AGI WRX Series User manual

Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: 31059 R1
Revised: November 2019
WRX Series
Portable Grain Auger
Assembly Manual
This manual applies to the following brands and models:
Westfield, AGI, Hutchinson, Mayrath
8-31, 8-36, 8-41, 8-46, 8-51, 8-56, 8-61, 8-71, 8-76
10-31, 10-36, 10-41, 10-51, 10-61, 10-71
Original Instructions

New in this Manual
The following changes have been made in this revision of the manual:
Description Section
New brands and models added
Model Decal Locations updated Section 4.4 – Brand and Model Decal Placement on
page 24
8" Model instructions added Section 4.5 – Assemble Tube & Flighting on page 25
Section 4.8 – Install the Spout on page 29
Section 4.20.6 – Sprocket Head Gearing (540 RPM
Only) on page 70
Added instructions for new models Section 4.16 – Attach Frame to Tube on page 40
Section 4.18 – Install the Electric Motor Drive on page
43
Section 4.20 – Install the PTO-SD on page 62
Section 4.22 – Install Manual Holder on page 75
Upper and Lower Track Stop Locations added for new
models
Section 4.7 – Install the Track Stops on page 27
New spout design for 10" models Section 4.8 – Install the Spout on page 29
Truss Towers and Truss Cables added for larger
models
Section 4.13 – Install Truss Towers on page 34
Section 4.14 – Install Truss Cable on page 36
New frame design for larger models Section 4.15 – Assemble the Frame on page 38
Cable Guide Assembly only required for MD augers Section 4.17 – Install the Manual Winch and Connect
the Lift Cable on page 42
Washers and Flange Nuts added on EMD Belt Guard
Assembly
Section 4.18.5 – Install the EMD Belt Guard Assembly
on page 47
Driveshaft and Driveshaft Guard instructions updated
for PTO-SD models
Section 4.20.1 – Install the Driveshaft and Guards on
page 62

WRX SERIES – PORTABLE GRAIN AUGER
31059 R1 3
CONTENTS
1. Introduction ............................................................................................................................................ 5
2. Safety....................................................................................................................................................... 6
2.1 Safety Alert Symbol and Signal Words...................................................................................... 6
2.2 General Safety ........................................................................................................................... 6
2.3 Rotating Flighting Safety ........................................................................................................... 7
2.4 Rotating Parts Safety................................................................................................................. 7
2.5 Hand Winch Safety .................................................................................................................... 7
2.6 Drives and Lockout Safety......................................................................................................... 7
2.6.1 Gas Engine Safety....................................................................................................... 8
2.6.2 Electric Motor Safety.................................................................................................. 8
2.6.3 PTO Driveline Safety................................................................................................... 9
2.6.4 Hydraulic Power Safety ............................................................................................ 10
2.7 Tire Safety................................................................................................................................ 11
2.8 Battery Safety .......................................................................................................................... 11
2.9 Personal Protective Equipment............................................................................................... 12
2.10 Safety Equipment .................................................................................................................. 12
2.11 Safety Decals ......................................................................................................................... 13
2.11.1 Decal Installation/Replacement............................................................................. 13
2.11.2 Safety Decal Locations and Details ........................................................................ 13
3. Features................................................................................................................................................. 22
4. Assembly ............................................................................................................................................... 23
4.1 Assembly Safety ...................................................................................................................... 23
4.2 Check Shipment....................................................................................................................... 23
4.3 Before You Begin ..................................................................................................................... 23
4.4 Brand and Model Decal Placement ........................................................................................ 24
4.5 Assemble Tube & Flighting...................................................................................................... 25
4.6 Install the Lower Driveshaft Guard (41', 71', and 76' Only) ................................................... 26
4.7 Install the Track Stops ............................................................................................................. 27
4.8 Install the Spout ...................................................................................................................... 29
4.9 Add Grease to Head Cover...................................................................................................... 30
4.10 Install the Intake Cage........................................................................................................... 31
4.11 Install the Hitch ..................................................................................................................... 32
4.12 Install the Lift Cable............................................................................................................... 32
4.13 Install Truss Towers............................................................................................................... 34
4.14 Install Truss Cable.................................................................................................................. 36
4.15 Assemble the Frame.............................................................................................................. 38
4.16 Attach Frame to Tube ........................................................................................................... 40
4.17 Install the Manual Winch and Connect the Lift Cable .......................................................... 42
4.18 Install the Electric Motor Drive ............................................................................................. 43
4.18.1 Install the Gearbox ................................................................................................. 43
4.18.2 Install the EMD Mount Assembly .......................................................................... 44
4.18.3 Install the Backplate Mount................................................................................... 45
4.18.4 Install the Electric Motor ....................................................................................... 46
4.18.5 Install the EMD Belt Guard Assembly .................................................................... 47
4.18.6 Install the Pulleys ................................................................................................... 48
4.18.7 Install the Belt ........................................................................................................ 49
4.18.8 Tension the Belt ..................................................................................................... 49

