E5850A Time Correlation Fixture
Quick Start/Installation Guide
The Agilent E5850A time correlation
fixture allows you to make time-correlated
measurements between a 1680 90 or 16700 logic
analyzer and an Agilent 548XX series Infiniium
oscilloscope. The instruments communicate
with one another through a LAN connection
and through the time correlation fixture. The
instruments connect to your target system
(device undertest) through separate probes,
just as when they are used independently.
Waveforms acquired by the oscilloscope can
be displayed on the logic analyzer.
Equipment Supplied
Equipment Required
Point-to-point cable
5061-7342
BNC cables (4)
8120-1840
You may use your own BNC
cables or combine two short
cables into a longer one using
the provided connector.
E5850A time
correlation fixture
CD-ROMs:
16700 software
Infiniium software update
Documentation
Power supply and power cord
WARNING Shock hazard. Use
only the 0950-2546 power supply
Caution Equipment damage. Use
only the 0950-2546 power supply
and cord.
If the cord you received is not
appropriate for your electrical
power outlet type, contact your
Agilent Technologies sales and
service office.
!
Agilent 548xx Infiniium
oscilloscope, with a probe.
548xxA models require
software version 4.00 or later.
Agilent 1680/90-series logic
analysis system, software
version 1.40 or later.
Note: The E5850A Time Correlation Fixture requires a 548xx Infiniium oscilloscope and either a 16700-series logic analysis
system or a 1680 90-series logic analysis system.
Agilent 16700-series logic
analysis system, software
version 2.50 or later.

2E5850A Quick Start Guide
Infiniium 548XX-series Oscilloscope
Point-to-Point Network Set Up
If your oscilloscope and logic analyzer are both already connected to a LAN, you can skip this step.
If your oscilloscope and logic analyzer are not already connected to a LAN, a simple point-to-point connection may be the most
convenient connection between the instruments. Use the cross-over (blue) cable provided with your E5850A. Connect one end of the
cable to the network interface on your Infiniium 548xx oscilloscope the and the other end to the network interface on logic analysis
system. You will need to configure the networking software on both systems.
➙
➋
➙
➊
➙
➌
➙
➙
➙
➙
➙
➙
➍
➏
➐
➑
Check that the TCP/IP
component is installed, then
select Properties.
In the Gateway tab,
remove any installed
gateways.
If necessary, turn on
the oscilloscope’s
graphical interface.
➙
➎
➙
In the IP Address
tab, set the IP
Address and
Subnet Mask.
In the WINS Configuration
tab, select Disable WINS
Resolution.
In the DNS
Configuration tab,
select Disable DNS.
Close the dialogs.
Click Yes when
asked to reboot.
From the File menu,
select Network
then Properties.

E5850A Quick Start Guide 3
6700-series Logic Analyzer System
Point-to-Point Network Set Up
If your logic analyzer and oscilloscope are both already connected to a LAN, you can skip this step.
If your oscilloscope and logic analyzer are not already connected to a LAN, a simple point-to-point connection may be the most
convenient connection between the instruments. You will need to configure the networking software on both systems.
➙
➙
➙
➙
➙
➙
➙
➙
➙
➙
➙
➋
➎
➏
➍
➌
Make sure Host Table is selected.
Enter: 192.0.2.231 infiniium.
Select Add and OK.
Select OK to close the Network Setup dialog.
Now when you use the E5850A software, you can enter
either infiniium or 192.0.2.231 as the Infiniium Host Name
or IP.
➐
➙
➊
➙
➙

4E5850A Quick Start Guide
Install the Software
Insert the 16700 Software CD into the logic analysis system. Click on the following fields to install the E5850A tool software.
If you purchased a 16700-series logic analyzer with the E5850 time correlation fixture, you can skip this step.
➙
➙
➙
➙
➙
➙
➙
➙
➙
Double-click to open
the AUXILIARY-SW
directory.
Click E5850A.

E5850A Quick Start Guide 5
Start the Correlation Tool Software
Start the Time Correlation setup wizard from
the logic analyzer System window.
Enter the Infiniium IP address here.
(192.0.2.231 or infiniium for a point-to-point
connection.) Then select a trigger direction
and select which analyzer to use.
➙
➙
➙
➙
➙
➙
Follow the instructions displayed by the
Setup Assistant to connect the cables.
When the calibration is complete, disconnect the scope probe and the logic analyzer
leads from the time correlation fixture, but do not disconnect the BNC connections.
Click Done to add the Infiniium tool to the 1670x
workspace window and run the deskew
calibration process.

6E5850A Quick Start Guide
680/90-series Logic Analyzer System
Point-to-Point Network Set Up
If your logic analyzer and oscilloscope are both already connected to a LAN, you can skip this step.
If your logic analyzer and oscilloscope are not already connected to a LAN, a simple point-to-point connection may be the most
convenient connection between the instruments. You will need to configure the networking software on both systems.
➙
➍
➙
➙
➋
➊
➙
➌
➙
➙
➙
➏
➑
➙
➙
➙
➙
➙
In the IP Settings
tab, remove any
installed gateways.
In the DNS
tab, remove
all DNS
addresses
from the list.
➐
In the WINS
tab, remove
all WINS
addresses
from the list.
➙➙
Close the dialogs.
Click on Yes if
prompted to
continue.
➙
➎
Right-click on Local
Area Connection and
select Properties.
Check that
the TCP/IP
component is
installed, then
select
Properties.
In the
Properties
Dialog, set the
IPAddressand
Subnet Mask.
Remove any
DNS server
addresses,
then select
Advanced.
Click on Start, then Settings.
From the Settings menu,
select Network and Dial-up
Connections.
➙
➙

E5850A Quick Start Guide 7
Start the Correlation Tool Software
➙
Start the Time Correlation setup
wizard from the logic analyzer
Setup menu. In the Add External
Oscilloscope wizard, select Next.
Enter the Infiniium IP address (192.0.2.231
for a point-to-point connection). Select a
trigger direction, then select Next.
➙
Follow the instructions displayed by the
wizard to connect the cables.
Select Automatic Deskew.
➙
➙
➙➙
Click Finish to add the Infiniium tool to the
1680/90 Overview window.
When the calibration is complete, disconnect the scope probe and the logic analyzer
leads from the time correlation fixture, but do not disconnect the BNC connections.
➙

8E5850A Quick Start Guide
For More Information
6700-series Logic Analyzer Help
680/90-series Logic Analyzer Help
Open the Time Correlation Fixture Help
from the Infiniium window in the logic
analysis system.
➙
➙
