ABB PowerValue 11/31 T Installation and operating instructions

© Copyright 2016 ABB, All rights reserved
User manual addendum
PowerValue 11/31 T
10-20 kVA

Modifications
reserved
Page 2/4
Document information
File name : ADD_ABB_PVA11-31T_10-20kVA_EN_REV-A.docx
UPS model
:
PowerValue 11/31 T 10-20 kVA
Date of issue : 28.04.2016
Article number : N/A
Document number : N/A
Revision : A
Foreword
IMPORTANT
This document is intended to supplement the following user manuals:
•PowerValue 11/31 T 10-20 kVA
version: 4NWP100559R0001_OPM_ABB_PVA31-11-T_10-20kVA_EN_140626
New information include:
•PowerValue 11/31 T 10-20 kVA
version: 4NWP100559R0001_OPM_ABB_PVA31-11-T_10-20kVA_EN_140626
ochapter 6.3.1 addendum (see highlighted in red)
oAppendix A: CS121 SNMP card available parameters
PowerValue 11/31 T 10-20 kVA (version: 4NWP100559R0001_OPM_ABB_PVA31-11-T_10-
20kVA_EN_140626)
Chapter 6.3.1
6.3.1 Installing a Serial Network Management Card (optional)
Each UPS has a communication slot for an optional Serial Network Management (SNMP) Card. After
installing an SNMP card, an environmental monitoring probe can be connected to the UPS.
Note: The UPS does not have to be shutdown before installing a communication card.
To install the Network Management Card, go through the following steps:
1. Remove the two screws that protect the communication slot of the UPS.
2. Insert the SNMP card into the communication slot.
3. Screw the SNMP card onto the slot using the screws removed in step 1.
Compatible SNMP card: CS121 Basic, CS121 ModBus, CS121 Advanced
For more information on the SNMP Cards, see the SNMP User's Manual. For more details about
parameters available when using SNMP card with PowerValue 11/31 T 10-20 kVA, please refer to
Appendix A

Modifications
reserved
Page 3/4
Appendix A
CS121 SNMP card available parameters (valid for CS121 Basic, CS121 ModBus, CS121 Advanced)
The parameters available from CS121 SNMP cards are herein described
Parameter Units Type Available interface Modbus register
Measurement Parameters
Input Voltage per Phase V Input Webserver / Modbus 104, 105, 106
Input Frequency Hz Input Webserver / Modbus 111, 112, 113
Output Voltage per Phase V Output Webserver / Modbus 97, 98, 99
Output Current per Phase A Output Webserver / Modbus 143, 144, 145
Output Load in Percentages % Output Webserver / Modbus 100, 101, 102
Output Frequency Hz Output Modbus 168
Total Output Power kW Output Webserver / Modbus 160, 161, 162
Battery Voltage V Battery Webserver / Modbus 110
Estimated Runtime min Battery Webserver / Modbus 108
Temperature °C Environmental Webserver / Modbus 107
UPS Status Information
On shutdown Webserver / Modbus 109
On inverter Webserver / Modbus 109
On battery Webserver / Modbus 109
UPS Alarms
Battery Low Webserver / Modbus 117
Input Bad Webserver / Modbus 120
On Bypass Webserver / Modbus 123
General Fault Webserver / Modbus 132
Test In Progress Webserver / Modbus 138
Shutdown imminent Webserver / Modbus 137
Diagnose test failed Webserver / Modbus 133

Contact us
www.abb.com/ups
[e-mail]
© Copyright ABB. All rights reserved. Specification
subjects to change without notice.
