Air Liquide SAF-FRO DIGIWAVE II Installation instructions

DIGIWAVE II
EN INSTRUCTIONS FOR OPERATION AND MAINTENANCE
Cat n° : 8695-1217
Rev : B
Date : 05/2014
Contact : www.saf-fro.com

EN Arc welding and plasma cutting may be dangerous for the operator
and persons close to the work area. Read the operating manual.

CONTENTS
1 - GENERAL INFORMATION ........................................................................................................................................................................................................................... 4
1.1. PRESENTAT ON OF NSTALLAT ON ................................................................................................................................................................................................. 4
1.2. WELD NG SET COMPONENTS .......................................................................................................................................................................................................... 4
1.3.POWER SOURCES TECHN CAL SPEC F CAT ONS ......................................................................................................................................................................... 6
1.4. COOL NG UN T TECHN CAL SPEC F CAT ONS............................................................................................................................................................................... 6
2 - STARTING UP ............................................................................................................................................................................................................................................... 7
2.1. ELECTR CAL CONNECT ONS TO THE MA NS ................................................................................................................................................................................. 7
2.2. CONNECT ON OF THE W RE FEEDER UN T ................................................................................................................................................................................... 7
2.3. CONNECT ON OF THE TORCH AND COOL NG UN T ..................................................................................................................................................................... 7
2.4. GAS NLET CONNECT ON ................................................................................................................................................................................................................. 7
2.5. START NG UP ..................................................................................................................................................................................................................................... 8
3 - EASY STARTING-UP .................................................................................................................................................................................................................................... 9
3.1. FRONT PANEL FUNCT ONS .............................................................................................................................................................................................................. 9
3.2. F RST SETT NG FOR EASY ACCESS TO WELD............................................................................................................................................................................ 11
4 – ADVANCED FUNCTIONNALITIES OF DIGIWAVE II ............................................................................................................................................................................... 16
4.1. M G-MAG WELD NG CYCLE ADVANCED SETT NG ...................................................................................................................................................................... 16
4.2. M G WELD NG CYCLE ADVANCED SETT NG ................................................................................................................................................................................ 21
4.3. SELECT ON AND GEST ON DES PROGRAMMES DE SOUDAGE ................................................................................................................................................ 23
4.4. MPORT / EXPORT OF WELD NG PROGRAMS ............................................................................................................................................................................. 26
4.5. USERS MANAGEMENT & TRACEAB LY ......................................................................................................................................................................................... 26
4.6. PROGRAM L M TAT ONS ................................................................................................................................................................................................................. 28
4.7. CONTROL PROCESS ....................................................................................................................................................................................................................... 29
5 - TIG MMA WELDING ............................................................................................................................................................................................................................... 31
6 - DETAILED INSTALLATION ........................................................................................................................................................................................................................ 32
6.1. GONF GURAT ON OF COOL NG UN T ............................................................................................................................................................................................ 32
6.2. AUTOMAT ON NTERFACE DECR PT ON ...................................................................................................................................................................................... 33
6.3. EXTERNAL COMMUN CAT ONS ...................................................................................................................................................................................................... 35
7 - MAINTENANCE OF INSTALLATION ......................................................................................................................................................................................................... 37
8 – OPTIONS .................................................................................................................................................................................................................................................... 38
8.1. UN T COOLER, REF. W000273516 .................................................................................................................................................................................................. 38
8.2. FLOWMETER, REF. W000376539 .................................................................................................................................................................................................... 38
8.3. W RE FEEDER DVU W500, REF. W000372327 .............................................................................................................................................................................. 38
8.4. REMOTE CONTROL RC JOB , REF. W000371925 ....................................................................................................................................................................... 38
8.5. REMOTE CONTROL RC S MPLE, REF. W000275904 .................................................................................................................................................................... 38
8.6. WORKSHOP TROLLEY , REF. W000279927 ................................................................................................................................................................................. 38
8.7. WORKSHOP TROLLEY OPT ON, REF. W000372274 ..................................................................................................................................................................... 39
8.8. DUST F LTER, REF. W000370925 ................................................................................................................................................................................................... 39
8.9. P ED P VOT, REF. W000279932 ...................................................................................................................................................................................................... 39
8.10. RC JOB PLUG ON THE GENERATOR, REF. W000374008 ....................................................................................................................................................... 39
8.11. TUBE HANDLE, REF. W000279930 ............................................................................................................................................................................................... 39
8.12. PUSH PULL CARD OPT ON, REF. W000279907 .......................................................................................................................................................................... 39
8.13. OPT ON POWERBOX, REF. W000305106 .................................................................................................................................................................................... 39
8.14. ADAPTATOR T G, REF. W000379466............................................................................................................................................................................................ 39
8.15. HARNESSES ................................................................................................................................................................................................................................... 40
9 - MAINTENANCE ........................................................................................................................................................................................................................................... 41
9.1. ENTRET EN ....................................................................................................................................................................................................................................... 41
9.2. ROLLERS AND W RE GU DE ........................................................................................................................................................................................................... 41
9.3. TORCH ............................................................................................................................................................................................................................................... 41
9.4. SPARE PARTS .................................................................................................................................................................................................................................. 42
9.5. FAULT L ST DESCR PT ON .............................................................................................................................................................................................................. 42
ANNEX 1 - SYNERGIES TABLES ................................................................................................................................................................................................................... 45
ANNEX 2 - SPECIFIC MIG/MAG WELDING CYCLE ...................................................................................................................................................................................... 48
ANNEX 3 - SYMBOLS ...................................................................................................................................................................................................................................... 49

