ADLINK Technology cPCI-R6100 User manual

Leading EDGE COMPUTING
Manual Rev.: 1.0
Revision Date: July 3, 2018
Part No: 50-15108-1000
cPCI-R6100
6U CompactPCI®Rear Transition Module
User’s Manual

ii Revision History
Leading EDGE COMPUTING
Revision History
Revision Release Date Description of Change(s)
1.0 2018/07/03 Initial release

Preface iii
cPCI-R6100
Preface
Copyright 2018 ADLINK Technology, Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsi-
bility to global environmental preservation
through compliance with the European Union's
Restriction of Hazardous Substances (RoHS)
directive and Waste Electrical and Electronic
Equipment (WEEE) directive. Environmental
protection is a top priority for ADLINK. We have
enforced measures to ensure that our products,
manufacturing processes, components, and raw
materials have as little impact on the environment as possible.
When products are at their end of life, our customers are encour-
aged to dispose of them in accordance with the product disposal
and/or recovery programs prescribed by their nation or company.
Battery Labels (for products with battery)
ᑜ㔚ᳰ⺧࿁ᡴ

iv Preface
Leading EDGE COMPUTING
California Proposition 65 Warning
WARNING: This product can expose you to chemicals
including acrylamide, arsenic, benzene, cadmium,
Tris(1,3-dichloro-2-propyl)phosphate (TDCPP), 1,4-Diox-
ane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC, and
vinyl materials, which are known to the State of California to cause
cancer, and acrylamide, benzene, cadmium, lead, mercury,
phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and
vinyl materials, which are known to the State of California to cause
birth defects or other reproductive harm. For more information go
to www.P65Warnings.ca.gov.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

Table of Contents v
cPCI-R6100
Table of Contents
Revision History...................................................................... ii
Preface.................................................................................... iii
List of Figures....................................................................... vii
List of Tables.......................................................................... ix
1 Introduction ........................................................................ 1
1.1 Overview.............................................................................. 1
1.2 Features............................................................................... 2
1.3 Package Contents ............................................................... 3
2 Specifications..................................................................... 5
2.1 cPCI-R6100 Series Specifications....................................... 5
2.2 Block Diagram ..................................................................... 7
3 Board Interfaces................................................................. 9
3.1 cPCI-R6100 Board Layout................................................... 9
3.2 cPCI-R6110/6120 Board Layout........................................ 11
3.3 Connector Pin Assignments .............................................. 13
3.4 Switch Settings .................................................................. 21
4 Getting Started ................................................................. 23
4.1 Installing a 2.5" SATA Drive............................................... 23
4.2 2nd 2.5" SATA drive on cPCI-R6120................................. 25
Important Safety Instructions.............................................. 27
Getting Service...................................................................... 29

vi Table of Contents
Leading EDGE COMPUTING
This page intentionally left blank.

List of Figures vii
cPCI-R6100
List of Figures
Figure 2-1: cPCI-R6100 Functional Block Diagram...........................7
Figure 3-1: cPCI-R6100 Board Layout - Component Side.................9
Figure 3-2: cPCI-R6100 SW1/SW2 Locations - Solder Side ...........10
Figure 3-3: cPCI-R6110/6120 Board Layout....................................11

viii List of Figures
Leading EDGE COMPUTING
This page intentionally left blank.

List of Tables ix
cPCI-R6100
List of Tables
Table 2-1: cPCI-R6100 Series Specifications...................................6
Table 3-1: DVI-D Connector Pin Definition.....................................13
Table 3-2: Front Panel COM Pin Definitions...................................14
Table 3-3: COM RJ-45 to DB-9 Cable Pin Definitions....................14
Table 3-4: VGA Pin Definition.........................................................15
Table 3-5: DB-6920SAT/DB-6920CF Connector Pin Definition......18
Table 3-6: CompactPCI rJ3 Connector Pin Definition.....................19
Table 3-7: CompactPCI rJ5 Connector Pin Definition.....................20
Table 3-8: PICMG 2.16 LAN Switch Settings .................................21

xListofTables
Leading EDGE COMPUTING
This page intentionally left blank.

