Zkteco Sbtl9000 series User manual

SBTL9000 Series User Manual

Thank you for choosing our product. Please read the instructions carefully

before operation. Follow these instructions to ensure that the product is

functioning properly. The images shown in this manual are for illustrative

purposes only.

For further details, please visit our Company’s website

www.zkteco.com.

User Manual

SBTL9000 Series

Date: September 2021

Doc Version: 1.0

English

SBTL9000 Series User Manual

Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any

way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company" or

"ZKTeco").

Trademark

is a registered trademark of ZKTeco. Other trademarks involved in this manual are owned by

their respective owners.

Disclaimer

This manual contains information on the operation and maintenance of the ZKTeco equipment. The

the property of ZKTeco. The contents hereof should not be used or shared by the receiver with any third

party without express written permission of ZKTeco.

The contents of this manual must be read as a whole before starting the operation and maintenance of the

supplied equipment. If any of the content(s) of the manual seems unclear or incomplete, please contact

ZKTeco before starting the operation and maintenance of the said equipment.

It is an essential pre-requisite for the satisfactory operation and maintenance that the operating and

maintenance personnel are fully familiar with the design and that the said personnel have received

thorough training in operating and maintaining the machine/unit/equipment. It is further essential for the

safe operation of the machine/unit/equipment that personnel has read, understood and followed the

safety instructions contained in the manual.

In case of any conflict between terms and conditions of this manual and the contract specifications,

drawings, instruction sheets or any other contract-related documents, the contract conditions/documents

shall prevail. The contract specific conditions/documents shall apply in priority.

ZKTeco offers no warranty, guarantee or representation regarding the completeness of any information

contained in this manual or any of the amendments made thereto. ZKTeco does not extend the warranty

of any kind, including, without limitation, any warranty of design, merchantability or fitness for a particular

purpose.

ZKTeco does not assume responsibility for any errors or omissions in the information or documents which

are referenced by or linked to this manual. The entire risk as to the results and performance obtained from

using the information is assumed by the user.

ZKTeco in no event shall be liable to the user or any third party for any incidental, consequential, indirect,

special, or exemplary damages, including, without limitation, loss of business, loss of profits, business

interruption, loss of business information or any pecuniary loss, arising out of, in connection with, or

SBTL9000 Series User Manual

relating to the use of the information contained in or referenced by this manual, even if ZKTeco has been

advised of the possibility of such damages.

This manual and the information contained therein may include technical, other inaccuracies or

typographical errors. ZKTeco periodically changes the information herein which will be incorporated into

new additions/amendments to the manual. ZKTeco reserves the right to add, delete, amend or modify the

information contained in the manual from time to time in the form of circulars, letters, notes, etc. for better

operation and safety of the machine/unit/equipment. The said additions or amendments are meant for

improvement /better operations of the machine/unit/equipment and such amendments shall not give any

right to claim any compensation or damages under any circumstances.

ZKTeco shall in no way be responsible (I) in case the machine/unit/equipment malfunctions due to any

non-compliance of the instructions contained in this manual (ii) in case of operation of the

machine/unit/equipment beyond the rate limits (iii) in case of operation of the machine and equipment in

conditions different from the prescribed conditions of the manual.

The product will be updated from time to time without prior notice. The latest operation procedures and

relevant documents are available on http://www.zkteco.com

If there is any issue related to the product, please contact us.

ZKTeco Headquarters

Address ZKTeco Industrial Park, No. 32, Industrial Road,

Tangxia Town, Dongguan, China.

Phone +86 769 - 82109991

Fax +86 755 - 89602394

For business-related queries, please write to us at: [email protected]m.

To know more about our global branches, visit www.zkteco.com.

SBTL9000 Series User Manual

About the Company

ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein)

readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition

Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and

Consumer products including battery-operated fingerprint and face-reader Door Locks. Our security

solutions are multi-lingual and localized in over 18 different languages. At the ZKTeco state-of-the-art

700,000 square foot ISO9001-certified manufacturing facility, we control manufacturing, product design,

component assembly, and logistics/shipping, all under one roof.

