Alinx AXU2CGA User manual

ZYNQ UltraScale+
FPGA Development Board
AXU2CGA/B
User Manual

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
2 / 29
Amazon Store: https://www.amazon.com/alinx
Version Record
Version
Date
Release By
Description
Rev 1.0
2021-04-08
Rachel Zhou
First Release

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
3 / 29
Amazon Store: https://www.amazon.com/alinx
Table of Contents
Version Record.......................................................................................................2
Part 1: AXU2CGA/B Introduction........................................................................4
Part 2: ZYNQ Chip.................................................................................................5
Part 3: DDR4 DRAM............................................................................................. 7
Part 4: QSPI Flash...............................................................................................11
Part 5: eMMC Flash (Only for AXU2CGB)......................................................12
Part 6: EEPROM................................................................................................. 13
Part 7: DP Display Interface.............................................................................. 13
Part 8: USB 3.0 Interface................................................................................... 15
Part 9: Gigabit Ethernet Interface.....................................................................16
Part 10: USB to Serial Port................................................................................17
Part 11: SD Card Slot Interface........................................................................ 18
Part 12: PCIE Interface...................................................................................... 19
Part 13: 40-Pin Expansion Header...................................................................20
Part 14: MIPI Camera Interface........................................................................22
Part 15: JTAG Debug Port................................................................................. 24
Part 16: DIP Switch Configuration....................................................................25
Part 17: LEDs.......................................................................................................25
Part 18: System Clock........................................................................................26
Part 19: ALINX Customized Fan Interface......................................................27
Part 20: Power Input........................................................................................... 28
Part 21: Board Size Dimension.........................................................................29

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
4 / 29
Amazon Store: https://www.amazon.com/alinx
Part 1: AXU2CGA/B Introduction
The AXU2CGA/B Board is characterized by its small size and extensive
peripherals. The main chip is Xilinx's Zynq UltraScale+ MPSoCs CG family chip,
the model is XCZU2CG-1SFVC784E. The PS side of AXU2CGA is mounted
with 2 slices of DDR4 (total 1GB, 32bit) and 1 slice of 256Mb QSPI FLASH.
The PS side of AXU2CGB is equipped with 4 DDR4 (total 2GB, 64bit), one 8GB
eMMC FLASH memory chip and one 256Mb QSPI FLASH.
Peripheral interfaces include 1 MINI DP interface, 4 USB3.0 interfaces, 1
Gigabit Ethernet interface, 1 USB serial port, 1 PCIE interface, 1 TF card
interface, 2 40-pin expansion ports, 2 MIPI Interface, KEYs and LEDs.
The board schematic is as Figure 1-1:
Figure 1-1: Board Schematic

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
5 / 29
Amazon Store: https://www.amazon.com/alinx
Part 2: ZYNQ Chip
The PS system of the XCZU2CG-1SFVC784E chip integrates two ARM
Cortex™-A53 processors with a speed of up to 1.2Ghz and supports Level 2
Cache; it also contains two Cortex-R5 processors with a speed of up to
500Mhz. The XCZU2CG Chip supports 32-bit or 64-bit DDR4, LPDDR4, DDR3,
DDR3L, LPDDR3 memory chips, with rich high-speed interfaces on the PS
side such as PCIE Gen2, USB3.0, SATA 3.1, DisplayPort; it also supports
USB2.0, Gigabit Ethernet, SD/SDIO, I2C, CAN, UART, GPIO and other
interfaces. The PL end contains a wealth of programmable logic units, DSP and
internal RAM. The overall block diagram of the XCZU2CG chip is shown in the
figure 2-1:
Figure 2-1: Overall Block Diagram of ZU2CG Chip

