ZKTeco SpeedFace V4LTI User manual

Installation Guide
Version: 1.0
Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the
actual product and the written information in this manual.
4-inch Thermal Imaging Product

1
How to Install the Device?
Attach the mounting template sticker to the wall, and drill holes according
to the mounting paper. Fix the backplate on the wall using wall mounting
screws.
1.
Attach the device to the backplate, and plug the USB cable into the USB port.
2.
Fasten the device to the backplate with a security screw.
3.
Please pass the wire through the backplate before installation.
1.50m
1 2 3


Wiring Diagram
Power Connection:
12V DC
GND
GND
12V
Recommended AС Adapter
1) 12V ± 10%, at least 3000mA.
2) To share the power with other devices, use an AС Adapter with higher current
ratings.

2
Ethernet Connection:
Connect the device and computer software over an Ethernet cable. As shown in the
example below:
Lock Relay Connection:
1) Device not sharing power with the lock
Default IP address: 192.168.1.201
Subnet mask: 255.255.255.0
Click [COMM.] > [Ethernet] > [IP Address] , input the IP address and click [OK].
Note: In LAN, the IP addresses of the server (PC) and the device must be in the
same network segment when connecting to ZKBioAccess IVS software.
IP address: 192.168.1.130
Subnet mask: 255.255.255.0
8
7
6RJ 45
5
4
3
2
1
TX+
TX-
RX+
RX-
ZKBioAccess IVS
DC12V
AL+
485A
IWD1
+12V
GND
IWD0
485B
NC
COM
NO
GND
+12V
GND
FR107
Normally Closed Lock
DC12V

3
Door Sensor, Exit Button & Auxiliary Input Connection:
2) Device sharing power with the lock
Normally Closed Lock
AL+
485A
IWD1
+12V
GND
IWD0
485B
NC
COM
NO
GND
+12V
GND
FR107
DC12V
AL+
NC
COM
NO
GND
AL-
BUT
AUX
SEN
GND
485A
IWD1
IWD0
485B BELL+
BELL-
GND
GND
Door
Sensor
ExitButton
+
-
Smoke
Detector
-
+
Alarm's Power
Switch
+
-
Alarm
COM
NO

RS485 Connection:
Wiegand Reader Connection:
4
Wiegand Reader
+12V
IWD1
IWD0
GND
+12V
GND
WD0
WD1
Access Controller
WD0
WD1
AL+
485A
IWD1
IWD0
485B
NC
COM
NO
GND GND
485+
485-
RS485 Reader

Download Center
Scan the QR Code to download the User Manual, Installation Guide and Quick Start
Guide.
QR Code (Download Center)
5

ZKTeco Industrial Park, No. 32, Industrial Road,
Tangxia Town, Dongguan, China.
Phone : +86 769 - 82109991
Fax : +86 755 - 89602394
www.zkteco.com
Copyright © 2021 ZKTECO CO., LTD. All Rights Reserved.