The founders of ZKTeco have been determined for independent research and development of biometric

verification procedures and the productization of biometric verification SDK, which was initially widely

applied in PC security and identity authentication fields. With the continuous enhancement of the

development and plenty of market applications, the team has gradually constructed an identity

authentication ecosystem and smart security ecosystem, which are based on biometric verification

techniques. With years of experience in the industrialization of biometric verifications, ZKTeco was

officially established in 2007 and now has been one of the globally leading enterprises in the biometric

verification industry owning various patents and being selected as the National High-tech Enterprise for 6

consecutive years. Its products are protected by intellectual property rights.

About the Manual

This manual introduces the operations of the SBTL9000 Series.

All figures displayed are for illustration purposes only. Figures in this manual may not be exactly consistent

with the actual products.

SBTL9000 Series User Manual

Document Conventions

Conventions used in this manual are listed below:

GUI Conventions

For Software

Convention Description

Bold font Used to identify software interface names e.g. OK, Confirm, Cancel.

> Multi-level menus are separated by these brackets. For example, File > Create >

Folder.

For Device

Convention Description

< > Button or key names for devices. For example, press <OK>.

[ ]

Window names, menu items, data table, and field names are inside square

brackets. For example, pop up the [New User] window.

/ Multi-

level menus are separated by forwarding slashes. For example,

[File/Create/Folder].

Symbols

Convention Description

This represents a note that needs to pay more attention to.

The general information which helps in performing the operations faster.

The information which is significant.

Care taken to avoid danger or mistakes.

The statement or event that warns of something or that serves as a cautionary

example.

SBTL9000 Series User Manual

Table of Contents

1OVERVIEW............................................................................................................................................ 6

CHASSIS DESIGN AND DIMENSIONS .................................................................................................................. 61.1

MECHANICAL SYSTEM ...................................................................................................................................... 81.2

ELECTRONIC CONTROL SYSTEM ........................................................................................................................ 81.3

WORKING PRINCIPLE........................................................................................................................................ 81.4

SYSTEM COMPOSITION..................................................................................................................................... 91.5

TECHNICAL SPECIFICATIONS............................................................................................................................. 91.6

2INSTALLATION................................................................................................................................... 11

INSTALLATION REQUIREMENTS .......................................................................................................................112.1

INSTALLATION POSITION ................................................................................................................................112.2

CABLES INSTALLATION AND FIXING ................................................................................................................ 122.3

3MENU INTRODUCTION...................................................................................................................... 14

PASSAGE SETTINGS ........................................................................................................................................ 143.1

3.1.1 GATE SYSTEM SETTINGS...................................................................................................................14

3.1.2 GATE FUNCTION SETTINGS .............................................................................................................. 15

3.1.3 EXTERNAL DEVICE INFORMATION ..................................................................................................18

WIRING AND TERMINAL..................................................................................................................................193.2

4CONNECT TO ZKBIOSECURITY.......................................................................................................... 21

5LCD SCREEN SETTINGS...................................................................................................................... 22

SET THE LCD SCREEN DISPLAY.......................................................................................................................235.1

CLEAR ALL THE PEOPLE COUNTS.....................................................................................................................245.2

6MAINTENANCE .................................................................................................................................. 25

CHASSIS MAINTENANCE................................................................................................................................. 256.1

MOVEMENT MAINTENANCE............................................................................................................................ 256.2

POWER SUPPLY MAINTENANCE ......................................................................................................................256.3

7TROUBLESHOOTING.......................................................................................................................... 26

SBTL9000 Series User Manual

1Overview

The SBTL9000 Series swing barrier turnstile is an elegant cost-effective entrance control system

designed for high-traffic volume. The SBTL9000 Series barriers are normally held in a locked position,

thus denying access to the secured side. Upon SBTL9000 Series’s reader (RFID and/or fingerprint)

positively recognizing a user’s valid access card or fingerprint, its barriers swing automatically, thus

allowing users passage to the secured side.

