ADF Web HD67D25-B2-868MHz User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 1 of 3
User Manual
Revision 1.
English
LoRaWAN / EtherNet/IP Slave - Converter
(Order Code: HD67D25-B2-868MHz
For Website information:
www.adfweb.com?Product=HD67D25-B2
For Price information:
www.adfweb.com?Price=HD67D25-B2-868MHz
Benefits and Main Features:
Very easy to configure
Power Supply 18…35V DC and 8…24 V AC
Temperature range: -4 °C/+85°C (-4 °F/+185°F)
For others LoRaWAN products, see also the following links:
Converter LoRaWAN to
www.adfweb.com?Product=HD67D 1 LoRaWAN)
www.adfweb.com?Product=HD67D 2 LoRaWAN)
www.adfweb.com?Product=HD67D 3 Modbus TCP Master)
www.adfweb.com?Product=HD67D 4 Modbus TCP Slave)
www.adfweb.com?Product=HD67D 5 Serial)
www.adfweb.com?Product=HD67D15 M-Bus)
www.adfweb.com?Product=HD67D16 BACnet Master)
www.adfweb.com?Product=HD67D17 BACnet Slave)
www.adfweb.com?Product=HD67D18 EtherNet)
www.adfweb.com?Product=HD67D19 CAN)
www.adfweb.com?Product=HD67D2 CANopen)
www.adfweb.com?Product=HD67D21 DeviceNet Master)
www.adfweb.com?Product=HD67D22 DeviceNet Slave)
www.adfweb.com?Product=HD67D23 DMX)
www.adfweb.com?Product=HD67D24 EtherNet/IP Master)
www.adfweb.com?Product=HD67D26 J1939)
www.adfweb.com?Product=HD67D27 KNX)
www.adfweb.com?Product=HD67D28 NMEA 0183)
www.adfweb.com?Product=HD67D29 NMEA 2000)
www.adfweb.com?Product=HD67D3 PROFIBUS Master)
www.adfweb.com?Product=HD67D31 PROFIBUS Slave)
www.adfweb.com?Product=HD67D32 PROFINET Master)
www.adfweb.com?Product=HD67D33 PROFINET Slave)
www.adfweb.com?Product=HD67D34 IEC61850 Client)
www.adfweb.com?Product=HD67D35 IEC61850 Server)
www.adfweb.com?Product=HD67D36 MQTT)
www.adfweb.com?Product=HD67D37 OPC UA Client)
www.adfweb.com?Product=HD67D38 OPC UA Server)
www.adfweb.com?Product=HD67D39 S7comm)
www.adfweb.com?Product=HD67D4 SNMP Manager)
www.adfweb.com?Product=HD67D41 SNMP Agent)
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 2 of 3
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
LORAWAN 1
ETHERNET 11
USE OF COMPOSITOR SW67D25 12
NEW CONFIGURATION / OPEN CONFIGURATION 13
SOFTWARE OPTIONS 14
SET COMMUNICATION 16
LORAWAN ACCESS 18
UPDATE DEVICE 2
LORAWAN PAYLOAD 22
PLC CONFIGURATION 23
MECHANICAL DIMENSIONS 27
ORDERING INFORMATIONS 28
ACCESSORIES 28
DISCLAIMER 29
OTHER REGULATIONS AND STANDARDS 29
WARRANTIES AND TECHNICAL SUPPORT 3
RETURN POLICY 3
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Chapter Description
1. 4/12/2 2 Ff All First release version

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 3 of 3
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 4 of 3
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 5 of 3
CONNECTION SCHEME:
Figure 1: Connection scheme for HD67D25- 2-xxxMHz

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 6 of 3
CHARACTERISTICS:
The HD67D25-B2 is a LoRaWAN / EtherNet/IP Converter.
It allows the following characteristics:
Electrical isolation between EtherNet/IP and Power Supply;
Mountable on 35mm Rail DIN;
Wide power supply input range: 12…35V DC and 8…24V AC;
Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].
CONFIGURATION:
You need Compositor SW67D25 software on your PC in order to perform the following:
Define the parameter of LoRaWAN line;
Define the parameter of EtherNet/IP line;
Define the list of LoRaWAN messages in uplink and downlink to the LoRaWAN gateway;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 7 of 3
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67D25-B2-xxxMHz 3.5
H
D67D
25
-
B2
-
xxxMHz
Caution: Not reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 8 of 3
FUNCTION MODES:
The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 9 of 3
LEDS:
The device has got four LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
2: LoRaWAN communication
(yellow) Blinks when LoRaWAN data is received Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
3: Ethernet/IP
communication (yellow) Blinks when a Ethernet/IP request is received Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
4: Error state (yellow) ON: An error in the communication busses occurs
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 1 of 3
LORAWAN:
The LoRaWAN® specification is a Low Power, Wide Area (LPWA) networking protocol designed to
wirelessly connect battery operated ‘things’ to the internet in regional, national or global
networks, and targets key Internet of Things (IoT) requirements such as bi-directional
communication, end-to-end security, mobility and localization services.
LoRaWAN® network architecture is deployed in a star-of-stars topology in which gateways relay
messages between end-devices and a central network server.
The wireless communication takes advantage of the Long Range characteristics of the LoRa
physical layer, allowing a single-hop link between the end-device and one or many gateways. All
modes are capable of bi-directional communication, and there is support for multicast
addressing groups to make efficient use of spectrum during tasks such as Firmware Over-The-
Air (FOTA) upgrades or other mass distribution messages.
Converters from HD67D25 serie act as end-devices and they can communicate with one or more
LoRwaWAN Gateways.
The converters support all the standard datarates and they work both on public and private
networks.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 11 of 3
ETHERNET:
The Ethernet port is used for programming the device and for EtherNet/IP communication.
The Ethernet connection must be made using Connector2 of HD67D25-B2 with at least a Category 5E cable. The maximum length of the
cable should not exceed 1 m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 1 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 12 of 3
USE OF COMPOSITOR SW67D25:
To configure the Converter, use the available software that runs with Windows called SW67D25. It is downloadable on the site
www.adfweb.com and its operation is described in this document. The software works with MS Windows (XP, Vista, Seven, 8, 1 ; 32/64bit).
When launching the SW67D25, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
F
igure 2: Main window for SW67D
25

