1Introduction
The COM Express approach of custom carrier combined with off the shelf system cores is an
excellent solution when you need to customize but lack the time or quantity for a complete
redesign. It fits most system integration projects with production volumes from 500 to 10,000 pcs
per year. The COM Express concept has a great many advantages over full custom designs, it
reduces engineering complexity, lowers the threshold for total project quantity and last but not
least brings your product to the market in no time. The average time to design a carrier board is
less than half the time of a full custom OEM board.
Express-BASE is a standardATX size carrier board. Together with the COM Express module of
your choice and off the shelf add-on cards you can quickly emulate the functionality of your
desired end product for software development and hardware verification.
To build a functional prototype of your target system you will need:
fCOM Express module
fExpress-BASE carrier board
fPCI Express or PCI add on cards
fPATA/ SATAstorage or Flash disk solution
Express-BASE accommodates up to five PCI Express x1 slots, one PCI Express Graphics x16
slot, one ExpressCard slot and one PCI slot.
The board is based on PICMG’s COM Express specification and is compatible with:
Standard form factor Type 2 COM Express modules

Express-BASE User’s ManualPage 8
2Special Features
2.1 Primary LPC based Super I/O
Express modules do not contain any Super I/O because this is considered legacy. Therefore
Super I/O is placed on the carrier board as an optional item. The Express-BASE uses a Winbond
W83627HG-AW that supports FDD, LPT, COM and PS/2 Keyboard and Mouse.
2.2 Secondary LPC based BIOS
Express-BASE contains a socket for secondary LPC BIOS on board in addition to the soldered
BIOS on the Express module. Selection of active BIOS can be done by jumper settings
2.3 Integrated Debug Port with Single Step Execution
In addition to a two digit POST code display the board also provides four digits display for ad-
dress. By jumper selection the board can be switched into single step BIOS execution mode.
Steps are executed using a manually operated on board mini switch.
2.4 Audio Codec
The onboard stereo audio power amplifier contains two identical amplifiers capable of delivering
6 W per channel of continuous average power into a 4-W load at 10% THD+N or 5 W per channel
at 1% THD+N. The gain of each channel is fixed at 20 dB. The amplifier features a mute/standby
function for power-sensitive applications.
2.5 Information LEDs
General information is obtained through signalling LEDs for HDD, Power and Watchdog status.
Additionally the Express-BASE give information about module types being plug into the board.

Page 9Express-BASE User’s Manual
3Component Location
SW3 SW1
JP6
CN37
JP5
CN33
CN29 CN28
CN25
CN43
CN27
CN26 CN24 CN19 CN18
CN8CN10CN14
U14
JP2
CN15
CN13
CN12 CN11 CN17
CN9
PCIE7
PCI2
PCIE1
PCIE2
PCIE4
PCIE5
PCIE3
PCIE6
CN40
CN42 LED15
LED16 LED17
LED18
LED19
SW2
JP1
LED9 LED10 LED11 LED12
LED14LED13
CN30
CN31
CN32
JP8 JP7
JP4
JP3
CNY8
CNY5
CNY9
CN41
CN35
CN21
CN20
CN4
CN3
CN6
CN5
CN7
CN1
CN16
CNZ1
LED20
LED2
LED21
PWR_OK
JPY11
JPY3
JPY2
JPY5
JPY4
CNY1
JPY9
JPY10
CNY4
JPY13 JPY12 JPY14
JPY1
JPY8
CNY7
JPY7 JPY6
CNY2
CNY3
CNY11
CNY10
Winbond W83627HG-AW
ALC
883
CN2
51-46604-0B20 ETXexpress-BASE
LEDX8 – X1

Express-BASE User’s ManualPage 10
4Function Block Diagram
AB
CD
LPC
W83627HG
Primary
Super I/O
LPT1
COM1
COM2
FDD
POST Code
Display
PCI Express
6x USB on Rear I/O
1x USB on header
ALC883
Codec
Audio on
Rear I/O
KB/MS
USB
Debug Header
SATA
4 onboard
SATA headers
Secondary
BIOS
Express
Card
CRT VGA
Rear I/O
TV-out
header
P
C
I
E
1
P
C
I
E
1
P
C
I
E
1
P
C
I
E
1
P
C
I
E
5
LVDS
headers
Gigabit
Ethernet
Rear I/O
PCI Express
Graphics x16
PCI Express x16
onboard slot
PATA
Onboard IDE
Connector
32-bit PCI
PCI
2
