© Copyright 2017 ABB, All rights reserved
Operating manual
PowerValue 11/31 T
10 kVA, 10 kVA B, 10 kVA B2, 10 kVA S
20 kVA, 20 kVA B, 20 kVA S

Modifications reserved
Page 3/49
Document information
File name : 4NWP100559R0001_OPM_ABB_PVA11-31-T_10-20kVA_EN_REV-C.docx
UPS model
:
PowerValue 11/31 T
Date of issue : 01.12.2016
Article number : 4NWP100559R0001
Document number : 4NWD003235
Revision : C
Foreword
The UPS system operates with mains, battery or bypass power. It contains components that carry high
currents and voltages. The properly installed UPS system is grounded to earth and IP 20 rated against
electrical shock and foreign objects.
This user manual contains guidelines to check delivery, installing and commissioning of the UPS and is
intended for people who plan the installation, install, commission and use or service the UPS. The reader
is expected to know the fundamentals of electricity, wiring, electrical components and electrical
schematic symbols.
COMMISSIONING AND OPERATIONS INSIDE THE UPS
MUST BE PERFORMED BY A CERTIFIED SERVICE
ENGINEER FROM THE MANUFACTURER OR FROM AN
AGENT CERTIFIED BY THE MANUFACTURER.
BY NOT FULFILLING THIS OBLIGATION, THE
PRODUCT MAY LOSE ITS WARRANTY
Read carefully all instructions and save this manual for future reference.

Modifications reserved
Page 4/49
Symbols
The following symbols are used in this manual, the list below describes each symbol.
WARNING SEVERE INJURY AND/OR SERIOUS DAMAGE TO THE SYSTEM WILL
RESULT IF PROPER PRECAUTIONS ARE NOT TAKEN
CAUTION MINOR INJURY AND/OR DAMAGE TO THE PRODUCT MAY RESULT IF
PROPER PREACAUTIONS ARE NOT TAKEN
NOTE REFER TO THE USER MANUAL TO AVOID PROPERTY DAMAGE
SAFETY WARNING: THIS SYMBOL IS USED TO WARN THE USER ABOUT
WARNINGS, CAUTIONS AND NOTES
DANGER: THIS SYMBOL IS USED IN THE OCCURRENCE OF ELECTRICAL
LIVE PARTS WITH HAZARDOUS VOLTAGE
PROTECTIVE GROUNDING TERMINAL: A terminal which must be connected
to earth ground prior to making any other connection to the equipment
A terminal to which or from which an alternating current or voltage (AC) may be
applied or supplied
A terminal to which or from which a direct current or voltage (DC) may be applied
or supplied
Battery
Power On, Idle or shutdown the UPS
Overload indication
Recycle
Do not dispose with ordinary trash

Modifications reserved
Page 5/49
Contents
1Safety instructions ................................................................................. 7
1.1 Operator precautions ......................................................................................7
1.2 Environmental Considerations........................................................................ 8
1.3 Declaration of Safety conformity and CE marking.........................................8
1.4 Inquiries ...........................................................................................................8
1.5 Operation .........................................................................................................9
2Maintenance ........................................................................................ 11
2.1 Battery Recycling .......................................................................................... 13
3General Characteristics ....................................................................... 14
3.1UPS front view............................................................................................... 14
3.2 UPS rear view ................................................................................................ 14
3.3 External battery cabinet front view............................................................... 15
3.4 External battery cabinet rear view ................................................................ 15
4Installation............................................................................................ 16
4.1 Delivery, Transportation, Positioning and Storage ...................................... 16
4.1.1 Receipt of the UPS and visual inspection ...............................................................16
4.1.2 Unpacking .................................................................................................................16
4.1.3 UPS storage ..............................................................................................................17
4.1.4 Planning before the installation................................................................................17
4.2 Electrical Installation ..................................................................................... 18
4.2.1 Commissioning .........................................................................................................18
4.2.2 Connections ..............................................................................................................18
4.2.2.1 Procedure .................................................................................................19
4.2.2.2 Parallel system cabling ..............................................................................23
4.3 Batteries......................................................................................................... 25
4.3.1 In-built batteries........................................................................................................25
4.3.2 External battery cabinets .........................................................................................25
4.4 Backfeed Protection...................................................................................... 26
4.5 Emergency Power Off (EPO) ......................................................................... 27
4.6 Installation Checklist ..................................................................................... 27