WRX SERIES – PORTABLE GRAIN AUGER
4 31059 R1
4.19 Install the Motor Drive .......................................................................................................... 51
4.19.1 Install the Gearbox ................................................................................................. 51
4.19.2 Install the Gearbox Brackets .................................................................................. 52
4.19.3 Install the Motor Mount ........................................................................................ 53
4.19.4 Install the Battery and Fuel Tank (Gas Motor Only).............................................. 57
4.19.5 Install the Motor .................................................................................................... 58
4.19.6 Install the Engine Pulley ......................................................................................... 59
4.19.7 Install the Gearbox Pulley ...................................................................................... 59
4.19.8 Install the Belt ........................................................................................................ 60
4.19.9 Install the Gearbox Pulley Cover............................................................................ 61
4.20 Install the PTO-SD.................................................................................................................. 62
4.20.1 Install the Driveshaft and Guards .......................................................................... 62
4.20.2 Install the Clamp-On Gearbox Assembly ............................................................... 67
4.20.3 Install the PTO Shield ............................................................................................. 68
4.20.4 Install the PTO ........................................................................................................ 68
4.20.5 Install the Saddle Bracket....................................................................................... 69
4.20.6 Sprocket Head Gearing (540 RPM Only)................................................................ 70
4.21 Install the Hydraulic Drive ..................................................................................................... 72
4.21.1 Install the Half Clamps ........................................................................................... 72
4.21.2 Install the Hydraulic Motor Mount Assembly ....................................................... 74
4.21.3 Install the Hydraulic Hoses..................................................................................... 75
4.22 Install Manual Holder ............................................................................................................ 75
5. Specifications ........................................................................................................................................ 77
6. Appendix ............................................................................................................................................... 80
6.1 Bolt Torque.............................................................................................................................. 80

31059 R1 5
11.. IInnttrroodduuccttiioonn
This manual describes how to assemble a Westfield Portable Grain Auger.
Before assembling, please read this manual. Familiarize yourself with the process and the necessary
precautions for efficient and safe assembly.
Everyone present at the assembly site is required to be familiar with all safety precautions.
Keep this manual available for frequent reference and review it with new personnel. Call your local
distributor or dealer if you need assistance or additional information.
WRX SERIES – PORTABLE GRAIN AUGER 1. INTRODUCTION

6 31059 R1
22.. SSaaffeettyy
2.1. Safety Alert Symbol and Signal Words
This safety alert symbol indicates important safety messages in this manual. When you see
this symbol, be alert to the possibility of injury or death, carefully read the message that
follows, and inform others.
Signal Words: Note the use of the signal words DANGER,WARNING,CAUTION, and NOTICE with the safety
messages. The appropriate signal word for each message has been selected using the definitions below as a
guideline.
Indicates an imminently hazardous situation that, if not avoided, will result in serious injury or
death.
Indicates a hazardous situation that, if not avoided, could result in serious injury or death.
Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation that, if not avoided, may result in property damage.
2.2. General Safety
It is the auger assembler and installation personnel’s responsibility to read and understand ALL safety
instructions, safety decals, and manuals and follow them when assembling, operating, or maintaining the
equipment.
• Only experienced personnel who are familiar with this type of assembly and installation should perform this
work. Untrained assemblers/installers expose themselves and bystanders to possible serious injury or death.
• Do not modify the auger in any way without written permission from the manufacturer. Unauthorized
modification may impair the function and/or safety. Any unauthorized modification will void the warranty.
• Follow a health and safety program for your worksite. Contact your local occupational health and safety
organization for information.
2. SAFETY WRX SERIES – PORTABLE GRAIN AUGER