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
6 / 29
Amazon Store: https://www.amazon.com/alinx
The main parameters of the PS system are as follows:
ARM dual-core Cortex™-A53 processor, speed up to 1.2GHz, each CPU
32KB level 1 instruction and data cache, 1MB level 2 cache, shared by 2
CPUs
ARM dual-core Cortex-R5 processor, speed up to 500MHz, each CPU
32KB level 1 instruction and data cache, and 128K tightly coupled memory
External storage interface, support 32/64bit DDR4/3/3L, LPDDR4/3
interface
Static storage interface, support NAND, 2xQuad-SPI FLASH
High-speed connection interface, support PCIe Gen2 x4, 2xUSB3.0, Sata
3.1, Display Port, 4 x Tri-mode Gigabit Ethernet
Common connection interface: 2xUSB2.0, 2x SD/SDIO, 2x UART, 2x CAN
2.0B, 2x I2C, 2x SPI, 4x 32b GPIO
Power management: support the division of Full/Low/PL/Battery four parts
of power
Encryption algorithm: support RSA, AES and SHA
System monitoring: 10-bit 1Mbps AD sampling for temperature and voltage
detection
The main parameters of the PL logic part are as follows:
Logic Cells: 103K
flip-flops : 94K
Lookup table (LUTs) : 47K；
Block RAM: 5.3Mb
Clock Management Unit (CMTs) : 3
Multiplier 18x25MACCs: 240

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
7 / 29
Amazon Store: https://www.amazon.com/alinx
Part 3: DDR4 DRAM
There are two Micron DDR4 chips on the PS side of the AXU2CGA board,
which form a 32-bit data bus bandwidth and a total capacity of 1GB. There are
4 Micron DDR4 chips on the PS side of the AXU2CGB board, which form a
64-bit data bus bandwidth and a total capacity of 2GB. The maximum operating
speed of DDR4 SDRAM on the PS side can reach 1200MHz (data rate
2400Mbps). The specific configuration of DDR4 SDRAM is shown below.
Among them, U71 and U72 are only AXU2CGB mounted.
Location
Capacity
Manufacturer
U3,U5,(U71,U72)
256M x 16bit
Micron
Table 3-1: DDR4 SDRAM Configuration
The hardware connection of DDR4 on the PS side is shown in Figure 3-1:
Figure 3-1: PS Side DDR4 DRAM Schematic
AXU2CGA PS side DDR4 SDRAM Pin Assignment:
Signal Name
Pin Name
Pin Number
PS_DDR4_DQS0_P
PS_DDR_DQS_P0_504
AF21
PS_DDR4_DQS0_N
PS_DDR_DQS_N0_504
AG21
PS_DDR4_DQS1_P
PS_DDR_DQS_P1_504
AF23
PS_DDR4_DQS1_N
PS_DDR_DQS_N1_504
AG23

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
8 / 29
Amazon Store: https://www.amazon.com/alinx
PS_DDR4_DQS2_P
PS_DDR_DQS_P2_504
AF25
PS_DDR4_DQS2_N
PS_DDR_DQS_N2_504
AF26
PS_DDR4_DQS3_P
PS_DDR_DQS_P3_504
AE27
PS_DDR4_DQS3_N
PS_DDR_DQS_N3_504
AF27
PS_DDR4_DQ0
PS_DDR_DQ0_504
AD21
PS_DDR4_DQ1
PS_DDR_DQ1_504
AE20
PS_DDR4_DQ2
PS_DDR_DQ2_504
AD20
PS_DDR4_DQ3
PS_DDR_DQ3_504
AF20
PS_DDR4_DQ4
PS_DDR_DQ4_504
AH21
PS_DDR4_DQ5
PS_DDR_DQ5_504
AH20
PS_DDR4_DQ6
PS_DDR_DQ6_504
AH19
PS_DDR4_DQ7
PS_DDR_DQ7_504
AG19
PS_DDR4_DQ8
PS_DDR_DQ8_504
AF22
PS_DDR4_DQ9
PS_DDR_DQ9_504
AH22
PS_DDR4_DQ10
PS_DDR_DQ10_504
AE22
PS_DDR4_DQ11
PS_DDR_DQ11_504
AD22
PS_DDR4_DQ12
PS_DDR_DQ12_504
AH23
PS_DDR4_DQ13
PS_DDR_DQ13_504
AH24
PS_DDR4_DQ14
PS_DDR_DQ14_504
AE24
PS_DDR4_DQ15
PS_DDR_DQ15_504
AG24
PS_DDR4_DQ16
PS_DDR_DQ16_504
AC26
PS_DDR4_DQ17
PS_DDR_DQ17_504
AD26
PS_DDR4_DQ18
PS_DDR_DQ18_504
AD25
PS_DDR4_DQ19
PS_DDR_DQ19_504
AD24
PS_DDR4_DQ20
PS_DDR_DQ20_504
AG26
PS_DDR4_DQ21
PS_DDR_DQ21_504
AH25
PS_DDR4_DQ22
PS_DDR_DQ22_504
AH26
PS_DDR4_DQ23
PS_DDR_DQ23_504
AG25
PS_DDR4_DQ24
PS_DDR_DQ24_504
AH27
PS_DDR4_DQ25
PS_DDR_DQ25_504
AH28
PS_DDR4_DQ26
PS_DDR_DQ26_504
AF28
PS_DDR4_DQ27
PS_DDR_DQ27_504
AG28
PS_DDR4_DQ28
PS_DDR_DQ28_504
AC27
PS_DDR4_DQ29
PS_DDR_DQ29_504
AD27
PS_DDR4_DQ30
PS_DDR_DQ30_504
AD28
PS_DDR4_DQ31
PS_DDR_DQ31_504
AC28

