AEMC FlexProbe 24-3001 User manual

FLEXIBLE
AC CURRENT PROBE
FlexProbe
®
24-3001
ENGLISH User Manual
®
INSTRUMENTS
CAT III
1000V
300A
3000A
OFF
ON OL
FlexProbe
®
24-3002
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An NIST traceable certificate may be
requested at the time of purchase, or obtained
by returning the instrument to our repair and
calibration facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer.
Serial #: ________________________________
Catalog #: 2120.81
Model #: 24-3001
Please fill in the appropriate date as indicated:
Date Received: _________________________________
Date Calibration Due: _______________________
Chauvin Arnoux®, Inc.
d.b.a AEMC®Instruments
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

2 FlexProbe®- Flexible AC Current Probe
Table of Contents
1. INTRODUCTION............................................................................... 3
1.1 International Electrical Symbols................................................3
1.2 DenitionofMeasurementCategories .....................................4
1.3 ReceivingYourShipment..........................................................4
1.4 OrderingInformation.................................................................4
1.4.1 AccessoriesandReplacementParts............................4
2. PRODUCT FEATURES ...................................................................... 5
2.1 Description................................................................................5
2.2 GeneralFeatures......................................................................6
2.3 FlexProbe®24-3001Features ..................................................7
3. SPECIFICATIONS............................................................................. 8
3.1 Electrical ...................................................................................8
3.2 Environmental...........................................................................9
3.3 MechanicalSpecications ........................................................9
3.4 SafetySpecications ..............................................................10
4. OPERATION .................................................................................. 11
4.1 MakingMeasurementswiththeFlexProbe®........................... 11
4.2 TipsforMakingPreciseMeasurements..................................12
5. MAINTENANCE ............................................................................. 14
Warning...........................................................................................14
5.1 ChangingtheBattery ..............................................................14
5.2 Cleaning..................................................................................14
Limited Warranty ...................................................................................16
WarrantyRepairs...................................................................................16
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

FlexProbe®- Flexible AC Current Probe 3
CHAPTER 1
INTRODUCTION
WARNING
• Read the instruction manual completely and follow all the safety
informationbeforeattemptingtouseorservicethisinstrument.
• Wearprotectiveclothingandglovesasrequired.
• Use caution on any circuit: potentially high voltages and currents
maybepresentandmayposeashockhazard.
• Read the safety specications section prior to using the current
probe.Neverexceedthemaximumvoltageratingsgiven.
• Safetyistheresponsibilityoftheoperator.TheFlexProbe®mustbe
used only by qualied personnel using applicable safety precau-
tions.
• ALWAYS de-energize the circuit before wrapping the FlexProbe®
aroundbareconductors,busbars,ornearliveparts.Donotwrapon
liveconductors.
• ALWAYSconnecttheelectronicmoduletothedisplaydevicebefore
wrappingtheFlexProbe®aroundthesamplebeingtested.
• ALWAYSinspectthemodule,sensor,sensorcable,andoutputtermi-
nalspriortouse.Replaceanydefectivepartsimmediately.Useonly
factoryparts.
• NEVER use the FlexProbe® on electrical conductors rated above
1000V CAT III and 600V CAT IV.
1.1 International Electrical Symbols
This symbol signifies that the instrument is protected by double or reinforced
insulation.
This symbol on the instrument indicates a WARNING and that the operator must
refer to the user manual for instructions before operating the instrument. In this
manual, the symbol preceding instructions indicates that if the instructions are
not followed, bodily injury, installation/sample and product damage may result.
Risk of electric shock. The voltage at the parts marked with this symbol may be
dangerous.
This symbol refers to a type B current sensor. Do not apply around or remove from
HAZARDOUS LIVE conductors without additional protective means (de-energizing
the circuit or wearing protective clothing suitable for high voltage work).
In conformity with WEEE 2002/96/EC
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

4 FlexProbe®- Flexible AC Current Probe
1.2 Definition of Measurement Categories
CAT I: FormeasurementsoncircuitsnotdirectlyconnectedtotheAC
supply wall outlet such as protected secondaries, signal level,
andlimitedenergycircuits.
CAT II: For measurements performed on circuits directly connected to
the electrical distribution system. Examples are measurements
onhouseholdappliancesorportabletools.
CAT III: For measurements performed in the building installation at
the distribution level such as on hardwired equipment in xed
installationandcircuitbreakers.
CAT IV: For measurements performed at the primary electrical supply
(<1000V) such as on primary overcurrent protection devices,
ripplecontrolunits,ormeters.
1.3 Receiving Your Shipment
Uponreceivingyour shipment,makesure thatthecontents are consis-
tentwiththe packinglist.Notify yourdistributorof anymissingitems. If
theequipmentappearstobedamaged,leaclaimimmediatelywiththe
carrierandnotifyyourdistributoratonce,givingadetaileddescriptionof
anydamage.Savethedamagedpackingcontainertosubstantiateyour
claim.
1.4 Ordering Information
FlexProbe®24-3001 (300/3000AAC,24",10mV/A/1mV/A,withlead) .... Cat. #2120.81
Includes a exible probe with electronic module, 9V battery and a user manual.
1.4.1 Accessories and Replacement Parts
Banana(Female)/BNC(Male)Adapter............................. Cat. # 2118.46
ForconnectionofFlexProbe®toBNCterminalsonscopesandotherdis-
playinginstruments.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

