ADC Adtemp 433 User manual

ADC
®
Adtemp
TM
433 Non-Contact
Infrared Body Thermometer
Instructions
for Use
1

A Special Thank You
Thank you for choosing the ADC®Adtemp™ 433 Non-Contact Thermometer. We're
proud of the care and quality that goes into the manufacture of each and every item
that bears our name. Only the finest materials are used to assure you of a timeless
instrument designed for optimal performance.
You'll quickly appreciate the results, for you now own one of the finest non-contact ther-
mometers that money can buy. With proper care and maintenance, your ADC Adtemp
433 is sure to provide you with many years of dependable service. The information and
instructions that follow will allow you to make the most of your ADC product.
Please read this booklet thoroughly before attempting to use your
new thermometer.
Thank you for your patronage.
It is indeed our pleasure to serve you.
Sincerely,
American Diagnostic Corp.
©2020 AMERICAN DIAGNOSTIC CORP.
2

4
5
5-7
7
7
7
8
8
9
9-10
10-11
11
11
11
12
12
13-14
15-16
17
17
ADC®AdtempTM 433 Non-Contact Infrared Body Thermometer
Table of Contents
1. SYMBOLS
2. INTRODUCTION / INTENDED USE
3. GENERAL WARNINGS AND CAUTIONS
4. USING THE THERMOMETER
4a. Controls and Features
4b. LCD Screen/Display
4c. Selecting a Scan Mode
5. TAKING A MEASUREMENT
6. MEMORY FUNCTION
7. ADJUSTABLE SETTINGS
8. TROUBLESHOOTING / ERROR MESSAGES
9. MAINTENANCE
9a. Replacing the Batteries
9b. Cleaning and Disinfecting
10. CALIBRATION TESTING
11. DISPOSAL
12. TECHNICAL SPECIFICATIONS
13. GUIDANCE AND MANUFACTURER’S DECLARATION
14. WARRANTY
15. CONTACT INFORMATION
3

4
1. SYMBOLS
WARNING: The warning statements in this manual identify conditions or practices that
could lead to illness, injury, or death.
CAUTION: The caution statements in this manual identify conditions or practices that
could result in damage to the equipment or other property, or loss of data.
Refer to operating instructions
Documentation Symbols
Storage Temperature
Storage Humidity
This device complies with Part 15 of the FCC (Federal Communications Commission)
rules
Dispose of this device in accordance with local or national regulations
Protected against solid foreign objects of 12.5mm diameter or greater. Protected against
vertically falling water drops when the device is titled up to 15°.
Recyclable
Restriction of hazardous substances compliant
Manufacturer
Do not throw away. Intended for multiple use.
European authorized representative
Indicator of measurement result
Lot number
Meets essential requirements of European Medical Device Directive 93/42EEC
Storage atmospheric pressure
Serial number
IP22

2. INTRODUCTION / INTENDED USE
Intended use
The Adtemp Non-Contact Infrared Thermometer is a clinical-grade device intended for
the intermittent measurement of human body temperature in people of all ages. It can
also be used to measure the temperature of objects.
Please note, this manual refers to the person whose temperature is being measured as
the “patient.” “Clinician” refers to the person taking the measurement.
3. GENERAL WARNINGS AND CAUTIONS
Warning and caution statements may appear on the thermometer, its packag-
ing, shipping container, or in this instruction manual.
This thermometer is safe for patients and clinicians when used in accordance with the
instructions and warning and caution statements included in this manual. Before using
the thermometer, users must familiarize themselves with the general safety information
included below. Specific warnings and cautions are also found throughout this manual.
Warning: This product is designed to measure human body temperature at the fore-
head or the surface temperature of objects. Do not use it for any other purpose.
Warning: Failure to review and adhere to the recommendations in this manual could
result in personal injury or affect the accuracy of the thermometer itself.
Warning: The infrared sensor can absorb heat from the measurement site, which may
impact reading accuracy. For best results, please allow about five seconds between
measurements.
Warning: Keep this thermometer and its batteries out of the reach of children.
Do not allow children to take their temperature with this thermometer unattended.
Warning: Dispose of this thermometer and its batteries in accordance with local or
national regulations for electronic waste.
Caution: When replacing the batteries, always replace both batteries and ensure that
they are of the type and specification indicated in this manual. Observe correct polarity
when inserting new batteries.
Caution: Do not use rechargeable batteries. The use of rechargeable batteries may
compromise the performance of this device.
5