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
9 / 29
Amazon Store: https://www.amazon.com/alinx
PS_DDR4_DM0
PS_DDR_DM0_504
AG20
PS_DDR4_DM1
PS_DDR_DM1_504
AE23
PS_DDR4_DM2
PS_DDR_DM2_504
AE25
PS_DDR4_DM3
PS_DDR_DM3_504
AE28
PS_DDR4_A0
PS_DDR_A0_504
W28
PS_DDR4_A1
PS_DDR_A1_504
Y28
PS_DDR4_A2
PS_DDR_A2_504
AB28
PS_DDR4_A3
PS_DDR_A3_504
AA28
PS_DDR4_A4
PS_DDR_A4_504
Y27
PS_DDR4_A5
PS_DDR_A5_504
AA27
PS_DDR4_A6
PS_DDR_A6_504
Y22
PS_DDR4_A7
PS_DDR_A7_504
AA23
PS_DDR4_A8
PS_DDR_A8_504
AA22
PS_DDR4_A9
PS_DDR_A9_504
AB23
PS_DDR4_A10
PS_DDR_A10_504
AA25
PS_DDR4_A11
PS_DDR_A11_504
AA26
PS_DDR4_A12
PS_DDR_A12_504
AB25
PS_DDR4_A13
PS_DDR_A13_504
AB26
PS_DDR4_WE_B
PS_DDR_A14_504
AB24
PS_DDR4_CAS_B
PS_DDR_A15_504
AC24
PS_DDR4_RAS_B
PS_DDR_A16_504
AC23
PS_DDR4_ACT_B
PS_DDR_ACT_N_504
Y23
PS_DDR4_ALERT_B
PS_DDR_ALERT_N_504
U25
PS_DDR4_BA0
PS_DDR_BA0_504
V23
PS_DDR4_BA1
PS_DDR_BA1_504
W22
PS_DDR4_BG0
PS_DDR_BG0_504
W24
PS_DDR4_CS0_B
PS_DDR_CS_N0_504
W27
PS_DDR4_ODT0
PS_DDR_ODT0_504
U28
PS_DDR4_PARITY
PS_DDR_PARITY_504
V24
PS_DDR4_RESET_B
PS_DDR_RST_N_504
U23
PS_DDR4_CLK0_P
PS_DDR_CK0_P_504
W25
PS_DDR4_CLK0_N
PS_DDR_CK0_N_504
W26
PS_DDR4_CKE0
PS_DDR_CKE0_504
V28

