Aaeon OMNI-5155L User manual

Last Updated: June 22, 2018
OMNI-5155L
Industrial Touch Panel PC
With Intel® Bay Trail Platform
User’s Manual 1st Ed

Preface II
Industrial Touch Panel PC OMNI-5155L
Copyright Notice
This document is copyrighted, 2018. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design without notice to its
users.

Preface III
Industrial Touch Panel PC OMNI-5155L
Acknowledgement
All other products’ name or trademarks are properties of their respective owners.
Microsoft Windows is a registered trademark of Microsoft Corp.
Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel Corporation
Core, Atom are trademarks of Intel Corporation
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines
Corporation.
All other product names or trademarks are properties of their respective owners.

Preface IV
Industrial Touch Panel PC OMNI-5155L
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
OMNI-5155L
1
Product CD with User’s Manual (in pdf) and drivers
1
HDD bracket
1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

Preface V
Industrial Touch Panel PC OMNI-5155L
About this Document
This User’s Manual contains all the essential information, such as detailed descriptions
and explanations on the product’s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver
installation instructions (if any), to facilitate users in setting up their product.
Users may refer to the AAEON.com for the latest version of this document.

Preface VI
Industrial Touch Panel PC OMNI-5155L
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references
1. All cautions and warnings on the device should be noted.
2. All cables and adapters supplied by AAEON are certified and in accordance with
the material safety laws and regulations of the country of sale. Do not use any
cables or adapters not supplied by AAEON to prevent system malfunction or
fires.
3. Make sure the power source matches the power rating of the device.
4. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
5. Always completely disconnect the power before working on the system’s
hardware.
6. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
7. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
8. Always disconnect this device from any AC supply before cleaning.
9. While cleaning, use a damp cloth instead of liquid or spray detergents.
10. Make sure the device is installed near a power outlet and is easily accessible.
11. Keep this device away from humidity.
12. Place the device on a solid surface during installation to prevent falls
13. Do not cover the openings on the device to ensure optimal heat dissipation.
14. Watch out for high temperatures when the system is running.
15. Do not touch the heat sink or heat spreader when the system is running
16. Never pour any liquid into the openings. This could cause fire or electric shock.

Preface VII
Industrial Touch Panel PC OMNI-5155L
17. As most electronic components are sensitive to static electrical charge, be sure
to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and contain all electronic components
in any static-shielded containers.
18. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
19. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.

Preface VIII
Industrial Touch Panel PC OMNI-5155L
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept
any interference received including interference that may
cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et
les directives gouvernementales de recyclage.

Preface IX
Industrial Touch Panel PC OMNI-5155L
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
○
○
○
○
○
○
外部信号
连接器及线材
○
○
○
○
○
○
外壳
○
○
○
○
○
○
中央处理器
与内存
○
○
○
○
○
○
硬盘
○
○
○
○
○
○
液晶模块
○
○
○
○
○
○
光驱
○
○
○
○
○
○
触控模块
○
○
○
○
○
○
电源
○
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。

Preface X
Industrial Touch Panel PC OMNI-5155L
China RoHS Requirement (EN)
Poisonous or Hazardous Substances or Elements in Products
AAEON Panel PC/ Workstation
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components
O
O
O
O
O
○
Wires &
Connectors
for External
Connections
O
O
O
O
O
O
Chassis
O
O
O
O
O
O
CPU & RAM
O
O
O
O
O
O
Hard Disk
O
O
O
O
O
O
LCD
O
O
O
O
O
O
Optical Drive
O
O
O
O
O
O
Touchscreen
O
O
O
O
O
O
PSU
O
O
O
O
O
O
O：The quantity of poisonous or hazardous substances or elements found in each of the
component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least one of the
component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this product is applicable under normal
usage only

Preface XI
Industrial Touch Panel PC OMNI-5155L
Table of Contents
Chapter 1 - Product Specifications ........................................................................................ 1
1.1 Specifications........................................................................................................... 2
Chapter 2 –Hardware Information.......................................................................................5
2.1 Dimensions.............................................................................................................. 6
2.2 Motherboard............................................................................................................7
2.3 System Memory ..................................................................................................... 9
2.4 Jumpers...................................................................................................................10
2.4.1 Clear RTC RAM (CLRTC)...........................................................................10
2.4.2 COM1 Ring/+5V/+12V selector (6-pin J1) .............................................11
2.4.3 Inverter voltage selection (3-pinJ2).......................................................12
2.4.4 Inverter Backlight Control of Inverter selector (3-pin J3)....................13
2.4.5 LVDS panel voltage selection (3-pin J4) ................................................14
2.4.6 BIOS programmable connector (8-pin SPI).........................................15
2.4.7 COM1 (RS232/422/485): D-SUB9(M) ....................................................16
2.4.8 COM2 (RS232): D-SUB9(M).....................................................................17
2.4.9 12VDC power Input...................................................................................17
2.5 Mount the OMNI onto the wall..........................................................................18
Chapter 3 - AMI BIOS Setup................................................................................................20
3.1 System Test and Initialization..............................................................................21
3.2 AMI BIOS Setup.................................................................................................... 22
3.3 Setup Submenu: Main......................................................................................... 23
3.4 Setup Submenu: Advanced ...............................................................................24
3.4.1 Advanced: Power Management............................................................ 25
3.4.2 Advanced: CPU Configuration............................................................... 27
3.4.2.1 Socket 0 CPU Information..................................................... 28
3.4.3 Advanced: Super IO Configuration ...................................................... 29

