User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 1 of 27
User Manual
Revision 1 000
English
PROFINET Master / Ethernet - Converter
(Order Code: HD67B84-A1)
for Website information:
http://www adfweb com/?Product=HD67B84
for Price information:
http://www adfweb com/?Price=HD67B84-A1
Benefits and Main Features:
Triple electrical isolation
Two Ethernet ports
Temperature range: -40°C/+85°C (-40°F/+185°F)
For others PROFINET Master devices, see also the following links:
PROFINET Master from/to …
www adfweb com?Product=HD67B45 (OPC U Server)
www adfweb com?Product=HD67B70 (Serial)
www adfweb com?Product=HD67B71 (Modbus Slave)
www adfweb com?Product=HD67B72 (PROFIBUS Slave)
www adfweb com?Product=HD67B73 (C N)
www adfweb com?Product=HD67B74 (C Nopen)
www adfweb com?Product=HD67B75 (DeviceNet Slave)
www adfweb com?Product=HD67B76 (Modbus TCP Slave)
www adfweb com?Product=HD67B77 (SNMP gent)
www adfweb com?Product=HD67B78 (EtherNet/IP Slave)
www adfweb com?Product=HD67B79 (KNX)
www adfweb com?Product=HD67B80 (MQTT)
www adfweb com?Product=HD67B81 (B Cnet Slave)
www adfweb com?Product=HD67B82 (IEC 61850 Server)
Do you have an your customer protocol?
See the following links:
www adfweb com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www adfweb com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 2 of 27
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 10
USE OF COMPOSITOR SW67B84 11
NEW PROJECT / OPEN PROJECT 12
SOFTWARE OPTIONS 13
SET COMMUNICATION 15
PROFINET ACCESS 16
UPDATE DEVICE 19
ETHERNET PROTOCOL 21
MECHANICAL DIMENSIONS 24
ORDERING INFORMATIONS 25
ACCESSORIES 25
DISCLAIMER 26
OTHER REGULATIONS AND STANDARDS 26
WARRANTIES AND TECHNICAL SUPPORT 27
RETURN POLICY 27
Pagina 2 di 27
UPD TED DOCUMENT TION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document
With this “Document Code” go to web page www adfweb com/download/
and search for the corresponding code on the page Click on the proper
“Document Code” and download the updates
REVISION LIST:
Revision Date uthor Chapter Description
1 000 13/03/2019 Ff All First release version
W RNING:
ADFweb com reserves the right to change information in this manual about
our product without warning
ADFweb com is not responsible for any error this manual may contain
TR DEM RKS:
All trademarks mentioned in this document belong to their respective
owners

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 3 of 27
SECURITY LERT:
G ENER L I NFORM TION
To ensure safe operation, the device must be operated according to the instructions in the manual When using the device, legal and
safety regulation are required for each individual application The same applies also when using accessories
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i e
independent limit switches, mechanical interlocks, etc )
Q U LIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job
R ESIDU L R ISKS
The device is state-of-the-art and is safe The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage
CE CONFORMITY
The declaration is made by our company You can send an email to support@adfweb com or give us a call if you need it

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 4 of 27
EX MPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 5 of 27
CONNECTION SCHEME:
Figure
1
: Connection scheme for HD67
B84
-
A
1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 6 of 27
CH R CTERISTICS:
The HD67B84-A1 is a PROFINET Master / Ethernet converter
It allows the following characteristics:
Up to 4096 bytes in reading and 4096 bytes in writing;
Two-directional information between Ethernet and PROFINET;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F]
CONFIGUR TION:
You need Compositor SW67B84 software on your PC in order to perform the following:
Define the parameter of the PROFINET;
Define the parameter of the Ethernet;
Define the list of PROFINET slaves connected to the converter;
Update the device

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 7 of 27
POWER SUPPLY:
The devices can be powered between a wide range of tensions For more details see the two tables below
V C
VDC
Vmin Vmax Vmin Vmax
HD67B84- 1 8V 24V 12V 35V
Consumption at 24V DC:
Device W/V
HD67B84-A1 4
Caution: Not reverse the polarity power
HD67B84-A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 8 of 27
FUNCTION MODES:
The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:
The first, with Dip1 in Off position (factory setting), is used for the normal working of the device
The second, with Dip1 in On position, is used for upload the Project/Firmware
For the operations to follow for the updating (see ‘UPDATE DEVICE’ section)
According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section)

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 9 of 27
LEDS:
The device has got six LEDs that are used to give information of the functioning status
The various meanings of the LEDs are described in the table below
LED Normal Mode Boot Mode
1: ON [supply voltage ]
(green)
ON: Device powered
OFF: Device not powered
ON: Device powered
OFF: Device not powered
2: MT [maintenance display]
(yellow)
ON: Maintenance are present
OFF: No maintenance are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: BF [bus fault] (red)
ON: The Ethernet connection is defective; the IP
address exists several times in the network; the own
NameOfStation exists several times in the network; no
IP address has been set
Flashing: At least one configured AR is no longer in
the data exchange
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: SF [group error] (red) ON: At least one AR is not in the data exchange
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Ethernet1 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
6: Ethernet2 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 10 of 27
ETHERNET:
The Ethernet connection must be made using Connector3 or Connector4 of HD67B84-A1 with at least a Category 5E cable The maximum
length of the cable should not exceed 100m The cable has to conform to the T568 norms relative to connections in cat 5 up to 100 Mbps To
connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended
the use of a cross cable