Caution: Remove the batteries when the device will not be used for an extended period
of time.
Caution: If battery leakage occurs, fully clean the battery compartment using personal
protective equipment prior to re-use.
Caution: Observe proper measurement distance, starting between 5 cm to 15 cm (2”
to 6”) from the patient's forehead. This is essential for measurement accuracy.
Caution: Do not modify or disassemble this device without prior authorization.
Caution: Ensure the thermometer lens is clean and intact prior to use and after meas-
urement is complete.
Caution: Avoid touching the lens directly with your fingers.
Caution: Do not expose the thermometer to extreme temperatures or humidity levels.
Do not expose to direct sunlight.
Caution: The thermometer is not waterproof; do not immerse in water or any other liquid.
Caution: Avoid dropping the device or exposing it to heavy shock or vibration.
Caution: Do not autoclave. Follow only the cleaning procedures described in this
manual.
Caution: Stop using this device if it operates erratically or if the display malfunctions.
Caution: Contact ADC or your local ADC representative for any assistance with this
device. Refer to the warranty section of this manual for contact details.
Caution: When the ambient temperature of the thermometer changes too much, such
as moving the thermometer from one place of lower temperature to another place of
higher temperature, allow the thermometer to remain in a room for 30 minutes where
the temperature is between 59°F to 104°F (15°C to 40°C).
Caution: Wherever possible, take measurements at the same area of the forehead.
Temperatures measured at different measurement sites (e.g., on the temples, on
opposite sides of the head) can vary considerably.
Caution: Head coverings that cover the forehead, perspiration, or hair may affect the
accuracy of measurements.
Caution: Avoid exposing the device to external heat sources or holding the thermome-
ter for an extended period of time as this can impact accuracy. Do not point thermome-
ter directly at known heat sources other than the patient.
6

Caution: If measuring human forehead temperature, select "body" mode; for measur-
ing objects, select "surface" mode.
Caution: Do not store or use near strong electrostatic or strong magnetic fields.
Caution: This product is intended for use as a screening tool in the home, in small
commercial or industrial settings (e.g., offices, factories, warehouses, restaurants,
retails shops, movie theaters) and in medical settings.
Caution: Avoid taking temperature measurements for at least 30 minutes after physical
activity, bathing, swimming, consuming food or beverages, or spending time outdoors.
Caution: If using for high-volume, rapid mass screenings, it is recommended that the
unit be allowed to rest for up to 30 seconds every 5 to 10 measurements so that the IR
temperature sensor can reset and stabilize.
4. USING THE THERMOMETER
4a. Controls and Features
7
1. IR sensor
2. Liquid crystal display (LCD)
3. MODE button
4. Down Arrow button
5. Up Arrow button
6. SET button
7. On/Measure button
8. Battery cover
9. Surface mode
10. Body mode
11. Data indicator
12. Indicator of measurement result
13. Low-battery indicator
14. Volume on/off indicator
15. Fahrenheit
16. Memory number
17. Celsius
18. Memory indicator
4b. LCD Screen/Display