Preface XII
Industrial Touch Panel PC OMNI-5155L
3.4.3.1 Serial Port 1 Configuration.................................................... 30
3.4.3.2 Serial Port 2 Configuration ....................................................31
3.4.4 Advanced: Trusted Computing.............................................................. 32
3.4.5 Advanced: USB Configuration............................................................... 33
3.4.6 Advanced: Hardware Monitor ...............................................................34
3.4.7 Advanced: IDE Configuration ................................................................ 35
3.5 Setup submenu: Chipset..................................................................................... 37
3.5.1 Chipset: North Bridge.............................................................................. 38
3.5.2 Chipset: South Bridge.............................................................................. 40
3.6 Setup submenu: Security....................................................................................42
3.6.1 Security: P1:WDC WD3200LP.................................................................43
3.7 Setup submenu: Boot..........................................................................................44
3.7.1 Boot: Hard Drive BBS Priorities.......................................................................... 45
3.8 Setup submenu: Exit............................................................................................ 46
Chapter 4 –Drivers Installation & Touchscreen Settings..................................................47
4.1 Product CD/DVD..................................................................................................48
Appendix A - Watchdog Timer Programming................................................................... 51
A.1 Watchdog Timer Initial Program....................................................................... 52
Appendix B - I/O Information..............................................................................................57
B.1 I/O Address Map.................................................................................................. 58
B.2 Memory Address Map........................................................................................ 60
B.3 IRQ Mapping Chart ..............................................................................................61

Industrial Touch Panel PC OMNI-5155L
Chapter 1
Chapter 1 - Product Specifications

Chapter 1 –Product Specifications 2
Industrial Modular Touch Panel PC OMNI-5155L
1.1 Specifications
System
Processor
Intel® Celeron® J1900, 2 GHz
System Memory
204-pin DDR3L 1333 SODIMM x 1, up to 8 GB
Ethernet
I0/100/1000Base-TX, RJ-45 x 2
Bottom I/O
DB-9 for RS-232 x 1
DB-9 for RS-485/422/232 x 1
10/100/1000Base-T, RJ-45 x 2
Type A USB 2.0 x 2
Type A USB 3.0 x 1
VGA x 1
HDMI x 1
Lockable 12 Vdc power input x 1
Power on/off switch x1
Storage Disk Drive
Internal SATA 2.5”HDD x 1
Expansion Slot
Full Size Mini Card x 1
Half Size mini card x 1
OS Support
Windows® 10
Windows® 7
Ubuntu16.04.4 Kernel 4.8.0-36-generic x86_64

Chapter 1 –Product Specifications 3
Industrial Modular Touch Panel PC OMNI-5155L
Environmental
Operating Temperature
-10°C~55°C with industrial grade device (with
0.5 m/s air flow, according to
IEC68-2-14
*AAEON suggests users use industrial grade
wide temperature DRAM and wide temperature
storage devices.
Storage Temperature
-20 ~ 70°C (-4 ~ -158°F)
Operating Humidity
90% @ 40°C, non-condensing
Anti-Vibration
1 Grms/ 5 ~ 500 Hz/ Operation (HDD)
EMC
CE/FCC Class A
Power Supply
DC Input
12 V
Mechanical
Construction
IP65/ NEMA 4 for aluminum front bezel
IP30 ECC chassis
Mounting
VESA 100 / Panel Mount / Stand
Dimension (W x H x D)
369 x 304 x 67 mm
Gross Weight
6.35kg

Chapter 1 –Product Specifications 4
Industrial Modular Touch Panel PC OMNI-5155L
LCD
Display Type
15”TFT LCD
Max. Resolution
1024 x 768
Max Colors
16.7M (RGB 8 bits)
Luminance (cd/m2)
300 nits
Contrast
2,000 : 1
Viewing Angle
176(H), 176(V)
Backlight
LED
Backlight MTBF (Hours)
70K
Touchscreen (P-CAP)
Type
5 Wire Resistive Touch Screen
Light Transmission
>80%
Lifetime
10,000,000 times keystrokes

Industrial Modular Touch Panel PC OMNI-5155L
Chapter 2
Chapter 2 –Hardware Information

Chapter 2 –Hardware Information 6
Industrial Touch Panel PC OMNI-5155L
2.1 Dimensions

Chapter 2 –Hardware Information 7
Industrial Touch Panel PC OMNI-5155L
2.2 Motherboard
Please refer to the table below for all of the system’s jumpers from EMB-BT1 that you
can configure for your application
Label
Function
1
12VDC connector (4-pin EATX_PWR1)
2
USB 2.0 connector
3
CPU
4
SO-DIMM memory slots
5
Standby Power LED (SB_PWR_LED1, SB_PWR_LED2)
6
Chassis fan connectors (4-pin CHA_FAN)
7
COM1 Ring/+5V/+12V selection (6-pin J1)

Chapter 2 –Hardware Information 8
Industrial Touch Panel PC OMNI-5155L
8
SATA power connector (SATA_PWR1)
9
Minicard connectors (MINI_CARD1, MINI_CARD2)
10
Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1, SATA6G_2)
11
Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1, SATA3G_2)
12
Digital I/O connector (DIO1)
13
System panel connector (10-1 pin F_PANEL)
14
Clear RTC RAM (CLRTC)
15
Serial port connectors (10-1 pin COM1, COM3~6)
16
PS/2 keyboard and mouse connector (KBMS1)
17
LPT connector (26-1 pin LPT1)
18
Backlight inverter power connector (5-pin INV1)
19
LVDS panel voltage selection (3-pin J4)
20
LVDS connector (30-pin LVDS1)
21
Inverter backlight control of inverter selector (3-pin J3)
22
Front panel audio connector (10-1 pin AAFP)
23
Inverter voltage selection (3-pin J2)
24
BIOS programmable connector (8-pin SPI)
