Advantech TPC-100W Series User manual

User Manual
TPC-100W Series
電腦
7"/10.1"/15.6" Touch Panel
Computer with
ARM® Cortex®-A53 Processor

TPC-100W Series User Manual ii
限用物質含有情況標示聲明書
Declaration of the Presence Condition of the Restricted Substances Marking
製造商：研華股份有限公司
地址：台北市內湖區瑞光路 26 巷 20 弄 1 號
電話：[phone]
設備名稱：電腦 型號 （型式）：TPC-100WW （系列型號參次頁）
Equipment name Designation (Type)
單元
Unit
限用物質及其化學符號
Restricted substances and their chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
電路板 － ○ ○ ○ ○ ○
內外殼 ○ ○ ○ ○ ○ ○
線材 ○ ○ ○ ○ ○ ○
其它固定
組件
( 螺絲、螺
柱 )
－ ○ ○ ○ ○ ○
顯示器 ○ ○ ○ ○ ○ ○
備考 1.“ 超出 0.1 wt %” 及 “ 超出 0.01 wt %” 係指限用物質之百分比含量超出百分比含
量基準值。
Note 1. “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the content of the
restricted substance exceeds the defined concentration limit.
備考 2.“ ○ ” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2. “○” indicates that the content of the restricted substance does not exceed the defined
concentration limit.
備考 3.“ － ” 係指該項限用物質為排除項目。
Note 3. “-” indicates that the restricted substance is not present in the product.

iii TPC-100W Series User Manual
Copyright
The documentation and the software included with this product are copyrighted 2022
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. The information provided in this manual is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties that may result from its use.
Acknowledgments
NXP and Freescale are registered trademarks of NXP Semiconductors N.V.
All other product names or trademarks are properties of their respective owners.
This manual is applicable to the following models:
TPC-107W
TPC-107W-N31A
TPC107WN31A2101-T, TPC107WN31A2102-T, TPC107WN31A2103-T,
TPC107WN31A2201-T, TPC107WN31A2202-T, TPC107WN31A2203-T,
TPC107WN31A2204-T, TPC107WN31A2205-T, TPC107WN31A2206-T,
TPC107WN31A2301-T, TPC107WN31A2302-T, TPC107WN31A2303-T,
TPC107WN31A2304-T, TPC107WN31A2305-T, TPC107WN31A2306-T,
TPC107WN31A2401-T, TPC107WN31A2402-T, TPC107WN31A2403-T,
TPC107WN31A2404-T, TPC107WN31A2405-T, TPC107WN31A2406-T
TPC107WN31A2501-T, TPC107WN31A2502-T, TPC107WN31A2503-T,
TPC107WN31A2504-T, TPC107WN31A2505-T, TPC107WN31A2506-T
TPC-110W
TPC-110W-N31A
TPC110WN31A2101-T, TPC110WN31A2102-T, TPC110WN31A2103-T,
TPC110WN31A2201-T, TPC110WN31A2202-T, TPC110WN31A2203-T,
TPC110WN31A2204-T, TPC110WN31A2205-T, TPC110WN31A2206-T,
TPC110WN31A2301-T, TPC110WN31A2302-T, TPC110WN31A2303-T,
TPC110WN31A2304-T, TPC110WN31A2305-T, TPC110WN31A2306-T,
TPC110WN31A2401-T, TPC110WN31A2402-T, TPC110WN31A2403-T,
TPC110WN31A2404-T, TPC110WN31A2405-T, TPC110WN31A2406-T
TPC110WN31A2501-T, TPC110WN31A2502-T, TPC110WN31A2503-T
TPC110WN31A2504-T, TPC110WN31A2505-T, TPC110WN31A2506-T
Part No. Edition 1
Printed in Taiwan January 2022

TPC-100W Series User Manual iv
TPC-115W
TPC-115W-N31A
TPC115WN31A2101-T, TPC115WN31A2102-T, TPC115WN31A2103-T,
TPC115WN31A2201-T, TPC115WN31A2202-T, TPC115WN31A2203-T,
TPC115WN31A2204-T, TPC115WN31A2205-T, TPC115WN31A2206-T,
TPC115WN31A2301-T, TPC115WN31A2302-T, TPC115WN31A2303-T,
TPC115WN31A2304-T, TPC115WN31A2305-T, TPC115WN31A2306-T,
TPC115WN31A2401-T, TPC115WN31A2402-T, TPC115WN31A2403-T,
TPC115WN31A2404-T, TPC115WN31A2405-T, TPC115WN31A2406-T
TPC115WN31A2501-T, TPC115WN31A2502-T, TPC115WN31A2503-T
TPC115WN31A2504-T, TPC115WN31A2505-T, TPC115WN31A2506-T
Product Warranty (2 years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers will be billed according to the cost of replacement mate-
rials, service time, and freight. Please consult your dealer for more details.
If you believe your product to be defective, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages displayed when the prob-
lem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship the pack-
age prepaid to your dealer.

