WISE-2210 Startup Manual 1
Thank you for purchasing the WISE-2210 LPWAN Energy
Management Starter Kit. This quick start guide is intended
to help you deploy your new solution. The guide contains
basic information on the power and application wiring.
Should you require additional instructions, please refer to
WISE-2210 and WISE-4210-AP user manual.
• 1 x WISE-2210
• 1 x WISE-4210-AP
• 2 x Antenna
• 1 x WebAccess/SCADA 75 tags license key
• 3 x 5~100A current transformer
• 2 x Mounting bracket
• 1 x Quick start manual
• 1 x China RoHS declaration (NA series only)
• 1 x 60w adapter
• 1 x 183cm power cord
• 1 x 70 cm Ethernet cable
• 1 x Screwdriver
WISE-2210 is plug and play analog input module, power
source comes from an analog input which is connected to a
0~100 mA current transformer. In other words, WISE-2210
measures data and gets power current from connected cur-
rent transformer. WISE-4210-AP is the LPWAN AP, power
source comes from adapter.
WISE-2210
LPWAN Energy Management Starter Kit
Startup Manual
WISE-2210 Application Wiring
WISE-4210-AP Power Supply Wiring
Overview
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service:
http://support.advantech.com/
This startup manual is for WISE-2210 Series.
Part No. 2043221010
Printed in Taiwan
Edition 1
August 2020
Packaging List
Input Power Requirements
Power Supply & Application Wiring
System Architecture

2 WISE-2210 Startup Manual
1. Power on WISE-2210 and WISE-4210-AP
2. Install WebAccess/SCADA in your PC.
3. To generate 75 tags use WebAccess/SCADA USB Hard Key as follows :
https://support.advantech.com/support/DownloadSRDetail_New.aspx?SR_ID=1-1YCRI3V&Doc_Source=Download
4. Download WebAccess/SCADA WISE Starter Kit project as follows : https://support.advantech.com/support/DownloadSR-
Detail_New.aspx?SR_ID=1-1Y7TAWX&Doc_Source=Download
5. Import WebAccess/SCADA WISE Starter Kit project into your PC. The import procedure is as follows :
https://support.advantech.com/support/KnowledgeBaseSRDetail_New.aspx?SR_ID=1-1Y6YZXN&Doc_
Source=Knowledge+Base
6. Open WISE Starter Kit project and copy IoTDemo_WISE-Project folder to c:\webaccess\node and c:\webaccess\node\
cong
7. OpenWISEStarterKitprojectandopenModiconDriver__UTCSwapfolder.Copy3dllleto:c:\webaccess\nodeandc:\
webaccess\node\deriverandc:\webaccess\node\cong\ProjectName\BINandc:\webaccess\node\ProjectName\BIN
8. Connect your PC with WISE-4210-AP, make sure the PC IP segment is same with WISE-4210-AP. Default IP on WISE-
4210-AP is 192.168.1.1
9. You can get the data from WISE-2210 directly on your WebAccess/SCADA WISEPaaS Dashboard, as follows: https://
localhost:3000/frame/SideBar?language=en&theme=dark&orgId=3.
Installation Procedure
