ACS Alcolock WR2 Installation and operating manual

Saskatchewan
Instruction and compliance manual
ALCOHOL INTERLOCK

Alcohol Countermeasure Systems Corp
60 International Boulevard
Toronto, Ontario M9W 6J2 CANADA
T [phone]
F [phone]
[email protected]
acs-corp.com
Toll-free number: 1-800-769-3312
ACS, ALCOHOL COUNTERMEASURE SYSTEMS, ALCOLOCK and the “Molly” are trademarks of Alcohol
Countermeasure Systems (International) Inc. and are used under license. Alcohol Countermeasure Systems is
the trading style of Alcohol Countermeasure Systems (International) Inc.
© 1992 - 2015 Alcohol Countermeasure Systems
The information disclosed in this document is the valuable property of Alcohol Countermeasure Systems and
all copyright and other proprietary rights to this document are reserved. No reproduction of this document is
permitted without the prior written consent of Alcohol Countermeasure Systems.

TABLE OF CONTENTS
Safety and Precautions.................................................................................................1
General.....................................................................................................................1
Warranty...................................................................................................................1
Maintenance.............................................................................................................1
Introduction....................................................................................................................2
What is an alcohol interlock? ...................................................................................2
How does it work? ...................................................................................................2
Installation ................................................................................................................2
More information ......................................................................................................2
Using the ALCOLOCK WR2..........................................................................................3
Starting the engine ...................................................................................................3
Running retests ........................................................................................................4
Start violation............................................................................................................5
Program violation .....................................................................................................5
Service due ..............................................................................................................5
Features..........................................................................................................................6
Restarting the engine ...............................................................................................6
Warm up...................................................................................................................6
Turning the power off................................................................................................6
Disconnecting the sampling head ............................................................................6
Emergency override .................................................................................................7
Display messages ........................................................................................................8
Maintenance and troubleshooting ............................................................................14
Calibration .............................................................................................................14
Troubleshooting table ............................................................................................14

SAFETY AND PRECAUTIONS
GENERAL
The ALCOLOCK WR2 alcohol interlock is a device that is designed for easy and safe
operation. The following precautions should be followed:
•Do not open the sampling head or the control module. Doing so will void the
warranty and potentially damage the components within
•Avoid exposing the unit to direct sunlight for extended periods of time
•If any liquid is spilled on the unit, remove all excess uid with a cloth and allow all
components to dry thoroughly. If it is believed that there is excessive water damage,
do not turn the unit on. Contact your dealer
•Turn off radio frequency (RF) transmitting devices (such as cell phones) while using
the ALCOLOCK WR2. Radio frequencies may cause the interlock to abort a test
WARRANTY
All ACS products are warranted to be free of defects in workmanship and materials for
a period of 1 year from the date of shipment.
ACS agrees to replace or repair any defective ALCOLOCK WR2 device, provided the
defect was not caused by misuse or mishandling.
Any ALCOLOCK WR2 being returned for warranty repair must be properly packaged
and shipped prepaid to the authorized dealer’s facility.
MAINTENANCE
The ALCOLOCK WR2 is made for eld use, making it susceptible to dirt and debris.
The unit should be cleaned with a damp cloth and mild soap. Do not use abrasive
cleaners or solvents.

