ZKTeco RevFace15 User manual

Installation Guide
Version: 1.0
Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the
actual product and the written information in this manual.
RevFace15

-1-
Installation Requirements
Device Installation
Installing on the wall
Baseline
1.5m
Place the mounting template sticker onto the wall, and drill holes according to the mounting paper.
Fix the back plate onto the wall using wall mounting screws.
Fix the device into back plate.
Use the safety screw to fasten the device to the back plate.

-2-
Power Connection
Recommended AC adapter: 12V 3A,
AC adapterTo share the power with other devices, use a with higher current ratings.n
DC 12V, 3A
Port Introduction
RJ45 Port
Power
RS232_TXD
RS232_RXD
GND
GND
GND
12VIN
12VIN
AL+
AL-
NC
COM
NO
BUT
GND
SEN
GND
AUX
GND
12V-OUT
GND
IWD0
IWD1
WD0-OUT
WD1-OUT
12V-OUT
GND
485A
485B
RS232
RS485
Wiegand In
Wiegand Out
Alarm
Lock
Exit Button
Sensor
Auxiliary Input
Power Out
Power Out
Power In

-3-
Printer Connection
RS232_TXD
RS232_RXD
GND
GND
GND
12VIN
12VIN
RS232
Printer
Wiegand Reader Connection
Wiegand Reader
GND
+12V
WD1
WD0
Access
Controller
WD1
WD0
+12V
GND
12V-OUT
GND
IWD0
IWD1
WD0-OUT
WD1-OUT
12V-OUT
GND
485A
485B

-4-
-
+
Detector
Power
Smoke Detector
COM
NO
RS485 Connection
RS485 Reader
485+
485-
+12V
GND
Door Sensor, Exit Button & Alarm Connection
Alarm Power
Alarm
-
+
-
+
Exit Button
Door Sensor
AL+
AL-
NC
COM
NO
BUT
GND
SEN
GND
AUX
GND
12V-OUT
GND
IWD0
IWD1
WD0-OUT
WD1-OUT
12V-OUT
GND
485A
485B

-5-
Lock Relay Connection
1) Device not sharing power with the lock 2) Device sharing power with the lock
The system supports both Normally Opened Lock and Normally Closed Lock. The NO Lock (normally
open when powered) is connected with 'NO' and 'COM' terminals, and the NC Lock (normally close
when powered) is connected with 'NC' and 'COM' terminals. The power can be shared with the lock or
can be used separately for the lock, as shown in the example with NC Lock below:
DC12V
FR107
NC Lock
DC12V
DC12V
FR107
NC Lock
Ethernet Connection
Connect the device and the software over an Ethernet cable. An example is shown below:
: 192.168.1.201Default IP address
: 255.255.255.0Subnet mask
: 192.168.1.130IP address
: 255.255.255.0Subnet mask
Click [Comm.] > [Ethernet] > [IP Address], input the IP address and click [OK].
Note: In LAN, the IP addresses of the server (PC) and the device must be in the same network
segment when connecting to ZKBioAccess IVS software.
+12V
GND
AL+
AL-
NC
COM
NO
BUT
GND
SEN
GND
AUX
GND
+12V
GND
AL+
AL-
NC
COM
NO
BUT
GND
SEN
GND
AUX
GND

-6-
Download Center
Use the mobile phone and scan the QR Code to download the User Manual, Installation Guide and
Quick Start Guide.