FlexProbe®- Flexible AC Current Probe 5
CHAPTER 2
PRODUCT FEATURES
2.1 Description
TheFlexProbe®isaexibleACcurrenttransformercomposedofaexible
sensorandanelectronicmodule.The exiblesensorpermitsmeasure-
mentsonconductorswherestandardclamp-onprobescouldnotbeused.
In particular, it can be installed in tight spaces, around breaker panels,
aroundcablebundles,aroundwideorlargebusbars,orevenwrapped
aroundirregularshapes.
TheShapeMemoryfeatureenablestheuserto“pre-shape”thesensor
beforeinsertingitbetweenoraroundconductors.Thisfeaturefacilitates
closing,enhancesusersafety,andalleviatesthedroopingeffecttypically
associatedwithexiblesensors.
TheFlexProbe®islightweight.Itdoesnotusemagneticcoreslikestandard
transformers.Thetransformationprincipleisbasedonanaircore.Itpres-
entsvirtuallynoloadtothesystemundertest,hasalowphaseshiftand
excellentfrequencyresponse,andcannotbedamagedbyoverloads.
Thesensorassemblyiswaterproofandinsulatedfor1000VCATIII;600V
CATIV.TheFlexProbe®meetsEN61010-1andisCEmarked.
The FlexProbe® has a mV output proportional to the current measured
fordirectreadingsonDMMs,dataloggers,oscilloscopes,andpoweror
harmonicmeters.TRMSmeasurementsaretakenwhenconnectedtoa
TRMSmeter.TheFlexProbe®isinsensitivetoDCcurrentsandonlythe
ACcomponentofthemeasuredsignalismeasured.Thesensorlengthis
24".
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

6 FlexProbe®- Flexible AC Current Probe
2.2 General Features
• Modelstomeasurefrom0.5to30,000Arms
• Accuracy1%ofReading±500mA
• TRMSmeasurementswhenconnectedtoaTRMSinstrument
• Nocoresaturationordamageifoverloaded
• OverrangeLEDformeasurementcircuitry
• EN61010;1000VCATIII;600VCATIV
• Waterproofsensor
• 9Vbatteryfortypical150hourcontinuousoperations
• ShapeMemory™forcustompre-shapingofsensorbeforeuse
 (nodrooping)
• Highfrequencyresponse
• Lowphaseshiftforpowermeasurements
• InsensitivetoDC,measuresonlyACcomponentonDC+AC
signals
• Excellent linearity
• Lightweight
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

FlexProbe®- Flexible AC Current Probe 7
2.3 FlexProbe®24-3001 Features
®
INSTRUMENTS
CAT III
1000V
300A
3000A
OFF
ON OL
FlexProbe
®
24-3002
1
2
3
6
4
5
8
7
1. Flexiblesensor(Ø0.5",12.5mm)
2. Rangeselectionswitch
3. PowerONindicator(GreenLED)
4. Overload indicator (Red LED)
5. Electronicmodule
6. Doubleinsulated14"(36cm)leadwith4mmsafetybananaplugs
7. FlexProbe®connector/latch
8. Sensor lead
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

8 FlexProbe®- Flexible AC Current Probe
CHAPTER 3
SPECIFICATIONS
Reference Conditions: 41°F ± 5°F (23°C ± 3°C), 20 to 70% RH, 50Hz, 1 minute warm-up, battery at
9V ± 0.1V, external magnetic eld < 40A/m, no DC component, no external current carrying conduc-
tor, 10MΩ load, conductor center.
3.1 Electrical
Current Range: 300/3000AAC
Output Signal:mVoutput(4000mVpeakmax)
Three position slide switch: 10mV/A 5A to 300Arms
1mV/A 50A to 3000Arms
ON/OFF
AC Current Accuracy (after calibration and for one year):
1%ofReading±500mA
Crest Factor: 4.5
Phase Shift:<0.7°at50or60Hz
Frequency Range:40to5kHz
Residual Noise When I Measured = 0: 200mArms
Working Voltage: 1000VrmsCATIII;600VCATIV
Common Mode Voltage: 600Vrms max
Inuence of Frequency: Add1%tothereferenceaccuracybetween40
and2000Hz,andupto5%at5kHz
Inuence of Adjacent Conductor: <2%
Inuence of Conductor Position in Jaw: <4%
Power Source:9Valkaline(NEDA1604A,IEC6LR61)
Battery Life: 150hourstypical(continuoususe)
 300hourswithLithiumbattery
Low Battery:GreenLEDOffwhen≥7V
Overload Indication: RedLEDindicatesinputgreaterthanselectedrange
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