INSTRUCTION AND COMPLIANCE MANUAL 2
INTRODUCTION
WHAT IS AN ALCOHOL INTERLOCK?
An alcohol interlock is an in-vehicle breath alcohol testing device. It prevents a vehicle
from starting if it detects that a driver’s breath alcohol concentration (BrAC) is over a
preset limit. It is designed to t inside the vehicle, near the driver’s seat and connects
directly to the vehicle’s ignition system. This unit consists of a control module, a
sampling head. The control module enables or disables the ignition of the engine and
stores the control module’s settings.
HOW DOES IT WORK?
The ALCOLOCK WR2 uses the same alcohol sensing technology used by police in
roadside screening. A special alcohol-sensitive cell detects the amount of alcohol in
breath. Breath alcohol concentration (BrAC) is directly proportional to the amount of
alcohol in the blood. The blood alcohol concentration limit is customizable and can be
set to any specic jurisdictional requirement.
INSTALLATION
The ALCOLOCK WR2 is to be installed by a qualied installer in accordance with
provincial regulations. An unqualied installation may invalidate the type approval of
the vehicle.
MORE INFORMATION
ALCOHOL INFLUENCE ON TESTING
Drinking alcohol and eating foods containing alcohol will cause a failed breath test.
Some other factors that may affect a test (because they may contain or produce
residual alcohol in the mouth) are: medicines, drops, smoking, using mouthwash or
mouth spray.
Rinsing out the mouth with water after using mouthwash or mouth spray will remove
any alcohol content.
Do not eat, smoke or drink for at least 10 minutes before taking a breath test.
Additionally, do not spray any air fresheners, disinfectants, cologne or perfume in the
vehicle prior to a breath test, as these can also contain alcohol.
NOTE: The above mentioned list of factors that may affect a breath test is not exhaustive.
There are additional items that may affect the results of a breath test. Follow this guide
carefully to avoid incorrect results.

ALCOLOCK WR23
OPERATING TEMPERATURE
The maximum ambient operational temperature is between -40 and 85 °C.
NOTE: Depending on the ambient temperature, warm up may take approximately
30 seconds at 20 °C and up to 5 minutes at 0 °C or below.
USING THE ALCOLOCK WR2
STARTING THE ENGINE
1. Push the power button on control module to power up the WR2. Do not attempt
a test until the unit has completed the power up cycle, which may take up to 5
minutes in cold weather.
NOTE: Do not turn on the ignition key, otherwise the display will indicate KEY OFF. 6
minutes of KEY OFF will cause an early recall.
2. Wait until READY is displayed on the control module before providing a breath
sample. Ensure that you have not ingested anything containing alcohol or rinsed
with mouthwash for 15 minutes prior to providing a breath sample.
3. Insert a new mouthpiece. Using a new mouthpiece practices good hygiene and
ensures a good breath sample.
NOTE: Do not eat, drink or smoke anything for at least 10 minutes before taking a test.
Drinking or smoking could contaminate the breath sample.
4. Blow into the mouthpiece with sufcient and consistent pressure. A tone can be
heard to indicate proper breath ow and “--------” is displayed. Continue blowing for 3
seconds, then blow and hum simultaneously for another 2 seconds until the tone ends.
The control module will display Wait… as it analyzes the breath sample. Do not turn
the ignition key on when the control module displays Wait… as doing so might result in
an abort of the test. The breath test result will be displayed within 10 seconds and can
be interpreted with the chart below:
IF THE CONTROL MODULE… YOU SHOULD…
Displays a Pass LED and displays StartCar Start the engine and drive safely
Displays a Fail LED and displays Lock Out 5
Minutes
Wait 5 minutes before providing another
breath sample
Displays a Fail LED and displays Lock Out 15
Minutes
Wait 15 minutes before providing another
breath sample
Displays a Fail LED and displays
PERMANENT LOCK OUT
Contact your local service centre and DO NOT
attempt another breath test
NOTE: Turning the key to the on position without starting the vehicle for 3 minutes will
cause an early recall.
A Pass BAC is between 0 and .019 mg% and a Fail BAC is over .020 mg% (the legal
limit is .04 mg%).