31059 R1 7
2.3. Rotating Flighting Safety
• KEEP AWAY from rotating flighting.
• DO NOT remove or modify flighting guards, doors, or covers.
Keep in good working order. Have replaced if damaged.
• DO NOT operate the auger without all guards, doors, and
covers in place.
• NEVER touch the flighting. Use a stick or other tool to
remove an obstruction or clean out.
• Shut off and lock out power to adjust, service, or clean.
2.4. Rotating Parts Safety
• Keep body, hair, and clothing away from rotating pulleys,
belts, chains, and sprockets.
• Do not operate with any guard removed or modified. Keep
guards in good working order.
• Shut off and remove key or lock out power source before
inspecting or servicing machine.
2.5. Hand Winch Safety
When Equipped:
• Inspect lift cable before using. Replace if frayed or damaged. Make sure lift cable is seated
properly in cable sheaves and cable clamps are secure.
• Tighten brake lock by turning winch handle clockwise at least two clicks after lowering the
auger.
• Lower the auger fully before towing, then rotate winch handle until cable has light tension.
• Do not lubricate winch brake discs.
2.6. Drives and Lockout Safety
Inspect the power source(s) before using and know how to shut down in an emergency.
Whenever you service or adjust your equipment, make sure you shut down the power
source and unplug or remove the key (as applicable) to prevent inadvertent start-up and
hazardous energy release. Know the procedure(s) that applies to your equipment from the
following power source(s). Ensure that all personnel are clear before turning on power to
equipment.
WRX SERIES – PORTABLE GRAIN AUGER 2. SAFETY

8 31059 R1
2.6.1 Gas Engine Safety
Power Source
• Keep guards in place and secure.
• Properly ventilate surrounding area.
• Never fill the fuel tank with the engine running, while
smoking, or near an open flame. Always shut down and allow
engine to cool before filling with fuel.
• Never overfill the tank or spill fuel. If fuel is spilled, clean it
up immediately.
• Be sure to use the correct type and grade of fuel. Ground the
fuel funnel or nozzle against the filler neck to prevent sparks
that could ignite fuel vapors.
• Be sure to replace the fuel fill cap when you are done.
Lockout
• For engines with an electric start, remove the ignition key,
the spark plug wire, or the spark plug.
• For engines with a rope or crank start, remove the spark plug
wire or the spark plug.
2.6.2 Electric Motor Safety
Power Source
• Electric motors and controls shall be installed and serviced by
a qualified electrician and must meet all local codes and
standards.
• A magnetic starter should be used to protect your motor.
• You must have a manual reset button.
• Reset and motor starting controls must be located so that the
operator has full view of the entire operation.
• Locate main power disconnect switch within reach from
ground level to permit ready access in case of an emergency.
• Motor must be properly grounded.
• Guards must be in place and secure.
• Ensure electrical wiring and cords remain in good condition;
replace if necessary.
• Use a totally enclosed electric motor if operating in
extremely dusty conditions.
SERVICE DISCONNECT
ON
OFF
Lockout
• The main power disconnect switch should be in the locked position during shutdown or
whenever maintenance is performed.
• If reset is required, disconnect all power before resetting motor.
2. SAFETY WRX SERIES – PORTABLE GRAIN AUGER

31059 R1 9
2.6.3 PTO Driveline Safety
Drive
• Keep body, hair, and clothing away from rotating PTO
driveline.
• Make certain the driveline shields telescope and rotate freely
on driveline before attaching.
• Make certain the driveline is securely attached at both ends.
• Do not operate auger unless all driveline, tractor, and
equipment shields are in place and in good working order.
• Do not exceed the specified operating speed.
• Keep universal joint angles small and equal. Do not exceed
maximum recommended length for PTO driveline.
• Engage tractor park brake and/or chock wheels.
Lockout
• Position all controls in neutral, shut off tractor’s engine, and remove key from tractor.
• If removing key is impossible, remove PTO driveline from tractor.
WRX SERIES – PORTABLE GRAIN AUGER 2. SAFETY