v TPC-100W Series User Manual
Technical Support and Assistance
1. Visit the Advantech website at www.advantech.com/support to obtain the latest
product information.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before calling:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
type of cable is available from Advantech. Please contact your local supplier for
ordering information.
Test conditions for passing also include the equipment being operated within an
industrial enclosure. In order to protect the product from damage caused by electro-
static discharge (ESD) and EMI leakage, we strongly recommend the use of CE-
compliant industrial enclosure products.
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference. In
this event, users are required to correct the interference at their own expense.
警告使用者
這是甲類測試產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情況下，
使用者會被要求採取某些適當的對策。

TPC-100W Series User Manual vi
Warnings, Cautions, and Notes
Warning! Warnings indicate conditions that if not observed can cause personal
injury!
Caution! Cautions are included to help prevent hardware damage and data
losses. For example,
“Batteries are at risk of exploding if incorrectly installed. Do not attempt
to recharge, force open, or heat the battery. Replace the battery only
with the same or equivalent type as recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.”
Note! Notes provide additional optional information.

vii TPC-100W Series User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect the equipment from all power outlets before cleaning. Use only a
damp cloth for cleaning. Do not use liquid or spray detergents.
4. For pluggable equipment, the power outlet socket must be located near the
equipment and easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
the equipment fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
8. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet.
9. Position the power cord away from high-traffic areas. Do not place anything over
the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage from transient overvoltage.
12. Never pour liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If any of the following occurs, have the equipment checked by service person-
nel:
–The power cord or plug is damaged.
–Liquid has penetrated the equipment.
–The equipment is malfunctioning, or does not operate according to the user
manual.
–The equipment has been dropped and damaged.
–The equipment shows obvious signs of breakage.
15. Do not leave the equipment in an environment with a storage temperature of
below -30° C (-22° F) or above 70° C (158° F) as this may damage the compo-
nents. The equipment should be kept in a controlled environment.
16. CAUTION: Batteries are at risk of exploding if incorrectly replaced. Replace only
with the same or equivalent type as recommended by the manufacturer. Discard
used batteries according to the manufacturer’s instructions.
17. In accordance with IEC 704-1:1982 specifications, the sound pressure level at
the operator’s position does not exceed 70 dB (A).
18. This product is not intended for use by children (this product is not a toy).
19. This equipment is not suitable for use in locations where children are likely to be
present.
DISCLAIMER: These instructions are provided according to IEC 704-1 standards.
Advantech disclaims all responsibility for the accuracy of any statements contained
herein.
Caution! Danger d'explosion si la batterie est mal remplace. Remplacer unique-
ment par le meme type ou equivalent recommandé par le fabricant.
Jeter les piles usagées selon les instructions du fabricant.

TPC-100W Series User Manual viii
安全指示
1. 請仔細閱讀此安全操作說明。
2. 請妥善保存此用戶手冊供日後參考。
3. 用濕抹布清洗設備前，請從插座拔下電源線。請不要使用液體或去汙噴霧劑清洗
設備。
4. 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。
5. 請不要在潮濕環境中使用設備。
6. 請在安裝前確保設備放置在可靠的平面上，意外跌落可能會導致設備損壞。
7. 設備外殼的開口是用於空氣對流，從而防止設備過熱。請不要覆蓋這些開口。
8. 當您連接設備到電源插座上前，請確認電源插座的電壓是否符合要求。
9. 請將電源線佈置在人們不易絆到的位置，並不要在電源線上覆蓋任何雜物。
10. 請注意設備上的所有警告和注意標示。
11. 如果長時間不使用設備，請將其同電源插座斷開，避免設備被超標的電壓波動損
壞。
12. 請不要讓任何液體流入通風口，以免引起火災或者短路。
13. 請不要自行打開設備。為了確保您的安全，請由經過認證的工程師來打開設備。
14. 如遇下列情況，請由專業人員來維修：
–電源線或者插頭損壞；
–設備內部有液體流入；
–設備曾暴露在過於潮濕的環境中使用；
–設備無法正常工作，或您無法通過用戶手冊來使其正常工作；
–設備跌落或者損壞；
–設備有明顯的外觀破損。
15. 請不要把設備保存在超出我們建議的溫度範圍的環境，即不要低於 -20°C （-4
°F）或高於 60°C （140°F），否則可能會損壞設備。
16. 注意：如果電池放置不正確，將有爆炸的危險。因此，只可以使用製造商推薦的
同一種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。
17. 根據 IEC 704-1:1982 的規定，操作員所在位置的音量不可高於 70dB(A)。
18. 限制區域：請勿將設備安裝於限制區域使用。
19. 免責聲明：該安全指示符合 IEC 704-1 的要求。研華公司對其內容的準確性不
承擔任何法律責任。
20. 使用過度恐傷害視力。
21. 使用 30 分鐘請休息 10 分鐘。
22. 未滿 2 歲幼兒不看螢幕，2 歲以上每天看螢幕不要超過 1 小時。
23. 本產品為國內裝置使用時，其電源僅限使用架構電源模組所提供電源直流輸入，
不得使用交流電源及附加其他電源轉換裝置提供電源這者，其電源輸入電壓及電
流請依說明書規定使用。