8
4c. Selecting a Scan Mode
With the power on, press the Mode button to switch
between body mode and surface mode. Body mode
is used for measuring human body temperature.
Surface mode is used to measure an object’s
surface temperature.
(The factory default is "body" mode.)
5. TAKING A MEASUREMENT
1. Turn on the thermometer by pressing the On/Measure button. The thermometer
will perform a self-test with all segments displayed for two seconds, followed by
three consecutive beeps. When ready to measure the display will look like this:
2. If needed, press the Mode button to change between body mode and surface mode.
3. Position the thermometer about 2" to 6" (5 cm to 15 cm) from the center of the
patient's forehead with the sensor aimed between the eyebrows.
4. Press and release the On/Measure button to start measurement. The unit will
beep once when the measurement is complete. The backlight color will display
green, yellow, or red depending upon the reading obtained.
Green: ≤99.2°F (37.3°C)
Yellow: 99.3°F to 100.5°F (37.4°C – 38.0°C)
Red: ≥100.6°F (38.1°C)
Note: For best results, please allow about five seconds between measurements. If
using for high-volume, rapid mass screenings, please allow a 30-second rest every five
to ten measurements. These precautions will prevent the infrared sensor from absorb-
ing heat from the measurement site, which can affect accuracy.
Note: If the patient’s skin is covered with hair, perspiration, or dirt, clean the area and
wait 10 minutes before taking a measurement.
Note: Ensure that the thermometer is held firmly during measurement and that the pa-
tient does not move until the measurement is complete. Patient movement can impact
the measurement.

9
6. MEMORY FUNCTION
The unit retains the last 50 readings. The newest reading will occupy memory cell 1,
the oldest, memory cell 50.
To recall previous readings:
1. With the power off, press the up "▲" or down "▼" button to view the history of
measured values. The display will indicate whether the reading was a body or
surface temperature measurement.
2. An empty memory cell shows “---°C” or “---°F”.
Note: Once 50 measurements are in memory each new measurement will overwrite
the oldest.
To delete readings from memory:
1. With the power on, press and hold the up "▲" or down "▼" button multifunction
key until the display shows "CLR." The device will sound a long beep, which means
that all stored temperature readings have been cleared.
Note: All readings (body and surface) will be cleared when deleting readings from memory.
7. ADJUSTABLE SETTINGS
The Adtemp 433 has three adjustable settings:
F1 Temperature Scale F/C
1. With the instrument on, press the SET button until the display reads F1.
2. Press the up "▲" or down "▼" button to move between Celsius and Fahrenheit scale.
3. Press the SET button to confirm the new setting.
Please note: The factory default is Fahrenheit.
F2 Fever-Alert Threshold
The fever-alert threshold is the temperature at which the backlit display color
turns red. The default fever alert is 100.6°F (38.1°C).
To change the threshold:
1. With the instrument on, press the SET button twice (until the display reads F2).
2. Press the down “▼” button to decrease by 0.2° F. Press the up "▲" button to
increase 0.2° F.
3. Press the SET button to save.

10
F3 Silent Mode
Silent mode will keep the unit from beeping.
To turn silent mode on or off:
1. With the instrument on, press the SET button three times (until the display
reads F3).
2. Press the down “▼” button or up "▲" button to toggle between on or off.
3. Once the desired mode is selected, press the SET button to save.
Factory Reset: Adjustable settings can be cleared by performing a factory reset. With
the unit on, press and hold the MODE button until RES appears in the display. This will
also clear any saved readings from memory.
8. TROUBLESHOOTING / ERROR MESSAGES
Display Situation Solution
Temperature taken is not within typical
human temperature range.
(93.2°F ~ 109.4°F or 34.0°C ~ 43.0°C)
Operating temperature exceeds the range
of specified temperature.
The screen flickered, and automatically
turned off.
Take measurement again.
Move to a room within operat-
ing range, wait 30 minutes
before taking temperature.
Replace battery or the
product has been damaged,
needs repair.
Low battery indication. Replace with new battery.
Measured over the distance 2-5.9 in
(5-15 cm).
Hair, antipyretic stickers, perspiration, or
dirt can interfere with measurement.
Move closer to patient.
Clean measurement area.
Body °F
Body °F
Body °F
Body °F

