Dear Customer,
We thank you for selecting our products and are pleased
to count you amongst our very valued customers at ABB.
We trust that the use of the MegaFlex 1000 to 1600
Uninterruptible Power Supply System, developed and
produced to the highest standards of quality, will give
you complete satisfaction.
Please read carefully the Installation Guide
, which
contains all the necessary information and describes all
you need to know about the installation of the UPS.
Thank you for choosing
ABB
!
Start-up and commissioning!
An ABB Global Services Field Engineer must perform start-up and commissioningof the UPS.
Please contact ABB Service Center at least two weeks prior to schedule start-
up and
commissioning at 1-800-292-3739.
Distributed in the USA by ABB Service Center
ABB Power Protection SA
Via Luserte Sud 9
CH – 6572 Quartino
Switzerland
ABB
Smart Power - Power Protection
5900 Eastport Blvd.
Richmond, VA 23231-4453
Phone: [phone]
http://new.abb.com/ups
To get important information on all
equipment warranties, please
contact the ABB Service Center or
request service follow-up or by
scanning the QR code.
http://new.abb.com/ups/service-ups

4
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
Preface
Congratulations on your choice of a MegaFlex 1000to 1600 Uninterruptible Power Supply (UPS).
It will keep youaway from any trouble due to unexpected power problems.
This Installation Guide describes how to prepare the installation site, and it provides weight and dimensions
and procedures for moving, installing and connecting the UPS.
Please refer to the accompanying User Manual, which describes the function of the UPS module, the purpose
and location of the switches, the meaning of the system events related to the front panel indication and
provides proceduresfor starting and stoppingthe equipment.
While every care has been taken to ensure the completeness and accuracy of this manual, ABB assumes no
responsibility or liability for any losses or damages resulting from the use of the information contained in this
document.
Note!
MegaFlex 1000 to 1600 is a Category C3 UPSProduct (according to IEC 62040-2).
This is a product for commercial and industrial application in the second environment
−
installation restrictions or additional measures may be needed to preventdisturbances.
We recommend that thismanual be kept next to the UPS for future references.
If any problems are encountered with the procedures contained in this manual, please contact your ABB
Service Center before you proceed.
This document shall not be copied or reproduced without the permission of ABB.
Due to technical improvements, some of the information contained in this manual may be changed without
notice.
Safety instructions
Carefully read the safety instructions contained on the following page before the installation, start-up and
maintenance of the UPS, options and Battery.
Pay attention to the rectangular boxes included in the text:
They contain important information and warningconcerning electricalconnections and personnel safety.
Parallel System securedwith“RPA – Redundant Parallel Architecture”
When included in the
text, this symbol refers to operation needed only for the RPA
Parallel System.