ix TPC-100W Series User Manual
Wichtige Sicherheishinweise
1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie
Keine Flüssig-oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch
zur Reinigung.
4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und leicht
zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen
oder Fallen könnte Verletzungen hervorrufen.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät vor über-
hitzung schützt. Sorgen Sie dafür, daB diese Öffnungen nicht abgedeckt
werden.
8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBwerte.
9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber fallen kann. Es
sollte auch nichts auf der Leitung abgestellt werden.
10. Es sollte auch nichts auf der Leitung abgestellt werden. Alle Hinweise und War-
nungen die sich am Ger?ten befinden sind zu beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom
Stromnetz trennen. Somit wird im Falle einer Überspannung eine Beschädigung
vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten in
das Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag aus-
lösen.
13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen
Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen
und von einer qualifizierten Servicestelle zu überprüfen:
–Netzkabel oder Netzstecker sind beschädigt.
–Flüssigkeit ist in das Gerät eingedrungen.
–Das Gerät war Feuchtigkeit ausgesetzt.
–Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert
oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.
15. VOSICHT: Explisionsgefahr bei unsachgemaben Austausch der Batterie.Ersatz
nur durch densellben order einem vom Hersteller empfohlene-mahnlichen Typ.
Entsorgung gebrauchter Batterien navh Angaben des Herstellers.
16. ACHTUNG: Es besteht die Explosionsgefahr, falls die Batterie auf nicht fach-
männische Weise gewechselt wird. Verfangen Sie die Batterie nur gleicher oder
entsprechender Type, wie vom Hersteller empfohlen. Entsorgen Sie Batterien
nach Anweisung des Herstellers.
17. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt
70dB(A) oder weiger.
18. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der
IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit
der in die- sem Zusammenhang getätigten Aussagen ab.

TPC-100W Series User Manual x
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

xi TPC-100W Series User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications............................................................................................ 2
1.2.1 System Kernel............................................................................... 2
1.2.2 Communication Interface.............................................................. 2
1.2.3 LCD Panel..................................................................................... 3
1.2.4 Touchscreen ................................................................................. 3
1.2.5 Environment.................................................................................. 3
1.2.6 EMC and Safety............................................................................ 3
1.2.7 Power............................................................................................ 4
1.2.8 External I/O................................................................................... 4
1.3 Mounting ................................................................................................... 4
1.4 Dimensions and Cutout............................................................................. 6
Chapter 2 System Setup.......................................9
2.1 Transport and Unpacking........................................................................ 10
2.2 System configuration............................................................................... 11
2.3 M.2 Key-E 2230 Express Module Installation ......................................... 12
2.4 System Power On ................................................................................... 13
2.4.1 Cabinet Installation and Earth Grounding Setup......................... 14
Chapter 3 Linux Yocto ........................................17
3.1 ARM Yocto 3.0........................................................................................ 18
3.2 ARM Yocto 3.0 Software Support ........................................................... 18
3.2.1 System Default Software ............................................................ 18
3.2.2 GPU Accelerations...................................................................... 18
3.2.3 Install Yocto 3.0 Software ........................................................... 19
3.3 TPC-100W Module Extension................................................................. 22
3.3.1 Module Information ..................................................................... 22
3.3.2 The Configuration and Connection of WIFI Module.................... 22
3.3.3 The Configuration and Connection of Bluetooth Module ............ 23
3.4 Time And Date Setting ............................................................................ 27
3.5 CAN Setting ............................................................................................ 28
3.6 Brightness Setting................................................................................... 29
3.7 COM Setting............................................................................................ 29
Appendix A Pin Assignments ...............................31
A.1 M.2 Slot (E-Key)...................................................................................... 32
A.2 COM Port ................................................................................................ 33