Chassis Design and Dimensions1.1

The SBTL9000 Series comes with Aluminum alloy housing, Acrylic panel which provides simple and

beautiful design with corrosion protection. It provides orderly and civilized passage to the persons

and restricts illegal personnel access. In case of emergencies, it ensures that evacuation passage

runs smoothly and is convenient for personnel.

The appearance and dimensions of the SBTL9000 Series are shown in Figure 1-1.

SBTL9000 Series User Manual

Figure 1-1

SBTL9000 Series User Manual

Mechanical System1.2

The mechanical system of the Swing Barrier turnstile includes the chassis and the core component.

The chassis is a carrier where the Direction indicator, Reader, Infrared sensor, and the Door lock are

installed. The core component mainly consists of the Motor, Frame, Bearing, and Swing Arm.

Electronic Control System1.3

The electronic control system of a swing barrier turnstile is mainly composed of the Reader, Master

Control Panel, Infrared Sensor, Direction Indicator and Alarm.

Reader: The reader reads the data in the card and sends it to the Access Controller.

Master Control Panel: The Master Control panel is the system’s control center that receives

signals from the reader and the photoelectric switch performs logical calculation and processing of

these signals and sends executive commands to the Direction indicator, electric motor and the

alarm.

Infrared Sensor: It detects the position of the pedestrian and plays the role of safety protection.

Direction Indicator: This indicator displays the pedestrian passage path and directs them to pass

through the lane in a safe and orderly manner.

Alarm: The alarm gives an alarm voice if the system detects any unauthorized entry to the passage.

Working Principle1.4

1. After supplying power to the device, the system performs Power-On Self-Test. The device

starts normally if no failure is detected. If a failure is detected, the system displays related

messages on the LCD display screen so that the user can have a quick knowledge of the

technical issue and solve the problem.

2. When the reader detects a valid card/fingerprint, the buzzer will give a positive audible

prompt to the pedestrian, indicating that the card is being read successfully or “fingerprint

successfully verified”. And then, the reader sends signals to the access controller to request

permission to pass through the passage. The access controller will send the signal to the

master control panel.

3. After receiving the signal from the access controller, the master control panel sends valid

control signals to the direction indicator and the electric motor. At last the direction arrow

turns green.

4. Pedestrians passes through the passage according to the direction indicator signs. Infrared

sensors keep on detecting the pedestrian during the whole process, and continue to send

SBTL9000 Series User Manual

signal to the master control board until the pedestrian passes completely through the

passage.

5. If the pedestrian enters the passage but forgets to flash the card, or if the card held by the

pedestrian is invalid, the system will prompt an audible alarm to stop and retreat the

pedestrian from the passage. The pedestrian can pass through the passage only after a valid

card is read by the card reader.

System Composition1.5

The single-lane management system is composed of two single-core swing barriers. The multi-lane

management system is composed of two single-core barriers and multiple dual-core barriers.

Working modes of the system

To make the product more versatile, this system provides multiple working modes for the user,

including Normal working mode, Normally open mode, Normally close mode and Testing mode.

Normal Working Mode: In this working mode, the turnstile works normally.

Normal Open Mode: In this working mode, the turnstile is always open.

Normal Close Mode: In this working mode, the turnstile is always closed.

Testing Mode: In this working mode, the turnstile performs Power-on Self-Test.

After supplying power to the device, the LCD screen on control board will display a default state,

which displays current work mode.

Technical Specifications1.6

Feature Specification

Power Requirements AC 100 to 120V/200 to 240V, 50/60Hz

Working Temperature -28°C to 60°C

Working Humidity 20% to 95% (Non-condensing)

Working Environment Indoor

Max. Speed of Throughput 35 people per minute

Lane Width (mm) 780

Infrared Sensor 12 pairs

Dimension (mm) L=1738, W=142, H=1080

SBTL9000 Series User Manual

Dimension with Packing (mm) L=1850, W=400, H=1130

Cabinet Material Aluminium Alloy

Lid Material Aluminium Alloy

Barrier Material Acrylic

Barrier Movement Swing

Emergency Mode Supports

Security Level Medium

Screen Size 15.2 inches

Pixel Format 1280 * 307 Pixels

SBTL9000 Series User Manual

2Installation

Installation Requirements2.1

1) It is recommended that the swing barrier must be installed on a horizontal solid platform with a

height of 50mm to 100mm.