5
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
Table of content Page
1Safety rules ....................................................................................................................................................................6
1.1 Safety symbols and warnings...............................................................................................................................................8
1.2 Cyber security..........................................................................................................................................................................9
2Layout...........................................................................................................................................................................10
2.1 Layout MegaFlex 1000 to1600...........................................................................................................................................10
3Environment.................................................................................................................................................................12
3.1 Recyclinginstructions..........................................................................................................................................................12
4Installation ...................................................................................................................................................................13
4.1 Transport...............................................................................................................................................................................13
4.1.1 Dimensions and weights MegaFlex 1000 to 1600................................................................................................................14
4.2 Delivery...................................................................................................................................................................................15
4.3 Storage...................................................................................................................................................................................15
4.3.1 Storage of the UPS...................................................................................................................................................................... 15
4.3.2 Storage of Battery....................................................................................................................................................................... 15
4.4 Place of installation..............................................................................................................................................................16
4.4.1 UPS location.................................................................................................................................................................................. 16
4.4.2 Later commissioning.................................................................................................................................................................. 16
4.4.3 Altitude...........................................................................................................................................................................................16
4.4.4 Positioning of the UPS................................................................................................................................................................16
4.4.5 Standing floor................................................................................................................................................................................17
4.4.6 Battery location............................................................................................................................................................................ 19
4.5 Ventilation and cooling........................................................................................................................................................20
4.6 Unpacking..............................................................................................................................................................................21
4.7 Inter cabinet connections....................................................................................................................................................23
4.7.1 Cabinets positioning and interconnection for electrical safety grounding...................................................................24
4.7.2 Bus bars interconnection...........................................................................................................................................................25
4.7.3 Control cables interconnection................................................................................................................................................26
4.7.4 Lower closures with air inlet grids assembling .................................................................................................................... 27
4.8 Electricalwiring.....................................................................................................................................................................28
4.8.1 Utility input connection..............................................................................................................................................................28
4.8.2 Input/output over current protection and wire sizing .......................................................................................................29
4.8.3 Battery connection......................................................................................................................................................................29
4.8.4 Input grounding systems...........................................................................................................................................................29
4.8.5 Data for Input/Output and Battery over current protection and wire sizing................................................................30
4.8.6 Installation requirements ..........................................................................................................................................................32
4.9 Wiring connection.................................................................................................................................................................33
4.9.1 MegaFlex 1000 to 1600 - Power connection with Common Input Utility........................................................................35
4.9.2 MegaFlex 1000 to 1600 - Power connection with Dual Input Utility ................................................................................36
4.9.3 Use of MegaFlex 1000 to 1600 in eBoost™ Operation Mode ............................................................................................37
4.9.4 Use of MegaFlex 1000 to 1600 as Frequency Converter.....................................................................................................38
4.10 RPA Parallel System connection..........................................................................................................................................39
4.10.1 Power wiring of Parallel Units...................................................................................................................................................39
4.10.2 Parallel Control Bus connection................................................................................................................................................40
4.10.3 Control Bus cable location.........................................................................................................................................................42
4.11 XA terminal Block................................................................................................................................................................. 44
4.11.1 XA Terminal block - UVR Command Contact.........................................................................................................................44
4.11.2 XA Terminal block – Q1 Auxiliary Contact...............................................................................................................................44
4.11.3 XA Terminal block – 24 Vdc Power Supply..............................................................................................................................44
4.11.4 “EPO - Emergency Power OFF” command connection........................................................................................................45
5Connectivity interface................................................................................................................................................47
5.1 Serial port J35µP - RS232 (Sub D, Female 9 pin) .............................................................................................................. 48
5.2 Customer interface board.................................................................................................................................................. 49
5.2.1 Connector J1 – RJ45 8P8C..........................................................................................................................................................50
5.2.2 X1 terminal block - Output signals on voltage-free contacts ............................................................................................50
5.2.3 X1 terminal block - Programmable input free contacts ......................................................................................................50
5.2.4 X2 terminal block – “EPO - Emergency Power Off”............................................................................................................... 51
5.2.5 X1 terminal block - Gen Set Signaling (GEN ON)................................................................................................................... 51
5.2.6 X1 terminal block - AUX External Maintenance Bypass .......................................................................................................52
5.2.7 X1 terminal block – eBoost control signal..............................................................................................................................52
6Notes.............................................................................................................................................................................53
6.1 Notes Form............................................................................................................................................................................53