TPC-100W Series User Manual xii

Chapter 1
1General Information

TPC-100W Series User Manual 2
1.1 Introduction
The TPC-100W series is a compact touch panel computer equipped with an NXP®
Cortex®-A53 i.MX8M Mini quad-core processor, 7”/10.1”/15.6” TFT LCD display,
multi-touch glass sensor,16GB of eMMC Storage. To ensure stable operation in
harsh industrial environments, TPC-100W supports a wide operating temperature
range (-20 ~ 60° C/-4~140° F) and Panel/VESA mounting and features an IP66-rated
front panel that protects against water and dust ingress.
For web-based operations, TPC-100W offers two 10/100/1000 LANs that one sup-
ports the IEEE 802.3 PoE-PD standard. The inclusion of and browsers enable rapid
Web application development and easy configuration. Finally, TPC-100W supports
various OS including Linux Ubuntu Desktop with full QT graphics, and Android to
ensure easy deployment for diverse applications.
NXP® ARM Cortex®-A53 i.MX8M Mini Quad core processor
7" 16:9 WSVGA LCD wide screen with PCAP multi-touch
10.1” 16:9 WXGA LCD wide screen with PCAP multi-touch
15.6” HD WXGA LCD wide screen with PCAP multi-touch
15.6” FHD LCD wide screen with PCAP multi-touch
Up to 2GB LPDDR4 RAM & 16GB eMMC storage onboard
10/100/1000 Mbps LAN
1MB FRAM backup memory for power interruption situation
2 x Serial port with termination resistor 120Ω that one supports CAN 2.0B proto-
col specification and programmable bit rate up to 1 Mb/sec
Linux Yocto 3.0 Support
Optional M.2 Wifi, Bluetooth,TPM.2.0 and POE (Just 7”and 10.1”support) mod-
ule expansion support
VESA and panel mounting with true-flat IP66 front panel support
-20 ~ 60° C wide operating temperature range
1.2 Specifications
1.2.1 System Kernel
CPU: NXP® ARM Cortex®-A53 i.MX8 Mini Quad Core 1.6 GHz Processor
Memory: Quad Core: 2GB DDR4 RAM on board
Storage Memory: 16GB eMMC on board; 1MB FRAM for data backup
Watchdog Timer: Programmable as 1 second
1.2.2 Communication Interface
Serial Port:
–1 x RS-232/422/485 (COM 1)
–1 x selectable mode for RS485 and CAN 2.0 B
LAN Port: 2 x RJ45 with 10/100/1000 Mbps LAN
Others:
–1 x USB 2.0 Micro USB Client
–2 x USB 2.0 Type-A Host 1 x Micro SD (Internal)
–1.M.2 Key-E 2230 (Wi-fi/BT)