4 DIGIWAVE II
1 - GENERAL INFORMATION
1.1. PRESENTATION OF
INSTALLATION
DIGIWAVE II is a manual welding set that enables :
☞M G-MAG welding
☞Feeding different types of wire

Steel, stainless steel, aluminum and special wires

Solid an
d cored wires

Diameters from 0.6
-
0.8
-
1.0
-
1.2
-
1.4
-
1.6mm
☞coated electrode welding
☞T G welding
☞ARC-A R Gouging process, using the torch for gouging: ARC A R. (maximum electrode diameter 6.3 mm)
☞to communicate the welding data from and to the external peripherals.
Delivered as ready-for-use package associated with the DVU W500 wire feeder. The power source of this set may also be used for simple automatic
applications.
1.2. WELDING SET COM
PONENTS
The welding set consists of
7
main components :
1. 420A or 500A power source including its power supply cable (5m) and its ground cable (5m)
2. Cooling unit,
3. Wire feeder,
4. Double-disconnectable harness between the wire feeder and the power source,
5. Workshop trolley (optional),
6. Wire feeder trolley (optional)
7. Pivot stand (optional)
Each item is ordered and supplied separately.
Options ordered with the welding set are delivered separately. To install these options, refer to the instructions supplied with the option.

DIGIWAVE II 5
WARNING
:
The plastic handles are not intended for slinging the set.
Stability of the equipment is guaranteed only for an incline of maximum 10°.
1
2
3
4
5
7
6