6
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
1Safety rules
Save these instructions!
This manual contains important instructions for models MegaFlex 1000 to 1600 that should be followed during
installation and maintenance of the UPS and Battery.
General
- Movethe UPSin an upright position in its original package to thefinal destination room.
To lift thecabinets, usea forklift or lifting belts with spreader bars.
- Check for sufficient floor and elevator loading capacity.
- Check the integrity of theUPS equipment carefully.
If you notice visible damage,do not installor start theUPS.
Contact your ABB Service Center immediately.
- WARNING! RISK OF ELECTRICAL SHOCK!
Do not remove covers, there are no user serviceable parts inside.
- After switching off takes 5 minutes for the DC capacitors to discharge because a lethally high voltage remains
at the terminals of the electrolytic capacitors.
- UPS’s and Batterysystem requirea 12 months periodic maintenance to operate reliably and safely.
This should be performed by qualifiedservice personnel. TheUPS contains its own energysource (Battery).
- The field-wiring outlets may be electrically live, even when theUPS is disconnected from the Utility.
- Dangerous voltages may be present during Battery operation.
- The Battery must be disconnected during maintenance or service work.
- This UPS contains potentially hazardous voltages.
- Be aware that theInvertercan restart automatically after the Utility voltage is restored.
- End user must follow applicable regional occupational safety codes/regulations during installation, operation
and equipment maintenance. This may require additional field marking or labelling defining appropriate level
of PPE (Personal Protection Equipment) to reducetherisk ofArc-flashrelated injuries.
Contact our ABB Service Centerfor productspecific information.
Installation
- This UPS must be installed and connected only by trained personnel.
- Verify accurately during Commissioning and Maintenance of theUPS, for thefollowing:
Damagedcomponents, squeezed wires and cables, or not correctly insertedplugs.
- After removingthe sidewalls of the UPS, makesure that all earth connections when reassembling, are correctly
reattached.
- This UPS is intended for use in a controlled indoor environment free of conductive contaminants and
protected against animals intrusion.
- WARNING! HIGH LEAKAGE CURRENT TOGROUND:
Groundconnection is essential beforeconnecting to AC input!
- Switching OFFthe Unit does not isolatethe UPS fromthe Utility.
- Do not install theUPS in an excessivelyhumid environment ornear water.
- Avoidspillingliquids on or dropping any foreign object into theUPS.
- The Unit must be placed in a sufficiently ventilated area; the ambient temperature should not exceed 104°F
(40°C).
- Optimal Battery life is obtained if theambient temperature does not exceed 77°F (25°C).
- It is important that air can move freely around and throughthe Unit. Do not block the air vents.
- Avoidlocations in directsunlight or near heat sources.
Storage
- Storethe UPSin a dry location;storage temperaturemust bewithin -13°F(-25°C) to131°F(+55°C).
- The optimal temperature for Battery storage is 68°F (20°C) to77°F (25°C) and shall never exceedthe range -4°F
(-20°C) to 104°F (40°C).
- If the Unit is stored for a period exceeding 3 months, the Battery must be recharged periodically (time
depending on storage temperature).
Battery
- The Battery-voltageis dangerous for person’s safety.
- When replacing theBattery,usethe same number, voltage(V) andcapacity (Ah).
- Proper disposal or recycling of the Battery is required.
Refer toyour local codes for disposal requirements.
- Never dispose of Battery in afire: they may explode.
- Do not open or mutilateBattery:their contents (electrolyte) may beextremelytoxic.
If exposedto electrolyte, wash immediately with plenty of water.
- Avoid charging in a sealed container.
- Never short-circuit theBatteries.
When working with Batteries, removewatches, rings or other metal objects andonly use insulated tools.
- In caseof air shipment, thecables+/- going to the Battery fuses/terminals shall bedisconnected and isolated.

7/54
MegaFlex 1000 to 1600 UPS Installation Guide / REV-A
Safety instructions when working with Battery
Danger!
External Battery must be installed and connected to the UPS by Qualified Service Personnel.
Installation Personnel must read this entire section before handling the UPS and Battery.
Full voltage and current are always present at the Battery terminals.
The Battery used in this system can provide dangerous voltages, extremely high currents and a risk of electric
shock.
If the terminals are shorted together or to ground they may cause severe injury.
You must be extremely careful to avoid electric shock and burns caused by contacting Battery terminals or
shorting terminals during Battery installation.
Do not touch uninsulated Battery terminals.
A qualified service person, who is familiar with Battery systems and required precautions, must install and service
the Battery.
The installation must conform to national and local codes.
Keep unauthorized personnel away from the Battery.
The qualified service person must take these precautions:
1Wear protective clothing, such as rubber gloves and boots and protective eye wear.
Battery contain caustic acids and toxic materials and can rupture or leak if mistreated.
Remove rings and metal wristwatches or other metal objects and jewellery.
Do not carry metal objects in your pockets where the objects can fall into the Battery cabinet.
High energy through conductive materials could cause severe burns.
2Tools must have insulated handles and must be insulated so that they will not short Battery terminals.
Do not allow a tool to short between individual or separate Battery terminals or to the cabinet or rack.
Do not lay tools or metal parts on top of the Battery and do not lay them where they could fall onto the
Battery or into the cabinet.
3Disconnect charging source prior to connecting or disconnecting Battery terminals.
Install the Battery as shown on the drawing provided with the Battery.
When connecting cables, never allow a cable to short across a Battery’s terminals, the string of Battery, or to
the cabinet or rack.
4Align the cables on the Battery terminals so that the cable lug will not contact any part of the cabinet or rack,
even if the Battery is moved.
Keep the cable away from any sharp metal edges.
5Install the Battery cables in such a way that the UPS or Battery cabinet doors cannot pinch them.
6Do not connect the Battery terminal to Ground.
If any Battery terminal is inadvertently grounded, remove the source of the ground.
Contacting any part of a grounded Battery can cause a risk of electric shock.
7Determine if Battery is inadvertently grounded. If inadvertently grounded, remove source from ground.
Contact with any part of a grounded Battery can result in electrical shock.
The likelihood of such shock can be reduced if such grounds are removed during installation and
maintenance.
8To reduce the risk of fire or electric shock, install the Battery in a temperature and humidity controlled
indoor area, free of contaminants.
9Battery system chassis ground (earth) must be connected to the UPS chassis ground (earth).
If you use conduits, this ground conductor must be routed in the same conduit as the Battery conductors.
10 Where conductors may be exposed to physical damage, protect the conductors in accordance with all
applicable codes.
11 If you are replacing the Battery or repairing Battery connections, shut OFF the UPS and remove the Battery
fuses.

