ADLINK cPCI Multi-port Communication Module Comparison Chart
3534 3544 3538
Serial port per system 4~8 4~32 8~16
RS-232 port per module 3-8
RS-422/485 per module 14-
CPU ---
Serial communication
controller 16C554 16C554 16C554
MAX System throughput
115.2K*4 115.2K*4 115.2K*8
Hardware compatibility cPCI bus cPCI bus cPCI bus
Software compatibility
DOS Windows
(3.1/95/98/NT)
LINUX SCO
Open Server
Windows
(95/98/NT) QNX
DOS Windows
(3.1/95/98/NT)
LINUX SCO
Open Server
External connector
Four DB25 male
cable connector
or DB9 male
connector
Four DB25 male
cable connector
or DB9 male
connector
Eight DB25 male
cable connector
or DB9 connector
Rear IO Connector R3534 R3544 R3538
Surge protection YYY
Accessory C425M
C409M C425M C409M C825M C809M
Isolation protection
Port D:
embedded
isolated RS422
or RS 485
Embedded
isolated RS422
or RS 485
Y (C888XB)
option external
isolated RS-232
or RS-422 or
RS-485
Dimension 160mm (length)
100mm (width)
160mm (length)
100mm (width)
160mm (length)
100mm (width)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table of Contents•i
Table of Contents
Chapter 1 Introduction.............................................................1
1.1 About the Serial Communication Modules .............................1
1.2 Overview of cPCI-3534 ........................................................2
1.2.1 What is cPCI-3534?.....................................................................2
1.2.2 Feature of cPCI-3534..................................................................2
1.2.3 Specification of cPCI-3534.........................................................3
1.2.4 Connector Pin Assignment of cPCI-3534................................4
1.3 Overview of cPCI-3544 ........................................................8
1.3.1 What is cPCI-3544?.....................................................................8
1.3.2 Feature of cPCI-3544..................................................................8
1.3.3 Specification of cPCI-3544.........................................................9
1.3.4 Connector Pin Assignment of cPCI-3544..............................11
1.4 Overview of cPCI-3538 ......................................................14
1.4.1 What is cPCI-3538?...................................................................14
1.4.2 Feature of cPCI-3538................................................................14
1.4.3 Specification of cPCI-3538.......................................................15
1.4.4 Connector Pin Assignment of cPCI-3538..............................17
Chapter 2 Installation.............................................................20
2.1 What You Have .................................................................20
2.2 Unpacking.........................................................................21
2.3 Installation Procedure ........................................................22
2.4 Hardware Configuration.....................................................23
2.4.1 Wiring Example..........................................................................23
2.5 Software Installation ..........................................................24
2.5.1 Windows NT Installation...........................................................24
2.5.2 Windows 95/98 Installation.......................................................26
2.5.3 For UNIX, LINUX and QNX user.............................................27
2.5.4 Windows 95/98/NT Utility Diagram for cPCI-3544................28
2.6 AP Examples ....................................................................30
2.6.1 Dos Environment........................................................................30
2.6.2 Windows(Windows 95/98/NT) Environment..........................30
2.6.3 Linux Environment.....................................................................30
Product Warranty/Service.....................................................31
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction •1
1
Introduction
1.1 About the Serial Communication Modules
♦The serial communication modules are intelligent serial
input/output multi-port controller modules, which go with the new
generation of PC platform CompactPCI. The modules can reduce
the frequency for serial communication controller to interrupt main
CPU on the mainboard to improve the whole system performance.
♦Traditionally, the serial communication controller will interrupt the
MPU character by character. This action will waste MPU
processing time and drop the system computing power. If the MPU
is processing some non-interrupted task, then the serial controller
will overrun and data lost.
♦The serial communication interface series can support buffer
capability or local processor and dual port RAM in each port’s
transmit and receive channel simultaneously. This capability will
reduce the frequency of interrupt and increase the non-interrupt
task’s interval.
♦The serial communication interface series use ASIC PCI controller
to interface the module to cPCI bus. The ASIC fully implement the
PCI local bus specification Rev. 2.1. All related bus configurations,
such as base memory address and interrupt assignment, are
automatically controlled by BIOS software. It does not need any
user interaction and pre-study for the configurations. This removes
the burden of searching for aconflict-free configuration.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2•Introduction
1.2 Overview of cPCI-3534
1.2.1 What is cPCI-3534?
The cPCI-3534 is an enhanced four ports serial communication module
used for Compact-PCI platform. It includes a PGA(Programmable Gate
Array) to support the serial communication controller and a 37-pin
connectortoconnectexternalI/Oportfromthefrontpanelorusingtherear
IO.
The expansion cable has four standard DB25 or DB9 connectors and one
DB37 connector to connect with cPCI-3534 interface card.
The R-3534 transition board can support rear IO connection by using one
DB37 connector.