6 DIGIWAVE II
1.3.POWER SOURCES TE
CHNICAL SPECIFICATIO
NS
DIGIWAVE II 420
W000371924
DIGIWAVE II 520
W000371927
PRIMARY
3-phases primary power supply 400 V +15 % -20 %
Frequency 50 / 60 Hz
Primary current RMS
22
,
1
A
3
1
,
1
A
Maximum primary current
28
,
1
A
3
6
,
3
A
Power and apparant power
13
,
3
Kw / 15,3 kVA
19,4 Kw / 21,7 kVA
Power and apparant power maximum
17,3 Kw /
19,5 kVA
2
2
,
8
k
w / 25,2 kVA
SECONDARY
No-load voltage 80 V 82 V
Current range 15 A – 420 A 15 A – 500 A
Duty cycle 100 % at 40° C 350 A 450 A
Duty cycle 60 % at 40°C 420 A 500 A
Protection degree P 23S
solation class F
Standard EN60974-1/ EN60974-10
Dimensions (L x W x H)
738 x 273 x 521 mm
Net
weight
37 kg
3
7
kg
P
ackaging
weight
43 kg
4
3
Kg
1.4. COOLING UNIT TE
CHNICAL SPECIFICATIO
NS
COOLER II PW
REF. W000273516
Power supply
Single
-
phase supply voltage
230 V ±15 % – 50/60 Hz
Frequency
50/60
Hz
Current consumption
1,4
A
Cooling circuit
Maximum flow rate
3,6
l/min
Maximum pressure at
zero flow rate
4,5
bar
Tank capacity
5
l
Thermal dissipation
1,3 KW à 20°C 1l/mn
Mechanical characteristics
Empty weight
16
kg
Weight in operating condition
21
kg
Dimensions
700 x 279 x 268
mm
Protection class
P 23 S
Standard
CE 60974
–
2, CE 60974
-
10
NOTE
: This power source cannot be used in falling rai
n or snow. t may be stored outside, but it is not designed for use without protection during raining.
Code letter P Degrees of protection
First digit
2
Against penetration of solid external foreign bodies with ∅ ≥ 12.5 mm
Second digit
1
Against penetration of vertical drops of water with harmful effects
3
Against penetration of rain (inclined up to 60° in relation to the vertical) with harmful effects
S
ndicates that testing for protection against the undes
irable effects of water penetration was carried out with all
parts of the equipment at idle.

DIGIWAVE II 7
2 - STARTING UP
Refer to the provided Quick Start literature for details on the several steps for the installation of the
DIGIWAVE II.
2.1. ELECTRICAL CO
NNECTIONS TO THE MAI
NS
DIGIWAVE II
is a 400 V 3
-
phase welding set.
f your mains supply corresponds to requirements, connect the "three
-
phase + ground" plug to the end of the power cable.
DIGIWAVE II
is compatible with the following generator sets
:
Ve
rsion 420
: 27 KVA generator mini
Version 520
: 40 KVA generator mini
ALW recommends using SDMO
generator.
WARNING
The electrical connection of the power source must be done by qualified persons and the power supply installation must be correctly
dimensioned regarding the characteristics of the power source (especially concerning the maximum consumed current).
This equipment does not comply with EC 61000-3-12. f it is connected to a public low voltage system, it is the responsibility of the
installer or user of the equipment to ensure, by consultation with the distribution network operator if necessary, that the equipment may be
connected.
This Class A equipment is not intended for use in residential locations where the electrical power is provided by the public low-voltage
supply system. There may be potential difficulties in ensuring electromagnetic compatibility in those locations, due to conducted as well
as radiated disturbances.
2.2. CONNECTION OF T
HE WIRE FEEDER UNIT
Refer to the
operating manual of the Wire Feeder and the Quick Start.
WARNING:
This must be carried out with the power source power off. The power plugs must be well tied up their tightening must be regularly
controlled, in particular after the moving of an installation.
2.3. CONNECTION OF T
HE TORCH AND COOLING
UNIT
Refer to the operating manual of the torch and the Quick Start literature.
The M G welding torch is connected to the front of the wire feeder, after ensuring it has been properly outfitted with
the wear parts corresponding to the
wire used for welding.
f you use a
WATER
-
COOLED
torch, make sure to connect your cooling unit to the rear of the
power source
, as well as to the "water" harness.
WARNING
:
Use exclusively the liquid provided by Air Liquide Welding to fill up the cooling unit.
Configuration on the interface is needed to ensure a good working of the cooling unit, cf § 6.1.
No-load operation of the cooling unit while unconnected to a torch may damage it.
2.4. GAS INLET CONNE
CTION
Refer to the Quick Start
.
The gas hose is linked to the harness connecting the power source to the wire feeder. Simply connect it to the pressure
-
regulator outlet of the gas
cylinder.
☞
Place the gas cylinde
r on the trolley at the rear of the power source and fasten the
cylinder
using the strap.
☞
Open the cylinder valve slightly to allow existing impurities to escape and then reclose it.
☞
Mount the pressure regulator/flow meter
☞
Connect the gas hose supplied
with the wire feeder harness to the regulator's outlet
☞
Open the gas cylinder.
During welding, the gas flow rate (l/min) should correspond to the diameter of the nozzle (mm).
WARNING
Make sure the gas cylinder is properly secured on the trolley by attaching the safety strap.

