is designed for TDS up to 800 ppm. For TDS above 800 ppm, consult
your dealer. (If the water being used is from a public supply, it will comply with
requirements for water to be used for the ZIP purifier.)

STARTUP
10 \
STARTUP AND OPERATING
1. Remove purifier and contents from box and place on a convenient counter
top or table within three feet (1 meter) of an electrical outlet. (fig. 1)
2. Equipment must be operated on a level surface and not inclined. (fig. 2)
3. Plug the transformer wire into the power socket on the back of the ZIP. Plug
the electric cord into a wall socket. (fig. 3) (The Push Button Control LED will
glow blue)
4. Remove the supply pitcher from its base by pulling out on the front handle.
(fig. 4) (The LED will flash yellow)
5. Place the pitcher under a faucet and fill to the “Max” level marked on the
front of the pitcher. (fig. 5)
3.

STARTUP
/ 11
8. To dispense Purified water, either push in or pull
out on the dispenser handle. When pulled out,
the handle will stay in the open position. (fig. 8)
6. Replace the supply pitcher to the base of the
ZIP, being sure the pitcher is securely seated
into the base. (The Push Button Control should
glow steady blue.)
7. Press the control button once. (fig. 7)
The purifier will draw water from the supply pitcher and direct purified water
to the Pure Water Tank.
A full course of treatment produces approximately 1/2 gallon (2 liters) of pure
water, stored in the upper reservoir. Unfiltered water is directed back to the
supply pitcher for recycling, allowing optimum performance.

PUSH BUTTON CONTROL
12 \
PUSH BUTTON CONTROL - USER INTERFACE
ZIP Purifier has a blue, yellow and red color coded LED electronic control
which integrates a timer, and security functions to efficiently manage the
filtering cycle and indicate any malfunctions detected.
The chart below shows condition of purifier by color coding.
INDICATOR
LIGHT STATUS LED FUNCTION MEANING
LED
Fixed Blue POWER ON System is waiting for
cycle.
LED
Flashing
Yellow
ALARMThe supply pitcher is not
mounted or set correctly.
LED
Flashing Blue FILTERING
The system is in
operation and treatment
is in process.
LED
Fixed Yellow
FILTERING
COMPLETE
or
ALARM
Pure water has been
drawn off from the supply
pitcher to the “minimum”
level and automatically
turned off. Cycle complete.
The lower reservoir is
empty or has insufficient
water

LED
Flashing red
FILTER
CHANGE
INDICATOR
Time to change filters.
LED
Steady red
RO MEMBRANE
CHANGE
INDICATOR
Time to change
RO membrane.
TREATMENT CYCLE / 13
TREATMENT CYCLE TIME
The time required to complete one cycle will vary according to water quality,
water temperature and how long the filters have been used. The filtering
process will turn off automatically once the cycle is completed.
Gradually as the filters and membrane become used, the filtering cycle time
will become longer. Usually the filtering process will complete before reaching
a preset 20 minute time limit. If the cycle does not complete in one 20 minute
cycle, this indicates that the filters should be changed.
Filtration completed less than
20 minutes
Filtration completed more than
20 minutes
Normal condition Filters should be changed

WATER SUPPLY
14 \
CHANGING WATER IN SUPPLY PITCHER.
After completing a filter cycle, completely empty the supply pitcher, and refill
with fresh water before starting another cycle. The water remaining in the
supply pitcher after a filtration cycle has a higher concentration of TDS, so
starting a new cycle, by adding fresh water to this remaining concentrate water
will lower system performance and can damage the RO membrane and filters.
FILTER INITIALIZATION
t When the purifier is being used for the first time, the filters should be rinsed
by running the purifier for two cycles, and discarding the water. Water
from the first cycle may contain fine carbon sediment form the post filter
which may give the water a slight gray color. This carbon is food grade and
healthy, and will not affect the quality of the water. After filtering two cycles,
the pure water reservoir may be removed from the purifier and rinsed with
tap water. (See page 15)
t With filters rinsed, the purifier may now be used for pure water filtration.
5.
Do not
add

CLEANING / 15
Notice:
t Water should not be stored in the purifier for extended periods of time
exceeding one week.
t If you plan to not use the purifier for more than one week, completely empty
the water supply pitcher and pure water reservoir, and disconnect the power
supply. When you return, filter two cycles of water to rinse the system.
t If the purifier has not been used for more than a month, remove and wash
with soap and water both the supply pitcher and pure water reservoir. Rinse
the reservoirs and filter two cycles of water to rinse the system.
CLEANING PURE WATER RESERVOUR
1. Remove top cover.
2. Slide the front cover panel up and remove.
3. Turn the pure water supply tube so it is pointing up.
4. Slide the pure water reservoir forward to remove.
5. Remove supply pitcher.
6. Wash both reservoirs with a soft cloth and soap and water.
1. 2. 3.
4. 5. 6.