Introduction 1
cPCI-R6100
1 Introduction
1.1 Overview
The cPCI-R6100 Series is a 6U CompactPCI® rear transition
module (RTM) in single/dual slot (4/8HP) width form factor featur-
ing up to quad Ethernet RJ-45 interfaces provided by an Intel®
Ethernet Controller I350-AM2.
The cPCI-R6100 Series provides rich I/O interfaces to maximize
the flexibility of the processor blade with up to four Ethernet RJ-45
ports, four USB 2.0, one DVI-D, one VGA, one RJ-45 serial port
and one PS/2 keyboard mouse on the rear panel. The cPCI-R6110
and cPCI-R6120 offer VGA, two Ethernet RJ-45 ports, four USB
2.0 ports and one PS/2 keyboard mouse. Onboard storage inter-
faces for the cPCI-R6100, cPCI-R6110 and cPCI-R6120 include
one SD card slot, one CompactFlash slot and two 7-pin SATA
ports. The cPCI-R6110 provides space for one onboard 2.5" SATA
drive and the cPCI-R6120 (8HP) offers an additional onboard 2.5"
SATA drive space.

2Introduction
Leading EDGE COMPUTING
1.2 Features
X6U CompactPCI RTM in 4HP/8HP width form factor
XCompliant with CompactPCI Specification 2.0, Rev. 3.0
XCompliant with CompactPCI Packet Switching Backplane
Specification PICMG 2.16 Rev. 1.0
XOne DVI-D port, one VGA port
XOne DB-9 RS-232 serial port
XFour USB 2.0 Type A ports
XTwo Gigabit Ethernet ports from onboard Intel® Ethernet
Controller I350-AM2
XTwo Gigabit Ethernet ports from processor blade by PICMG
2.16 (cPCI-R6100 only)
XOne PS/2 keyboard mouse on faceplate
XTwo SATA 7-pin connectors, CF card slot, SD card slot
X2.5” drive space on cPCI-R6110, space for additional 2.5” drive
on cPCI-R6120

Introduction 3
cPCI-R6100
1.3 Package Contents
The cPCI-R6100/cPCI-R6110/cPCI-R6120 is packaged with the
following components. If any of the items on the contents list are
missing or damaged, retain the shipping carton and packing mate-
rial and contact the dealer for inspection. Please obtain authoriza-
tion before returning any product to ADLINK.
Rear Transition Module
cPCI-R6100
XY-cable for PS/2 combo port (PN: 30-01016-2000)
XRJ-45 to DB-9 COM cable (PN: 30-01020-0200)
cPCI-R6110
XThe DB-6920SAT daughter board (PN: 59-37534-0000)
XHDD screw/standoff pack (PN: 58-00109-0000)
XY-cable for PS/2 combo port (PN: 30-01016-2000)
cPCI-R6120
XThe DB-6920SAT daughter board (PN: 59-37534-0000)
XHDD screw/standoff pack (PN: 58-00109-0000)
XY-cable for PS/2 combo port (PN: 30-01016-2000)
XThe 2nd SATA drive HDD kit (PN: 58-00250-0000)
Optional CompactFlash Adapter Kit
XDB-CF-SA kit for cPCI-R6110/R6120 (PN: 91-37533-0010)
ZDB-6920CF adapter board
ZScrew pack
ZCF card retention bracket

4Introduction
Leading EDGE COMPUTING
CAUTION:
This product must be protected from static discharge and
physical shock. Never remove any of the components
except at a static-free workstation. Use the anti-static bag
shipped with the product when putting the board on a sur-
face. Wear an anti-static wrist strap properly grounded on
one of the system's ESD ground jacks when installing or
servicing system components.
NOTE:
NOTE:
The contents of non-standard cPCI-R6100 Series configu-
rations may vary depending on the customer requests.