2) It is also recommended that the swing barrier turnstile should not be used in the corrosive

environment.

3) Make sure the ground wire of the system is reliably connected to avoid personal injuries or

other accidents.

4) After installation, check if the connection is done correctly at the connecting points of the

ground wire, at the connector assemblies and wiring points of the circuits, as well as at each

movable part of the swing barrier turnstile. Any loose nuts, screws and other fasteners should

be tightened in time to avoid any failures caused by long-time operations.

Installation Position2.2

The installation position of the swing barrier turnstile depends on its size. A distance of 100mm

between the swing barrier turnstile and the wall needs to be reserved for ease of opening the top

cover of the machine to perform maintenance and adjustment. The reference figure is shown

below:

Figure 2-1 The SBTL9000 Series Dual-lane

SBTL9000 Series User Manual

Cables Installation and Fixing2.3

For the outlets of the concealed cables, please refer the below diagram indicating the mounting

holes. The input voltage for this swing barrier turnstile is AC100V-120V/200V-240V and its master

and slave are connected by an 8-core cable (signal) and a 2-core cable (power). When installing

the swing barrier turnstile, the user only needs to connect it to the corresponding ports. Note that

the PVC conduits are laid 100mm under the ground, with the height of the exposed part not

exceeding 100mm. In addition, the conduit outlet is bent back to prevent the ingress of water into

the conduit.

The SBTL9000 Series installation holes and cabling positions is shown in Figure 2-2:

Figure 2-2

SBTL9000 Series User Manual

Mark the screw hole at the centre of the stand, and the edge of the chassis base on the

ground according to the sizes as shown on the Figure 2-2.

Drill the holes and embed M12 anchor bolts or expansion bolts.

Place the swing barrier turnstile according to the sizes and positions as shown in the figure

before installation and fixing.

Connect the online cables and perform the power-on test.

If the test is OK, tighten the screws.

It is recommended that a warning line be marked on the ground after installing the device,

so as to prompt the pedestrian to stand behind the warning line when swiping the card.as

shown in Figure 2-3:

Figure 2-3

SBTL9000 Series User Manual

3Menu Introduction

Passage Settings3.1

On the Main Menu interface, tap on Passage Settings to go to the interface.

On this interface, one can set the parameters like Gate Passage Mode and the opening and closing

speed of the barrier on the connected gates.

3.1.1 Gate System Settings

On the Passage Settings interface, tap on Gate System Setting to set the Gate System.

These functions are available in Gate System Settings: -

Motor Driver Board Type

The motor drive type is automatically matched and subitems cannot be modified as an

information reference.

Gate Opening Speed

Sets the speed to open the gate. The smaller the number is set, the faster the speed, and the

value can be set between 1 to 100 seconds.

Gate Closing Speed

Sets the speed to close the gate. The smaller the number is set, the faster the speed, and the

value can be set between 1 to 100 seconds.

Brake Distance

The opening angle of the arm which is pushed unauthorizedly, and the valid value is 1 to 100.

SBTL9000 Series User Manual

Limit Adjustment

You can set the adjustment of the right open limit, the left open limit and the closing limit of

the gate.

Swing Arm Type

Sets the swing arm type. The types are Ordinary Swing Door and Extra Wide Swing Door.

Infrared Expansion Board

Enable or disable infrared expansion board as per the requirement.

IR Quantity

Emission range infrared supported by the device, and the valid value is 1 to 65535.

Ambient Light Settings

Control the blue LED light on the gate.

Offline Using

Enable or disable offline using as per the requirement.

Clear Running Times

Clears all the running records.

Test Mode

Test the left opening, right opening and closing of the gate.

3.1.2 Gate Function Settings

On the Passage Settings interface, tap on Gate Function Setting to set the Gate Function.

