ALFRA 2070 User manual

Bedienungsanleitung / Operation Instructions / Manuel d'utilisation
Akku Compact Hand Hydraulik
Battery Packed Compact Hydraulic Punch
Poinçonneuse manuelle hydraulique Compact à accus rechargeable
Punzonadora hidráulica manual a bateria Compact
Artikel Nr. / Prod.-No. / N°de produit / No. de articulo 02070
®

2
Inhaltsverzeichnis / Contents / Table des matières / Contenido
Sicherheitshinweise, Bestimmungsgemäße Verwendung,
Leistungsdaten, Beschreibung, Betätigungsfunktionen,
Stanzen mit Rund-, Quadrat- und Rechtecklocher, Verfügbare
Zugbolzen, Distanzeinsätze und Distanzbuchsen,
Betriebsdauer, Technische Daten Akku und Ladegerät, Akku
und Ladegerät, Stanzzeit und Stanzleistung, Wartung,
Aufbewahrung und Transport, Entsorgung, EG-
Konformitätserklärung.
Vor Inbetriebnahme
lesen und
aufbewahren!
Seite 3
Safety instructions, Specified Conditions of Use, Performance
dates, Description, Operating functions, Punching with round,
square and oblong puncher, Available hydraulic screws,
distance inserts and spacer sleeves, Operating time, Technical
data battery and battery charger, Battery and battery charger,
Punching time and punching capacity, Maintenance, Storage
and transport, Disposal, CE-Declaration of Conformity.
Please read and save
these instructions!
Page 11
Consignes de sécurité, Conditions d’utilisation,
Caractéristiques, Description, Fonctions, Utilisation des
emporte-pièses circulaires, carrés et rectangulaires, Les vérins
hydrauliques, les éléments et les douilles d’ecartement, Durée
d’opération, Caractéristiques accu et chargeur, Accu et
chargeur, Durée et capacité de poinçonnage, Maintenance,
Entreposage et transport, Mise hors service, Déclaration de
conformité CE.
À lire avant la mise en
service puis à
conserver !
Page 19
Avisos de seguridad, Uso previsto, Datos de rendimiento,
Descripción, Funciones de accionamiento, Utilización de
perforadores redondos, cuadrados y rectangulares, Los
pernos de tracción, insertos distanciadores y casquillos
distanciadores disponibles, Tiempo de funcionamiento, Datos
técnicos, La bateria y del cargador, Tiempo de punzonado /
Potencia de punzonado, Mantenimiento, Almacenamiento y
transporte, Evacuación, CE-Declaración de conformidad.
¡Leer atentamente
antes de la puesta en
marcha y conservar!
Página 27

11
Safety instructions
Wear safety goggles during drilling the guiding hole and during punching.
Keep hands out of the punching area during the punching process to avoid serious injuries.
Make sure
that
no other persons stay in front or close to the hydraulic punch
during the
punching process to avoid serious injuries caused by splinters at material failure or incorrect
use of hydraulic punch.
Before changing the punching inserts it’s absolutely necessary to remove the battery from the
device to avoid unintended use.
While operating it can come to sparking which could set fire on flammable or explosive
materials.
At intensive operating the hydraulic punch can be damaged because of overheating.
The hydraulic punch must not be operated in damp locations.
The punching process can be interrupted at any time by releasing the operating switch. Then
the hydraulic punch can be vented by pressing the vent lever.
Specified conditions of use
The Battery Packed Compact Hydraulic Punch is destined to punch metal sheets.

12
Performance dates
Round punch: up to 80 mm Ø
(3,0 mm St. 37, 2,0 mm chrome nickel steel)
Square and oblong
punches: 68 x 68 mm
(3,0 mm St. 37, 2,0 mm chrome nickel steel)
92 x 92 mm only with special hydraulic screw and spacer sleeves
(2,0 mm St. 37, 1,5 mm chrome nickel steel)
Punching capacity: 80 kN with pressure relief valve
The optimal working temperature for the Battery Packed Compact Hydraulic Punch is between 15°and 25°C.
Description
The ALFRA Battery Packed Compact Hydraulic Punch is a hand operated device and is made up of the following
components:
1. Punching head head for the reception of the tension bolt including punch and die
2. Operating switch initiating of the punching procedure
3. Vent lever lever for vent of the punching head
4. Drive drive with operating switch
5. Battery rechargeable 18 V, 3,0 Ah NiMH battery
6. Punch Insert composed of punch and die to perforate the holes
7. Spacer sleeves 3 spacer sleeves in different strengths
Operating functions
The punching will be initiated through the activation of the operating switch. This switch must be pressed during the
whole punching process. After terminating of the punching process (if the punch has perforated completely)
unblock the switch. By pressing the vent lever once the piston moves backwards to its starting position.
If the hydraulic punch is strained to
the maximum pressure limit (due to improper tool
selection, incorrest spacers or false assembly) a higher pressure to the vent lever is
necessary.