3 TPC-100W Series User Manual
Chapter 1 General Information
1.2.3 LCD Panel
1.2.4 Touchscreen
Touch Points: 10 Points
Light Transmission: above 85%
Pencil Hardness: 7H
Type: Projected capacitive (P-CAP) touch
1.2.5 Environment
Operating Temperature: -20 ~ 60 °C (-4 ~ 140 °F)
The Temperature of Safety Certification is from -20 ~ 50 °C (-4 ~ 140 °F)
Storage Temperature: -30 ~ 70 °C (-22 ~ 158 °F)
Humidity: 10 ~ 90% RH @ 40 °C, non-condensing
Ingress Protection: Compliant with IP66 on front panel
Vibration Protection: 2 Grms random vibration (5 ~ 500 Hz) during operation
(compliant with IEC60068-2-64)
Shock Protection: 10 G shock under 11 ms operation (compliant with
IEC60068-2-27)
1.2.6 EMC and Safety
EMC: CE, FCC Class B, BSMI
Safety: CB, UL, CCC
Category Item 7" 10.1" 15.6" (HD) 15.6" (FHD)
LCD
Display Type WSGA TFT
LCD
WXGA TFT
LCD
WXGA TFT
LCD FHD TFT LCD
Max.
Resolution 1024 x 600 1280 x 800 1366 x 768 1920 X 1080
Aspect Ratio 16:9 16:10 16:9 16:9
Max. Color 16.7 M 16.2M 16.7 M 16.2 M
Luminance
(cd/m²) 425 500 300 450
Viewing Angle
(H/V°) 170/170 170/170 160/160 170/170
Backlight Life 50,000hrs 50,000hrs 50,000hrs 50,000hrs
Contrast Ratio 800:1 800:1 500:1 800:1
Touch
Type Projected
capacitive
Projected
capacitive
Projected
capacitive
Projected
capacitive
Transmission 88% ± 2% 88% ± 2% 88% ± 2% 88% ± 2%
System
Temperature
Operating -20 ~ 60 °C
(-4 ~ 140 °F)
-20 ~ 60 °C
(-4 ~ 140 °F)
-20 ~ 60 °C
(-4 ~ 140 °F)
-20 ~ 60 °C
(-4 ~ 140 °F)
Storage -30 ~ 70 °C
(-22 ~ 158 °F)
-30 ~ 70 °C
(-22 ~ 158 °F)
-30 ~ 70 °C
(-22 ~ 158 °F)
-30 ~ 70 °C
(-22 ~ 158 °F)

TPC-100W Series User Manual 4
1.2.7 Power
Input Voltage: 24VDC ± 20%
Power Consumption:
–TPC-107W: 6W (Typ.); 9W (Max.)
–TPC-110W: 10W (Typ.); 12W (Max.)
–TPC-115W: 13W (Typ.); 16W (Max.)
This product is intended to be supplied by IEC/UL 60950-1 and/or IEC/UL 62368-1
Listed adapter complies with Limited Power Source and rated from : 24 Vdc, mini-
mum 0.6A, minimum operating temperature 50°C.
1.2.8 External I/O
The arrangement of I/O ports is shown below.
1.3 Mounting
VESA Mount
The TPC-100 rear cover features four VESA mounting (100 x 100 mm) holes. The
VESA mounting kit needs to be installed by 4pcs M4x10L screws. Please use suit-
able mounting apparatus to avoid risk of injury.
Le capot arrière du TPC-100 dispose de quatre trous de montage VESA (100 x 100
mm). Le kit de montage VESA doit être installé à l’aide de 4 vis M4x10L. Veuillez uti-
liser un appareil de montage approprié pour éviter tout risque de blessure.
Panel Mount
There is an adhesive waterproof gasket on the front bezel. Make sure the waterproof
gasket is in position before installing a TPC-100W panel computer into the panel
opening.
1. Install the TPC into the panel opening.
2. Find the six clamps and six long screws in the accessory pack. Hook the clamps
to the holes around the four sides of the bezel. Insert the screws into every
clamp and fasten them. These screws will push the mounting panel and fix the
unit.
3. The suggested mounting panel thickness is less than 6 mm (0.236”).

5 TPC-100W Series User Manual
Chapter 1 General Information
Il y a un joint adhésif imperméable sur le panneau avant. Assurez-vous que l'imper-
méable Le joint est en place avant d'installer un ordinateur à panneau TPC-100W
dans l'ouverture du panneau.
1. Installez le TPC dans l'ouverture du panneau.
2. Recherchez les six pinces et les six vis longues dans le pack d’accessoires.
Accrocher les pinces aux trous autour des quatre côtés de la lunette. Insérez les
vis dans chaque attachez-les et attachez-les. Ces vis vont pousser le panneau
de montage et fixer le unité.
3. L'épaisseur de panneau de montage suggérée est inférieure à 6 mm (0,236 ”).
Insert the screws into each clamp and tighten
them to fasten the clamp in place.
Insérez les vis dans chaque collier et serrez-les
pour fixer le collier en place.
Hook the clamp into the holes and fasten the
screws (Torque: 2 kgf-cm)
These screws will push the mounting panel and
secure the unit.
Accrocher la pince dans les trous et serrer les vis
(couple: 2 kgf-cm)
Ces vis vont pousser le panneau de montage et
sécuriser l'unité.
Size W7 W10 W15
Screw (M4 x 25mm) &
Clamper Q’ty 4 8 10

TPC-100W Series User Manual 6
1.4 Dimensions and Cutout

7 TPC-100W Series User Manual
Chapter 1 General Information
LED Indicator
Off - “dark”
ON - “Blue”
Standby - “orange”

TPC-100W Series User Manual 8