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
10 / 29
Amazon Store: https://www.amazon.com/alinx
AXU2CGB PS side DDR4 SDRAM data pin assignment is the same as
AXU2CGA, additional data signal assignment is as follows:
Signal Name
Pin Name
Pin Number
PS_DDR4_DQS4_P
PS_DDR_DQS_P4_504
N23
PS_DDR4_DQS4_N
PS_DDR_DQS_N4_504
M23
PS_DDR4_DQS5_P
PS_DDR_DQS_P5_504
L23
PS_DDR4_DQS5_N
PS_DDR_DQS_N5_504
K23
PS_DDR4_DQS6_P
PS_DDR_DQS_P6_504
N26
PS_DDR4_DQS6_N
PS_DDR_DQS_N6_504
N27
PS_DDR4_DQS7_P
PS_DDR_DQS_P7_504
J26
PS_DDR4_DQS7_N
PS_DDR_DQS_N7_504
J27
PS_DDR4_DQ32
PS_DDR_DQ32_504
T22
PS_DDR4_DQ33
PS_DDR_DQ33_504
R22
PS_DDR4_DQ34
PS_DDR_DQ34_504
P22
PS_DDR4_DQ35
PS_DDR_DQ35_504
N22
PS_DDR4_DQ36
PS_DDR_DQ36_504
T23
PS_DDR4_DQ37
PS_DDR_DQ37_504
P24
PS_DDR4_DQ38
PS_DDR_DQ38_504
R24
PS_DDR4_DQ39
PS_DDR_DQ39_504
N24
PS_DDR4_DQ40
PS_DDR_DQ40_504
H24
PS_DDR4_DQ41
PS_DDR_DQ41_504
J24
PS_DDR4_DQ42
PS_DDR_DQ42_504
M24
PS_DDR4_DQ43
PS_DDR_DQ43_504
K24
PS_DDR4_DQ44
PS_DDR_DQ44_504
J22
PS_DDR4_DQ45
PS_DDR_DQ45_504
H22
PS_DDR4_DQ46
PS_DDR_DQ46_504
K22
PS_DDR4_DQ47
PS_DDR_DQ47_504
L22
PS_DDR4_DQ48
PS_DDR_DQ48_504
M25
PS_DDR4_DQ49
PS_DDR_DQ49_504
M26
PS_DDR4_DQ50
PS_DDR_DQ50_504
L25
PS_DDR4_DQ51
PS_DDR_DQ51_504
L26
PS_DDR4_DQ52
PS_DDR_DQ52_504
K28
PS_DDR4_DQ53
PS_DDR_DQ53_504
L28
PS_DDR4_DQ54
PS_DDR_DQ54_504
M28
PS_DDR4_DQ55
PS_DDR_DQ55_504
N28

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
11 / 29
Amazon Store: https://www.amazon.com/alinx
PS_DDR4_DQ56
PS_DDR_DQ56_504
J28
PS_DDR4_DQ57
PS_DDR_DQ57_504
K27
PS_DDR4_DQ58
PS_DDR_DQ58_504
H28
PS_DDR4_DQ59
PS_DDR_DQ59_504
H27
PS_DDR4_DQ60
PS_DDR_DQ60_504
G26
PS_DDR4_DQ61
PS_DDR_DQ61_504
G25
PS_DDR4_DQ62
PS_DDR_DQ62_504
K25
PS_DDR4_DQ63
PS_DDR_DQ63_504
J25
PS_DDR4_DM4
PS_DDR_DM4_504
R23
PS_DDR4_DM5
PS_DDR_DM5_504
H23
PS_DDR4_DM6
PS_DDR_DM6_504
L27
PS_DDR4_DM7
PS_DDR_DM7_504
H26
Part 4: QSPI Flash
The AXU2CGA/B board has a 256MBit Quad-SPI FLASH chip, the model
is MT25QU256ABA1EW9-0SIT. QSPI FLASH is connected to the GPIO port of
BANK500 in the PS part of the ZYNQ chip. Figure 4-1 shows the part of QSPI
Flash in the schematic.
Figure 4-1: QSPI Flash
Configure Chip Pin Assignment:
Signal Name
Pin Name
Pin Number
MIO0_QSPI0_SCLK
PS_MIO0_500
AG15
MIO1_QSPI0_IO1
PS_MIO1_500
AG16

