ZKTeco DL30DB User manual

Installation Guide
Version: 1.0
Date: July,2017
DL30DB Digital Lock with Voice Guide Feature

Before Installation
Diagram
1
A
B
C
C
D
F
EG
H
I
J
K
L
MN

56mm 6 4mm
25mm 35mm
20mm 30mm
Mounting Hardware Package Mounting Hardware Package
for door thickness of 30-38mm for door thickness of 39-46mm
A
H
E
L
M
J
H
E
L
M
J
G
FK
Packing List
D
CI
2
B
N

Door Preparation
Note: The standard lock includes 2 mounting hardware packages only, which are used for the door
thickness of 30-38mm and 39-46mm separately.
Note: Please refer to the above picture to adjust the direction of strike plate F and latch D.
1. Check the door thickness and prepare the corresponding mounting
hardware package.
2. Check door opening direction.
30~38 56 20 10 25
39~46 64 30 10 35
47~54 72 35 10 40
55~60 80 45 10 50
H Spindle Length
(mm)
J Screw Length
(mm)
M Screw Length
(mm)
L Screw Length
(mm)
Door Thickness
(mm)
3
Left inward Right inward
Left outward Right outward
F
FF
F
D
DD
D

4
3. Change latch (D) direction.
Fix the latch trim panel by using screws.
Remove screws from the latch trim panel with a
screwdriver and rotate the latch bolt at 180°.
Hexagon Screw
N
A
How To Use Mechanical Key And Change Handle Direction?

Remarks
1. New lock is configured to grant any password or card access.
2. The lock is equipped with mechanical keys for manual unlocking. Remove mechanical keys from the
package and keep them in a safe place.
3. To power up the lock, four alkaline AA batteries (not included) are required. Non-alkaline and
rechargeable batteries are NOT recommended.
4. The operation of lock setting has a stand-by time limit of 10 seconds; if there is no any activity, the lock
will shut off after 10 seconds.
5

Note 1: Align the template along the vertical center
line of the latch(D) at the desired handle height,
and tape it to the door.
Note 2: Mark the holes first, and then start drilling.
1. Drill holes on the door. 2. Install the latch (D).
E
E
D
center line of the
handle
desired handle
height
Installation
6
62mm

3. Install outdoor unit (B) with gasket (C) and spindle(H) on the door.
7
Correct Position: T he small triangle
must be vertically upward.
Incorrect position
H
B
C

4. Install mounting plate (I) with gasket (C) on the door.
J
5. Install indoor unit (K).
M
Note : Push cable into the hole first.
L
B
C
I
I
C
J
8
M
L
K

6. Insert batteries.
EG
F
7. Mark and drill holes for the strike.
8. Test the lock by rotating the back handle and using the mechanical
key (A).
Note : When the door is l ocked and the clutch is idle, the front handle
can be turned, but the door will remain locked.
9
[43/8"]
24 mm
[15/16"]
111 mm
22 mm
[55/64"]
29 mm
[19/64"]
3mm
[1/8"]
[43/8"]
72 mm