11
9. MAINTENANCE
9a. Replacing the Batteries
The thermometer comes with two 1.5V AAA (LR03) alkaline batteries. Replace with two
new AAA (LR03) batteries when the low-battery symbol “ ” appears on the display.
Ensure correct polarity as indicated inside the battery cover. Always replace both batter-
ies at the same time. Remove batteries when the thermometer will not be used for an
extended period of time.
9b. Cleaning and Disinfecting
Use only a soft cloth to clean the surface of the device and LCD with 70% isopropyl
(rubbing) alcohol. Do not use unapproved cleaning or disinfection agents. Use of these
agents may cause damage to components.
Caution: Never use abrasive cleaning agents, thinners, benzene or submerge the ther-
mometer in water.
Caution: Always keep the thermometer within storage temperature range and humidity range.
Caution: Never use water to wash the thermometer lens directly. Slightly moisten a cot-
ton swab or cloth with isopropyl (rubbing) alcohol and gently wipe the surface of the lens.
Caution: Never insert a sharp object into the scanner area or any other open surface
on the thermometer.
Caution: Avoid touching the lens except when cleaning is required.
Note: ADC is not responsible for validating alternative cleaning or disinfection processes
outside of our facility. You should determine the requirements for personnel, equipment,
and materials necessary to achieve your desired disinfection levels and may need to em-
ploy routine monitoring of your disinfection protocols within your facility. After cleaning
or disinfecting, wait at least 10 minutes prior to taking another measurement.
Ambient temperature changes too fast. Wait until the ambient
temperature is stable.
1. Power is off.
2. Improper battery installation.
3. The battery is exhausted.
4. Display remains blank.
1. Press ON button again.
2. Check the battery polarity.
3. Replace with new batteries.
4. Contact Customer Service.

10. CALIBRATION TESTING
This thermometer is calibrated at the time of manufacture. If the thermometer is oper-
ated in accordance with these instructions, periodic readjustment is not required. ADC
recommends checking calibration on an annual basis or whenever clinical accuracy of
the thermometer is in question.
11. DISPOSAL
The thermometer contains no hazardous materials. Remove the batteries before disposal.
Discard both thermometer and batteries in accordance with national or local regulations.
12

13
Measurement unit: °F / °C
Operating mode: Adjusted mode (Body mode)
Direct mode (Surface mode)
Measuring site: Forehead
Reference body site: Axillary
Measurement range: Body mode:
93.2°F to 109.4°F (42.9°C to 43.0°C)
Surface mode:
32.0°F to 212.0°F (0°C to 100.0°C)
Accuracy: Body mode:
93.2°F to 94.8°F: ±0.5°F (34.0°C to 34.9°C:±0.3°C);
95.0°F to 107.6°F: ±0.4°F (35.0°C to 42.0°C:±0.2°C);
107.8°F to 109.4°F: ±0.5°F (42.1°C to 3.0°C:±0.3°C)
Surface mode:
±3.6°F (±2°C)
Display resolution: 0.1°F / 0.1°C
Three-color backlight: 95.9°F to 99.2°F (35.5°C to 37.3°C):
(Color alarm) Green (Normal temperature)
99.3°F to 100.5°F (37.4°C to 38.0°C):
Yellow (Slight fever)
100.6°F to 109.4°F (38.1°C to 43.0°C):
Red (High fever)
Note:
Surface mode is always Green backlight.
Facial indication: Happy Face: 95.9°F to 99.2°F (35.5°C to 37.3°C)
Sad Face: 99.3°F to 109.4°F (37.4°C to 43.0°C)
Auto power off time: ≤18 seconds
Measuring time: 2 seconds
Measuring distance: 2in - 5.9in (5cm - 15cm)
Memory: 50
Power Supply Requirements
Batteries: 1.5V (AAA) Alkaline battery (x2) (IEC Type LR03)
Battery life: 2,000 measurements
Adaptable range: 2.6V~3.6V
Environmental
Operating condition: Operating temperature: 59°F to 104°F (15°C to 40°C)
Relative humidity: 85%,
Atmospheric pressure: 70 Kpa - 106 Kpa
12. TECHNICAL SPECIFICATIONS