8 DIGIWAVE II
For optimal use, the welding installation must respect the following positioning constraints for correct cooling.
WARNING
The power source is not designed to be slung alone.
Only the complete installation mounted on the workshop trolley W000279927 and quipped with the tube handle option W000279930 and the
swivel leg option W000279932 can be slung, without the gas bottle. n that case, use exclusively the slinging rings designed for this use of
the swivel leg option W000279932.
2.5. STARTING UP
The main switch is located at the rear of the generator. Flip this switch to turn the machine on. This switch must never be
flipped during welding. At each start-up, the generator displays the software version, the power and the connected optional
device, as relevant of the power source.
WARNING
:
When starting up for the first time, the configuration is required cf § 6.1.

DIGIWAVE II 9
3 - EASY STARTING-UP
To ensure an optimal use of the installation and a good understanding
of the following nstructions for use, we recommend you read the Wire Feeder
operating manual first.
3.1. FRONT PANEL FUN
CTIONS
FIRST CONFIGURATION OF THE HUMAN
-
MACHINE
INTERFACE (H
M
I)
The human-machine interface (HM ) is located on the front panel of the power source:
1
Validation
2
Escape button to cancel the operations in progress or go back to the previous menu or page
3
Tuning
encoder
4
Selection
and navigation encoder
5
Button corresponding to the current icons on the scree
n
6
Colour
Screen
HUMAN
-
MACHINE
INTERFACE (H
M
I) SCREEN
Main menu selection
Validation of the current selection
Back
User login page
Access to the information window

10 DIGIWAVE II
The homepage contains 8 M
ain Menus :
T G L FT Traceability
MMA Configuration
M G/MAG Maintenance
Welding Programs User Synergy
H
M
I CONFIGURATION STEP
S
For the first use of the power source, you must do the 4 following steps.
STEP 1
Choice of the interface language
Language selection
Validation of the selection
1
Position
2
Selected language
21
languages are available on the
DIGIWAVE II.
STEP 2
:
Time & date settings
The clock is used for the functions of traceability and export
.
Change of the value
Change of the column
Save

DIGIWAVE II 11
STEP 3
:
Name of the power source.
This is the name used for identifying the machine when installations communicate.
Please check that different installation have different names. During an export to an external storage device, the name of the directory created is
composed of the power source name and the date.
Change in the characters column
Add or suppression of a character
Save
STEP 4
:
Configuration du groupe de refroidissement s’il est utilisé. (paragraphe 6.1)
HARNESS CALIBRATION
Harnesses calibration is imperative to weld with a good quality.
The calibration is to be re
-
done, in
case of polarity change, or change of one of these following components:
•torch
•harness
•ground cable
•position of the clip of the ground cable
Access in the menu: M G > SETUP > Harness calibration
•Automatic Calibration: (Only available in M G). Follow the instructions on the screen.
WARNING
During this operation, a current of 400A for 1 second is generated. t is imperative then to wear the correct protection equipment required for
welding during this operation, in particular, protection glasses.
3.2.
FIRST SETTING FOR EA
SY ACCESS TO WELD
PRESENTATION OF THE MIG WELD
ING TUNING PAGE
Parameters selection
Parameters value selection
Validation
/
Welding
Programs
Management
Access Zone 1 or Zone 11
Welding Cycle Management Setup Access to the information window

