AGI WHEATHEART X Series Installation and operating instructions

Part Number: 30787 R2
Revised: 20/8/2015
Read this manual before using product. Failure
to follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
X-SERIES 13" AUGERS
X130-74, X130-84, X130-94
ASSEMBLY AND OPERATION MANUAL
ORIGINAL INSTRUCTIONS

This product has been designed and constructed according to general engineering
standardsa. Other local regulations may apply and must be followed by the operator.
We strongly recommend that all personnel associated with this equipment be trained
in the correct operational and safety procedures required for this product. Periodic
reviews of this manual with all employees should be standard practice. For your
convenience, we include this sign-off sheet so you can record your periodic reviews.
a. Standards include organizations such as the American Society of Agricultural and Biological Engineers,
American National Standards Institute, Canadian Standards Association, International Organization for
Standardization, EN Standards, and/or others.
Date Employee Signature Employer Signature

TABLE OF CONTENTS
WHEATHEART - X-SERIES 13" AUGERS
X130-74, X130-84, X130-94
30787 R2 3
1. Introduction .......................................................................................................................... 7
1.1. Overview .................................................................................................................. 8
1.1.1. Auger Power Source .................................................................................. 8
1.1.2. Grain Transfer Boot.................................................................................... 9
1.1.3. Grain Hopper............................................................................................ 10
1.1.4. Auger Tube Hydraulic Lift......................................................................... 11
2. Safety .................................................................................................................................. 13
2.1. General Safety Information .................................................................................... 13
2.2. Assembly Safety..................................................................................................... 14
2.3. Operating Safety .................................................................................................... 15
2.4. Hydraulic Safety..................................................................................................... 15
2.5. PTO Driveline Safety.............................................................................................. 16
2.6. Tire Safety.............................................................................................................. 16
2.7. Transport Safety..................................................................................................... 17
2.8. Storage Safety........................................................................................................ 17
2.9. Maintenance Safety................................................................................................ 17
2.10. Safety Decals....................................................................................................... 18
2.10.1. Decal Installation/Replacement.............................................................. 18
2.10.2. Safety Decal Locations and Details........................................................ 18
3. Assembly ............................................................................................................................ 25
3.1. General Assembly.................................................................................................. 25
3.2. Identify Auger Tube Sections................................................................................. 27
3.3. Assemble the Main Auger Tube............................................................................. 30
3.4. Install the Boot on the Auger tube.......................................................................... 31
3.5. Install Boot Bearing, Lower Sprocket, and Drive Chain ......................................... 33
3.6. Install the Boot Tow Bar......................................................................................... 34
3.7. Install the Discharge Spout .................................................................................... 35
3.8. Set the Thrust Adjuster........................................................................................... 35
3.9. Apply Logo and Model Decals................................................................................ 36
3.10. Auger Tube Truss Assembly................................................................................ 37
3.10.1. X130-74 Auger Tube Truss Assembly.................................................... 37
3.10.2. X130-84/X130-94 Auger Tube Truss Assembly..................................... 42
3.11. Assemble the Auger Frame................................................................................. 50
3.12. Installing the Hydraulic Cylinders......................................................................... 57
3.13. Assemble Wheel Hubs and Install Tires............................................................... 58
3.14. Attaching the Auger Tube to the Frame............................................................... 59
3.15. Connecting Hydraulic Hose to Cylinders.............................................................. 62
3.16. Install Low Profile Intake Hopper.......................................................................... 66
3.17. Installing the Hopper Lift Arm and Winch............................................................. 70
3.18. Install the Hitch Jack ........................................................................................... 74
3.19. Connecting the PTO Driveline.............................................................................. 74
3.20. Auger-to-Tractor Hookup...................................................................................... 76

