ABB HiPerGuard MV UPS User manual

© Copyright 2020 ABB, All rights reserved.
— HiPerGuard MV UPS User Manual
—
MEDIUM VOLTAGE UPS
HiPerGuard MV UPS
User Manual
COVER PICTURE

—
ABB's HiPerGuard MV UPS is an
industry-first that provides a
continuous and reliable power sup-
ply of up to 24 kV for mission
critical facilities to protect loads,
whilst reducing downtime.
HiPerGuard supports sustainability
with the highest levels of
efficiency available on the market,
at 98 percent – translating to a
potential carbon emission
reduction of 1,245 tons over a
typical 15-year lifespan.

3
—
About this document
—
Document information
https://new.abb.com/ups/
Copyright notice
The information in this manual is subject to change without notice. This manual and parts thereof must not be re-
produced or copied, or disclosed to third parties, nor used for any unauthorized purpose without written permis-
sion from ABB Ltd. The hardware and software described in this manual are provided under a license and may be
used, copied, or disclosed only in accordance with the terms of such license.
Document identification
Document number : 2UCD400000E001
Ownership: ABB Ltd., Power Conditioning Products
Issue date: 07, 2021
Revision:Rev B
Contact information
Address: ABB Ltd. 111 Main North Road, Napier, New Zealand.
Website: https://new.abb.com/ups
Equipment covered by the manual
This manual covers the standard HiPerGuard MV UPS product and provides general information regarding:
• General functions of the MV UPS
• Operation
• Component enclosures
• Graphical Display Module (GDM)
• Control and adjustments
The manual does not claim to cover all variations and details of the HiPerGuard MV UPS, nor to consider all eventu-
alities that may arise during installation, commissioning, operation and maintenance of the product.
If the MV UPS is adapted to specific customer needs or applications, and handling, installation, and operation of
the product are affected by these modifications, the information will be provided in the appropriate documenta-
tion (e.g., mechanical drawings, wiring diagrams, project-specific data, engineering notes). Some products may
differ from the basic configuration hereby presented. Refer to the project documentation for details.
If information is required beyond the instructions in this manual, please refer the matter to ABB
Target groups and required qualifications
The product presented in this manual is part of a CAT III/IV environment where voltages are present that contain a
potential hazard of electric shock and/or burn. For this reason, only personnel who have a thorough knowledge of
the MV UPS and the industrial environment and have obtained the required qualification may handle, install, oper-
ate, or maintain the product.
The manual addresses personnel who are responsible for unpacking, transportation, installation, operation and
maintenance of the MV UPS. The personnel must carry out the listed tasks in a manner that does not cause physi-
cal harm or danger, and that ensures the safe and reliable functioning of the product.

4HIPERGUARD MV UPS USER MANUAL
—
Document information
https://new.abb.com/ups/
Maintenance
The personnel include all persons who:
• are qualified to carry out preventive and corrective maintenance on MV UPS as described in this manual.
• are thoroughly familiar with the product.
• have a sound knowledge of the relevant electrical codes and specifications covering low and medium voltage
equipment.
• are able to assess the hazards as-sociated with the energy sources of the MV UPS system and act correspond
ingly.
• know the safe shutdown and grounding procedures for the MV UPS system.
• are familiar and understand the instructions contained in the Service manual (see related documentation).
Responsibilities of the user
It is the responsibility of those in charge of the HiPerGuard MV UPS to ensure that each person involved in the in-
stallation, operation or maintenance of the product has received the appropriate training and has thoroughly read
and clearly understood the instructions in this manual and the relevant safety instructions.
Intended use of equipment
Those in charge of the HiPerGuard MV UPS must ensure that the product is only used as specified in the contrac-
tual documents, operated under the conditions stipulated in the technical specifications and on the rating plate
of the product, and serviced in the intervals as specified by ABB.
Use of the HiPerGuard MV UPS outside the scope of the specifications is not permitted and can lead to malfunc-
tion or hazardous situtations. Intended equipment use also implies that only spare parts recommended and ap-
proved by ABB may be used. Unauthorized modifications and constructional changes of the HiPerGuard MV UPS
can cause malfunction and result in hazardous situations. Therefore, such modifications are not permitted.
Handling and Installation
Handling
The personnel must be skilled and experienced in unpacking and transporting heavy equipment.
Mechanical installation
The personnel must be qualified to prepare the installation site according to the site and equipment requirements
and to perform the installation accordingly.
—
Commissioning of the HiPerGuard must only be performed by qualified
and certified ABB personnel
Electrical installation
The personnel must have a sound knowledge of the relevant electrical codes and specifications covering low and
medium voltage equipment, be experienced with electrical wiring principles, and know the electrical symbols typ-
ically used in wiring diagrams.
Operation
The personnel include all persons who operate the HiPerGuard from the GDM. Those people must know the func-
tions of the Graphic Display Module (GDM), be adequately trained for the MV UPS, and understand its operation
process