12 DIGIWAVE II
1
Synergy bar + Trigger Mode
2
ALW Data base Synergies / User Synergies
3
Choice of metal
4
Choice of wire diameter
9
Welding cycle representation
5
Choice of gas
10
ndicative welding values
6
Choice of the arc transfer
11
Main welding parameters
7
Choice
of the working mode
8
Choice of the trigger mode
SYNERGY BASE MODE SETTING AND TRIGGER MODE
Synergies
Standards synergies provided by Air Liquide Welding. These synergies are specially well suited to most applications. Standard
synergies are optimized for flat fillet.
User synergies previously created or loaded by the user. The DIGIWAVE II can store up to 50 user synergies.
Some synergies require reversing the polarity of the power source (inversion of the 2 power cables). Follow t
he on
-
screen instructions.
Choice of the consumables (metal, diameter, gas)
M G
-
MAG
Welding require the use of adapted wire for type and diameter, as well as the use of the appropriate gas. See synergies table
in the annex 1.
Choice of the arc transfer (annex 2)
Choice of the working mode
SYN mode allows to work on a predetermined operating point by adjusting only the wire speed on suitable interval
MAN mode allows you to adjust the voltage and wire speed over the entire range separately.
FREE mode is dedicated to high skilled welders, see devoted annex.Page 26

DIGIWAVE II 13
Choice of the trigger mode
This mode defines the way the welder use his torch trigger.
The cycles below describe the mode 2T and 4T during a simple welding cycle of 5 steps:
1
Pre
-
gas
2
Slows
wire
forwarding
3
Welding
step
4
Crater
fill
5
Post
-
gas
Description
The welder holds the trigger during the whole welding. Pressing the tr
igger will launch the welding (the beginning of the pregas), and releasing the
trigger will stop the welding (beginning of crater filling).
The welder can however shorten the crater filling by a short press on the trigger during this phase (if the corresponding option of configuration is
activated).
Option
Configuration > Installation > Cycle
:
-
Shorten
down slope
control
-
Program call by trigger out of welding
The Spot Mode is a special mode and you can define the time of the welding step (3) in the cycle welding paremeters.
: Wire speed
/
: Trigger pressed/ released

14 DIGIWAVE II
Description
The 4T mode implies that the welder can weld without keeping the trigger pressed. He presses and releases the trigger a first
time to launch the
welding, then he presses and releases a second time to end the welding.
Option
Configuration > nstallation > Cycle
:
-
Call
the
trigger
program
out
welding
-
Call
the
trigger
program
in welding
.
MAIN WELDING PARAMETERS SETTING
The welding cycle is actualized with the setting of the main welding parameters.
n the paragraph below, we detail the setting of the main welding parameters
:
WIRE SPEED
MANUAL mode:
By placing
the cursor on
SPEED
W RELESS
, pressing
OK
shows the
parameters
together to
facilitate the adjustment of
parameters
.
Setting
Mode Unit nterval step
SYN The wire speed varies in a range settled by the synergy. m/mn Depending of
synergy 0.1
MAN The wire speed is not limited by the synergy table. m/mn [1 ; 25] 0.1
ARC VOLTAGE
The arc tension is defined accor
ding to the regime of arc
:
•flat: average voltage
•pulsed: choose voltage
Setting
Mode Unit nterval Step
SYN
Arc length:
Relative tuning of the arc voltage by ±50 increments around the
programmed synergic value.
Increments -50 || +50
1
Volts -10 || +10 0.2
MAN Arc voltage:
Absolute tuning of the arc voltage during the welding phase. Volts [10 ; 50] 0.2
Volts
equivalent