8
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
1.1 Safety symbols and warnings
Safety warnings
The text of this manual contains some warnings to avoid risk to the persons and to avoid damages to the UPS
system and the supplied critical loads.
The non-observance of the warnings reminding hazardous situations could result in human injury and equipment
damages.
Please payattention to the meaning of thefollowingwarnings and symbols.
Throughout this manual the following symbols are defined:
Warning,if instruction is notfollowed injury or serious equipment damage may occur!
Caution, internal parts have dangerous voltage present.
Risk of electric shock!
PE (Earth) – GND (Ground)
Protective Grounding terminal:
A terminal which must be connected to earth ground prior to making any other connection to
the equipment.
A terminal to
which or from which an alternating (sine wave) current or voltage may be applied
or supplied.
A terminal to which orfrom which a direct current or voltage may be applied or supplied.
This symbol indicated theword “phase”.
This symbol indicates the principal ON/OFF switch in the on position.
This symbol indicates the principal ON/OFF switch in the off position.

9
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
1.2 Cyber security
UPS mustbe protectedin a Security Restricted Area.
UPS mustbe installed in a location/roomwith mechanical lock.
Limit access to authorized personnel only and it shall stay under Authorized Personnel Operator to
manage the accesses.
The UPS products are designed to be connected and to communicate
information and data via a
network interface through the optional SNMPcard, which should be connected toa secure network.
It is customer sole responsibility to provide and continuously ensure a secure connection between
the product and customer network o
r any other network and to establish and maintain appropriate
measures (such as but not limited to the installation of firewalls, application of authentication
measures, encryption of data, installation of antivirus programs, etc.) to protect the UPS produ
ct,
the network, its system and interfaces against any kind of security breaches, unauthorized access,
interference, intrusion, leakage and/or theft of data or information.
ABB Ltd and its affiliates are not liable for damages and/or losses related to su
ch security
breaches, unauthorized access, interference, intrusion, leakage and/or theft of data or information.
Although ABB provides functionality testing on the products and updates that we release, you
should institute your own testing program for any
product updates or other major system updates
(to include but not limited to code changes, configuration file changes, third party software
updates or patches, hardware change out, etc.) to ensure that the security measures that you have
implemented have n
ot been compromised and system functionality in your environment is as
expected
.