5
—
Document information
https://new.abb.com/ups/
Quality certificates and applicable standards
The following certificates and conformity declarations are available from ABB:
– ISO 9001 certificates stating that ABB Ltd in Napier has implemented and maintains a management system that
fulfils the requirements of the normative standards.
– EC conformity declaration.
– List of the standards the MV UPS complies with:
• IEC62477-2.
• IEC61000-6-2.
• WEEE.
• IEC60076 (for the medium voltage magnetics).
Items covered by delivery
Delivery comprises the following items:
– HiPerGuard low voltage Power Conversion Unit (PCU). This is a plinth with six enclosures already in
stalled and interwired. The six enclosures are: DCT enclosure, APS enclosure, Utility enclosure, 3 x
PE120 encloures.
– HiPerGuard Medium Voltage Magnetics (MVM) enclosure.
– Nuts, bolts, washers, brackets, plinth covers, and other metalwork parts required to interconnect PCU
to MVM enclosure.
– Communications and fan power cables to interconnect PCU to MVM enclosure.
– Fiber cable to interconnect MV UPS to Medium Voltage Switchgear enclosure.
For information on items supplied, see the shipping note.
Identifying the delivery
The HiPerGuard and accessories are identified by the type code printed on the rating label. The label is located on
the back of the PE120-1 enclosure door.
The label provides information on the HiPerGuard MV UPS rated voltage, frequency, rated current and auxiliary
power supply.

6HIPERGUARD MV UPS USER MANUAL
—
Abbreviations & Terms
https://new.abb.com/ups/
The following table lists terms and abbreviations users should be familiar with when using this manual. Some of
the terms and abbreviations used in the manual are unique to ABB and might differ from the common use.
Abbreviation/Term Meaning
LV Low Voltage. Voltage level up to 1000 Vac or 1500 Vdc.
MV Medium Voltage. Voltage level between 1 kVac and 35 kVac.
PCS120 Power Conversion System 120. PCS120 is the product platform for the ABB power condi-
tioning products.
PEBB Power Electronic Building Block.
PE120-N Platform Enclosure 120. PE120 is the enclosure that contains several PEBB modules. The
product has three enclosure designated as PE120-1, PE120-2 & PE120-3.
DCT Direct Current Termination. DCT is an enclosure where the energy storage cables are ter-
minated and connected to the MV UPS PE120 cabinets.
APS Auxiliary Power Supply. APS is an enclosure that contains the MV UPS switched-mode
power supplies, remote input/output modules, control circuits and auxiliary transformer.
ILR Isolating Line Reactor. ILR is a medium voltage impedance connected in series, between
the grid and the load.
CXF Coupling Transformer. CXF is a transformer that couples the medium voltage network to
the low voltage power converters.
Sin Input Switch. Represents the designation of the input circuit breaker connecting the MV
UPS to the grid.
Sout Output Switch. Represents the designation of the output circuit breaker connecting the
MV UPS to the load.
Sabp
Automatic Bypass Switch. Represents the designation of the bypass circuit breaker that
by-passes the MV UPS system and connect the grid directly to the load. This breaker is au-
tomatically controlled by the MV UPS.
PCM Power Conditioning Mode. When operating on this mode, the MV UPS continuously condi-
tions the load voltage.
IM Independent Mode. When operating on this mode, the MV UPS disconnects from the grid
by opening the input circuit breaker and supplies the load through the energy storage.
Bypass mode The term is used to describe the system in bypass (not operating). When working in by-
pass mode, the bypass breaker is closed, and the input/output breakers are opened.
MC Main Controller. Universal controller located in the PE120-1 enclosure.
UC Universal Controller.
HUB Two HUB controllers are located in PE120-2 and PE120-3 cabinets respectively. The main
function is to transfer the information to the main controller.

