Technical Data Sheet: FireProtect 2 (Heat/CO) Jeweller
Jeweller
EN 50291-
201
FireProtect 2
(Heat/CO) Jeweller
Wireless re detector with heat and CO
sensors. Features a built-in siren
for alarms and events notication.
Operates as part of the Ajax system
or without pairing with an Ajax hub.
Find the detailed information
on the device at:
support.ajax.systems/en/manuals/reprotect-2-heat-co/
The device is available in two versions: with replaceable or sealed batteries. The name
of a detector with replaceable batteries contains the RB mark, and with sealed batteries — SB
FireProtect 2 RB (Heat/CO) Jewelle
FireProtect 2 SB (Heat/CO) Jeweller
Key features
Advanced hardware and software
 An interconnected alarm of all re detectors at the facility in 20 second
 Built-in siren with a volume of 85 dB at a distance of 3 meters
 Ability to operate autonomously without an Ajax hu
 10 years of operation with sealed batteries, and up to 7 years — with replaceable batteries
E asy to install and con g ure
 SmartBrac et mountin g panel with the ability to ali g n the detector after installatio 
 R emote control and con g urin g via Ajax app
 Pairin g with the Ajax hub via QR code

2
Technical Data Sheet: FireProtect 2 (Heat/CO) Jeweller
Operat ng pr nc ple
Detect on of a rap d
temperature r se
Two built-in thermistors are responsible for the reaction
to temperature rise. Thermistors are located outside
the detector for faster threat detection.
If the room temperature exceeds +64°C or increases by more than 10°C within a minute, the detector
recognizes this as a rapid temperature rise and raises the alarm.
Detect on of dangerous CO
concentrat on level
A built-in chemical sensor with a service life
of at least 10 years is responsible for detecting
a dangerous concentration of carbon monoxide
in FireProtect 2.
Carbon monoxide (CO) is a colourless, tasteless, and odourless gas produced due to incomplete fuel
combustion in automobile engines and heating appliances that use coal or other natural fuels.
For example, it can be made by replaces, boilers, or heating systems. In airtight or closed rooms
with poor ventilation, life-threatening concentrations of carbon monoxide can accumulate.
Interconnected re detectors alarms
The detector supports interconnected re alarms.
The feature activates built-in sirens of all Ajax re
detectors at the facility if at least one of them
is triggered. In case of a re, this allows alerting
as many people as possible.
FireProtect 2 detectors have an improved
interconnected re alarm algorithm that activates all re
detectors ' sirens within 20 seconds. The function
is available only when detectors operate with the hub.

3
Technical Data Sheet: FireProtect 2 (Heat/CO) Jeweller
Operati n with ut a hub
FireProtect 2 detectors can be used
without pairing to an Ajax hub. In this case,
the detector noties about re alarms
with a built-in siren and LED indication,
and does not send a notication to the user's
smartphone, Ajax Translator, or PRO Desktop.
Manual and aut matic testing
FireProtect 2 regularly checks the status of batteries and built-in sensors. If a malfunction is detected,
the hub will notify users and the monitoring station instantly. And the detector will turn on the light and sound
alert by the built-in siren and LEDs. All detector states can be checked at any time in Ajax apps.
The detector supports manual testing mode. It is activated by pressing the device's front panel. The front
panel has a mechanical button, which can be pressed either manually or with a oor mop. During the test,
the built-in siren and testing of sensors are run. This allows the installer to test the device at any time
and to demonstrate to the customer the light and sound indication of the detector for various types
of alarms.
Aut n m us perati n
FireProtect 2 (Heat/CO) is available in two versions:
with replaceable or sealed batteries. Detectors
with replaceable batteries operate for up to 7 years
with pre-installed CR123A batteries. After discharge,
the batteries can be replaced with new ones. The model
with sealed lithium batteries operates for at least 10
years. After the batteries are discharged, the detector
should be replaced with a new one.