TABLE OF CONTENTS
WHEATHEART - X-SERIES 13" AUGERS
X130-74, X130-84, X130-94
430787 R2
4. Transport............................................................................................................................. 79
4.1. Transport Procedure............................................................................................... 79
5. Placement ........................................................................................................................... 83
5.1. Placement Procedure............................................................................................. 83
5.2. Positioning Tractor for Right-angle Drive Operation............................................... 87
6. Operation ............................................................................................................................ 89
6.1. Pre-operation Checklist ......................................................................................... 89
6.2. Operator Controls................................................................................................... 90
6.2.1. PTO Drive Operation................................................................................ 91
6.2.2. Hydraulics Operation................................................................................ 91
6.3. Operating Procedures ............................................................................................ 92
6.3.1. Initial Start-Up........................................................................................... 92
6.3.2. Normal Start.............................................................................................. 93
6.3.3. Normal Shutdown..................................................................................... 94
6.3.4. Emergency Stop / Full-Tube Restart ........................................................ 95
6.3.5. Reverser Operation .................................................................................. 96
6.3.6. Lowering & Completion............................................................................. 99
7. Maintenance...................................................................................................................... 101
7.1. Maintenance Intervals .......................................................................................... 101
7.2. Fluids and Lubricants ........................................................................................... 102
7.3. Maintenance Procedures...................................................................................... 102
7.3.1. Visual Inspection..................................................................................... 102
7.3.2. Hydraulic Hose and Coupler Inspection ................................................. 103
7.3.3. Machine Greasing................................................................................... 103
7.3.4. Hopper Lift Cable Inspection .................................................................. 105
7.3.5. Winch and Pulley Servicing.................................................................... 105
7.3.6. Swing Tube Coupler Chain Servicing..................................................... 106
7.3.7. Boot and Hopper Chain Drive Servicing................................................. 107
7.3.8. Gearbox Oil Level................................................................................... 108
7.3.9. Speed Reducer Gearbox Oil Levels....................................................... 109
7.3.10. Machine Cleaning................................................................................. 109
7.3.11. Tire Pressure Check............................................................................. 109
7.3.12. Wheel Bearings Repack....................................................................... 109
7.3.13. Wheel Bolt Tightening........................................................................... 110
7.3.14. Cable Adjustment (X130-74) ................................................................ 111
7.3.15. Cable Adjustment (X130-84, X130-94)................................................. 112
7.3.16. Changing Upper/Lower Gearbox Oil..................................................... 113
7.3.17. Changing the Speed Reducer Gearbox Oil.......................................... 113
8. Storage.............................................................................................................................. 115
9. Troubleshooting ............................................................................................................... 117

WHEATHEART - X-SERIES 13" AUGERS
X130-74, X130-84, X130-94
30787 R2 5
10. Appendix......................................................................................................................... 119
10.1. Specifications..................................................................................................... 119
10.2. Bolt Torque Values............................................................................................. 120
Warranty Registration ........................................................................................................... 123
Limited Warranty................................................................................................................... 125

WHEATHEART - X-SERIES 13" AUGERS
X130-74, X130-84, X130-94
630787 R2

WHEATHEART - X-SERIES 13" AUGERS 1. INTRODUCTION
X130-74, X130-84, X130-94
30787 R2 7
1. Introduction
Congratulations on the purchase of your new Wheatheart X13 Series Auger. This
equipment will complement your agricultural operation by safely and efficiently
moving grain, pulse crops, fertilizer, and any other granular materials.
Many of the features incorporated into this machine are the result of suggestions
made by customers like you. Your new Wheatheart auger will serve you well if
you understand how it operates, and if you use it and care for it properly. This
manual is intended to help you learn how to operate and maintain your
equipment in a safe, efficient, and trouble-free manner. Please read this manual
before you use your new grain auger.
This manual covers all X13 Series augers built by Wheatheart Manufacturing.
Use the table of contents as a guide when searching for specific information.
Keep this manual in a safe place for future reference and for ordering
replacement parts.
Should any information remain unclear after thoroughly reviewing this manual,
contact your Wheatheart Dealer for clarification before operating your auger.
Knowing the serial number and date of purchase will save time in getting your
questions answered. Please write down this information in the space provided
below.