7
—
Abbreviations & Terms
https://new.abb.com/ups/
The following table lists terms and abbreviations users should be familiar with when using this manual. Some of the
terms and abbreviations used in the manual are unique to ABB and might differ from the common use.
ZISC
Impedance Isolated Static Converter. ZISC refers to the architecture of the HiPerGuard MV
UPS where the static power converters of the MV UPS are isolated from the grid via an im-
pedance.
SOC State of Charge. SOC refers to the state of charge of the energy storage connected to the
MV UPS.
EOA End of Autonomy. EOA refers to the end of the specified back-up autonomy time of the en-
ergy storage.
EOD End of Discharge. EOD refers to the state of energy storage when it is fully depleted.
Smbp
Maintenance Bypass Switch. Represents the designation of the external maintenance by-
pass circuit breaker that bypasses the MV UPS system and its automatic bypass switch-
gear and connect the grid directly to the load. This breaker is not controlled by the MV
UPS.
GDM Graphical Display Module. Has the local Human Machine Interface (HMI) and it is located in
the PE120-1 enclosure.
PCU Power Conversion Unit. The PCU consists of the LV enclosures of the HiPerGuard MV UPS
unit.
MVM Medium Voltage Magnetics. The MVM consists of the coupling transformer and the isolat-
ing line reactor.
UPSU Uninterruptible Power Supply Unit. Refers to a single HiPerGuard MV UPS machine.
UPSS Uninterruptible Power Supply System. Refers to the HiPerGuard MV UPS unit (or multiple
units) in addition to the medium voltage switchgear and the energy storage.
PE-E Protective Earth.
PE-I Inverter Earth.
PCC
Point of Common Coupling. The PCC is the point in the electrical power supply system
where the responsibility of the utility changes to the industrial customer. The utility is re-
sponsible for providing clean voltage and current with respect to harmonic distortion up
to the PCC. The industrial customer is responsible not to distort voltage and current by its
electrical systems.
Line voltage RMS line to line voltage of the main power supply of the MV UPS input.
PCB Printed Circuit Board.
EMC
Electromagnetic Compatibility. All measures to suppress electromagnetic disturbances
caused by different electrical equipment in the same electromagnetic environment, and to
strengthen the immunity of the equipment to such disturbances.
RTD Resistance Temperature Detector. The RTD is a temperature sensor where the change in
electrical resistance is used to measure the temperature.

8HIPERGUARD MV UPS USER MANUAL
—
Abbreviations & Terms
https://new.abb.com/ups/
The following table lists terms and abbreviations users should be familiar with when using this manual. Some of the
terms and abbreviations used in the manual are unique to ABB and might differ from the common use.
Bypass isolate state A state where the MV UPS is not operating, input and output breakers are opened, and the
automatic bypass breaker is closed.
Starting state
A state where the MV UPS ramps its output voltage from zero to input/output voltage
magnitude, synchronizes to frequency and phase, closes the output and input circuit
breakers and opens the automatic bypass circuit breaker.
Stopping state A state where the MV UPS synchronizes the input to the output voltage, closes the auto-
matic bypass circuit breaker and opens the input/output circuit breakers.
PCM Normal state
A state where the grid input voltage is within specified limits and the MV UPS continuously
conditions the load voltage to the system nominal voltage value while the utility is supply-
ing the load active power requirements.
PCM Active state
A state where the grid input voltage is out of threshold and the MV UPS is keeping the load
voltage within specified limits while monitoring to decide whether to disconnect from the
grid.
Island state A state where the MV UPS decided to go into independent mode by opening the input cir-
cuit breaker and supplying the load through the energy storage.
Resynchronizing state A state where the MV UPS resynchronize to the grid input voltage and commands the input
circuit breaker to close when the grid voltage is back and stable for reconnection.
—
Trademarks
Names that are believed to be trademarks of other companies and organizations are designated as such. The absence
or presence of such a designation should however not be regarded as an offence of the legal status of any trademark.
The following registrations and trademarks are used in this manual:
Abbrevation/Term Meaning
Modbus® Registered trademark of Schneider Electric USA, Inc