Modifications reserved
Page 6/49
5Operation .............................................................................................28
5.1 Control Panel .................................................................................................28
5.1.1 LEDs.......................................................................................................................... 28
5.1.2 Selection Keys.......................................................................................................... 29
5.1.3 LCD Display .............................................................................................................. 29
5.2 Operating Mode .............................................................................................30
5.3 UPS Start-up and Shutdown .........................................................................31
5.3.1 UPS start-up............................................................................................................. 31
5.3.2 UPS Shutdown ......................................................................................................... 32
5.3.3 Parallel UPS system................................................................................................. 32
5.4 UPS Operation ...............................................................................................34
5.4.1 Changing the operating-mode ................................................................................ 34
5.4.2 Navigation................................................................................................................. 34
5.4.2.1 Event log .................................................................................................. 35
5.4.2.2 Measurements ......................................................................................... 35
5.4.2.3 Control ..................................................................................................... 35
5.4.2.4 Identification ............................................................................................. 36
5.4.2.5 User’s Settings......................................................................................... 36
6Communication.................................................................................... 39
6.1 RS-232 port....................................................................................................39
6.2 USB port.........................................................................................................40
6.3 Network Management Card (Optional) .........................................................40
6.3.1 Installing a Serial Network Management Card (optional) ...................................... 40
6.3.2 AS400 Dry Contact card .......................................................................................... 41
6.3.3 Monitoring Software................................................................................................. 41
7Troubleshooting ...................................................................................42
7.1 Fault identification and rectification..............................................................42
7.1.1 Troubleshooting without an error message............................................................ 42
7.1.2 Troubleshooting based on error message.............................................................. 42
8Appendix A........................................................................................... 44
9Appendix B...........................................................................................45
10 Appendix C ..........................................................................................46

Modifications reserved
Page 7/49
1Safety instructions
1.1 Operator precautions
The user must follow the precautions and only perform the described operations. Also in these
measures, the operator of the UPS System must adhere to the instructions in this manual. Any
deviations from the instructions could be dangerous to the user or cause accidental load loss.
The only user operations permitted are:
•Use of the LCD control panel (LCD Display) and Maintenance Bypass (if present)
•Start up and shut down of the UPS (excluding the commissioning start up)
•Operation of additional connectivity devices
THE SUPPLIER DOES NOT TAKE ANY RESPONSIBILITY FOR DAMAGES CAUSED THROUGH
WRONG MANIPULATIONS OF THE UPS SYSTEM
DANGER!
WARNING!
DO NOT REMOVE ANY SCREWS FROM THE UPS SYSTEM OR FROM THE
BATTERY CABINET: DANGER OF ELECTRICAL SHOCK.
DANGER!
WARNING!
HIGH FAULT CURRENTS (LEAKAGE CURRENTS):
BEFORE CONNECTING THE MAINS YOU MUST ENSURE THAT THERE IS
A PROPER EARTH CONNECTION!
DANGER!
WARNING!
THE USER MUST DISPLAY A WARNING LABEL ON ALL PRIMARY POWER
ISOLATORS INSTALLED REMOTE FROM THE UPS AREA TO WARN
ELECTRICAL MAINTENANCE PERSONNEL THAT THE CIRCUIT FEEDS A
UPS. THE WARNING LABELS MUST CONTAIN THE FOLLOWING
WORDING OR EQUIVALENT: “ISOLATE UNINTERRUPTIBLE POWER
SUPPLY (UPS) BEFORE WORKING ON THIS CIRCUIT”