13
Punching with round, square and oblong puncher
1. Pre-drilling with a twist drill or a multistep drill
Drilling diameter for standard punches:
•forscrewswithØ9,5mmdrillmin.Ø11,0mm
•forTriStarsplitpunchesdrillØ10,0mm
•forscrewswithØ11,1mminstainlessmaterialdrill min. Ø 11,5 mm
•forscrewswithØ19,0mmdrillmin.Ø20,4mm
(predrillingasmallerdiameterundthenpunchingis also possible).
Ø 20,4 mm
Ø 10,0 mm
Ø 11,0 mm
Ø 11,5 mm
2. Screw the hydraulic screw with the short thread side Ø 19,0 mm completely into the hydraulic cylinder.
3. Place the suitable spacer sleeves with the die on the hydraulic screw.
The application of a spacer sleeve is absolutely necessary.
4. Put the hydraulic screw through the pre drilled hole and screw in the round punch from the backside.
Forsquareandoblongpunchesplugthepunchonthe axis guidance of the hydraulic screw and retain with the
correspondingcounternut.Whenmountingthehydraulic screw for square and oblong punches, screw only the
longthreadedsideintothepunchinghead.Alignthe die to the crossline mark using the line mark on the stamp.
Pay attention on the right combination of punch and die. The diameter is stamped on
correspondingly.
Do not punch with incomplete screwed in punches. The whole thread turns of the punch have
to be screwed in on the hydraulic screw.
The punch should not hit the interior ground of the punch. This can cause damages to the tool
and on the hydraulic punching unit.
The punch must be screwed on, that a gentle contact with the sheet is given.

14
1 - Punching head
7 - Spacer sleeve
6 - Punching inserts (punch and die)
For the application of square punchers 92 x 92 mm the special hydraulic screw
(
Prod.
-
No.
01395) and the spacer sleeve (Prod.-No. 01396) is necessary. Screw the spacer sleeve tightly on
the die of the square punch 92 x 92 mm.
8 6 6 7 9 1
1 Punching head
6 Punching inserts:
punch 92 x 92 mm,
die 92 x 92 mm
7 Spacer sleeve, Prod. No. 01396
8 Counter nut
9 Special hydraulic screw, Prod. No. 01395
5. Press the operating switch and the punching process will be initiated. The punching process is finished as soon
as the punch has punched the sheet.
6. Press the vent lever located on the side so the punch will be vented and the piston moves backwards to his
initial position.
Vent lever
7. Unscrew and remove the die or correspondingly the counter nut and remove also the chad from the die.
6
7
1

15
Available hydraulic screws, distance inserts and spacer sleeves
Distance inserts
Prod. No. 02004
Special hydraulic Distanzbuchse
screw
Prod. No. 01395 Prod. No. 01396
Operating time
The device is not suitable for permanent operation. After approx. 40 to 50 punching procedures a break should be
taken of approx. 10 to 20 minutes so the hydraulic punch cools down.
Technical data battery and battery charger
Battery: 18 V; 3,0 Ah NiMH
Charging time: 45 min. after complete discharge
Charging cycles: ~ 500 at normal conditions
Use: 0°bis + 40°C, loosing capacity under 0°C
Battery charger: -charges all batteries between 18 up to 28 V
-compatibleforNiCad-,NiMH-andLi-Ion-batteries
-automatictemperaturecontrol
-thechangebetweenquickchargestoconservationcharging avoids overloading of the battery cells
-the state of charge will be indicated by LED-indication
-the PCB is completely moulded

16
Battery and battery charger
The battery can be used both-sided for optimal counterweight to the punching tool.
No dissimilar batteries may be used in the charger.
The battery as well as the charger must be protected against humidity.
The charger is designed for a voltage of 230 Volt / 50 Hz.
Prod. No. 02071 Prod. No. 02072
New batteries must be fully charged before first use. For charging the battery put the plug of the charger into to the
power outlet and the battery into the charger. The charging time is approx. 45 minutes.
Do not work
with a feeble or partial discharged
b
attery, especially at application with large
diameter, square and oblong punches. The device could stop during the punching procedure
and it could come to damages.
Charge the battery, as soon as the speed of the hydraulic punching unit slows down.
The battery charge level can be read off an LED on the charging unit.
Green: battery is completely charged
Red: battery is empty and is charging
Blinking: battery is not completely inserted or battery is too hot. An acoustic signal sounds.
Do not charge a battery which is partial unloaded.
If you want to charge 2 batteries one after another, wait approx. 15 minutes before you load the
2
nd
battery.

17
Punching time and punching capacity
22,5 mm Ø St. 37 2 mm 5 sec. 190 Holes / Battery
63,5 mm Ø St. 37 2 mm 7 sec. 100 Holes / Battery
68 x 68 mm St. 37 2 mm 7 sec. 70 Holes / Battery
Maintenance
The device is designed to be maintenance free.
If the device should not build up pressure contact the distributor or the after-sales-service.
Storage and transport
After use put the punching unit back into the transport case. Store in a dry place.
Disposal
The disposal of the individual components must occur separately. The oil must be drained first and then disposed.
At disposal of all parts of the unit please respect the EC-Environmental-Norm.
Hydraulic oils pose a danger for the ground water. Uncontrolled drain or inappropriate
disposals are strictly forbidden.
The Battery must be disposed under special consideration of the battery directive.
The device must not be disposed as a complete unit into the residual / non-recyclable waste
because it could cause damage to the environment on the landfill.
A revocation of the used appliances through the manufacturer can be assured at a free
transmittal.

18
Markus A. Döring
(Geschäftsführer)
CE Declaration of Conformity
We
Alfred Raith GmbH
2. Industriestraße 10
68766 Hockenheim
declare under our sole responsibility that this product:
ALFRABatteryPackedCompactHydraulicPunch
is in conformity with the following standards or normative documents:
DIN EN 60745-1
DIN EN 292 Part 1 and 2
EN 294
EN 349
EN 60204-1
EN 28662-1
EN 50081-1
EN 50082-2
EN 60529
in accordance with the regulations of directives 98/37/EEC, 89/335/EEC.
Documentation:
Cornelia Dorn
Hockenheim, 01.09.2008