10
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
2Layout
2.1 Layout MegaFlex 1000 to 1600
Fig. 2.1
-
1
MegaFlex
1000 to 1600
-
General view
Fig. 2.1
-
3 Control Panel
Fig. 2.1-4
Connectivity Rack
Fig. 2.1
-
2
MegaFlex
1000 to 1600
-
General view with open doors
MGF_UL_1000-1600_UPS_ABB_02
SNMP
CI
J35DSP
1 2
MGF_UL_1000-1600_Connectivityinterface_01
EPO
EPO
+-Q1UVR
J35µPXA
MGF_UL_1000-1600_S1_UPS_04
12
XA
RPA
J35P
SNMP
CR
CI
J35DSP
EPO
EPO
+-Q1UVR

11
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
Fig. 2.1-5 MegaFlex 1000 to 1600 - General view without protection panels
1Opening for top cable entry (please remove the plate before drilling any holes)
2Opening for bottom cableentry (please removethe plate beforedrilling any holes)
3Bus barsfor Utility input connection
4Bus barsfor Load outputconnection
5Bus barsfor External Battery connection
CI Customer Interface Board (see Fig. 2.1-4)
CR ConnectivityRack
J35DSP Serial portRS232 (only forABB Service Center)
J35µPSerial port RS232 for IMV protocol
RPA RPA board (Redundant Parallel Architecture)for Parallel System(option -see Fig.2.1-2)
SNMP 3-ph SNMP/WEB plug-in adapter (option- seeFig. 2.1-4)
XA
Terminal
block
(see Section 4.11)
Caution!
Convenience testterminalsare availablefor ABB Service Technician only.
Unauthorized access to test terminals exposes to electric shock hazard risk and
increases risk of
UPS failure.
MGF_UL_1000-1600_UPS_ABB_05
4
5
3
2
1

12
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
3Environment
3.1 Recycling instructions
Note!
This product has been designed to respect the environment, using materials and components
respecting eco-design rules.
It does not contain CFCs (Carbon Fluor Clorid) or HCFCs (Halogen Carbon Fluor Clorid).
Packing material recycling!
ABB, in compliance with environment protection, uses only environmentally friendly material
at
the end of its service life, must be recovered conforming to the local applicable regulations.
UPS packing materials must be recycled in compliance with all applicable regulations.
Recyclingat the end of service life!
ABB, in compliance with environment protection recommends to the User
that the UPS
equipment, at the end of its service life, must be recovered conforming to the local applicable
regulations.
Battery disposal!
Leads contained in the B
atteries is a dangerous substance for the environment, therefore it
must be correctly recycledby specialized companies.

13
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
4Installation
4.1 Transport
The UPSis packagedon a pallet suitable for handling with aforklift.
The UPS must be moved in upright position.
Do not tilt cabinets more than +/- 10° duringhandling.
Move the UPS in its original package to the finaldestination site.
Do not stack other packages on top
:This could damage the
UPS.
Forklift
Fig. 4.1-1 Position of the forklift when moving the unpacked UPS
Forklift
The UPS must be lifted with a forklift in upright
position.
Take note of the
Center of Gravity
marked on the
package
.
Warning!
Check for
sufficient floor and elevator loading
capacity.
Transport UPS only in upright position.
Do not stack other package on top of the UPS.
Crane
Fig. 4.1
-
2 Position of the carrying belts when moving the unpacked UPS
Crane
If the UPS has to
be lifted by crane, use suitable
carrying belts taking note of the Center of Gravity
marked on the package.
Take all necessary precautions to avoid damage
to the cabinet while hoisting the UPS
.
Warning!
When loading / unloading and when moving
the UPS, it is forbidden:
When loading / unloading and when moving
the UPS, pay attention to:

14
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
4.1.1 Dimensions and weights MegaFlex 1000 to 1600
Fig. 4.1.1
-
1
MegaFlex
1000 to 1600
–
UPS dimensions
Dimensions (Wx D x H): 129.92 x39.37 x86.62inches /3300 x1000*x 2200mm
*) For seismic installations allow additional 3” (76 mm) spacing at rear of the
UPS to accommodate anchoring when placing against the wall!
Weight:
MegaFlex
1000
–
1100
–
1200
UPS complete:
9150
lbs
4150
kg
Power Section cabinet: 4564 lbs 2070 kg
In/Out Section cabinet:
4586
lbs
2080
kg
MegaFlex
1500 & 1600
UPS complete:
10274
lbs
4660
kg
Power Section cabinet:
5424
lbs
2460
kg
In/Out Section cabinet: 4850 lbs 2200 kg
Floor loading (UPS complete):
MegaFlex
1000
–
1100
–
1200
MegaFlex
1500 & 1600
265 lbs/sq.ft / 1294 kg/m
2
315 lbs/sq.ft / 1538 kg/m
2
Note!
The weight of each single piece ismarked outside the package!
MGF_UL_1000-1600_UPSdimensions_01
62.99"
1600 mm
86.62"
2200mm
129.92"
3300mm
66.93"
1700 mm
PowerSectioncabinetIn/OutSectioncabinet
39.37"
1000mm