INSTRUCTION AND COMPLIANCE MANUAL 4
If the control module displays a Fail LED, the vehicle cannot be started and the driver
will be prevented from attempting another test for 5 minutes. If a second Fail BAC test
were to follow, the lockout period would be 15 minutes.
RUNNING RETESTS
Additional breath samples will be required at random intervals of between 5 to 15
minutes for the rst retest to ensure that the driver has not consumed alcohol since the
engine started.
NOTE: If a retest is not taken within 3 minutes, then the control module will display Time
/ Lapse and the vehicle’s horn will sound. Failing to provide another breath sample after
another 3 minutes, or the vehicle is not shut off and the power button pressed, constitutes
a program violation. The interlock service date will be automatically changed to 7 days. The
vehicle must be taken to a service centre for maintenance at an additional expense.
1. Wait until the unit beeps and displays Retest.
Do not provide a breath sample while the vehicle is in motion. The ALCOLOCK
WR2 allows 3 minutes for the driver to stop in a safe location to provide a breath
sample.
The retest must be conducted within 3 minutes of the retest request indication.
2. Blow into the mouthpiece with constant and consistent pressure. A tone can be
heard to indicate proper breath ow. Continue blowing for 3 seconds, then blow
and hum simultaneously for another 2 seconds until the tone ends.
The control module will display Wait… as it analyzes the breath sample. 1 of 2
possible outcomes may occur:
a. A Pass LED is displayed. You may continue driving safely.
b. A Fail LED is displayed. The driver has 3 minutes to pull over and then
press the power button on the control module to acknowledge the failed
breath test. Lock Out 5 Minutes will be displayed. Wait 5 minutes before
providing another breath sample.
WARNING! Ensure that there are no traces of alcohol in your mouth before providing
another breath sample. Another failed breath test will result in a Lock Out 15 Minutes and
then a subsequent PERMANENT LOCK OUT after that.
If a retest is not taken within 3 minutes of the initial indication, the unit will enter a Time
Lapse Fail and display Time Lapse with an alarm horn.
If the test is not taken within a further 3 minutes, or the vehicle is not shut off and the
power button pressed, then the service reminder will be reset to 7 days and the vehicle
will have to be brought in for service at the participant’s additional expense. This is a
program violation.

ALCOLOCK WR25
START VIOLATION
If the vehicle’s engine is started by hot wiring or push starting, then the control module
will display START VIOLATION. This constitutes a program violation. The service
reminder will be automatically reset to 5 days. The vehicle must be taken to a service
centre for maintenance at an additional expense.
PROGRAM VIOLATION
Disconnecting the vehicle’s battery for more than 15 minutes is considered a program
violation. A grace period of 5 minutes is allowed to boost the vehicle’s battery. However,
3 instances of a battery being off for more than 5 minutes will result in an early recall.
The control module will display Early / Service 14 and the service reminder will
be automatically reset to 7 days. The vehicle must be taken to a service centre for
maintenance at an additional expense.
SERVICE DUE
The control module will display Due Date 7 days before the service date. If the vehicle
has not been serviced within 7 days, then the control module will display Past Due and
the missed appointment date.
If the vehicle has not been serviced 5 days after the due date, then the control
module will display PERMANENT LOCK OUT and the vehicle will be permanently
immobilized. The vehicle must be taken to a service centre for maintenance at an
additional expense.
WARNING! If the owner doesn’t contact a service centre after a permanent lockout, then
they may be placed in revoked status by the administering authorities.

INSTRUCTION AND COMPLIANCE MANUAL 6
FEATURES
RESTARTING THE ENGINE
There is a grace period of 3 minutes for the engine to be restarted without providing
another breath sample. In case of engine stalls and / or failures, start the car as normal
and continue driving safely within the allotted time. Another breath sample may be
required if the engine stalls for longer than 3 minutes, but for less than 15 minutes.
NOTE: Letting the vehicle stall for more than 15 minutes may lead to a program violation.
WARM UP
The warm up feature allows the vehicle to idle without having to provide a retest. To
enable this feature, the vehicle must idle lower than the preset limit set by the service
centre.
To activate the warm up feature, press and hold the power button on the control
module until WarmUp is displayed. A retest will not be required within 30 minutes
unless the power button is pressed on the control module, the vehicle idle rises above
the specied limit or if the vehicle stalls.
NOTE: It if the participant’s responsibility to ensure that their vehicle idles properly.
TURNING THE POWER OFF
2 hours after the vehicle engine is switched off, the interlock will automatically power
off. The driver can power off the interlock manually by turning off the ignition, waiting 6
seconds and then holding the power button for 6 seconds.
NOTE: The power lamp will turn off.
DISCONNECTING THE SAMPLING HEAD
The sampling head must be disconnected from the control module in times of cold
weather. Ensure that the sampling head is stored indoors and at room temperature.
Storing the sampling head indoors will shorten the warm up cycle of the unit.
Disconnecting the sampling head will cause the unit to shut off automatically after 3
minutes.
WARNING! Use extreme caution when connecting and disconnecting the sampling head.
Forcing it into place may cause internal components to break and / or malfunction.