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 13 of 3
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a Programmable “LoRaWAN / EtherNet/IP Slave -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 14 of 3
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67D25 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 15 of 3
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 16 of 3
SET COMMUNICATION:
By Pressing the “Set Communication” button from the main window for SW67D18
(Fig. 2) the window “Set Communication” appears (Fig. 3).
The means of the fields for the “LoRaWAN” section are:
In the field “RF Band” the wireless band used for LoRaWAN communication
is defined;
In the field “Network Type” the type of LoRaWAN network is defined;
If the field “Adaptive Data Rate” is checked, the converter will enable the
ADR functionalities to select the best data rate to be used in relation to the
environmental conditions;
In the field “Data Rate” the data rate for LoRaWAN communication is
defined;
In the field “Transmission Type” the type of LoRaWAN communication is
defined;
In the field “Max Payload Size” the maximum dimension of the LoRaWAN
messages is defined (fixed in relation to the data rate selected);
In the field “Activation Method” the method used to join into a LoRaWAN
network is defined;
In the field “Device Address” the device identifier (DevEUI) is defined (only
for ABP method);
In the field “Application Identifier” the application identifier (AppEUI) is
defined (only for ABP method);
In the field “Network Session Key” the key used for the communication
with the LoRaWAN gateway (NwkSKey) is defined (only for ABP method);
In the field “Application Session Key” the key for encryption and
decryption of the payload (AppSKey) is defined (only for ABP method);
If OTAA method is selected, in the field “Application Key” the secret key
for the dynamic activation of the converter in the LoRAWAN network is
defined.
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 17 of 3
The means of the fields for “EtherNet/IP” are:
In the field “IP Address” the IP address for EtherNet/IP side of the converter is defined;
In the field “SubNet Mask” the SubNet Mask for EtherNet/IP side of the converter is defined;
In the field “Gateway” the default gateway of the net is defined. This feature can be enabled or disabled pressing the Check Box
field. This feature is used for going out of the net;
In the field “Port” the port used for EtherNet/IP communication is defined. The port has a fixed value of 44818.
In the fields “Number Byte IN” the number of input byte of the slave station is defined;
In the fields “Number Byte Out” the number of output byte of the slave station is defined.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 18 of 3
Figure 4a: “LoR
a
WAN Access

LoRaWAN Upli
nk” window
LORAWAN ACCESS:
By Pressing the “LoRaWAN Access” button from the main window for SW67D25 (Fig. 2) the window “Set LoRaWAN Access” appears (Fig.
4). This section is used to define the LoRAWAN messages where the converter will place the data read from Ethernet/IP (Uplink) and the
LoRAWAN messages that the converter will take (Downlink) for writing the data to Ethernet/IP.
L O R A WAN U PLINK
The means of the fields are:
If the field “Enable” is checked, the LoRaWAN message is enabled;
In the field “Start Byte” the starting byte of the internal memory array where taking the data is defined;
In the field “Num. Byte” the number of consecutive bytes to take from the internal array starting from “Start Byte” is defined;
If the field “On Change” is checked, the LoRaWAN message is sent only when the data from EtherNet/IP change;
If the field “On CMD” is checked, the LoRaWAN message is sent when a EtherNet/IP request is received;
If the field “On Timer” is checked, the LoRaWAN message is sent cyclically with the delay defined in “Time s)” field;
In the field “Mnemonic” a description of the message is defined.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 19 of 3
Figure 4b: “LoRaWAN Access  LoRaWAN Downlink” window
L O R A WAN D OWNLINK
The means of the fields are:
If the field “Enable” is checked, the LoRaWAN message is enabled;
In the field “Start Byte” the starting byte of the internal memory array where placing the data is defined;
In the field “Num. Byte” the number of consecutive bytes to write to the internal array starting from “Start Byte” is defined;
In the field “Mnemonic” a description of the message is defined.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
LoRaWAN
/
EtherNet/IP Slave
Document code: MN67D25_ENG Revision 1. Page 2 of 3
UPDATE DEVICE:
By pressing the “Update Device” button, it is possible to load the created Configuration
into the device; and also the Firmware, if necessary. This by using the Ethernet port.
If you don’t know the actual IP address of the device you have to use this procedure:
Turn OFF the Device;
Put Dip1 of ‘Dip-Switch A’ in ON position;
Turn ON the device
Connect the Ethernet cable;
Insert the IP “192.168.2.205”;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn OFF the Device;
Put Dip1 of ‘Dip-Switch A’ in OFF position;
Turn ON the device.
If you know the actual IP address of the device, you have to use this procedure:
Turn ON the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode.
At this point the configuration/firmware on the device is correctly updated.
Figure 5: “Update device” windows