15
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
4.2 Delivery
When delivered, inspect the package integrity and the physicalconditions of the cabinets carefully.
In case of any damage sustained during transport, immediately inform the carrier and contact your local ABB
Service Center.
Adetailed report of thedamageis necessary for anyinsurance claim.
Note!
A damaged UPS must never be installed or connected to Utilityor Battery!
4.3 Storage
4.3.1 Storage of the UPS
The equipment is carefully packed for transport and storage so that it is in a
perfect condition when eventually installed.
Never leave an UPS outside the building and do not store the UPS one on top of
theother.
It is advisable to store the UPS in its original package in a dry, dust-free room, away from chemical substances,
and with a temperature range not exceeding -13°F (-25°C) to 131°F (55°C).
In casethe Battery is included please refer to Section 4.3.2.
Some important functions of the UPS, such as the customized functions, are defined by parameters stored in a
RAM memory.
A small backup Battery located on the Control Unit board suppliesthe RAM.
If the storage time of the UPS exceeds 1 year, these functions should be verified by an authorized Service Center
before putting the UPS into operation.
4.3.2 Storage of Battery
When the delivery includes a maintenance free Battery, keep in mind that they are subject to self-discharge and
therefore you must rechargethe Battery.
The storage timewithout Battery recharge depends on the temperature of the storagesite.
The optimal room temperature for Battery storage is 68°F (20°C) to 77°F (25°C) and shall never exceed the range
-4°F (-20°C)to 104°F (40°C).
Recharge storedmaintenance free Battery every:
6 monthswhen the storage temperature is 68°F(20°C)
3 monthswhen the storage temperature is 86°F (30°C)
2 monthswhen the storage temperature is 95°F (35°C)

16
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
4.4 Place of installation
4.4.1 UPS location
Note!
UPS installation and connectionmust be performed only by an ABB Service Technician!
If optional cabinets and accessories are included with the UPS, please refer to those accompanying
manualsfor installation andoperating instructions.
The UPS is intended for use in electrical rooms.
Do not locate or stockeasily flammable materials in the same room as the UPS.
It is important to have a clean, dust-free environment provided with proper ventilation and air-conditioning to
keep the ambient temperature within the specified operating range.
The recommendedair inlet temperature is from 68°F (20°C) to 77°F (25°C) (max. 104°F / 40°C).
Refer to Section 4.5.
Check for sufficient floor load capacity before installing theUPS andthe Battery.
Refer to Section 4.1.1.
For Battery installation follow the localcodes and the recommendationof the Battery supplier.
Note!
Operationat temperatures higher than 77°F (25°C)will reduce Battery life.
Potential consequences are explained in the User
Manual to Section 9.1.4: read and understand
them.
The MegaFlex 1000to 1600 UPS can radiate radio frequencyenergy.
Although some RFI (Radio Frequency Interference) filtering is inherent to the UPS there is no guarantee that the
UPS will not influence sensitivedevices such ascameras andmonitors that are positioned closeby.
If interference is expected, the UPSshould be moved away from the sensitive equipment.
4.4.2 Later commissioning
It’s not recommended to unpack UPS until commissioning can be performed. In any case, care must be taken to
prevent foreign object to fall into UPS openings (e.g. debris due to construction works or fasteners). Do not
perform construction work over the UPS cabinet.
4.4.3 Altitude
Maximum altitudeof installation without derating is 3300 ft(1000m).
4.4.4 Positioning of the UPS
Fig. 4.4.
4
-
1
MegaFlex
1000 to 1600
–
Positioning of the UPS
The rear panel of the UPS may be mounted flush to a wall or
other structure.
Clearance around the front of the unit should be sufficient
to enable free passage of personnel with the doors fully
open, andto allowsufficient airflowto the door vents.
Check Section 110-
26(A) of the NEC code for specific
requirements.
To guarantee proper cooling air exhaust, the
mandatory
minimum clearance between ceiling and top of the UPS is
18” (460 mm).
A single-phase power outlet (120Vac) should be provided
near the UPS for connection of power tools, test
equipment orconnectivity devices.
This outlet must be grounded.
Min.
18" / 460mm
MGF_UL_1000-1600_S1_UPSdisposition_01