14
Safety classification of ME equipment
Protection against
electric shock: Internally powered ME equipment
Applied part: Non applied part
Protection against harmful
ingress of water or
particulate matter: IP22
Mode of operation: Continuous operation
NOTE: Not intended to be sterilized. Not for use in an oxygen rich environment.
Transport/Storage Storage temperature: -4°F to 131°F (-20°C to 55°C)
condition: Relative humidity: 93%,
Atmospheric pressure: 70 Kpa - 106 Kpa
Dimension and Weight
Weight: .26 lbs (116g) (without batteries)
Size: 5.9” L x 3.7” W x 1.7” H (150mm x 95mm x 44mm)
Compliance
Item: Compliant with
Equipment classification:
Safety standards: EN 60601-1: 2006+A1:2013,
EN 60601-1-1-2: 2015
Type of protection: Internally powered equipment (on battery power)
Degree of protection: Non applied part
Front panel and
case labeling: EN ISO 15223-1:2016
Temperature: EN ISO 80601-2-56:2017
Home healthcare
environment: EN ISO 60601-1-11:2015
Calculated values of the indicators according to ISO 80601-2-56
Indicators: Calculated value
Clinical bias, ▲cb: -0.027
Standard deviation, j: 0.14
Limits of agreement, LA:0.26
Clinical repeatability, r: 0.07
NOTE: The above value is calculated from clinical data of the 433 (Model HTD8818A).

15
Guidance and manufacture’s declaration - electromagnetic emission
The Infrared Body Thermometer is intended for use in the electromagnetic environment specified below.
The customer or the user of the Infrared Body Thermometer should assure that it is used in such an environment.
Anti-interference detection IEC 60601 test level Compliance level
Electrostatic discharge (ESD)
IEC 61000-4-2
Contact: +8 KV
Air: +2,+4,+8,+15 KV
Contact: +8 KV
Air: +2,+4,+8,+15 KV
Surge
IEC 61000-4-5
Input power ports: +0.5, +1.0 KV
Signal input/output:+2.0 KV Not applicable
Surge
IEC 61000-4-5
Voltage dips
IEC 61000-4-11
Voltage interruption
IEC 61000-4-11
Power frequency (50H z / 60 H z)
magnetic field IEC 61000-4-8 30A/m 30A/m
NOTE: UT is the a.c. mains voltage prior to application of the test level.
250 (50Hz)/300 (60Hz) cycles for
>95% UT (sync angle (degrees):0)
0.5 cycles for > 95%
(sync angle (degrees):0, 45, 90,
135, 180,225, 270, 315)
1 cycles for >95% UT
(sync angle (degrees):0)
25 (50Hz)/30 (60Hz) cycles for
30% U T (sync angle (degrees):0)
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth Not applicable
Not applicable
Guidance and manufacture’s declaration - electromagnetic emission
Immunity Test IEC 60601 test level Compliance level
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
Radiated RF
IEC 61000-4-3
Professional healthcare environment:
3 V/m home
Healthcare environment:
10 Vm 80 MHz to 2700 MHz
Professional healthcare environment:
3 V/m home
Healthcare environment:
10 Vm 80 MHz to 2700 MHz
Not applicable
NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
a) Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mo-
bile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with ac-
curacy. To access the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey
should be considered. If the measured field strength in the location in which the Non Contact Infrared Body Ther-
mometer is used exceeds the applicable RF compliance level above, the Non Contact Infrared Body Thermometer
should be observed to verify normal operation. If abnormal performance is observed, additional measures may be
necessary, such as re-orienting or relocating the Non Contact Infrared Body Thermometer.
b) Over the frequency range 150 kHz to 80 MHz, Field strength should be less than 3 V/m.
The Infrared Body Thermometer is intended for use in the electromagnetic environment specified below.
The customer of the user of the Infrared Body Thermometer should assure that it is used in such an environment.
13. GUIDANCE AND MANUFACTURER’S DECLARATION