1. INTRODUCTION WHEATHEART - X-SERIES 13" AUGERS
1.1. OVERVIEW X130-74, X130-84, X130-94
830787 R2
1.1. OVERVIEW
X13 augers are equipped with standard features that include a hydraulically
controlled main auger tube lift, a low-profile grain hopper (left or right side
operation), service access doors, and a PTO driveline for auger power.
Available option kits include:
• Hydraulic Winch
• Hydraulic Power Swing for Hopper
• Electric Power Swing for Hopper
• Right Angle Drive
• 540 RPM PTO Reverser
• 1000 RPM PTO Drive and Reverser
1.1.1. AUGER POWER SOURCE
The power source for the auger is a standard 540 RPM tractor PTO (see Figure
1.1). An optional Right-Angle PTO Drive kit allows the auger to be powered by a
tractor positioned at a 90 degree angle to the auger (Figure 1.2).
An optional 1000 RPM PTO Drive kit provides a speed reducer that allows use
with 1000 RPM PTO tractors, as well as reverser capability that is used to rotate
the auger flightings in the reverse direction (transferring grain in the auger tube
back to the hopper).
An optional 540 RPM Reverser kit provides a similar reverser capability for
540 RPM PTO connections.
Figure 1.1 Standard PTO Driveline

WHEATHEART - X-SERIES 13" AUGERS 1. INTRODUCTION
X130-74, X130-84, X130-94 1.1. OVERVIEW
30787 R2 9
Figure 1.2 Right Angle PTO Driveline Kit
1.1.2. GRAIN TRANSFER BOOT
The grain transfer boot is located at the bottom of the main auger tube, and
contains gearing for power transfer as well as flights for transferring grain.
Figure 1.3 Grain Transfer Boot
GRAIN TRANSFER BOOT
SWING ARM SPOUT HEAD
OVERFLOW
PTO DRIVELINE
HITCH
HITCH JACK
SPOUT HEAD
SERVICE HATCH
CLEAN-OUT HATCH MANUAL WINCH (HOPPER)
BALL
VALVE
PANEL

1. INTRODUCTION WHEATHEART - X-SERIES 13" AUGERS
1.1. OVERVIEW X130-74, X130-84, X130-94
10 30787 R2
PTO driveline connection (including connection to the optional 540 RPM PTO
Reverser and 1000 RPM PTO Drive) is provided on the back of the boot, above
the tractor hitch (and hitch jack).
The ball valve used to raise or lower the main auger tube is located on the side of
the boot (see figure below), as is the manual winch used to raise and lower the
grain hopper (see Section 6.2. Operator Controls on page 90 for further infor-
mation on auger controls).
Several access hatches are provided for maintenance and repair (the swing arm
spout head access hatch is shown below), as well as an overflow panel on the
swing-arm spout head and a clean-out hatch at the bottom of the boot.
1.1.3. GRAIN HOPPER
The low-profile grain hopper is designed to be rolled into position to receive grain
for transfer through the boot to the auger discharge spout. Ground clearance can
be adjusted by raising or lowering the position of the hopper wheel axles.
The grain hopper must be lifted and secured for transport using the hopper lift
arm, winch (hydraulic or manual operation, according to the installed option), and
transport chain and hook (see Figure 1.5).
The grain hopper provides service to the side of the auger that it is installed on,
but the hopper, lift arm, and winch can be quickly reconfigured to install the
hopper on the other side if required.
Do not approach, open or close the maintenance hatch located on the transition
between the swing are tube and the hopper unless all power to the auger is
locked out.
DANGER
Rotating Auger Hazard
Contact with rotating flighting will result in
amputation or severe laceration.
DO NOT operate with guards removed or
modified.
Keep hands and feet away from rotating
auger.
Tie up long hair and remove jewelry.
DO NOT wear loose-fitting clothing or items
that could become caught.
Shut off and lock out the power source before
unplugging or cleaning.