17
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
4.4.5 Standing floor
Make surestanding floor (especially in caseof raised floor) has sufficient weight loading capability to tolerate the
UPS and extra weight that might occur from time to time.
The UPSmust be installedon concrete or another non-combustible surface.
MegaFlex 1000 to 1600 Opening for input andoutput cable connections
Fig. 4.4.
5
-
1
MegaFlex 1000 to 1600
–
Opening on top of the cabinet for input and output cables connections
Fig. 4.4.5
-
2
MegaFlex 1000 to 1600
–
Opening on bottom of the cabinet for input & output cables connections
MegaFlex 1000 to 1600 openings are provided on the top (*) and the bottom (*) of the UPS cabinet
for the
connection of input andoutput cables.
Pay attention to the position of these openings, when choosing the placement of theUPS.
Theseopenings are covered with a protective plate.
*
)
Please remove theplate beforedrilling anyholes
(see Fig. 4.9
-
2).
MGF_UL_1000-1600_S1_UPS view top_01US
Frontal side
Power Section cabinet In/Out Section cabinet
35.63 " / 905 mm
39.37 " / 1000 mm
107.44" / 2729mm
129.92 " / 3300 mm
1.26 " / 32 mm
21.22 " / 539 mm
1.04 "
26.5 mm
2.70 "
68.5 mm
Opening on top
for input & output
cables connections
Opening on top
for input & output
cables connections
MGF_UL_1000-1600_S1_UPS view bottom_01US
Frontal side
Power Section cabinet In/Out Section cabinet
33.15 " / 842 mm
39.37 " / 1000 mm
108.11 " / 2746mm
129.92 " / 3300 mm
1.97 " / 50 mm
19.84 " / 504 mm
2.72 "
69 mm
3.50 "
89 mm
Opening on bottom
for input & output
cables connections

18
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
Fixing of the UPScabinet
MegaFlex 1000 to
1
6
00
on the floor
The UPScabinet is freestandingandnormally does not require to be boltedto thefloor.
The UPScabinet can befixedhowever to thefloor bybolting it with the supporting blocks to the floor.
Fig. 4.4.5.3 MegaFlex 1000 to 1600
–
Fixing of the UPS cabinet on the floor
Fig. 4.4.5.4 MegaFlex 1000 to 1600 – UPS cabinet floor fixing points
MGF_UL_1000-1600_S1_UPSfixing_01
A
Detail A
MGF_UL_1000-1600_S1_UPSfixing_02US
Power Section cabinet
Frontal side
Seismic installations (option)
1.69"
43mm
Ø0.55"
14mm
2.57" /65.5mm 14.37" / 365mm 29.13" / 740mm 14.37" / 365mm
5.00" / 127mm
19.72" / 501mm 21.30" / 541mm
2.59"/ 65mm
2.76" / 70.5mm18.11" / 460mm
36.77" / 934mm
39.37" /1000mm
0.91"
23mm
1.65" / 42mm
1.65" / 42mm
Holes
16.73"/ 425mm
3.35"
85mm
16.73" / 425mm
2.59"
65mm
39.37" /1000mm
8.80"
223.5mm 23.67" 601mm
1.28" / 32.5mm
129.92"/ 3300mm
4.17"
106mm 5.43"
138mm 5.43" 138mm 9.33"
237mm 9.69" 246mm 14.68" 373mm 17.36"
441mm
4.65"
118mm 14.80"
376mm
5.43"
138mm 0.55" / 14mm
4.65"
118mm
129.92"/ 3300mm
1.69"
43mm
0.98"
25mm
Ø0.55"/14mm
Detail hole