DIGIWAVE II 15
FINE TUNING
The fine tuning is defined according to the regime of arc
:
•Flat: Arc dynamism
•Pulsed: Current impulsion energy
se
tting
Mode Unit nterval Step
SYN
&
MAN
Relative fine tuning by ±10 increments around the programmed
synergic value. Increments -10 || +10 1
Tuning
advice
:
n flat regime, a low value of the fine tuning enables a quick rise of the short cut current. Thus, the regime is dynamic and hot which allows welding in
position but has the drawback of generating more spatter. On the contrary, a high value of the fine tuning reduces the dynamism and cools the weld pool.
Note : The welding position is further facilitated by "speed short arc" arc transfer than"smooth" arc transfer.
n Pulsed mode , fine tuning adjusts the energy of the current pulse and optimize the drop detachment.
Specifically, if fine projections detach from the wire, reduce the fine tuning, if rather large drops off, increase the fine tuning.
MIG WELDING PAGE
you are allowed to weld only if the color of the top left icon is green .
1
Arc
current
measure
2
Arc
voltage
measure
3
Wirespeed
4
Motor current of the wire f
eeder
5
Welding time (includes all the steps of the welding cycle)
The motor current of the wire feeder is proportional to the motor torque. Beyond 1.3A at constant regime, check that the wire feeder liner is not
clogged with dirt.
The previous welding parameters are accessible on the SETUP page from the M G-MAG menu.
f "call off the trigger program welding" is not active: Short press the trigger vacuum (if program change).

16 DIGIWAVE II
4 – ADVANCED FUNCTIONNALITIES OF DIGIWAVE II
4.1. MIG
-
MAG
WEL
DING CYCLE ADVANCED
SETTING
MIG
-
MAG
WELDING
C
YCLE SETTING
The M G welding cycle setting menu distinguishes 7 phases on the welding cycle:
1.
Pregas
2.
Hotstart
3.
Welding
step
4.
Crater
filler
5.
Burn
back
6.
Affûtage fil
7.
Post
gas
WARNING
the voltage is present at the end of the wire from the slow wire forwarding phase to the post retract spray phase.
1
List of the phases of the cycle
2
Selected
cycle phase
3
Parameters table of the selected cycle phase.
Use the left encoder to scroll
the settings
.
Use the right encoder to adjust the selected parameter
4
Switch the cursor between cycle phase selection and parameter table.
Also possible with the OK and ESC buttons
1. Pregas
Gas timing before the welding cycle starts
Variables : T(s) [0.0 ; 10.0]
2. H
otstart/Softstart
n the hotstart phase, a wire speed greater than the weldi
ng phase wire speed allows
quicker penetration on start-up. Otherwise, the hotstart phase allows a low start-up with
a progressive ramp up of wire speed.
Variables : T
(s)
[0.0
; 10.0]

DIGIWAVE II 17
Softstart
The softstart phase can be pre-set for the start of the weld, allowing a limited wire speed with
low energy.
Variables
:
Temps de palier : T(s) [0.00 ; 10.00]
Temps de transitions : T(s) [0.00 ; 10.00]
Paramètres principaux de soudage du palier de Hostart/Softstart.
Note: f the setting exceeds the capacity of the source, the curve appears red
Remark:
With the SYN mode, the wire speed of the Hotstart / Softstart step is tuned relatively to the wire speed of the welding step (∆ ±70 %), the real
speed is shown for information in grey tint, and is directly tunable with the MAN mode: wire speed (m/min) [1.0 ; 25.0].
3. Welding
This menu allows refining of the tuning of the welding step.
Remark:
Once you’ve chosen the mode, the main welding parameters are actualized. t is then possible to tune the parameters of each mode directly from
the main welding tuning page.
Advanced Sequencer ( + )
Sequence the welding phase in two regimes 1 and 2, which can have different arc transfers: Flat or Pulsed.
The arc transfer of the regime 1 is the one selected on the synergy bar of the main welding tuning page.
Variables :
Arc transfer regime 2: Transfer2
Main welding parameters of the regimes 1 and 2
The timing of regimes 1 and 2 are independent and allow tuning of a dissymmetrical cycle. T(s) [0.1 ; 5.0]
Transit time T(s) [0.00 ; 1.00]
Intermittent mode ( )
The welding is made intermittently by a succession of times ON and times OFF.
Variables :
Main welding parameters
The timings of step ON and OFF are independent and allow tuning a dissymmetrical cycle. T(s) [0.5 ; 10.0]
Remark:
You can choose to realize the hotstart only on the first time ON in the menu:Configuration > Installation > Cycle.
Step mode ( )
Bearing change by a short press on the trigger
Variables :
Step number [2 ; 4]
Main welding parameters of every step
Program call during welding ( )
Once you activate this option, you can call programs with the trigger while you’re welding. See §
4.3. page
23
. Program Management.
Remark:
You can activate the program call out of welding in the menu: Configuration > Installation > Cycle