FILTER REPLACEMENT
16 \
FILTER REPLACEMENT
Periodic filter replacement is required to insure water quality and proper
performance of filters. These are the recommended filter change periods to be
used as a guideline for municipal inlet water. Filters may need to be changed
more often if inlet water is of lower quality.
Prefilter PP5μ
Change at 12 months
Prefilter Carbon
Change at 12 months
RO Membrane
Change at 2 years
Post Filter
Change at 12 months
PREFILTER REPLACEMENT
PREFILTER PP5μAND PREFILTER CARBON
To change the prefilters proceed as follows.
1. Unscrew the two screws on the back of purifier.
2. Remove the back cover.
3. Identify the filter to be changed. Rotate clockwise.

POSTFILTER REPLACEMENT / 17
POSTFILTER REPLACEMENT
To change the postfilter, proceed as follows.
1. Remove the back cover. (fig. 7)
2. Pull the postfilter out to free it from the retaining clips. (fig. 8)
3. Disconnect the tubes from the elbow connectors on both ends of the
postfilter. To do this, (1) remove the safety clip from under the collet sleeves
on the elbow connector. (See Fig. 9 and diagrams on page 18 ) (2) Push the
collet sleeves in towards the elbow connector. (3) While holding the collet
sleeves in, pull the tube out of the elbow.
7. 8.
4. Once unscrewed, remove from purifier.
5. Remove new filter from packaging and insert into purifier by gently pushing
upwards while rotating counterclockwise until seated in place. (fig. 6 above)
6. Replace back cover.
7. Reset filter indicator light. See page 22 for filter notice reset procedure.

QUICK CONNECTORS
18 \
HOW QUICK CONNECTORS WORK
t To remove tubing from the connector: Remove the safety clip from under
the collet, push in the collet, and pull the tube out. (fig. A)
t Installation. Ensure the tube is clean and free of burrs. Push the tube into
the connector until it stops. (fig. B)
t Replace safety clip.
4. Unscrew the elbow connectors from the ends of the postfilter. (fig.10)
5. Remove new post filter from its wrapping and screw the elbow connectors
into the ends of the new postfilter. (fig. 11)
6. Insert the tubes into the top and bottom elbow connectors paying attention
to the direction of flow indicated by the arrow on the outside of the post
filter, (top to bottom). Be sure to push the tubes all the way in to the elbow
till they set at the back of the elbow. Slide the collet sleeve out and replace
safety clip under collet sleeve.
7. Mount the postfilter back into the retaining clips. (fig. 12) and replace back
cover.
8. Reset filter indicator light. See page 22 for filter notice reset procedure.
B.
Collet
(Do not remove)
Insert tubing
A.
Push collet in
and pull tube out
1.
2.
safety clip
12.

RO MEMBRANE REPLACEMENT / 19
RO MEMBRANE REPLACEMENT
How to tell if the RO membrane needs replacement:
The condition of the membrane is assessed by testing the percent TDS (Total
Dissolved Solids) rejection:
Using a TDS meter, compare the TDS of the inlet water to the pure RO water,
and obtain the percentage of TDS rejection.
Your supplier can help you to check your water quality, or you can purchase a
TDS tester to test by yourself.
% rejection rate = TDS of inlet water – TDS of pure water
TDS of inlet water
Example:
Inlet water TDS = 300ppm; Pure water TDS = 18ppm*
300 – 18
300
If rejection goes below 70% the membrane life has come to an end.
* After the RO membrane, the filtered water passes through the post filter which
adds minerals to the water, raising the TDS by about 10 -20 PPM. So the TDS
after the post filter will be higher than immediately after the RO membrane. As
long as the rejection rate calculated after the postfilter (final product water) is
above 70%, the RO membrane is still okay.
90 - 95% > Maximum Quality
70 - 80% > Low Quality
80 - 90% > Medium Quality
x 100
x 100 = 96% rejection rate
TDS Tester