WHEATHEART - X-SERIES 13" AUGERS 1. INTRODUCTION
X130-74, X130-84, X130-94 1.1. OVERVIEW
30787 R2 11
Figure 1.4 Grain Hopper
Figure 1.5 Grain Hopper Lifted into Transport Position
1.1.4. AUGER TUBE HYDRAULIC LIFT
The auger tube is raised and lowered using two single-acting hydraulic cylinders
powered by the hydraulic supply of the connected tractor. The main auger tube is
raised by extending the cylinders, and lowered by allowing the cylinders to
retract.
A hydraulic ball valve mounted on the side of the grain pick-up boot controls flow
of hydraulic fluid to the lift cylinders, and with appropriate use of the hydraulic
controls on the connected tractor, allows the main auger tube to be raised,
lowered, or locked at a specific height during operation (see “Operator Controls”
on page 90).
INTAKE HOPPER
FLIGHTS AND
SWING ARM
MAINTENANCE HATCH
SPOUT HEAD
MAIN AUGER TUBE
BOOT FLIGHT GUARDING
WINCH CABLE AND HOOK
SAFETY CHAIN AND HOOK HOPPER LIFT ARM

1. INTRODUCTION WHEATHEART - X-SERIES 13" AUGERS
1.1. OVERVIEW X130-74, X130-84, X130-94
12 30787 R2

WHEATHEART - X-SERIES 13" AUGERS 2. SAFETY
X130-74, X130-84, X130-94 2.1. GENERAL SAFETY INFORMATION
30787 R2 13
2. Safety
2.1. GENERAL SAFETY INFORMATION
The Safety Alert symbol identifies important safety messages on the product and
in the manual. When you see this symbol, be alert to the possibility of personal
injury or death. Follow the instructions in the safety messages.
Why is SAFETY important?
• Accidents disable and kill.
• Accidents cost.
• Accidents can be avoided.
SIGNAL WORDS: Note the use of the signal words DANGER, WARNING,
CAUTION, and NOTICE with the safety messages. The appropriate signal word
for each message has been selected using the definitions below as a guideline.
DANGER
Indicates an imminently hazardous situation
that, if not avoided, will result in serious injury
or death.
WARNING
Indicates a hazardous situation that, if not
avoided, could result in serious injury or
death.
CAUTION
Indicates a hazardous situation that, if not
avoided, may result in minor or moderate
injury.
NOTICE
Indicates a potentially hazardous situation that, if not
avoided, may result in property damage.

2. SAFETY WHEATHEART - X-SERIES 13" AUGERS
2.2. ASSEMBLY SAFETY X130-74, X130-84, X130-94
14 30787 R2
YOU are responsible for the SAFE use and maintenance of your equipment.
YOU must ensure that you and anyone else who is going to work around the
equipment understands all procedures and related SAFETY information
contained in this manual.
Remember, YOU are the key to safety. Good safety practices not only protect
you, but also the people around you. Make these practices a working part of your
safety program.
Important: Below are general instructions that apply to all safety practices. Any instructions
specific to a certain safety practice (e.g., Operational Safety), can be found in the
appropriate section. Always read the complete instructional sections and not just
these safety summaries before doing anything with the equipment.
• It is the equipment owner, operator, and maintenance personnel's responsi-
bility to read and understand ALL safety instructions, safety decals, and man-
uals and follow them when assembling, operating, or maintaining the
equipment. All accidents can be avoided.
• Equipment owners must give instructions and review the information initially
and annually with all personnel before allowing them to operate this product.
Untrained users/operators expose themselves and bystanders to possible
serious injury or death.
• Use this equipment for its intended purposes only.
• Do not modify the equipment in any way without written permission from the
manufacturer. Unauthorized modification may impair the function and/or
safety, and could affect the life of the equipment. Any unauthorized modifica-
tion of the equipment voids the warranty.
• Do not allow any unauthorized person in the work area.
2.2. ASSEMBLY SAFETY
• Read and understand the assembly instructions to get to know the sub-
assemblies and hardware that make up the equipment before proceeding to
assemble the product.
• Do not take chances with safety. The components are large, heavy, and can
be hard to handle. Always use the proper tools, stands, jacks, and hoists for
the job.
• Always have two or more people assembling the equipment. Because of the
weight, do not attempt assembly alone.