1.2.2 Feature of cPCI-3534
•32-bit CompactPCI 3U form factor
•PCI Rev.2.1 Plug and Play
•IRQ and IO address automatically assigned by PCI plug-n-play
•4 communication ports intelligent buffer
•One isolated industry communication port
•High Speed Communication (max. 115200 bps)
•Suitable for modems, data display, data collection,
telecommunication
•Supports up to 2 cards/8 ports per system
•Supports DOS, Windows 3.1, Windows 95/98, and Windows NT
operation system
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction •3
1.2.3 Specification of cPCI-3534
♦Compliant with PCI Spec.2.1
♦Serial communication controller:
•16C550A compatible
•1.8432 ~7.3728 MHz
♦System IO mapping:
•Assigned by PCI BIOS
•Shared IRQ
♦Flow control
•Xon/Xoff control
•RTS/CTS control
♦Port Capability:
•3 independent RS-232C compatible ports
•1 isolated RS-422/485 port (DIP switch select)
•Max. port per system: 8 (2 card)
♦Isolation voltage: 2500VDC
♦Baud rate: Each port can be configured to 50~115,200 bps
♦Operation System Compatibility: DOS, Windows 3.1, and Windows
95/98/NT
♦Connector: DB37 female connector
♦Cable: External cable with 4 standard DB25 male connector
♦Operating temperature: 0 ~ 55°C
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4•Introduction
♦Storage temperature: -20 ~ 65°C
♦Humidity: 10% ~ 95%, non-condensing
♦Dimension: 160 x 100 mm2(6.3 x 3.9 in.2) 3U
•Power consumption: +5V @ 1400mA typical
1.2.4 Connector Pin Assignment of cPCI-3534
DB37 female connector pin assignment for cPCI-3534.
DB37 Pin No. Signal Name DB37 Pin No. Signal Name
1RXD1(IN) 20 TXD1(OUT)
2CTS1(IN) 21 RTS1(OUT)
3DSR1(IN) 22 DTR1(OUT)
4DCD1(IN) 23 RI1(IN)
5GND 24 RXD2(IN)
6TXD2(OUT) 25 CTS2(IN)
7RTS2(OUT) 26 DSR2(IN)
8DTR2(OUT) 27 DCD2(IN)
9GND 28 RI2(IN)
10 -- 29 RI3(IN)
11 GND 30 DCD3(IN)
12 DTR3(OUT) 31 DSR3(IN)
13 RTS3(OUT) 32 CTS3(IN)
14 TXD3(OUT) 33 RXD3(IN)
15 GND4 34 --
16 -- 35 422TXD4-(I/O)
17 422RXD4-(IN) 36 485TRXD4+(I/O)
18 485TRXD4-(I/O) 37 422TXD4+(OUT)
19 422RXD4+(IN) -- --
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction •5
DB25 male connector pin assignment in cPCI-3534 module for RS-232
interface (port A, B and C).
DB25 Pin No. Signal Name
2TXD(OUT)
3RXD(IN)
4RTS(OUT)
5CTS(IN)
6DSR(IN)
7GND
8DCD(IN)
20 DTR(OUT)
DB25 male connector pin assignment in cPCI-3534 module for
RS-422/485 interface (port D).
DB25 Pin No. Signal Name
2422TXD+(OUT)
3422RXD+(IN)
4485TRXD+(I/O)
5485TRXD-(I/O)
6422RXD-(IN)
7GND
20 422TXD-(OUT)
DB9 male connector pin assignment in cPCI-3534 module for RS-232
interface (port A, B and C).
DB9 Pin No. Signal Name
2TXD(OUT)
3RXD(IN)
4RTS(OUT)
5CTS(IN)
6DSR(IN)
7GND
8DCD(IN)
9DTR(OUT)
DB9 male connector pin assignment in cPCI-3534 module for RS-422/485
interface (port D).
DB25 Pin No. Signal Name
2422TXD+(OUT)
3422RXD+(IN)
4485TRXD+(I/O)
5485TRXD-(I/O)
6422RXD-(IN)
7GND
20 422TXD-(OUT)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6•Introduction
J2 connector pin assignment in cPCI-3534 module for RS-232/422/485
interface.
22 GND
GA4 GA3 GA2 GA1 GA0 GND
21 GND
GND
20 GND
GND
19 GND
FG N+ N-SG GND
18 GND
GND
17 GND
GND
16 GND
TXD+
TXD-SG GND
15 GND
FG RXD+
RXD-GND
14 GND
GND
13 GND
GND
12 GND
DSRŽ
SGŽDCDŽ
DTRŽ
GND
11 GND
FGŽTXŽRXŽRTSŽ
CTSŽ
GND
10 GND
GND
9GND
GND
8GND
DSR•
SG•DCD•
DTR•
GND
7GND
FG•TX•RX•RTS•
CTS•
GND
6GND
GND
5GND
GND
4GND
DSRŒ
SGŒDCDŒ
DTRŒ
GND
3GND
FGŒTXŒRXŒRTSŒ
CTSŒ
GND
2GND
GND
1GND
GND
Pin
ZABCDEF
P2
/
J2
C
O
N
N
E
C
T
O
R
ŒPortA •Port B ŽPort C
RS-232
FG :Frame Ground TX :Transmit Data
RX :Receive Data
RTS :Request to Send CTS :Clear to Send
DSR:Data Set Ready
SG :Signal Ground DCD :Data Carrier Detect
DTR :Data Terminal Ready
RS-422
TXD+ :Transmit Data Positive
TXD-:Transmit Data Negative
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction •7
RXD+ :Receive Data Positive
RXD-:Receive Data Negative
RS-485
D+ :Data Signal Positive
D-:Data Signal Negative
R-3534 Rear IO Daughter Board
The R-3534 rear I/O daughter board provides a rear I/O connection
transition, the connector and cable used in the rear is the same as the
front.