FlexProbe®- Flexible AC Current Probe 9
3.2 Environmental
Operating Temperature Range: 14°to131°F(-10°to+55°C)
Storage Temperature Range: -40°to158°F(40°to+70°C)
Inuence of Temperature:
Sensor:-14°to212°F(-10°to100°C);<0.5%per10°C
Module:-14°to131°F(-10°to55°C);<0.5%per10°C
Operating Relative Humidity:
50°to86°F(10°to30°C);85±5%RH(withoutcondensation)
104°to122°F(40°to50°C);45±5%RH(withoutcondensation)
Altitude: Operating:0to2000m
 Non-operating:0to12000m
3.3 Mechanical Specifications
Dimensions (Sensor): 24"±1"(610x25mm)
Color (Sensor): Redwithblackconnector
Dimensions (Electronic Module):4.9x2.5x1.1"(124x64x28mm)
Color (Electronic Module): Darkgray
Weight: 1.1lb(0.5kg)
Output: Doubleinsulated14"(355Mm)leadwith4mmsafetybananaplugs
Maximum Cable Diameter: 7.6"(193mm)
Cable Length from Sensor to Module:6.5ft(2m)
Drop Test:
1.0mon38mmofOakonconcrete.TestaccordingtoEN61010.
Case Protection: Sensor:IP65ElectronicModule:IP40
Vibration: Test Per IEC 68-2-6
Frequency Range:10to55Hz
Amplitude: 0.15mm
Mechanical Shock: 100G,TestPerIEC68-2-32
Material: Module:PolycarbonateUL94V1
 CableAssembly:PolyurethaneUL94V0
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

10 FlexProbe®- Flexible AC Current Probe
3.4 Safety Specifications
Electrical Safety
Doubleinsulationorreinforcedinsulationbetweentheprimaryorthesec-
ondaryandtheoutercaseofthehandleperEN61010.
EN61010,1000VCATIII,600VCATIV
PollutionDegree:2
Electromagnetic Compatibility:
EN 50081-1 Class B
EN50082-2 ElectrostaticdischargeIEC1000-4-2
Radiated Field IEC 1000-4-3
Fast transients IEC 1000-4-4
MagneticFieldat50/60HzIEC1000-4-8
*Specications are subject to change at any time without notice
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

FlexProbe®- Flexible AC Current Probe 11
CHAPTER 4
OPERATION
Please make sure that you have already read and fully understand the
WARNINGsectiononpage2.
4.1 Making Measurements with the FlexProbe®
1. ConnecttheelectronicmoduletotheACVoltrangeofyourDMMor
measuringinstrument.
2. Select the appropriate module output voltage range. If the current
magnitudeisunknown,selectthe3000Arange.
3. Wraptheexiblecorearoundtheconductortobetested.Selectthe
300Arangetoobtainthe best resolution,ifthereading is lessthan
300mV.
Do not exceed specied current range for the output. Do not
use on selected range if Overload LED goes on.
4. Example:
a. ReadtheDMMdisplayedvalue:2.59V
b. DeterminetherangeandoutputusedontheFlexProbe:0.01V/A
forthe300Arange;.001V/Aforthe3000Arange
c. Dividethereadingbytheoutputtodeterminetheactualcurrent
value:2.59÷0.01=259Aor2.59÷0.001=2590A
Forbestaccuracy,carefullycentertheconductorinsidetheexiblecore,
andavoidifpossible,theproximityofotherconductorswhichmaycreate
noiseandinterference(particularlynearthelatch).
TrueRMSmeasurementsareobtainedwhentheFlexProbe®is connected
toaTrueRMSmeter.NotethattheDCcomponentisnotmeasured.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