Modifications reserved
Page 8/49
1.2 Environmental Considerations
To operate the UPS at the best efficiency point, your installation site should meet the environmental
parameters outlined in this manual. Excessive amount of dust or moisture in the operating environment
may cause damage or lead to malfunction. The UPS should be always protected from the outside
weather and sunshine. The operating environment must meet the weight, airflow, size and clearance
requirements specified in the technical datasheet.
Under no circumstances, the UPS should be installed in an airtight room, in the presence of flammable
gases, or in an environment exceeding environmental requirements here below.
An ambient temperature of +20°C to +25°C is recommended to achieve a long life of the UPS and
batteries. The cooling air entering the UPS must not exceed +40 °C and the humidity should be below
95% (non-condensing).
1.3 Declaration of Safety conformity and CE marking
PowerValue 11 RT
is designed, manufactured and commercialized in accordance with the standard
EN ISO 9001
of Quality Management Systems.
These products are in conformity with the directives:
•
2014/35/EU
Low voltage directive
•
2014/30/EU
Electromagnetic Compatibility directive (EMC)
•
2011/65/EU
Restriction of the use of certain hazardous substances (RoHS) directive
and with the following product standards:
Product Standards
Safety IEC/EN 62040-1:2008+A1:2013
EMC IEC/EN 62040-2:2006
RoHS IEC/EN50581:2012
Figure 1: Standards
1.4 Inquiries
Address inquiries about the UPS to the local office or agent authorized by the supplier. Please note the
type code and the serial number of the equipment and contact your nearest agent authorized by the
supplier. The serial number is shown in the nameplate of the product. For further information on
troubleshooting, go to Section 7.

Modifications reserved
Page 9/49
1.5 Operation
DANGER!
WARNING!
DO NOT REMOVE THE ENCLOSURE OF THE UPS
CAUTION!
EARTH CONNECTION IS ESSENTIAL BEFORE CONNECTING TO THE
BUILDING-WIRING TERMINAL
CAUTION!
DO NOT DISCONNECT THE MAINS CABLE FROM THE UPS OR THE
BUILDING WIRING SOCKET DURING OPERATION AS THIS WOULD
REMOVE THE GROUND TO THE UPS AND OF ALL CONNECTED LOADS.
CAUTION!
AN INTEGRAL SINGLE EMERGENCY SWITCHING D
EVICE WHICH
PREVENTS FURTHER SUPPLY TO THE LOAD BY THE UPS IN ANY MODE
OF OPERATION SHOULD BE PROVIDED IN THE BUILDING WIRING
INSTALLATION.
CAUTION!
AN APPROPRIATE DISCONNECTION DEVICE SUCH AS SHORT-CIRCUIT
BACKUP PROTECTIONS SHOULD BE PROVIDED IN THE BUILDING
WIRING INSTALLATION

Modifications reserved
Page 10/49
NOTE!
TO DISCONNECT COMPLETELY THE UPS, FOLLOW THE INSTRUCTIONS
IN SECTION 5.3.2
CAUTION!
INDISCRIMINATE OPERATION OF SWITCHES MAY CAUSE OUTPUT LOSS
OR DAMAGE TO EQUIPMENT
WARNING!
ENSURE THAT NO LIQUID OR OTHER FOREIGN OBJECTS ENTER THE UPS

Modifications reserved
Page 11/49
2Maintenance
CAUTION!
PLEASE REFER TO YOUR AUTHORIZED SERVICE PARTNER FOR THE
RECOMMENDED MAINTENANCE PLAN (INCLUDING THE SPECIFIC
SCHEDULED REPLACEMENT OF FANS). PERFORMING REGULAR AND
PREVENTIVE MAINTENANCE NOT ONLY KEEPS THE PERFORMANCE
STABLE AND EXTENDS THE LIFE OF THE EQUIPMENT, BUT ALSO
DECREASES THE RISK OF FAILURE. IN CASE THESE ACTIVITIES NOT
PERFORMED, THE CORRECT FUNCTIONING OF THE EQUIPMENT MAY
BE AFFECTED
DANGER!
WARNING!
ONLY QUALIFIED MAINTENANCE PERSONNEL SHOULD CARRY OUT
REPAIRING AND BATTERY REPLACEMENTS
DANGER!
WARNING!
BEFORE CARRYING OUT ANY KIND OF SERVICE AND/OR MAINTENANCE,
DISCONNECT THE BATTERIES. VERIFY THAT NO CURRENT IS PRESENT
AND NO HAZARDOUS VOLTAGE EXISTS IN THE CAPACITOR OR BUS
CAPACITOR TERMINALS.
DANGER!
WARNING!
EVEN AFTER THE UNIT IS DISCONNECTED FROM THE MAINS POWER
SUPPLY, COMPONENTS INSIDE THE UPS ARE STILL CONNECTED TO
THE BATTERY