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 11 of 27
USE OF COMPOSITOR SW67B84:
To configure the Converter, use the available software that runs with Windows called SW67B84 It is downloadable on the site
www adfweb com and its operation is described in this document (This manual is referenced to the last version of the software present on
our web site) The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit)
When launching the SW67B84, the window below appears (Fig 2)
Note:
It is necessary to have installed Net Framework 4
Figure 2: Main window for SW67B84

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 12 of 27
NEW CONFIGUR TION / OPEN CONFIGUR TION:
The “New Configuration” button creates the folder which contains the entire device’s configuration
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “PROFINET Master / Ethernet -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 13 of 27
SOFTW RE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor
In the section “Language” it is possible to change the language of the
software
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb com website
Checking the option “Check Software Update at Start of Program”, the
SW67B84 check automatically if there are updatings when it is launched

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 14 of 27
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 15 of 27
SET COMMUNIC TION:
This section define the fundamental communication parameters of two buses,
PROFINET and Ethernet
By Pressing the “Set Communication” button from the main window for SW67B84
(Fig 2) the window “Set Communication” appears (Fig 3)
The means of the fields for “PROFINET Master” are:
In the fields “IP ddress” the IP address for PROFINET side of the converter is
defined;
In the fields “SubNet Mask” the SubNet Mask for PROFINET side of the
converter is defined;
In the fields “Gateway” the default gateway of the net is defined This feature
can be enabled or disabled pressing the Check Box field This feature is used
for going out of the net;
In the field "Name of Station" the name of the PROFINET node is defined
The means of the fields for “Ethernet” are:
In the fields “IP ddress” the IP address for Ethernet side of the converter is
defined;
In the fields “SubNet Mask” the SubNet Mask for Ethernet side of the
converter is defined;
In the fields “Gateway” the default gateway of the net is defined This feature
can be enabled or disabled pressing the Check Box field This feature is used
for going out of the net;
In the field “TCP Port” the TCP port used for Ethernet communication is
defined;
In the field “UDP Port” the UDP port used for Ethernet communication is
defined
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 16 of 27
Figure 4: “Definition of ROFINET Devices resent in Network” window
PROFINET CCESS:
By Pressing the “PROFINET ccess” button from the main window for SW67B84 (Fig 2) the window “Definition of PROFINET Devices
Present in Network” appears (Fig 4)
This section is used to define the list of the PROFINET slaves to read/write with the PROFINET Master It is possible to add the PROFINET
slaves from the hardware catalog If a new device will be connected, it is possible to instal the GSDML file

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 17 of 27
The means of the fields below are:
If the field “Name of Station” is checked, the name of the PROFINET slave is defined;
In the field “IP ddress” the IP Address of the PROFINET slave is defined;
If the field “ utomatic new session when StationProblemIndicator is active” is checked, the converter will restart the
PROFINET communication when the error indicator in the slave is present;
In the field “Update Time [ms]” the delay used for IO communication is defined;
In the field “ nswer TimeOut” the allowed number of cycles without response from the slave is defined
Warning:
The data from/to the slaves are mapped consecutively into the IN/OUT PROFINET arrays, following the order with which they are
defined

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 18 of 27
Figure 5: “Definition Module and/or Submodules of ROFINET Device” window
By clicking on “Modules” button, it is possible to import the modules for the selected PROFINET slave device The window “Definition Module
and/or Submodules of PROFINET Device” appears (Fig 5) In the main table it is possible to import the Modules of the PROFINET device in
use In the properties below, it is possible to set the parameters of the slave These options depends on the slave in use, refer to the manual
of the PROFINET device
The means of the checkboxes inside the table are:
If the field “Map Only Data” is checked, only the data of the modules are mapped into the PROFINET arrays Otherwise, for each
module there will be the status of IN and OUT areas too (1 byte);
If the field “Different Word” is checked, the data of the different modules are mapped in different and consecutive words without
splitting them

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 19 of 27
UPD TE DEVICE:
By pressing the “Update Device” button, it is possible to load the created
Configuration into the device; and also the Firmware, if necessary This by using the
Ethernet port
If you don’t know the actual IP address of the device you have to use this procedure:
Turn OFF the Device;
Put Dip2 of ‘Dip-Switch A’ in ON position;
Turn ON the device
Connect the Ethernet cable;
Insert the IP “192.168.2.205”;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn OFF the Device;
Put Dip2 of ‘Dip-Switch A’ in OFF position;
Turn ON the device
If you know the actual IP address of the device, you have to use this procedure:
Turn ON the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode
At this point the configuration/firmware on the device is correctly updated
Figure 6: “Update device” windows

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET Master /
Ethernet
Document code: MN67B84_ENG Revision 1 000 Page 20 of 27
Note:
When you receive the device, for the first time, you also have to update the Firmware in the HD67B84 device
Warning:
If Fig 7 appears when you try to do the Update try these points before seeking
assistance:
Check if the serial COM port selected is the correct one;
Check if the serial cable is connected between the PC and the device;
Try to repeat the operations for the updating;
Try with another PC;
Try to restart the PC;
Check the LAN settings;
If you are using the program inside a Virtual Machine, try to use in the main
Operating System;
If you are using Windows Seven, Vista, 8 or 10 make sure that you have the
administrator privileges;
In case you have to program more than one device, using the "UDP Update", you
have to cancel the ARP table every time you connect a new device on Ethernet
For do this you have to launch the "Command Prompt" and write the command
"arp -d" Pay attention that with Windows Vista, Seven, 8, 10 you have to launch
the "Command Prompt" with Administrator Rights;
Pay attention at Firewall lock
Warning:
In the case of HD67B84 you have to use the software “SW67B84”: www adfweb com\download\filefold\SW67B84 zip
Figure
7
:
“
Error
” window