ALCOLOCK WR27
EMERGENCY OVERRIDE
WARNING! A driver with an ignition interlock condition on their license is restricted from
driving a vehicle that is in an Emergency Override. Only a driver with a non-conditional
license can operate the vehicle whilst in an Emergency Override.
The vehicle can be started without a breath sample in emergency situations.
1. To activate the Emergency Override function, turn the ignition key on. KEY OFF
will be displayed and a beep can be heard.
2. Press and hold the power button on the control module until EMERGENCY
OVERRIDE is displayed. The vehicle may now be started. When the vehicle starts,
the vehicle alarm horn will sound.
NOTE: The vehicle will continue to be in Emergency Override until the vehicle is shut off
for more than 60 minutes, or when disabled by the driver.
3. To disable an Emergency Override, turn the ignition key off and press and hold the
power button on the control module for 10 seconds.
Once the emergency overide has been activated, the service reminder will be reset to 5
days and the vehicle will have to be brought in for service at the participant’s additional
expense.

INSTRUCTION AND COMPLIANCE MANUAL 8
DISPLAY MESSAGES
NOTE: The ALCOLOCK WR2 may not accept a breath sample and could display error
messages instead. To minimize errors, ensure that the sampling head is connected
properly, the vehicle’s battery is in good condition and that mobile phones are not in use
during the breath sampling process.
The following is a list of messages (including error messages) that the control module
may display:
DISPLAY MESSAGES DESCRIPTION ACTION
ABORT 10 Problem with the sampling
head.
Contact your local service centre.
ABORT 20 Problem with the sampling
head.
Contact your local service centre.
ABORT 30 Problem with the sampling
head.
Contact your local service centre.
ABORT 40 Possible problem with the
sampling head (1 ABORT 40
per 100 tests is considered
normal).
Try the breath test again. Contact
your local service centre if this
message persists.
ABORT 50 Possible problem with the
sampling head (1 ABORT 50
per 100 tests is considered
normal).
Try the breath test again. Contact
your local service centre if this
message persists.
BATTERY / FAULT The battery voltage (Vcar) is
below 8 volts, too low to start
the vehicle.
Charge the vehicle battery or get
a boost.
WARNING! Boosting the vehicle
with more than 18 volts may
damage the unit.
Blow / Harder Blowing pressure is below
the minimum threshold at
any time during the 5 second
sampling period.
Blow harder, especially while
humming and ensure that mobile
phones are off.
Blow / Softer Blowing pressure is above
the maximum threshold at
any time during the 5 second
sampling period.
Blow softer during the breath
sample and ensure that mobile
phones are off.