19
/
54
MegaFlex 1000 to
1600
UPS Installation Guide
/ REV
-
A
Fig. 4.4.5-5 MegaFlex 1000 to 1600 – RPA Parallel System disposition
In case of Parallel System, try to place the UPS modules in sequence of their numbers (marked
on the packing).
If the units are positioned “side by side”, the side panels must bemounted on allunits.
Remove the side air inlet grids on the intermediate units to run the control bus cable
connections.
4.4.6 Battery location
Batteries require a well-ventilatedroom with controlled temperature to obtain reliable operation.
The Battery canbe installed immediately adjacent to the UPS (left or right side) or remotely from theUPS.
If the Battery is installed remotely from the UPS, a wall mounted DC disconnect device must be installed within
line-of-site to both the UPS andthe Battery.
The optimal room temperature for Batterystorage is 68°F (20°C) to 77°F (25°C) andshall neverexceed the range -
4°F (-20°C) to 104°F (40°C).
The life of valve-regulated Battery will be reduced by 50% for each additional 18°F (10°C) that the Battery ambient
temperature is above 77°F (25°C).
The Battery System associated with larger UPS is usually either rack mounted or installed in multiple Battery
Cabinets.
Installation and assembly must be made according to the local standards and Battery System manufacturer‘s
recommendations.
The Battery Circuit Breaker mustbe mounted asnear as possible to the Battery.
Warning!
Battery installation and connection must be performed by Qualified Personnel only.
Read all safety instructions before proceeding with the installation (see Chapter 1).
Battery discharging and/or charging activities may cause the emission of hydrogen gas; therefo
re,
the room requires proper ventilation and fresh air.
Comply with the UL1778-
CSAC22.2no170.3 UPS safety standard, ANSI/IEEE P1184 Guide for
Batteries for Uninterruptible Power Supply Systems and applicable codes and governmental
regulations.
MGF_UL_1000-1600_S1_RPAdisposition_ABB_01US
UPS 1
UPS
3 - 4- 5 - 6
UPS 2

20/54
MegaFlex 1000 to 1600 UPS Installation Guide / REV-A
4.5 Ventilation and cooling
Fig. 4.5-1 Installation on plain floor Fig. 4.5-2 Installation on raised floor
The heat produced by the UPS is transferred to the environment by its ventilation.
Air inlets for UPS ventilation are located on the front of the UPS, while air outlets are on top of the cabinet.
A suitable ventilation or cooling system must be installed to extract the heat from the UPS room.
Note!
Do not put anything on the top of the cabinet.
18”(460mm) of air clearance from the top must be left free of any object for a sufficient exhausted
air exchange, proper cooling, service access and safety.
Air filtering systems could be required when the UPS operates in a dirty environment.
In order to prevent overheating of the UPS, the available air intake flow rate must exceed the total air exhaust
flow rate requirement of the UPS system.
Contact your ABB Service Center for appropriate solutions.
The below table indicates the heat dissipation at full Load at PF = 1and charged Battery, up to 3280 ft (1000 m)
altitude, for cooling air 77°F (25°C) to 86°F (30°C).
UPS model
Losses Cooling air flow
VFI
eBoost™ (option)
VFI
PF = 1 PF = 1 PF = 1
MegaFlex 1000
145914 BTU/hr 42753 kW 55495 BTU/hr 16260 kW 7339 CFM 12469 m3/h
MegaFlex 1100
156427 BTU/hr 45833 kW 57171 BTU/hr 16751 kW 7868 CFM 13368 m3/h
MegaFlex 1200
166209 BTU/hr 48699 kW 58152 BTU/hr 17039 kW 8360 CFM 14204 m3/h
MegaFlex 1500
202223 BTU/hr 59252 kW 62179 BTU/hr 18219 kW 10172 CFM 17283 m3/h
MegaFlex 1600
209810 BTU/hr 61475 kW 60736 BTU/hr 17796 kW 10553 CFM 17930 m3/h
Note!
Even when eBoost™ Operating Mode option is available,
the ventilation and cooling system shall be
rated as for operation in VFI mode.
Air Intake
MGF_UL_1000-1600_S1_UPS ventilation_Plain floor_01US
Air Extraction
Cables
MGF_UL_1000-1600_S1_UPS ventilation_Raised floor_01US
Air Extraction
Air Intake