DIP Switch and Jumper Setting
SW1 ON OFF
SW1-1Card1 Card2
SW1-4RS-422 RS-485
The JP1 is for the RS422 terminator and the JP2 is for the RS-485
terminator. The terminator is ON while the jumper is ON
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8•Introduction
1.3 Overview of cPCI-3544
1.3.1 What is cPCI-3544?
The cPCI-3544 is an enhanced four ports serial communication modulefor
industrycommunicationinterfaceRS-422/485 by Compact-PCI platform. It
includes a PGA(Programmable Gate Array) to support the serial
communication controller and a 37-pin connector to connect external I/O
port from the front panel or using the rear IO.
The expansion cable has four standard DB25 or DB9 connectors and one
DB37 connector to connect with cPCI-3544 interface card.
The R-3544 transition board can support rear IO connection by using one
DB37 connector.
1.3.2 Feature of cPCI-3544
♦32-bit CompactPCI 3U form factor
♦PCI Rev.2.1 Plug and Play
♦IRQ and IO address automatically assigned by PCI plug-n-play
♦4 communication ports intelligent buffer
♦RS-422/485 hardware/software selectable
♦RS-485 with auto direction flow control
♦Channel to channel isolated industry communication port
♦High speed communications concurrently (max. 115200 bps)
♦Supports up to 8 cards/32 ports per system
♦Supports DOS, Windows 95/98, and Windows NT operation
system
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction •9
1.3.3 Specification of cPCI-3544
♦Compliant with PCI Spec.2.1
♦Serial communication controller:
♦16C550A compatible
♦1.8432 ~ 7.3728 MHz
♦System IO mapping:
•Assigned by PCI BIOS
•Shared IRQ
♦Flow control
•RS-485 auto direction
♦Port Capability:
•4 isolated RS-422/485 port (DIP switch/software select)
•Max. port per system: 32 (8 card)
♦Isolation voltage: 500VDC
♦Baud rate: Each port can be configured to 50~115,200 bps
♦Operation System Compatibility: Windows 95/98/NT/QNX
♦Connector: DB37 female connector
♦Cable: External cable with 4 standard DB25(C425M) or
DB9(C409M) male connector
♦Operating temperature: 0 ~ 55°C
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10 •Introduction
♦Storage temperature: -20 ~ 65°C
♦Humidity: 10% ~ 95%, non-condensing
♦Dimension: 160 x 100 mm2(6.3 x 3.9 in.2) 3U
♦Power consumption: +5V @ 1400mA typical
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction •11
1.3.4 Connector Pin Assignment of cPCI-3544
DB37 female connector pin assignment for cPCI-3544.
DB37 Pin No. Signal Name DB37 Pin No. Signal Name
1422_RXD1+(IN) 20 422_TXD1+(OUT)
2485_D1+(I/O) 21 --
3422_RXD1-(IN) 22 422_TXD1-(OUT)
4485_D1-(I/O) 23 --
5GND1 24 422_RXD2+(IN)
6422_TXD2+(OUT)
25 485_D2+(I/O)
7-- 26 422_RXD2-(IN)
8422_TXD2-(OUT)
27 485_D2-(I/O)
9GND2 28 --
10 -- 29 --
11 GND3 30 485_D3-(I/O)
12 422_TXD3-(OUT)
31 422_RXDC-(IN)
13 -- 32 485_D3+(I/O)
14 422_TXD3+(OUT)
33 422_RXD3+(IN)
15 GND4 34 --
16 485_D4-(I/O) 35 422_TXD4-(OUT)
17 422_RXD4-(IN) 36 --
18 485_D4+(I/O) 37 422_TXD4+(OUT)
19 422RXD4+(IN) -- --
DB25 male connector pin assignment in cPCI-3544 module for
RS-422/485 interface.
DB25 Pin No. Signal Name
2422_TXD+
3422_RXD+
5485_D+
6422_RXD-
7GND
8485_D-
20 422_TXD-
DB9 male connector pin assignment in cPCI-3544 module for RS-422/485
interface.DB9 Pin No. Signal Name
1485_D-
2422_RXD+
3422_TXD+
4422_TXD-
5GND
6422_RXD-
8485_D+
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