10 31059 R1
2.6.4 Hydraulic Power Safety
Power Source
• Refer to the rules and regulations applicable to the power
source operating your hydraulic drive.
• Do not connect or disconnect hydraulic lines while system is
under pressure.
• Keep all hydraulic lines away from moving parts and pinch
points.
• Escaping hydraulic fluid under pressure will cause serious
injury if it penetrates the skin surface (serious infection or
toxic reaction can develop). See a doctor immediately if
injured.
• Use metal or wood as a backstop when searching for
hydraulic leaks and wear proper hand and eye protection.
• Check all hydraulic components are tight and in good
condition. Replace any worn, cut, abraded, flattened, or
crimped hoses.
• Clean the connections before connecting to equipment.
• Do not attempt any makeshift repairs to the hydraulic fittings
or hoses with tape, clamps, or adhesive. The hydraulic
system operates under extremely high pressure; such repairs
will fail suddenly and create a hazardous and unsafe
condition.
Lockout
• Always place all hydraulic controls in neutral and relieve
system pressure before disconnecting or working on
hydraulic system.
2. SAFETY WRX SERIES – PORTABLE GRAIN AUGER

31059 R1 11
2.7. Tire Safety
Failure to follow proper procedures when mounting a tire on a
wheel or rim can produce an explosion that may result in
serious injury or death.
• DO NOT attempt to mount a tire unless you have the proper
equipment and experience to do the job.
• Have a qualified tire dealer or repair service perform
required tire maintenance.
• When replacing worn tires, make sure they meet the original
tire specifications. Never undersize the replacement tire.
• DO NOT weld to the tire rim with the tire mounted on the
rim. This action may cause an explosion which could result in
serious injury or death.
• Inflate tires to the manufacturer’s recommended pressure.
• Tires should not be operated at speeds higher than their
rated speed.
• Keep wheel lug nuts tightened to manufacturer’s
recommendations.
• Never reinflate a tire that has been run flat or seriously
under-inflated without removing the tire from the wheel.
Have the tire and wheel closely inspected for damage before
remounting.
2.8. Battery Safety
• Wear safety glasses and protective gloves when working near
batteries.
• Make certain the battery or terminal covers are in place and
in good working order.
• Keep all sparks and flames away from batteries; gas given off
by electrolyte is explosive.
• Avoid contact with battery electrolyte. Wash off any spilled
electrolyte immediately.
• Do not tip batteries more than 45° to avoid electrolyte loss.
• To avoid injury from sparks or short circuits, disconnect
battery ground cable before servicing any part of an electrical
system.
WRX SERIES – PORTABLE GRAIN AUGER 2. SAFETY

12 31059 R1
2.9. Personal Protective Equipment
The following Personal Protective Equipment (PPE) should be worn when assembling the equipment.
Safety Glasses
• Wear safety glasses at all times to protect eyes from debris.
Coveralls
• Wear coveralls to protect skin.
Hard Hat
• Wear a hard hat to help protect your head.
Steel-Toe Boots
• Wear steel-toe boots to protect feet from falling debris.
Work Gloves
• Wear work gloves to protect your hands from sharp and rough edges.
2.10. Safety Equipment
The following safety equipment should be kept on site:
Fire Extinguisher
• Provide a fire extinguisher for use in case of an accident. Store in a highly visible and
accessible place.
First-Aid Kit
• Have a properly-stocked first-aid kit available for use should the need arise, and
know how to use it.
2. SAFETY WRX SERIES – PORTABLE GRAIN AUGER

31059 R1 13
2.11. Safety Decals
• Keep safety decals clean and legible at all times.
• Replace safety decals that are missing or have become illegible. See decal location figures that follow.
• Replaced parts must display the same decal(s) as the original part.
• Replacement safety decals are available free of charge from your distributor, dealer, or factory as applicable.
2.11.1 Decal Installation/Replacement
1. Decal area must be clean and dry, with a temperature above 50°F (10°C).
2. Decide on the exact position before you remove the backing paper.
3. Align the decal over the specified area and carefully press the small portion with the exposed sticky backing
in place.
4. Slowly peel back the remaining paper and carefully smooth the remaining portion of the decal in place.
5. Small air pockets can be pierced with a pin and smoothed out using the sign backing paper.
2.11.2 Safety Decal Locations and Details
Replicas of the safety decals that are attached to the auger and their messages are shown in the figure(s) that
follow. Safe operation and use of the auger requires that you familiarize yourself with the various safety decals
and the areas or particular functions that the decals apply to, as well as the safety precautions that must be
taken to avoid serious injury, death, or damage.
WRX SERIES – PORTABLE GRAIN AUGER 2. SAFETY

14 31059 R1
Figure 1. Safety Decal Locations for Basic Auger
17113
20807
17109
19960
20813
20817
20811
Figure 2. Safety Decal Locations for EMD Option
20804 20803
2. SAFETY WRX SERIES – PORTABLE GRAIN AUGER