Specifications 5
cPCI-R6100
2 Specifications
2.1 cPCI-R6100 Series Specifications
Standards • CompactPCI® Specification 2.0, Rev. 3.0
• CompactPCI® Packet Switching Backplane Specification
PICMG 2.16 Rev. 1.0
Form Factor • Standard 6U CompactPCI® Rear Transition Module
• Board size: 233.35mm x 80mm
• cPCI-R6100, cPCI-R6110: single slot (4HP, 20.32mm)
• cPCI-R6120: dual-slot (8HP, 40.64mm)
• CompactPCI® connectors rJ3 and rJ5
Onboard
Peripherals cPCI-R6100 • 2x 7-pin Serial ATA connectors
• CompactFlash Type II slot (converted from USB)
• SD card slot
cPCI-R6110
• Direct connector for 2.5" SATA drive via DB-6920SAT
daughter board*
• 2x 7-pin SATA connectors
• CompactFlash Type II slot (converted from USB)
• SD card slot
cPCI-R6120
• Space for 2x 2.5" SATA drives
• Direct connector for 2.5" SATA drive via DB-6920SAT
daughter board*
• 2x 7-pin SATA connectors
• CompactFlash Type II slot (converted from USB)
• SD card slot
*Can be replaced by optional DB-CF-SA CompactFlash
Adapter Kit (PN: 91-37533-0010)
Ethernet • One Intel® Ethernet Controller I350-AM2 on RTM for
additional two Gigabit Ethernet ports (GbE a & b)
• Two 10/100/1000BASE-T ports switched from PICMG 2.16
(GbE c & d, cPCI-R6100 only)

6 Specifications
Leading EDGE COMPUTING
Table 2-1: cPCI-R6100 Series Specifications
Faceplate I/O cPCI-R6100
• 4x USB2.0 ports
•DVI-Dport
• DB-15 VGA port
• RJ-45 RS-232 serial port
• PS/2 Keyboard/Mouse port
• 2x 10/100/1000BASE-T Ethernet ports from PICMG 2.16
cPCI-R6110, cPCI-R6120
• 4x USB 2.0 ports
• 2x 10/100/1000BASE-T Ethernet ports from onboard
Intel® Ethernet Controller I350-AM2
• DB-15 VGA port
• PS/2 Keyboard/Mouse port
Miscellaneous • Optional Gold Cap for RTC backup power in case there is
no battery on the processor blade
NOTE:
NOTE:
Windows does not support USB as host boot device.
Therefore, a CompactFlash card cannot be used to install
a Windows operating system.

Specifications 7
cPCI-R6100
2.2 Block Diagram
Figure 2-1: cPCI-R6100 Functional Block Diagram
Face- Plate
GbE c, d (PICMG 2.16)
COM
4x USB 2.0
7 pin
SATA 1
SATA 2
SATA 3
TMDS DVI-D
GbE a
PCIe x4
PS/2
USB
VGA
2.5” HDD/CF
SD
Intel
I350-AM2 GbE b
USB2251i
Rechargeable battery
CF
7 pin
rJ3
rJ5

8 Specifications
Leading EDGE COMPUTING
This page intentionally left blank.

Board Interfaces 9
cPCI-R6100
3 Board Interfaces
This chapter illustrates the board layout, connector pin
assignments, and switch settings to familiarize users with the
cPCI-R6100.
3.1 cPCI-R6100 Board Layout
Figure 3-1: cPCI-R6100 Board Layout - Component Side
U16 Intel I350-AM2 GbE
controller BT1 Gold Cap battery
U13 USB 2.0 Flash Card
Reader Controller SATA1/ SATA2 7-pin SATA connectors
CN11 SD card slot CN5 SATA 5-pin power
connector
CN12 CompactFlash slot CN9 DB-15 VGA connector
CN13 2x GbE ports from Intel®
I350-AM2 (GbE a/b) CN8 2x GbE ports from
PICMG 2.16 (GbE c/d)
CN1/2/3/4 USB 2.0 ports CN7 PS/2 keyboard/mouse
connector
CN10 DVI-D connector CN14 RJ-45 serial port
CN11
BT1
U13
SATA1 SATA2
CN5
CN12
CN9 CN13
CN4/3/2/1 CN7 CN14 CN10
U16
CN8

10 Board Interfaces
Leading EDGE COMPUTING
cPCI-R6100 SW1/SW2 Locations
Figure 3-2: cPCI-R6100 SW1/SW2 Locations - Solder Side
SW2 SW1