WHEATHEART - X-SERIES 13" AUGERS 2. SAFETY
X130-74, X130-84, X130-94 2.3. OPERATING SAFETY
30787 R2 15
2.3. OPERATING SAFETY
• Ensureguards
are installed
and secure.
• Clear the work
area of
untrained peo-
ple.
• Clean the
work area to
prevent slip-
ping or trip-
ping.
• Have a fully
equipped first
aid kit and fire
extinguisher
on hand and
know how to
use them.
• Be certain the
PTO driveline
is securely
attachedtothe
auger and to
the tractor.
• Before start-
ing the tractor,
be certain that
the PTO is in
the off posi-
tion.
• Keep hands,
feet, hair, and
clothing away
from all mov-
ing or rotating parts.
2.4. HYDRAULIC SAFETY
• Always place all tractor hydraulic controls in neutral before disconnecting
from tractor or working on hydraulic system.
• Make sure that all components in the hydraulic system are kept in good con-
dition and are clean.
• Replace any worn, cut, abraded, flattened, or crimped hoses.
Figure 2.1

2. SAFETY WHEATHEART - X-SERIES 13" AUGERS
2.5. PTO DRIVELINE SAFETY X130-74, X130-84, X130-94
16 30787 R2
• Do not attempt any makeshift repairs to the hydraulic fittings or hoses by
using tape, clamps, or cements. The hydraulic system operates under
extremely high-pressure. Such repairs create a hazardous and unsafe condi-
tion because they will fail suddenly.
• Wear proper hand and eye protection when searching for a high-pressure
hydraulic leak. Do not use hands. Use a piece of wood or cardboard as a
backstop to isolate and identify a leak.
• If injured by a concentrated
high-pressure stream of
hydraulic fluid, seek medical
attention immediately. Seri-
ous infection or toxic reaction
can develop from hydraulic
fluid piercing the skin surface.
2.5. PTO DRIVELINE SAFETY
• To prevent serious injury or death:
• Keep body, hair, and clothing away from rotating PTO driveline.
• Do not operate equipment unless all driveline, tractor, and equipment shields
are in place and in good working order.
• Make certain the driveline shields turn freely on driveline.
• Make certain the driveline is securely attached at both ends.
• Do not exceed operating speed of 540 rpm.
• Keep u-joint angles small and equal. Do not exceed maximum recommended
length for PTO driveline.
• Do not exceed manufacturer’s recommended operating length.
• Set the tractor brake and block wheels on the tractor and the implement to
insure proper spacing of the PTO shaft at all times.
• Make sure driveline is properly secured to prevent damage during transport.
2.6. TIRE SAFETY
• Failure to follow proper procedures when mounting a tire on a wheel or rim
can produce an explosion that may result in serious injury or death.
• Do not attempt to mount a tire unless you have the proper equipment and
experience to do the job.
• Have a qualified tire dealer or repair service perform required tire mainte-
nance.
• When replacing worn tires, make sure they meet the original tire specifica-
tions. Never undersize the replacement tire.
• Do not weld to the tire rim with the tire mounted on the rim. This action may
cause an explosion which could result in serious injury or death.
• Inflate tires to the manufacturer's recommended pressure.