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
12 / 29
Amazon Store: https://www.amazon.com/alinx
MIO2_QSPI0_IO2
PS_MIO2_500
AF15
MIO3_QSPI0_IO3
PS_MIO3_500
AH15
MIO4_QSPI0_IO0
PS_MIO4_500
AH16
MIO5_QSPI0_SS_B
PS_MIO5_500
AD16
Part 5: eMMC Flash (Only for AXU2CGB)
There is an eMMC FLASH chip with a capacity of 8GB on the AXU2CGB
board. The eMMC FLASH is connected to the GPIO port of the BANK500 of
the PS part of ZYNQ UltraScale+. Figure 5-1 is the eMMC Flash schematic.
Figure 5-1: eMMC Flash Schematic
Configure Chip Pin Assignment:
Signal Name
Pin Name
Pin Number
MMC_DAT0
PS_MIO13_500
AH18
MMC_DAT1
PS_MIO14_500
AG18
MMC_DAT2
PS_MIO15_500
AE18
MMC_DAT3
PS_MIO16_500
AF18
MMC_DAT4
PS_MIO17_500
AC18
MMC_DAT5
PS_MIO18_500
AC19
MMC_DAT6
PS_MIO19_500
AE19
MMC_DAT7
PS_MIO20_500
AD19
MMC_CMD
PS_MIO21_500
AC21
MMC_CCLK
PS_MIO22_500
AB20
MMC_RSTN
PS_MIO23_500
AB18

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
13 / 29
Amazon Store: https://www.amazon.com/alinx
Part 6: EEPROM
The AXU2CGA/B development board has a piece of EEPROM onboard,
the model number is 24LC04. The I2C signal of the EEPROM is connected to
the MIO port of the ZYNQ PS side. Figure 6-1 is EEPROM schematic:
Figure 6-1: EEPROM Schematic
EEPROM Pin Assignment:
Signal Name
Pin Name
Pin Number
PS_IIC1_SCL
PS_MIO32_501
J16
PS_IIC1_SDA
PS_MIO33_501
L16
Part 7: DP Display Interface
The AXU2CGA/B board has a MINI-type DisplayPort output display
interface, which is used for video image display, and supports up to 4K x
2K@30Fps output. The TX signals of LANE0 and LANE1 of ZU2CG PS MGT
are connected to the DP connector in a differential signal mode. The
DisplayPort auxiliary channel is connected to the MIO pin of the PS. The
schematic diagram of the DP output interface is shown in Figure 7-1:

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
14 / 29
Amazon Store: https://www.amazon.com/alinx
Figure 7-1: DP interface design Schematic
The DisplayPort interface ZYNQ pin assignment is as follows:
Signal Name
ZYNQ Pin Number
ZYNQ Pin
Number
Description
GT0_DP_TX_P
PS_MGTTXP3_505
B23
Low bits of DP Data
Transmit Positive
GT0_DP_TX_N
PS_MGTTXN3_505
B24
Low bits of DP Data
Transmit Negative
GT1_DP_TX_P
PS_MGTTXP2_505
C25
High bits of DP Data
Transmit Positive
GT1_DP_TX_N
PS_MGTTXN2_505
C26
High bits of DP Data
Transmit Negative
505_DP_CLKP
PS_MGTREFCLK2P_50
5
C21
DP Reference Clock
Positive
505_DP_CLKP
PS_MGTREFCLK2N_50
5
C22
DP Reference Clock
Negative
DP_AUX_OUT
PS_MIO27
J15
DP Auxiliary Data Output
DP_AUX_IN
PS_MIO30
F16
DP Auxiliary Data Input
DP_OE
PS_MIO29
G16
DP Auxiliary Data Output Enable
DP_HPD
PS_MIO28
K15
DP Insertion Signal Detection