12 FlexProbe®- Flexible AC Current Probe
4.2 Tips for Making Precise Measurements
• When using the FlexProbe® with a meter, it is
important to select the range that provides the
best resolution. Failure to do this may result in
measurementerrors.
• For best results, select the highest FlexProbe®
output signal possible and the most sensitive
meterrangeforthisoutput.
• MakesuretheDMMormeasuringinstrumentcan
accurately measure mVAC. Certain inexpensive
DMM have poor resolution and accuracy when
measuringlowmVAC.
• Forbestaccuracy,centertheFlexProbe®around
theconductortobemeasured.
• Toincreasethesensitivityormeasureonlowcur-
rents, the FlexProbe® may be wrapped several
timesaroundtheconductor.Remembertodivide
yourreadingbythenumberofturnsfortheactual
measurement(SeeFigure1).
• Theoverallmeasurementaccuracyisthesumof
theFlexProbe® accuracyandthedisplayinginstru-
mentaccuracy.
• TheFlexProbe®maybedoubledaroundthecon-
ductortobemeasuredtodoubletheoutput.(See
Figures1and2toshowthedifferentvaluesona
DMMwhilemeasuring250AAC.)
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

FlexProbe®- Flexible AC Current Probe 13
ACV DCV
COM +
500.0 MV
One turn around a
conductor carrying 250AAC
Figure 1
Figure 2
3000A
Range
3000A
Range
250A
®
INSTRUMENTS
CAT III
1000V
300A
3000A
OFF
ON OL
FlexProbe
®
24-3002
ACV DCV
COM
+
250.0 MV
®
INSTRUMENTS
CAT III1000V
300A
3000A
OFF
ON OL
FlexProbe
®
24-3002
Double the turns to double
the output in low current applications
or for higher sensitivity
250A
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

14 FlexProbe®- Flexible AC Current Probe
CHAPTER 5
MAINTENANCE
Warning
• Formaintenanceuseonlyspeciedreplacementparts.
• Toavoidelectricalshock,donotattempttoperformanyservicing
unlessyouarequaliedtodoso.
• Do not perform any service while the FlexProbe®is on any
circuit.
• Toavoidelectricalshockand/ordamagetotheinstrument,donot
getwaterorotherforeignagentsintotheelectronicmodule.
• Alsoseewarningonpage2.
5.1 Changing the Battery
IfthepowerONindicator(greenLED)blinksordoesnotlightup,replace
thebattery.
Disconnect the instrument from any source of electricity.
• To replace the battery, open rear case, replace battery and re-
assemble.
• ThegreenLEDshouldgoonwhenthemoduleisturnedon.
5.2 Cleaning
• Useasoftclothlightlydampenedwithsoapywater,thendrywith
adrycloth.
• Donotsplashwaterdirectlyontheinstrument.
• Donotusealcohol,solventsorhydrocarbons.
• Make sure the sensor, electronic module, and all leads are dry
beforeanyfurtheruse.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

16 FlexProbe®- Flexible AC Current Probe
Limited Warranty
TheFlexProbe®iswarrantedtotheownerforaperiodofoneyearfromthe
dateoforiginalpurchaseagainstdefectsinmanufacture.Thislimitedwarranty
isgivenbyAEMC®Instruments,notbythedistributorfromwhomitwaspur-
chased.Thiswarrantyisvoidiftheunithasbeentamperedwith,abusedorif
thedefectisrelatedtoservicenotperformedbyAEMC®Instruments.
Full warranty coverage and product registration is available on our
website at www.aemc.com/warranty.html.
Please print the online Warranty Coverage Information for your records.
What AEMC®Instruments will do:
Ifamalfunctionoccurswithintheone-yearperiod,youmayreturntheinstrument
tousforrepair,providedwehaveyourwarrantyregistrationinformationonle
oraproofofpurchase.AEMC®Instrumentswill,atitsoption,repairorreplace
thefaultymaterial.
Warranty Repairs
What you must do to return an Instrument for Warranty Repair:
First, request a Customer ServiceAuthorization Number (CSA#) by phone
orbyfaxfromourServiceDepartment(seeaddressbelow),thenreturnthe
instrumentalongwith the signedCSAForm.Please writetheCSA#onthe
outsideoftheshippingcontainer.Returntheinstrument,postageorshipment
pre-paidto:
Ship To: ChauvinArnoux®,Inc.d.b.a.AEMC®Instruments
 15FaradayDrive•Dover,NH03820USA
 Phone:(800)945-2362(Ext.360)
[phone] (Ext. 360)
 Fax: (603)742-2346or(603)749-6309
 E-mail:[email protected]
Caution:Toprotectyourselfagainstin-transitloss,werecommendyouinsure
yourreturnedmaterial.
NOTE: You must obtain a CSA# before returning any instrument.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

01/15
99-MAN100272v8
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
            
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664