9
—
Related documentation
The following documents are available for further information:
Document title Document type Document number
HiPerGuard MV UPS Installation Manual Installation Manual 2UCD400000E003
HiPerGuard MV UPS Commissioning Manual Commissioning Manual 2UCD400000E004
Layout Drawings Drawings 2UCD400000E102
Service Manual Service 2UCD400000E411
HiPerGuard MV UPS Switchgear Interface Schematics 2UCD000500E3092
HiPerGuard MV UPS System Schematics Schematics 2UCD000500E313

10 HIPERGUARD MV UPS USER MANUAL
—
Introduction
Thank you for selecting ABB as your preferred supplier of critical power equipment and congratulations on your
choice of the HiPerGuard MV UPS to protect your installation.
The HiPerGuard MV UPS is the medium voltage UPS intended for multi-megawatt power protection. Based on the
impedance isolated static converter (ZISC) architecture, the HiPerGuard MV UPS introduces a flexible solution
with high reliability and high efficiency for critical power installations. Please carefully read this User Manual,
which contains all the necessary information and describes all you need to know about the use of the MV UPS.
The User Manual describes the function of the MV UPS, its operation, system components, the meaning of the
system events related to the user interface and provides procedures for starting and stopping the equipment.
Please refer to the Installation Manual, which describes how to prepare the installation site, and provides weight,
dimensions and procedures for moving, installing and connecting the HiPerGuard MV UPS.
While every care has been taken to ensure the completeness and accuracy of this manual, ABB assumes no respon-
sibility or liability for any losses or damages resulting from the use of the information contained in this document.
Thank you for choosing ABB!

11
—
Contents
About this document ......................................................... 3
Document information................................................................. 3
Document information.................................................................4
Document information.................................................................5
Abbreviations & Terms.................................................................6
Abbreviations & Terms................................................................. 7
Abbreviations & Terms.................................................................8
Trademarks....................................................................................8
Related documentation ...............................................................9
Introduction ...................................................................... 10
Contents .............................................................................11
Safety ................................................................................. 14
1.1 Safety notices..................................................................... 16
1.2 General safety information ..............................................18
1.3 Possible residual risk.........................................................18
Cyber Security................................................................... 19
Overview............................................................................ 19
2.1 Deployment guidelines ..................................................... 19
Product Description.........................................................20
Overview............................................................................20
3.1 Single line diagram ............................................................20
3.2 Operating principle............................................................ 21
3.3 Major MV UPS components ..............................................29
3.4 Cooling system................................................................... 33
Model definition ............................................................... 35
Product type code ............................................................ 35
4.1 Platform code .....................................................................35
4.2 Product code.......................................................................35