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
15 / 29
Amazon Store: https://www.amazon.com/alinx
Part 8: USB 3.0 Interface
There are 4 USB3.0 interfaces on the AXU2CGA/B board, the interface is
HOST working mode (Type A), and the data transmission speed is up to
5.0Gb/s. The USB3.0 interfaces connect external USB PHY chip and USB3.0
HUB chip through ULPI interface to realize high-speed USB3.0 data
communication.
The USB Schematic is shown in Figure 8-1:
Figure 8-1: USB 3.0 Schematic
USB Pin Assignment:
Signal Name
Pin Name
Pin Number
Description
USB_SSTXP
PS_MGTTXP2_505
D23
USB3.0 Data Transmission
Positive
USB_SSTXN
PS_MGTTXN2_505
D24
USB3.0 Data Transmission
Negative
USB_SSRXP
PS_MGTRXP2_505
D27
USB3.0 Data Receive Positive
USB_SSRXN
PS_MGTRXN2_505
D28
USB3.0 Data Receive Negative

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
16 / 29
Amazon Store: https://www.amazon.com/alinx
505_USB_CLKP
PS_MGTREFCLK2P_505
E21
USB3.0 Reference Clock
Positive
505_USB_CLKN
PS_MGTREFCLK2N_505
E22
USB3.0 Reference Clock
Negative
USB_DATA0
PS_MIO56
C16
USB2.0 Data Bit0
USB_DATA1
PS_MIO57
A16
USB2.0 Data Bit1
USB_DATA2
PS_MIO54
F17
USB2.0 Data Bit2
USB_DATA3
PS_MIO59
E17
USB2.0 Data Bit3
USB_DATA4
PS_MIO60
C17
USB2.0 Data Bit4
USB_DATA5
PS_MIO61
D17
USB2.0 Data Bit5
USB_DATA6
PS_MIO62
A17
USB2.0 Data Bit6
USB_DATA7
PS_MIO63
E18
USB2.0 Data Bit7
USB_STP
PS_MIO58
F18
USB2.0 Stop Signal
USB_DIR
PS_MIO53
D16
USB2.0 Data Direction Signal
USB_CLK
PS_MIO52
G18
USB2.0 Clock Signal
USB_NXT
PS_MIO55
B16
USB2.0 the NEXT Data Signal
Part 9: Gigabit Ethernet Interface
There is 1 Gigabit Ethernet interface on AXU2CGA/B, and the Ethernet
interface is on BANK502 of PS connected through GPHY chip. The GPHY chip
uses the KSZ9031RNXIC Ethernet PHY chip from Micrel, and the PHY
Address is 001. Figure 9-1 is a schematic diagram of the connection of the
Ethernet PHY chip on the ZYNQ PS side:
Figure 9-1: ZYNQ PS System and GPHY Schematic

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
17 / 29
Amazon Store: https://www.amazon.com/alinx
The Gigabit Ethernet pin assignments are as follows:
Signal Name
Pin Name
Pin Number
Description
PHY1_TXCK
PS_MIO64
E19
RGMII Transmit Clock
PHY1_TXD0
PS_MIO65
A18
Transmit data bit０
PHY1_TXD1
PS_MIO66
G19
Transmit data bit1
PHY1_TXD2
PS_MIO67
B18
Transmit data bit2
PHY1_TXD3
PS_MIO68
C18
Transmit data bit3
PHY1_TXCTL
PS_MIO69
D19
Transmit data Enable Signal
PHY1_RXCK
PS_MIO70
C19
RGMII Receive Clock
PHY1_RXD0
PS_MIO71
B19
Receive Data Bit0
PHY1_RXD1
PS_MIO72
G20
Receive Data Bit1
PHY1_RXD2
PS_MIO73
G21
Receive Data Bit2
PHY1_RXD3
PS_MIO74
D20
Receive Data Bit3
PHY1_RXCTL
PS_MIO75
A19
Receive Data Enable Signal
PHY1_MDC
PS_MIO76
B20
MDIO Clock Management
PHY1_MDIO
PS_MIO77
F20
MDIO Management Data
Part 10: USB to Serial Port
There is a Uart to USB interface on the AXU2CGA/B board for system
debugging. The conversion chip uses the USB-UAR chip of Silicon Labs
CP2102, and the USB interface uses the MINI USB interface. It can be
connected to the USB port of the PC with a USB cable for independent power
supply of the core board and serial data communication. The schematic
diagram of the USB Uart circuit design is shown in Figure 10-1:
Figure 10-1: USB to serial port schematic