WHEATHEART - X-SERIES 13" AUGERS 2. SAFETY
X130-74, X130-84, X130-94 2.7. TRANSPORT SAFETY
30787 R2 17
2.7. TRANSPORT SAFETY
• Ensure tires are inflated to the tire manufacturer’s recommended pressure.
• Make sure that all lights and reflectors required by the local highway and
transport authorities are in place, are functioning, and can be seen clearly by
all overtaking and oncoming traffic.Check with local authorities regarding
transportation of agricultural equipment on public roads. Obey all applicable
laws and regulations.
• Be sure the unit is hitched securely to the towing vehicle.
• Do not allow riders while transporting.
• Display a Slow Moving Vehicle (SMV) emblem when transporting below 15
mph (24 km/h).
• Use hazard-warning flashers when transporting with a tractor unless prohib-
ited.
• Keep to the right and yield the right-of-way to allow faster traffic to pass.
• Never transport faster than the road terrain or conditions will safely allow.
• Use caution when turning corners or meeting traffic.
• Use caution when approaching height-limiting objects.
• Be especially careful when transporting during times of limited visibility (rain,
snow, fog, dusk, or at night). If you can, wait for a more appropriate time to
move the equipment.
• Do not transport auger on a slope greater than 20°—the auger may overturn.
• The manual winch must be in the locked position. To lock, turn handle clock-
wise until you hear two clicks. Also ensure that the locking pin and clips are in
place on the hopper lift arm.
2.8. STORAGE SAFETY
• Store in an area away from human activity.
• Do not permit children to play on or around the stored machine.
2.9. MAINTENANCE SAFETY
• Shut off and disable the power source before working on the machine.
• Ensure service area is clean and dry.
• Ensure electrical outlets and tools are properly grounded.
• Use proper tools for the job and wear appropriate safety gear.
• Ensure there is adequate lighting to perform the job safely.
• Place chocks in front and behind the wheels to prevent the machine from roll-
ing.
• Use extra caution when cleaning and servicing augers because flighting
edges can be sharp.
• Follow proper procedures when mounting a tire on a rim. If in doubt, have a
qualified tire repair service perform the required maintenance.
• Install and secure all guards after maintenance work is completed.

2. SAFETY WHEATHEART - X-SERIES 13" AUGERS
2.10. SAFETY DECALS X130-74, X130-84, X130-94
18 30787 R2
2.10. SAFETY DECALS
• Keep safety decals clean and legible at all times.
• Replace safety decals that are missing or have become illegible. See decal
location figures that follow.
• Replaced parts must display the same decal(s) as the original part.
• Replacement safety decals are available free of charge from your distributor,
dealer, or factory.
2.10.1. DECAL INSTALLATION/REPLACEMENT
1. Decal area must be clean and dry, with a temperature above 50°F (10°C).
2. Decide on the exact position before you remove the backing paper.
3. Align the decal over the specified area and carefully press the small portion
with the exposed sticky backing in place.
4. Slowly peel back the remaining paper and carefully smooth the remaining
portion of the decal in place.
5. Small air pockets can be pierced with a pin and smoothed out using the sign
backing paper.
2.10.2. SAFETY DECAL LOCATIONS AND DETAILS
Replicas of the safety decals that are attached to the equipment and their
messages are shown in the figure(s) that follow. Safe operation of the equipment
requires that you familiarize yourself with the various safety decals and the areas
or particular functions that the decals apply to, as well as the safety precautions
that must be taken to avoid serious injury, death, or damage.

WHEATHEART - X-SERIES 13" AUGERS 2. SAFETY
X130-74, X130-84, X130-94 2.10. SAFETY DECALS
30787 R2 19
Figure 2.2
WARNING
HIGH PRESSURE FLUID HAZARD
Hydraulic fluid can cause serious injury if it
penetrates the skin. If it does, see a doctor
immediately.
• Relieve pressure before disconnecting hydraulic line.
• Wear proper hand and eye protection and use wood or
cardboard, not hands, when searching for leaks.
20805
DECAL #20805

2. SAFETY WHEATHEART - X-SERIES 13" AUGERS
2.10. SAFETY DECALS X130-74, X130-84, X130-94
20 30787 R2
Figure 2.3
DECAL #18859
NOTICE
Disconnect PTO driveline
fromtractorbefore moving
equipment.
If attached, driveline will
bottom out, severely
damaging theCVu-joint
and lower flight shaft.
See manualfor
maintenance.
95881adanaCniedaM
NOTICE
Disconnect PTO driveline
from tractor before moving
equipment.
If attached, driveline will
bottom out, severely
damaging the CV u-joint
and lower flight shaft.
See manual for
maintenance.
95881adanaCniedaM
NOTICE
• Follow dimensions above for correct
auger-to-tractor hookup.
To prevent
damage
during
auger-to-
tractor
hookup:
• Adjust drawbar as needed.
• See operation manual for complete details.
• Auger must be on level ground and in full down
position when measuring.
17531
Made in Canada
DECAL #17531