These functions are available in Gate Function Settings:

Passing Mode

You can set any of the passing mode among these:

1. Two-way Control: Verification is required for both entry and exit.

2. In Control, Out Free: Verification is required only for entry.

SBTL9000 Series User Manual

3. In Free, Out Control: No verification is needed during entry, but verification is required for

exit.

4. Two-way Free: No verification is required for entry and exit.

5. In Control, Out Forbidden: Verification is required for entry, but exit is forbidden.

6. In Forbidden, Out Control: Entry is forbidden, but verification is required for exit.

7. In Free, Out Forbidden: No verification is needed for entry but exit is forbidden.

8. In Forbidden, Out Free: Entry is forbidden, and no verification is required for exit.

9. Two-way Forbidden: Both entry and exit are forbidden.

10. Two-way Normally Open: During entry and exit, the gate/flap will close only after

successful verification.

Clutch Alarm Setting

The way to unlock the gate which is pushed in an unauthorized way and the clutch is locked

automatically. It can be set as Automatic release or Authorized release.

Anti-pinch Area Setting

If a person/object is detected in the anti-pinch area, the wings will stop automatically. Anti-

pinch Area Setting can be set as, Anti-pinch in the Channel or No Anti-pinch at Head and

Tail.

Anti-pinch Action Setting

When swing barrier has obstacle to work, the machine will stop automatically. Anti-pinch

Action Setting can be set as Anti-pinch to Stop, Anti-pinch to Open Gate or Disabled.

False Direction Entry

When the turnstile opens to the left, but a person enters in the opposite direction, it is known as

False Direction Entry. It can be set as Reverse Break-in to Close Gate, Not Close Gate or

Disabled.

Anti-tailgate Setting

Anti-Tailgating refers to restricting an unauthorized person from gaining access through a

turnstile after an authorized person has already gained access. Anti-tailgate Setting can be set

as Anti-tailgate to Close Gate, Not Close Gate or Disabled.

SBTL9000 Series User Manual

Verification Mode

You can set the verification mode as Allow verification in Channel, or No verification

allowed in Channel.

Memory Function

When more than two legal access signals are given at the same time (including the same

direction and the opposite direction), the system will remember all pass requests and complete

each pass in turn.

Stay Duration Time

You can set the duration of stay in the channel after successful verification, with a valid value of

0-60 seconds.

Open Duration Time

Open duration time refers to the period of time from opening to closing once the turnstile

receives an open signal. You can set the unattended time or Open Duration Time, with a valid

value of 2 to 60 seconds.

Gate Closing Delay Time

After pedestrian passes through the last infrared sensor, the gates will keep opening the time

what you set, then close immediately. You can set the Gate Closing Delay Time, with a valid

value of 0-60 seconds.

Fire Mode

According to the external fire equipment, select the corresponding type of trigger mode. You

can set Fire Mode as Entry Opening, Exit Opening or Disabled.

Volume Setting

You can adjust the volume of the device, with a valid value of 0-100.

Alarm Tone Setting

You can enable or disable the alarm tone.

In/Out Exchange

You can switch the direction of the entrance and exit.

SBTL9000 Series User Manual

Reset Counter

It can be set as Clear all counters, Clear the entry counter, Clear the exit counter or Clear

the alarm counter.

3.1.3 External Device Information

You can enable/disable the direction infrared function to manage the external devices.

States Description

ON When enable, it will display the entry and exit directions information of the

LCD screen.

OFF When disable, it will display the reader entry and exit, you can set to close,

or choose to connect Wiegand reader or 485 reader.

SBTL9000 Series User Manual

Wiring and Terminal3.2

Reset USB Slot Ethernet/POE Interface

Antenna

AUX IN

24V DC Power Supply

Wiegand Reader 1

RS 485

EXT RS485

Status Indicator

Exit or entry status indicator

12V DC Power Supply

FACP_SIGNAL

Speaker

AUX OUT

IR Sensor

Door

Exit or entry status indicator

Wiegand Reader 2

AUX OUT

IR Sensor