Modifications reserved
Page 12/49
DANGER!
WARNING!
THE BATTERY CIRCUIT IS NOT ISOLATED FROM THE INPUT VOLTAGE.
HAZARDOUS VOLTAGES MAY OCCUR BETWEEN THE BATTERY
TERMINALS AND THE GROUND. VERIFY THAT NO VOLTAGE IS PRESENT
BEFORE SERVICING
DANGER!
WARNING!
A BATTERY CAN PRESENT A RISK OF ELECTRICAL SHOCK AND HIGH
SHORT CIRCUIT CURRENT. THE FOLLOWING PRECAUTIONS SHOULD BE
OBSERVED WHEN WORKING ON BATTERIES:
•REMOVE WATCHES, RINGS OR OTHER METAL OBJECTS
•MAKE USE OF PROPER PPE (PERSONAL PROTECTION EQUIPMENT)
AS PER LOCAL POLICIES AND RULES
WEAR FLAME/ARC RESISTANT WHOLE BODY CLOTHING
WEAR SUITABLE VOLTAGE RATED GLOVES
USE SAFETY DIELECTRIC FOOTWEAR
WEAR ARC FLASH FACE SHIELD
USE VOLTAGE RATED TOOLS
•DO NOT LAY TOOLS OR METAL PARTS ON TOP OF BATTERIES
•DISCONNECT THE CHARGING SOURCE PRIOR TO CONNECTING OR
DISCONNECTING BATTERY TERMINALS
CAUTION!
REPLACE BATTERIES WITH THE SAME NUMBER AND SAME TYPE OF
BATTERIES.
CAUTION!
REPLACE FUSES ONLY BY DEVICES OF THE SAME TYPE AND OF THE
SAME AMPERAGE IN ORDER TO AVOID FIRE HAZARDS.

Modifications reserved
Page 13/49
-If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the
batteries must be replaced. In this case please contact your dealer.
-The UPS should be charged once every 4 to 6 months if it has not been used for a long time. The
batteries charge to 90% capacity in approximately 4 hours. However, it is recommended that the
batteries charge for 48 hours after long-term storage.
-In high temperature regions, the battery should be charged and discharged every 2 months. The
standard charging time should be of at least 12 hours.
-Under normal conditions, the battery life lasts 3 to 5 years. In case the battery is not in good
conditions, earlier replacement should be made.
-When the discharging time is less than 50% of specified after full charged, the battery may need
to be replaced. Please check the battery connection or contact your local dealer to order new
battery.
2.1 Battery Recycling
WARNING!
NEVER DISPOSE BATTERIES ON FIRE AS THEY MAY EXPLODE.
WARNING!
DO NOT OPEN OR MUTILATE THE BATTERIES.
WARNING!
RELEASED ELECTROLYTE IS HARMFUL TO THE SKIN AND EYES.
Discard appropriately the UPS, battery module and batteries and follow your local laws and regulations.

Modifications reserved
Page 14/49
3General Characteristics
The UPS and external battery cabinet mechanical structure are indicated in the tables and pictures of
this section.
3.1 UPS front view
Number Description
1 LCD display
2 LEDs
3 Control keys
4 Ventilation inlets
5 Wheels
6 UPS support
Figure 2: Front view of PowerValue 11/31 T 10-20 kVA
3.2 UPS rear view
10 kVA 20 kVA
Number Description
1 Terminal blocks
2 Input breaker
3 Back feed control
4 Fans
5 Relay card slot
6 EPO contact
7 RS232 port
8 USB port
9 Parallel port
10
Network interface card
slot
11 Maintenance switch
Figure 3: Rear view of PowerValue 11/31 T 10-20 kVA

Modifications reserved
Page 15/49
3.3 External battery cabinet front view
Number Description
1 Ventilation inlets
2 Wheels
3 UPS support
Figure 4: Front view of external battery cabinet
3.4 External battery cabinet rear view
Number Description
1 Ventilation inlets
2 Fuse holder
3 Connection terminals
4 Wheels
5 UPS support
Figure 5: Rear view of external battery cabinet

Modifications reserved
Page 16/49
4Installation
4.1 Delivery, Transportation, Positioning and Storage
4.1.1 Receipt of the UPS and visual inspection
Upon receiving the UPS, carefully examine the packing container and the UPS for any sign of physical
damage. In case of damage, notify immediately the carrier.
The packing container of the UPS protects it from mechanical and environmental damage. To increase
its protection, the UPS is wrapped with a plastic sheet. Preserve the packaging for later re-use.
4.1.2 Unpacking
To unpack the unit, follow the steps below:
1.
Using a forklift, position the unit in the place
where it will be installed. The UPS has wheels
that makes it easy to move be moved after
unpacked but avoid dragging it long not to
damage the wheels.
2.
Remove the caron box from the top of the
unit.
3. Remove the protection on the sides and top
of the unit.
4. Using the wooden piece provided on the top
of the UPS, slide the UPS out of the pallet
with care.
5. Install the side mounting brackets (used for shipping) back to the unit to ensure higher stability of
the UPS. If desired, the UPS can also be fixed to the floor with M8 bolts.