4
Technical Data Sheet: FireProtect 2 (Heat/CO) Jeweller
Jeweller
communication technology
Jeweller is a radio protocol for fast and reliable two-way communication between hubs and connected
devices. The protocol provides a wireless radio communication range with FireProtect 2 up to 1,700 meters.
This communication range allows you to install detectors even on large-scale objects.
Jeweller is responsible for transmitting alarms and events. The radio protocol also provides an interconnected
re detectors alarm activation within 20 seconds in a system with any number of FireProtect 2. Thanks
to Jeweller, users and the monitoring station can always see the current status of detectors in Ajax apps.
Quick pairing and installation
There is no need to disassemble the detector
during installation. With an improved
SmartBracket panel, an installer can effortlessly
x the detector on ceilings and level it at 90°
angles after mounting. The Ajax apps help
quickly make the device a part of the system.
And it can always be recongured remotely
without site visits.
Technical specications
Communication with
the hub or range
extender
Jeweller
communication
technolog
Frequency band
866.0–866.5 MH
868.0–868.6 MH
868.7–869.2 MH
905.0–926.5 MH
915.85–926.5 MH
921.0–922.0 MH
Depends on the region
of sale.
Compatibility
H ubs 
H ub P l u s 
H ub 2 ( 2 G)
H ub 2 ( 4 G)
H ub 2 P l u s 
H ub H yb rid ( 2 G)
H ub H yb rid ( 4 G)

R ange e x tenders 
R e X
R e X 2 

5
Technical Data Sheet: FireProtect 2 (Heat/CO) Jeweller
Communication with
the hub or range
extender
Maximum effective
radiated power (ERP
up to 20 m
Communication rang
up to 1,700 
In an open space.
Heat detection Sensitive elemen
two thermistor
Heat alar
 10°C increase
in temperature
within 1 minut
 exceeding +64°C
According
to the requirements
for heat A1R-class
detectors of EN 54-5
standard
Additional features Built-in sire
volume of 85 dB
at a distance of 3 meter
Interconnected re alar
All re detectors
in the system turn
on built-in sirens if at least
one of the detectors
registers an alarm.
LED indicatio
green is a power
indicatio
T he interconnected alarm
is activated after no more
than 20 seconds
L ights up once every
minute.
Com p liance with
regulations
EN 54-5 : 2017+A1 : 201 
EN 502 9 1-1 : 201 
Carbon monoxide
(CO) detection
Sensitive elemen
chemical C O senso 
C O alar
 50 ppm ( 0.005 %) in no
more than 9 0 minute 
 100 ppm ( 0.01 %) in no
more than 40 minute 
 300 ppm ( 0.03 %) in no
more than 3 minute
Sensor service lif
10 years
Anti - sabotage
p rotection
T ampering alar 
Protection against
spoon 
device authenticatio 
Detection 
of communication failur
within 15 minute
T he time to detect
communication loss
depends on the number
of undelivered data
pac k ages setting ( specied
in the J eweller or J eweller /
F ibra settings ) . T he polling
interval is xed at 300
seconds 

6
Technical Data Sheet:FireProtect 2 (Heat/CO) Jeweller
Additional features yellow is an indication
of malfunction
red is an indication of re
alarm
Button on the front panel
of the detecto
In normal mode,
when pressed, it starts
the detector test
In the event of an alarm
or malfunction,
the pressing turns
off the detector sound
notication.
Lights
up when malfunctions
are detected. For example,
in the case of discharged
batteries
Lights
up when the detector
detects a re alarm
Power supply RB versio
2 replaceable CR123A
batterie
SB versio
2 sealed lithium batterie
Up to 7years of battery
life
10 years of battery life
Enclosure and
installation
Dimension
43.5 х 86 х 86 m
Weigh
149 
145 
Operating temperature
rang
from 0°С to +50°
Operating humidit
up to 80
Protection clas
IP2
Colour
Blac
Whit
For RB version
For S B version
Co m plete set RB versio
FireProtect 2 RB (H eat / C O)
J ewelle 
S martBrac k et mounting
pane 
Installation k i 
2 × CR123A batteries
Q uic k start guid
SB versio
FireProtect 2 S B (H eat / C O)
J ewelle 
S martBrac k et mounting
pane 
Installation k i 
Q uic k start guid 
Pre - installed 