12 HIPERGUARD MV UPS USER MANUAL
4.3 System frequency ..............................................................35
4.4 Magnetics configuration ..................................................36
4.5 Medium voltage cable entry .............................................36
4.6 System voltage2............................................................................................................................ 36
4.7 Energy storage code.......................................................... 37
4.8 DC cables entry.................................................................. 37
4.9 System configuration........................................................ 37
4.10 Installation .......................................................................... 37
4.11 Layout .................................................................................. 37
4.12 Demand response interface .............................................38
4.13 Upstream standby generator...........................................38
Technical specifications .................................................. 39
General product data....................................................... 39
5.1 Utility input.........................................................................39
5.2 Load output ....................................................................... 40
5.3 Energy Storage.................................................................. 40
5.4 Environmental conditions1................................................... 41
5.5 Interface ..............................................................................41
5.7 Dimensional data ...............................................................42
External power and control connections ......................43
Overview............................................................................43
6.1 Overview of external connections...................................43
6.2 Medium voltage connections to MVM enclosure.......... 44
6.3 Energy storage connections to DCT enclosure ............ 44
6.4 Power and I/O interfaces to APS enclosure....................45
6.5 Communication between MV Switchgear .....................52
6.6 Modbus TCP/Web interfaces............................................53
6.7 Communication in parallel configuration.......................53
User Interface.................................................................... 55
Overview............................................................................ 55
7.1 Graphic Display Module (GDM) ........................................55
7.2 Web Interface.....................................................................70
7.3 Ethernet Interface.............................................................70
Operation........................................................................... 72
Safety ................................................................................. 72

13
8.1 Machine State Flow diagram ............................................72
8.2 System Start ....................................................................... 74
8.3 System Bypass....................................................................78
8.4 Independent mode.............................................................78
8.5 Resynchronize mode......................................................... 80
8.6 System EPO ........................................................................ 80
8.7 Hard fault ............................................................................81
8.8 Energy storage depleted ..................................................82
Maintenance Schedule ..................................................... 83
Overview............................................................................ 83

14 HIPERGUARD MV UPS USER MANUAL
—
Safety
BG
Предупреждение: Опасно напрежение!
Вижте инструкциите за работа.
Изключете и блокирайте захранването преди да работите с устройството.
Внимание! Да се монтира само от експерт електротехник.
CS
Varování: Nebezpečné napětí! Viz návod k obsluze.
Před zahájením prací na tomto zařízení odpojte a uzamkněte napájení.
Pozor! Toto zařízení smí instalovat pouze osoba s elektrotechnickou
odborností.
DA
Advarsel: Farlig elektrisk spænding! Se betjeningsvejledningen.
Frakobl enheden, og afbryd strømforsyningen, før du arbejder med denne enhed.
Giv agt! Installation må kun foretages af personer med elektroteknisk
ekspertise.
DE
Warnung: Gefährliche Spannung! Siehe Bedienungsanleitung.
Vor dem Arbeiten Gerät ausschalten und von der Spannungsversorgung trennen.
Achtung! Installation nur durch elektrotechnische Fachkraft.
EL
Προειδοπο ηση: Επι νδυνη  ση! Αναρ ξε σι οδη ε λειουρ α .
Αποσυνδ σε αι απομον σε ην παρο ισ ο προο ξε ιν σεε ι ερασ ε σε αυ ν η συσευ .
Προσο ! Η εα σαση πρ πει να  νεαι μ νο απ αδειο ο ηλερολ ο εαασ η.
EN
Warning: Hazardous voltage! Refer to installation instructions.
Disconnect and lock out power before working on this device.
Attention! Installation by person with electrotechnical expertise only.
ES
Advertencia: ¡Tensión peligrosa! Consulte las instrucciones de funcionamiento.
Antes de trabajar con este dispositivo, desconecte y bloquee la corriente.
¡Atención! La instalación debe ser realizada únicamente por un técnico
electricista.
ET
Hoiatus: Elektrilöögi oht! Lisateavet vaadake kasutusjuhendist.
Enne selle seadmega töötamist ühendage lahti ja lukustage toide.
Tähelepanu! Seadet tohib paigaldada ainult elektrotehnilise kogemusega isik.
FI
Varoitus: Vaarallinen jännite! Katso käyttöohje.
Katkaise virta ja estä virran kytkeminen lukituksella ennen töiden aloittamista.
Huomio! Asennuksen saa suorittaa vain henkilö, jolla on kokemusta sähkötekniikasta.
FR
Avertissement: Tension dangereuse! Consultez les consignes d’utilisation.
Débranchez et verrouillez l’alimentation électrique avant d’entreprendre des travaux sur cet appareil.
Attention! L’installation doit être effectuée uniquement par une personne ayant une expertise en électrotech-
nique.
HR
Upozorenje: Opasan napon! Pogledajte upute za uporabu.
Odspojite i isključite struju prije rada na ovom uređaju.
Pažnja! Ugradnja je dopuštena samo osobama stručnim u području elektrotehnike.
HU
Figyelmeztetés: Veszélyes feszültség! Lásd a használati utasítást.
Válassza le és zárja ki az áramellátást, mielőtt a berendezésen dolgozni kezd.
Figyelem! Az üzembe helyezést csak elektrotechnikai szakértelemmel rendelkező sze-mély végezheti el.
IT
Attenzione: Tensione pericolosa!
Fare riferimento alle istruzioni per l’uso.
Prima di intervenire su questo dispositivo, scollegare e isolare tutte le fonti di alimentazione.
Attenzione! L’installazione deve essere eseguita esclusivamente da un installatore qualificato.