31059 R1 15
Figure 3. Safety Decal Locations for MD Option
20804
20803
Figure 4. Safety Decal Locations for PTO-SD Option
20819
Figure 5. Safety Decal Locations for Hydraulic Drive Option
20806
WRX SERIES – PORTABLE GRAIN AUGER 2. SAFETY

16 31059 R1
Table 1. Safety Decals
Part Number Description
20813
To prevent death or serious injury:
• KEEP AWAY from rotating auger flighting.
• DO NOT remove or modify auger flighting
guards, doors, or covers. Keep in good working
order. Have replaced if damaged.
• DO NOT operate the auger without all guards,
doors, and covers in place.
• NEVER touch the auger flighting. Use a stick or
other tool to remove an obstruction or clean out.
• Shut off and lock out power to adjust, service, or
clean.
ROTATING FLIGHTING HAZARD
DANGER
2. SAFETY WRX SERIES – PORTABLE GRAIN AUGER

31059 R1 17
Table 1 Safety Decals (continued)
Part Number Description
20819
DANGER
ROTATING PTO DRIVELINE
To prevent serious injury or death:
• Keep body, hair, and clothing away from
rotating PTO driveline.
• Do not operate equipment unless all driveline,
tractor, and equipment shields are in place
and in good working order.
• Make certain the driveline shields turn freely
on driveline.
• Make certain the driveline is securely attached
at both ends.
• Do not exceed specified operating speed (see
operator’s manual).
• Keep u-joint angles small and equal. Do not
exceed maximum recommended length for
PTO driveline.
20817
To prevent death or serious injury:
• When operating or moving, keep equipment
away from overhead power lines and devices.
• Fully lower equipment before moving.
This equipment is not insulated.
Electrocution can occur without direct contact.
DANGER
ELECTROCUTION HAZARD
WRX SERIES – PORTABLE GRAIN AUGER 2. SAFETY

18 31059 R1
Table 1 Safety Decals (continued)
Part Number Description
20803 (placed on
machine behind
guard)
To prevent serious injury or
death, shut off power and
reattach guard before operating
machine.
MISSING GUARD HAZARD
WARNING
20804
To prevent serious injury or death:
• Keep body, hair, and clothing away from rotating
pulleys, belts, chains, and sprockets.
• Do not operate with any guard removed or
modified. Keep guards in good working order.
• Shut off and remove key or lock out power
source before inspecting or servicing machine.
ENTANGLEMENT HAZARD
WARNING
2. SAFETY WRX SERIES – PORTABLE GRAIN AUGER

31059 R1 19
Table 1 Safety Decals (continued)
Part Number Description
20807
To prevent serious injury or death:
• Read and understand the manual before
assembling, operating, or maintaining the
equipment.
• Only trained personnel may assemble, operate,
or maintain the equipment.
• Children and untrained personnel must be kept
outside of the work area.
• Do not modify the equipment. Keep in good
working order.
• If the manual, guards, or decals are missing or
damaged, contact factory or representative for
free replacements.
• Lock out power before performing maintenance.
• To prevent equipment collapse or upending,
support equipment tube while disassembling
certain components.
• Electric motors must be grounded. Disconnect
power before resetting overloads.
WARNING
WRX SERIES – PORTABLE GRAIN AUGER 2. SAFETY

20 31059 R1
Table 1 Safety Decals (continued)
Part Number Description
20811
WARNING
UPENDING HAZARD
To prevent death or serious injury:
• Anchor intake end and/or support discharge end
to prevent upending.
• Intake end must always have downward weight.
Do not release until attached to tow bar or
resting on ground.
• Do not raise intake end above tow bar height.
• Empty tube and fully lower before moving.
17113
To prevent serious injury or death:
• Securely attach equipment to vehicle with
correct pin and safety chains.
• Use a tow vehicle to move equipment.
TRANSPORT HAZARD
WARNING
20806
HIGH PRESSURE FLUID HAZARD
Hydraulic fluid can cause serious injury if it
penetrates the skin. If it does, see a doctor
immediately.
• Relieve system pressure before repairing, adjusting
or disconnecting.
• Wear proper hand and eye protection when searching
for leaks. Use wood or cardboard instead of hands.
WARNING
2. SAFETY WRX SERIES – PORTABLE GRAIN AUGER