18 DIGIWAVE II
4.
Craterfiller
The crater fill phase allows filling up of the crater at the end of the weld for a good finish of
welding. t is made by decreasing the arc regime at the end of the weld (downslope), then
maintaining a low level of the wire speed for a defined timing (Craterfiller step).
Variables :
Step time : T(s) [0.05 ; 10.00]
downslope : T(s) [0.05 ; 10.00]
Main welding parameters of the Craterfiller step
Remark :
With the SYN mode, the wire speed of the Crater fill step is tuned relatively to the wire speed of
the welding step (∆ [-70 %]), the real speed is shown for information in grey tint, and is directly
tunable with the MAN mode: wire speed (m/min) [1.0 ; 25.0].
You can activate the option Shorten down slope control in the menu:
Configuration > Installation > Cycle.
5.
B
urn back
Evite le collage du fil dans le bain en décalant l’arrêt du fil et l’arrêt de la puissance Variables :
Manual – Burn back time (ms) [0, 500]
Automatic – Burn back fine tuning (ms) [-100 ; 200]
6.
S
harpening thread
You can set 3 parameters:
Sharpening thread : The Post Retract Spray allows ejecting the drop at the end of the wire after the welding
Stuck wire test: Test if the wire is stuck in the weld pool at the end of welding
Automatic unsticking: if the test indicates that the wire is stuck, a power impulsion will automatically burn back the wire, and then will
check it.
7. Post
-
gaz
Timing of gas output after the end of welding in order to prevent oxidation while the bead is still
hot.
Variables : T
(
s)
[0.0
;
2
0.0]

DIGIWAVE II 19
FULL
MIG
-
MAG
WELDING CYCLE
1
Pre
-
gas
2
Slow wire inch [forward]
3
Hotstart
4
Welding
phase
5
Crater
fill
er
6
Burnback
6
Affûtage fil
7
Post
-
gas
STRIKING ADJUSTMENT
The striking adjustment is accessible in the menu SETUP of the M G page.
Note: the striking is the 2 phase of the welding cycle.
The striking of every synergy is by default optimal in most of the application cases. However, in few very specific application cases, the user may want to
modify the striking characteristics.
Tuning parameters of striking:
K = Variable coefficient de -10 / 0 / +10
Name of the parameter
Description
Striking low wire advance K Allows modifying the low wire advance before striking.
Striking current K Allows tuning the striking current energy.
Striking transition energy K
Allows tuning the arc energy during the transit between the arc striking and the first
regime of the welding cycle.
WARNING
The user is responsible for the eventual dysfunction which a modification of the striking parameters may cause.

20 DIGIWAVE II
USER SYNERGIES
The User Synergies Menu is accessible from the homepage. This function of the power source allows the user to create their own synergies from the
existing ones.
From the synergy bar, lo
cated on the top of the screen as in the M G menu, choose an existing synergy by selecting the following parameters: metal,
diameter, gas, arc transfer. Choose those parameters as close as possible from the user synergy you want to create.
Once the parameters are selected, press the button User Synergy Creation:
1. The first step is the selection of the synergy points that will serve as support for the new synergic curves. Select at least 2 points, then validate.
2.
The second st
ep is the modification of the selected points, the addition of new points or the suppression of existing points.
Select a point among the list, press on “edit”. See below the settable parameters:
-Wire speed (m/min) : to create a new point, change this value and press the add point button.
-Arc length
-Fine tuning
-Thickness (mm)
- (A)
-U (V)
-Striking adjustment
The tuning of those parameters allows you adjusting the User Synergy according to your needs.
On this schematic example of a synergic curve, 4 points are
selected in order to create the user synergy.
The user added 3 points on the 4 support points by
setting the adjustable parameters for new values of the
wire speed.