15
LT
Įspėjimas: Pavojinga įtampa!
Žr. naudojimo instrukcijas.
Atjunkite ir laikinai užblokuokite maitinimą prieš dirbdami su šiuo įrenginiu.
Dėmesio! Įrengti gali tik asmuo, turintis elektrotechniko patirties.
LV
Brīdinājums: Bīstams spriegums!
Skatiet darba norādījumus.
Pirms sākat darbu ar šo ierīci, atvienojiet un bloķējiet strāvas padevi.
Uzmanību! Uzstādīšanu drīkst veikt tikai persona ar zināšanām par elektrotehniku.
NL
Waarschuwing: Gevaarlijke spanning!
Raadpleeg de bedieningsinstructies.
Koppel dit apparaat los van de stroomvoorziening voordat u werkzaamheden uitvoert.
Let op! Installatie mag alleen worden uitgevoerd door een monteur met elektrotechnische expertise.
NO
Advarsel: Farlig spenning!
Se i bruksanvisningen.
Koble fra og steng av strømmen før du arbeider på denne enheten.
Forsiktig! Montering skal kun utføres av kvalifiserte personer med elektrokompetanse.
PL
Ostrzeżenie: Niebezpieczne napięcie!
Patrz: instrukcja obsługi.
Przed rozpoczęciem wykonywania pracy z tym urządzeniem odłącz i zablokuj zasilanie.
Uwaga! Montaż może wykonywać wyłącznie osoba posiadająca doświadczenie elektrotechniczne.
PT
Aviso: Tensão perigosa!
Consulte as instruções de operação.
Desconecte e desligue a energia elétrica antes de trabalhar nesse dispositivo.
Atenção! A instalação deve ser feita apenas por uma pessoa com especialidade eletrotécnica.
RO
Avertisment: Tensiune electrică periculoasă!
Consultați instrucțiunile de utilizare.
Deconectați și închideți sursa de energie înainte de a lucra cu acest
dispozitiv.Atenție! Instalare
RU
Внимание: Опасное электрическое напряжение!
Обратитесь к инструкциям по эксплуатации.
Отключите питание и обесточьте устройство перед началом работ.
Внимание! Установка должна выполняться только специалистом по электротехническим работам.
SK
Výstraha: Nebezpečné napätie!
Pozrite si návod na použitie.
Pred začatím prác na tomto zariadení odpojte a zablokujte napájanie.
Pozor! Inštaláciu smie vykonávať len osoba s odbornými znalosťami v oblasti elektrotechniky.
SV
Varning: Livsfarlig spänning!
Se i bruksanvisningen.
Frånkoppla och blockera anläggning eller en anläggningsdel innan arbeite utförs.
Obs! Får endast installeras av behörig elektriker.
TR
Uyarı: Tehlikeli gerilim!
Çalışma talimatlarına bakın.
Bu cihaz üzerinde çalışmadan önce elektriği kesin ve kilitleyin.
Dikkat! Yalnızca elektroteknik uzmanlığa sahip kişiler tarafından kurulabilir.
ZH
警 告 ：高 压 危 险 !
请参见操作手册
操作本设备前请断开并锁定电源。
注意！安装仅限专业电工人员。