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
18 / 29
Amazon Store: https://www.amazon.com/alinx
USB to serial port ZYNQ pin assignment:
Signal name
Pin Name
Pin Number
Description
PS_UART1_TX
PS_MIO24
AB19
PL Uart Data Output
PS_UART1_RX
PS_MIO25
AB21
PL Uart Data Input
Part 11: SD Card Slot Interface
The AXU2CGA/B board contains a Micro SD card interface. The SDIO
signal is connected to the IO signal of BANK501. The SD card connector
schematic is shown in Figure 11-1.
Figure 11-1: SD Card Connector Schematic
SD card slot pin assignment:
Signal Name
Pin Name
Pin Number
Description
SD_CLK
PS_MIO51
l21
SD Clock Signal
SD_CMD
PS_MIO50
M19
SD Command Signal
SD_D0
PS_MIO46
L20
SD Data0
SD_D1
PS_MIO47
H21
SD Data1
SD_D2
PS_MIO48
J21
SD Data2
SD_D3
PS_MIO49
M18
SD Data3
SD_CD
PS_MIO45
K20
SD Card Detection Signal

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
19 / 29
Amazon Store: https://www.amazon.com/alinx
Part 12: PCIE Interface
There is a PCIE x1 slot on the AXU2CGA/B board for connecting PCIE
peripherals, and the PCIE communication speed is up to 5Gbps. PCIE signal is
directly connected to LANE0 of BANK505 PS MGT transceiver. The schematic
diagram of PCIE x 1 design is shown in Figure 12-1:
Figure 12-1: PCIE Schematic
PCIE Interface ZYNQ Pin Assignment
Signal Name
Pin Name
Pin
Number
Description
PCIE_TXP
PS_MGTTXP0_505
E25
PCIE Data Transmission Positive
PCIE_TXN
PS_MGTTXN0_505
E26
PCIE Data Transmission Negative
PCIE_RXP
PS_MGTRXP0_505
F27
PCIE Data Receive Positive
PCIE_RXN
PS_MGTRXN0_505
F28
PCIE Data Receive Negative
PCIE_REFCLK_P
PS_MGTREFCLK0P_505
F23
PCIE Data Reference Clock Positive
PCIE_REFCLK_N
PS_MGTREFCLK0N_505
F24
PCIE Data Reference Clock Negative

ZYNQ Ultrascale + FPGA Board AXU2CGA/B User Manual
20 / 29
Amazon Store: https://www.amazon.com/alinx
Part 13: 40-Pin Expansion Header
The AXU2CGA/B board is reserved with two 0.1-inch standard pitch 40-pin
expansion ports J12 and J15, which are used to connect the ALINX modules or
the external circuit designed by the user. The expansion port has 40 signals, of
which 1-channel 5V power supply, 2-channel 3.3 V power supply, 3-channle
ground and 34 IOs. Do not directly connect the IO directly to the 5V device
to avoid burning the FPGA. If you want to connect 5V equipment, you
need to connect level conversion chip.
The IO port of the J15 expansion port is connected to the ZYNQ chip
BANK25 and BANK26, and the level standard is 3.3V. The schematic diagram
of the design is shown in Figure 13-1:
Figure 13-1: Expansion Header Schematic
J12 Expansion Header ZYNQ Pin Assignment
J12 Pin
Signal Name
Pin Number
J12 Pin
Signal Name
Pin Number
1
GND
-
2
VCC5V
-
3
IO1_1N
F7
4
IO1_1P
G8
5
IO1_2N
F6
6
IO1_2P
G6