ALCOLOCK WR29
Blow / then Hum Hum tone detected within the
rst 2 seconds of the breath
sample.
Blow for the rst 3 seconds before
humming.
Due Date Reminder of a scheduled
service appointment. This
message is displayed 7
days prior to the scheduled
appointment.
Take your vehicle to a service
centre on the date displayed.
Early / Service 1 An early service reminder
for 7 days, initiated because
of a time lapse fail of over 3
minutes.
The date shown on the
control module is the
rescheduled service date.
Contact your local service centre to
schedule a new appointment.
Early / Service 2 An early service reminder for
7 days, initiated because of
a PullOver time lapse fail of
over 3 minutes.
The date shown on the
control module is the re-
scheduled service date.
Contact your local service centre to
schedule a new appointment.
Early / Service 3 – 7 An early service reminder for
7 days, initiated because of a
detected service matter.
The date shown on the
control module is the
rescheduled service date.
Contact your local service centre to
schedule a new appointment.
Early / Service 8 A service reminder for 5 days,
initiated because of the use
of the Emergency Override
function.
The date shown on the
control module is the day of
the detected violation.
Contact your local service centre to
schedule a new appointment.
Early / Service 9, 10
and 12
A service reminder for 7 days,
initiated because of a Fail
BAC program violation.
The date shown on the
control module is the day of
the detected violation.
Contact your local service centre to
schedule a new appointment.

INSTRUCTION AND COMPLIANCE MANUAL 10
Early / Service 11 A service reminder for 7
days, initiated because of
5 lockouts within a 30 day
period.
Contact your local service centre to
schedule a new appointment.
Early / Service 14 A service reminder for 7 days,
initiated because of multiple
power disconnects.
The date shown on the
control module is the day of
the detected violation.
Contact your local service centre to
schedule a new appointment.
Early / Service 15 A service reminder for 5
days, initiated by a START
VIOLATION.
The date shown on the
control module is the day of
the detected violation.
Contact your local service centre to
schedule a new appointment.
Early / Service 16 Service Reminder for 7
days with display message,
initiated because of 2
consecutive 15 minute
lockouts.
Contact your local service centre to
schedule a new appointment.
EMERGENCY
OVERRIDE
The WR2 is in Emergency
Override mode.
A driver with a non-conditional
license must drive the vehicle to
a safe location and then turn the
engine off. Contact your local
service centre immediately.
Engine Off Occurs after the ignition
key is turned off. A 3 minute
stall protect timer begins in
which the vehicle may be
started without the need of an
additional breath sample.
Press the power button on the
control module and wait for the unit
to display READY before providing
a breath sample.
Head / Fault The sampling head requires
service.
Contact your local service centre to
schedule a new appointment.
Hi Batt The battery voltage (Vcar) is
above 16.0 volts, indicating a
possible charging problem.
Have your vehicle serviced at a
local garage.
Notify your local service centre
before having your vehicle
serviced.

ALCOLOCK WR211
HUM No hum tone detected during
the 4th and 5th seconds of
the breath sample.
Hum while blowing after the rst 3
seconds of the breath sample.
KEY FAULT
then
Test / Required
If a breath sample is not
provided and the Ignition
On signal is detected for 3
minutes, then the alarm horn
will sound and display KEY
FAULT.
The vehicle will have to be
brought into a service centre
for an early recall.
Ensure that the ignition key is off
before providing a breath test.
Lock Out 5 Minutes Occurs after a failed breath
test (or a failed retest). A
Fail LED light ashes on the
control module and displays
Lock Out 5 Minutes.
The vehicle may not be
started for 5 minutes.
Wait until the lock out period
ends (5 minutes) before providing
another breath sample.
Lock Out 15 Minutes Occurs after a second
consecutive failed breath test
(or retest). A Fail LED light
ashes on the control module
and displays Lock Out 15
Minutes.
The vehicle may not be
started for 15 minutes.
Wait until the lock out period ends
(15 minutes) before providing
another breath sample.
Low Batt The battery voltage (Vcar) is
below 10.4 volts, indicating a
possible battery or charging
problem.
Have your vehicle checked at a
local garage.
Notify your local service centre
before having your vehicle
serviced.
Not Connected The sampling head is partially
or completely unplugged from
the control module.
Plug the sampling head into the
control module.
Past Due / Date This message is displayed
after a missed scheduled
service date. The vehicle
must be taken to your local
service centre within the 5
day grace period, ending on
the date displayed on the
control module.
Contact your local service centre to
schedule a new appointment.