16 HIPERGUARD MV UPS USER MANUAL
—
1.1 Safety notices
Symbol/sign Meaning
DANGER
This manual provides information for the safe operation of the HiPerGuard MV UPS. It does NOT
provide installation, commissioning or service information. For such information, refer to the ap-
propriate manual.
CAUTION – Trained operators
All operations on the HiPerGuard MV UPS must only be carried out by a trained operator familiar
with the contents of this manual. Hazardous conditions could arise from incorrect adjustment.
DANGER – Hazardous voltages
An Operator must not open doors or panels marked as containing hazardous voltages. Many parts in
this product, including printed circuit boards operate at lethal high voltages. Stored energy compo-
nents such as batteries and capacitors can hold this voltage even after the opening of isolation
switches. DO NOT TOUCH components or connections that may have voltage present.
DANGER – High voltages
Lethal high voltages are present inside the MVM and Medium Voltage Switchgear enclosures under
normal operation or fault conditions. Do not remove any panels or guards. This may only be done by
trained technical personnel after following the stipulated isolation, grounding, and lockout proce-
dures. DO NOT TOUCH components or connections that have voltage present.
DANGER – Stored charge
Stored charge is present after the device is switched off. When the MV UPS is powered down, lethal
voltages will remain in the energy storage elements and the complete HiPerGuard MV UPS should be
considered live. To remove this hazard, energy storage will need to be isolated and locked off, and
filter capacitors discharged. This may only be done by trained technical personnel while following
the stipulated isolation, grounding, and lockout procedures.
DANGER – Protective covers
Normal operation of this product requires all protective covers to be in place and all doors secured
closed.
DANGER – Personal Protective Equipment
Ensure safety glasses and other appropriate PPE are worn while working if any part of the unit could
be energized. Observe site requirements for PPE while operating this equipment.
Safety instructions are used to highlight a potential hazard when working on the equipment. Safety instructions
must be strictly followed! Non-compliance can jeopardize the safety of personnel, the equipment and the environ-
ment.
This manual contains important information regarding the operation of the ABB HiPerGuard MV UPS and provides
technical and operational guidance for operators. The following safety instructions are to be observed.

17
DANGER – Arc flash
Arc flash is a dangerous phenomenon associated with operation at medium voltages. It may be
caused by switchgear failure, insulation breakdown or foreign object intrusion. It may result in se-
vere burns, severe eye injury, blindness, or death. To minimize the risk, keep all doors closed and cov-
ers in place while operating the equipment. Observe any arc flash protection boundaries that may be
in place around the MVM and Medium Voltage Switchgear enclosures.
DANGER – Potential material hazard of batteries and capacitors
If a battery or capacitor is damaged electrically or physically, the resulting debris could represent a
material hazard. Refer to the appropriate Material Safety Data Sheet for information on safe han-
dling and disposal.
Safety labels are attached to the enclosures to alert personnel of potential hazards when working on the equip-
ment. The instructions on the safety labels must always be followed, and the labels must be kept in a perfectly
legible condition.