16
Guidance and manufacture’s declaration - RF wireless communication equipment immunity
Pulse
modulation b)
18 Hz
FMc)
5 kHz standard
deviation
1 kHz sinusoidal
710
745
780
810
870
930
1720
1845
1970
5240
5500
5785
2450
Pulse
modulation
b)
217 Hz
Pulse
modulation
b)
217 Hz
Pulse
modulation
b)
217 Hz
Local network
802.11
year wireless
Pulse
modulation
b)
217 Hz
Pulse
modulation
b)
18 Hz
GSM 800/900;
TETRA 800;
IDEN 820;
CDMA 850;
Band LTE 5
Bluetooth,
Wireless LAN, 802.11
b / g / n, RFID 2450,
LTE Band 7
GSM 1800;
CDMA 1900;
GSM 1900;
DECT;
Band LTE 1, 3, 4,
25; UMTS
a) Some services include only uplink frequencies.
b) The carrier wave should be modulated using a 50% duty cycle square wave modulated.
c) As an alternative to frequency modulation, 50% pulse modulation at 18 Hz can be used because, although it does not
represent actual modulation, it would be the worst option.
1,8
2
0,2
2
2
2
0,2
380-390
430-470
704-787
800-960
1700-1990
2400-2570
5100-5800
385
450
TETRA 400
GMRS 460,
FRS 460
Band LTE 13, 17
0,3
0,3
0,3
0,3
0,3
0,3
0,3
27
28
9
28
28
28
9
Frequency
Test (MHz)
Band a)
(MHz)
Service a) Modulation b) Maximum
Power
(W)
Distance
(m)
IMMUNITY
TEST LEVEL
(V/m)
Guidance and manufacture’s declaration - electromagnetic emission
The Infrared Body Thermometer is intended for use in the electromagnetic environment specified below.
The customer or the user of the Infrared Body Thermometer should assure that it is used in such an environment.
Emission test Compliance
RF emissions CISPR 11 Group 1
RF emission CISPR 11 Class B
Harmonic emissions IEC 61000-3-2 Not applicable
Voltage Fluctuations/flicker emissions Not applicable
IEC 61000-3-3

17
14. WARRANTY
This thermometer is guaranteed for a period of two years from date of purchase. This
warranty does not cover batteries or damage resulting from improper handling or use.
Specific legal rights stipulated in your state may guide this warranty. If you have a legit-
imate claim under this warranty, send item(s) postage paid to ADC Attn: Repair Dept.,
55 Commerce Dr., Hauppauge, NY 11788. Please include your name and address,
phone no., proof of purchase, and a brief note explaining the problem.
Implied Warranty: Any implied warranty shall be limited in duration to the terms of
this warranty and in no case beyond the original selling price (except where prohibited
by law). This warranty gives you specific legal rights and you may have other rights
which vary from state to state.
For Australian Consumers: Our goods come with guarantees that cannot be ex-
cluded under the Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and compensation for any other reasonably foreseeable loss or dam-
age. You are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a major failure.
15. CONTACT INFORMATION
To register your product visit us at
www.adctoday.com/register
This manual is available online in a
variety of languages,
follow the links for language options.
www.adctoday.com/care

Hetaida Technology Co., Ltd.
4F, BaiShiDa High-Tech Park
XiangDong Industrial Area,
DaLingShan Town,
DongGuan City,
GuangDong, China
Wellkang, Ltd.
16 Castle St, Dover, CT16 1PW, UK
Distributed by: ADC®
55 Commerce Drive
Hauppauge, NY 11788
Inspected in the U.S.A.
Made in China
tel: [phone]
1-800-232-2670
fax: [phone]
email: [e-mail]
www.adctoday.com
0598
IB p/n 93-433EU-00 rev 0 Printed in China
18
REF 433EU
Model HTD8808C