INSTRUCTION AND COMPLIANCE MANUAL 12
PERMANENT LOCK
OUT
The vehicle is permanently
immobilized. It is the result of
failing to report to a service
appointment after the 5 day
grace period has expired.
Contact your local service centre to
schedule a new appointment.
The vehicle must be towed to
the service centre at the owner’s
expense.
Press / Button Occurs 6 seconds after the
ignition switch has been
turned off following a
Time / Lapse or a PullOver.
A breath sample cannot
be supplied until the power
button has been pressed
on the control module and
READY is displayed.
Turn the ignition key off, wait 6
seconds, then press the power
button on the control module.
Provide a breath sample after
READY is displayed.
PullOver Occurs when a Fail BAC
result is recorded on a retest.
The driver has 3 minutes to
pull over in a safe location,
park and turn off the vehicle
before the alarm horn sounds.
Pull over, park and turn off the
vehicle in a safe location. Wait
6 seconds for Press / Button to
appear on the control module.
Press the power button to engage
a lock out.
READY The unit is ready to collect a
breath sample in order to start
the engine.
Provide a breath sample into the
sampling head of the unit.
Relay / Fault There is a problem with the
control module.
Contact your local service centre.
Retest A double alarm horn sounds
and Retest is displayed.
The driver has 3 minutes
to produce another breath
sample.
Conduct the retest as required.
Running! An accepted breath test with
an alcohol concentration
below the limit has been
provided and the vehicle
engine has been started.
Drive safely.

ALCOLOCK WR213
StartCar A breath test has been
passed. You may start the
vehicle.
NOTE: Turning the ignition
key on for 3 minutes
without starting the engine
will cause an early recall.
Start the engine and drive safely.
START VIOLATION
then
Test / Required
If a breath sample is not
provided but the vehicle is
started (by hot wiring or push
starting) a start violation is
recorded and an immediate
(5 day) recall will commence.
START VIOLATION will be
displayed for 30 seconds
while a speaker tone sounds.
Test / Required will be
displayed and the unit
will go through the retest
procedures.
Conduct the breath test as
requested and contact your local
service centre immediately.
Time / Lapse Appears when a retest
request isn’t completed within
3 minutes. The alarm horn
will sound until the driver
pulls over in a safe location
to provide another breath
sample.
Pull over in a safe location and
provide another breath sample or
turn the ignition key off and press
the power button on the control
module after Press / Button is
displayed.
TryAgain Improper test condition. Provide another breath sample
and ensure that all mobile phones
are off.
If the message persists, contact
your local service centre.
Unstable Improper test condition. Provide another breath sample
and ensure that all mobile phones
are off.
If the message persists, contact
your local service centre.

INSTRUCTION AND COMPLIANCE MANUAL 14
WarmUp Prevents the unit from
requesting a retest for 30
minutes as long as the engine
is idling.
Press and hold the power button on
the control module until WarmUp is
displayed.
Wait… The unit is analyzing a breath
sample.
Wait until the breath sample is
analyzed and you are provided with
further instructions.
WAIT… Communication is being
re-established with the control
module when the sampling
head is plugged in.
Wait until READY is displayed
before providing a breath sample.
XXXXXXXXX... There is a power interruption. Disconnecting the vehicle battery
for more than 15 minutes is a
program violation and should not
be done without rst contacting
your local service centre.
MAINTENANCE AND TROUBLESHOOTING
CALIBRATION
Yearly calibration is required to maintain optimum breath test accuracy. The control
module displays Due Date 7 days before a calibration is due.
TROUBLESHOOTING TABLE
The following table lists basic problems that may occur, along with their solutions. For
other problems, contact your dealer.
IF THE WR2… YOU SHOULD…
Will not turn on Check the vehicle battery
Displays an error code Refer to the “Display Messages” section of this
manual
Aborts a breath test Retry the test, or refer to the “Display
Messages” section of this manual
Is in PERMANENT LOCKOUT Contact your local service centre
Requires service Contact your local service centre

IRM-COM-SK-ENG-60-000716-A
© 1992 - 2015