18 HIPERGUARD MV UPS USER MANUAL
—
1.2 General safety information
1.2.1. Operator duties
The scope of work for an operator of the HiPerGuard MV UPS is to control and monitor the MV UPS from the GDM,
remote start/stop controls, or from the web page. An operator is not normally authorized to undertake any main-
tenance, service or repair work. The operator may be authorized to provide assistance to a maintenance, service,
or repair technician, by performing his or her duties under the direction of a service team. If so, the operator must
be wearing PPE to the same level as those of the service team.
1.2.2. Before energization
Before the MV UPS is energized, inspect to make sure:
– Any maintenance work being done on the HiPerGuard has been completed and all tools and equipment
are removed.
– All covers on the HiPerGuard enclosures are securely fastened, and all doors are closed, locked, and/ or
bolted.
1.2.3. In case of fire
In case of fire in the UPS room:
– Observe the established rules and regulations for fire protection,
– Only fireman with appropriate personal protective equipment are allowed to enter the UPS room.
—
1.3 Possible residual risk
The following risks can arise from a MV UPS system and pose a hazard to
people. These risks must therefore be considered by the system integrator
and/or the plant owner when assessing the risks of the machinery.
The HiPerGuard is a high energy power conversion machine. Components may be dislodged, or damaged while be-
ing commissioned, operated or serviced, due to, for example:
– External influence on, or damage to the equipment,
– Wrong parameter settings,
– Operation of the equipment outside the scope of the specifications,
– Faulty hardware.
Any one of these faults may cause the noisy ejection of high temperature materials and gases.
Hazardous touch voltages can be present on the HiPerGuard system components caused by, for example:
– Operation of the equipment outside the scope of the specifications,
– External influence on, or damage to the equipment,
– Induced voltages by external equipment,
– Condensation on equipment components or pollution,
– Faulty hardware.
For all the above reasons, always operate with all side panels in place and all doors shut and latched.

19
—
2.1 Deployment guidelines
This product is designed to be connected to and to communicate information and data via network interface.
It is customer's sole responsibility to provide and continuously ensure a secure connection between the product
and customer network or any other network (as the case may be). Customer shall establish and maintain any ap-
propriate measures (such as but not limited to the installation of firewalls, application of authentication mea-
sures, encryption of data, installation of anti-virus programs, etc.) to protect the product, the network, its system
and the interface against any kind of security breaches, unauthorized access, interference, intrusion, leakage and/
or theft of data or information.
ABB and its affiliates are not liable for damages and/or losses related to such security breaches, any unauthorized
access, interference, intrusion, leakage and/or theft of data or information.
—
Cyber Security
Overview
The recommended Cyber Security deployment for the HiPerGuard MV UPS is for it to be only used in a trusted net-
work with restricted access. The user is responsible for creating a defense-in-depth protection by allocating fire-
wall solutions to each network.
For secure remote access, use a VPN connection – the HiPerGuard MV UPS is not approved by ABB for direct Inter-
net connection. The user of the product should be aware that the unsecure nature of the Modbus TCP protocol ex-
poses the communication between the product and the control system. Authentication and integrity of transmit-
ted information is not provided by the protocol. This enables certain types of attacks, such as man-in-the-middle
attacks, eavesdropping attacks and replay attacks for instance. The main security is provided through monitoring
the cybersecurity, topology (asset management) and correct operation of the data networks using the cybersecu-
rity monitoring modules and features of the firewalls and managed switches.

20 HIPERGUARD MV UPS USER MANUAL
—
3.1 Single line diagram
The ABB HiPerGuard MV UPS is a high-performance high-efficiency UPS system that ensures protection from
power quality events, enabling the continuous conditioned power supply to sensitive and critical loads.
Based on the ZISC (Impedance Isolated Static Converter) architecture, the HiPerGuard MV UPS uses a special cou-
pling reactor combined with new generation PCS120 power modules to interface from the utility to the load. The
reactor acts as a barrier, preventing grid disturbances to reach the load and improves the power factor seen from
the grid side.
It is used to protect sensitive loads from the full spectrum of utility voltage events and combined with a wide
range of modern energy storage solutions ABB’s ZISC provides autonomies from seconds to many minutes.
The equipment is connected to the medium-voltage network through the MV switchgear. The input breaker con-
nects the power supply to the MV UPS, which also has an active role in the normal operation. The output breaker
connects the MV UPS to the load, and a bypass breaker is connected between the whole MV UPS system, as shown
in the single line diagram.
—
Product Description
Overview
—
Figure 3.01: HiPer-
Guard MV UPS Single
Line Diagram