Modifications reserved
Page 17/49
Examine the UPS for any sign of damage and ensure that the received UPS corresponds to the material
indicated in the delivery note. Notify your carrier or supplier immediately if damage is apparent. The
content of the package is:
-1 x PowerValue 11/31 T UPS
-1 x User manual
-1 x parallel cable
-1 x parallel port cover plate
-1 x Metal 3 pin connector
-1 x Metal 2 pin connector
-1 x Cable for connections from M2 to L3
-4 x cable glands
-1 x Monitoring Software CD
4.1.3 UPS storage
If you plan to store the UPS prior to use, keep the UPS in a dry, clean and cool storage room with an
ambient temperature between -15 °C and +60°C and humidity of less than 95% non-condensing. If the
packing container has been removed, protect the UPS from dust. Keep the UPS always in upright
position and do not drop the equipment.
4.1.4 Planning before the installation
The appropriate place of installation for the unit is to be selected in such a way that the danger of
damage to the UPS is minimized and a long service life of the device is thus ensured. Please observe
the following instructions:
-Install the UPS in an indoor area.
-Leave 50 cm of space on each side of the cabinet to enable cooling airflow and ensure that the
circulation of air to the ventilation slits is not obstructed.
-Avoid excessively high temperature and excessive moisture.
-Make sure that the surface is solid and flat.
-Note that water condensing may occur if the UPS is unpacked in a very low temperature
environment.
In this case, it is necessary to wait until the UPS is fully dried inside out before proceeding with the
installation to avoid hazards and electric shock.

Modifications reserved
Page 18/49
4.2 Electrical Installation
4.2.1 Commissioning
The UPS must be commissioned by a fully trained and authorized field service engineer before being
put into use. The commissioning of the UPS involves the connection of the UPS and batteries, the
verification of the electrical installation and operating environment of the UPS, the controlled start-up
and testing of the UPS and customer training.
CAUTION!
TO ENSURE CORRECT OPERATION OF THE UPS AND BATTERIES, IT IS
NECESSARY TO PROVIDE THE MAINS CABLES WITH APPROPRIATE FUSE
PROTECTION
4.2.2 Connections
Before installing the electrical wiring, check the nominal amperage of your incoming feeder.
DANGER!
WARNING!
THE CABLING CONNECTIONS MUST BE CARRIED OUT BY QUALIFIED
ELECTRICAL PERSONNEL
CAUTION!
DO NOT USE THE WALL SOCKET AS THE INPUT POWER SOURCE FOR
THE UPS. ITS RATED CURRENT IS NOT ADEQUATE TO THE FEED THE UPS
AND MAY BURN THE SOCKET
The UPS is cabled through the terminal blocks as indicated in
Figure 6: Terminal blocks

Modifications reserved
Page 19/49
4.2.2.1 Procedure
1. Open the terminal block cover located
on the rear panel of the UPS.
2. Remove the protective plates of the cable
entries (the bypass hole should remain closed
for safety purposes if it is not used)
3.
Connect the wires according to the illustrations in the subsections that follow according to your
configuration (11 or 31, single or dual input feed). Run the cables through the holes from the
bottom to the top installing also the cable glands provided with the UPS.
Note: If the UPS is used as a standalone UPS, JP1 and JP2 must be connected. If the UPSs are
used in parallel configuration, the jumper between JP1 and JP2 must be removed.
4. Check that all wires have been properly connected.
5. Close the terminal box with the protective
cover. This is very important to prevent
access to energized cables and
connectors.
6. Install the output breakers between the output
terminal and the load. The breaker should have
a leakage current protective function according
to the UPS voltage and current ratings.
Protective plates
Cable gland
Cable outer diameter:18-25mm
Cable gland
Cable outer diameter:16-28mm
