Allmatic CT INVERTER AM Safety guide

CT INVERTER AM CONTROL UNIT
Programmable control board for sliding gates
with inverter technology
Manual for installation
Compatible from firmware version CSMAM02

ITA ENG FRA ESP DEU POR 2 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
WARNING: DO NOT INSTALL THE CONTROL UNIT WITHOUT READING THE INSTRUCTIONS FIRST!
The Single-phase control unit CT INVERTER AM is a device suitable for operating and controlling the sliding gate in a way easy and complete; it is
designed in order to satisfy all possible needs.
The inverter on board allows to set the maximum torque limits along with the possibility to modify the frequency (the speed of the motor).
The possibility to use motors with encoder allows the unit to detect possible obstacles along the run and reverse its direction of motion. It is suitable to
command and control automatics accesses with its single-phase motor 230Vac max 1,5KW (current limited to 10A) WITHOUT using a starting
condenser. Every control board is equipped with a memory module that stores all personal settings and parameters needed for operating the control
board (these data can be transferred from one unit to another one). It is equipped with inputs for self-tested photocells, keys for SS (step-by-step),
PED (partial opening), OPEN and CLOSE, switch limits, security stops and a wide display with 3 keys for settings. It is also equipped with a molex
connector for a plug-in receiver, output for courtesy and flashing light. It is possible to connect an additional card (R1) to operate an electric lock.
1. Introduction
NOTE: All unused NC inputs must be jumpered with the common.
It is FUNDAMENTAL to connect the motor and the unit
to the EARTH in order to operate the control unit correctly!
In case an encoder is applied, it is compulsory to use a shielded cable with the screening connected to the EARTH
only by one end of the cable itself.
ANTENNA Antenna
COM Common
S.S. Step by Step
PHOTO Photocell
STOP Stop
EDGE Safety edge
L.S.CL. Closing limit switch
L.S.OP. Opening limit switch
PED. Partial opening
OPEN Opening command
CLOSE Closing command
ENCODER Encoder
SIG. Encoder signal
GND Ground
PHOTO POWER
SUPPLY Photocells power supply
+RX Photo Receiver
+TX Photo transmitter
CLOSE (21)
OPEN (22) Motor connections
COM (23)
PE Earth
N Neutral Power supply
L Phase
SYSTEM MEMORY System memory
BLINKER Flashing light
COURTESY LIGHT Courtesy light
ELECTRIC LOCK
CARD CONNECTOR Electric lock or brake card connector
RADIO RECEIVER Radio receiver
FUSE Fuse
INPUT LEDS Input leds
POWER ON LEDS Power on leds
For the connection of the motor we recommend to use a screened cables 3 poles + earth 1.5 mm2 (type FD781CY)
For the connection of the possible encoder we recommend to use a screened cable 3 x 0,75mm2 (type OLFLEX-110CH)

ITA ENG FRA ESP DEU POR 3 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
2. Collegamenti
1
2
3
4
5
6
7
8
9
10
11
ANTENNA INPUT
Connect the signal cable of the antenna to the
clamp 1 of the terminal board.
Connect the ground of the antenna to the clamp
2 of the terminal board.
The presence of the metallic parts or humidity in the
walls could have negative influences on the range
of the system. We suggest therefore to not place
the receiving antenna and/or transmitters near big
metallic objects, near the floor or on the ground.
STEP BY STEP INPUT
Connect the STEP-BY-STEP BUTTON (S.S.)
between the clamps 3 and 4.
ATTENTION: leave it open if not used
Under the dead man mode the STEP BY STEP
BUTTON operates as OPEN.
PHOTOCELL INPUT
Connect the NORMALLY CLOSED contact
of the photocell (PHOTO) between the clamps 3
and 5 of the terminal board.
ATTENTION: jumper the inputs if not used
The functioning of the photocells can be modified in
the MENU A.
STOP INPUT
Connect the contact NORMALLY CLOSED of
the STOP between the clamps 3 and 6 of the
terminal board.
ATTENTION: jumper the inputs if not used
SAFETY EDGE INPUT
Connect the contact NORMALLY CLOSED of
the SAFETY EDGE between the clamps 3 and
7 of the terminal board.
ATTENTION: jumper the inputs if not used
INPUT CLOSING LIMIT SWITCH
Connect the contact NORMALLY CLOSED of
the CLOSING LIMIT SWITCH (L.S.CL.) between
the clamps 3 and 8 of the control board.
Before activating the installation make sure that the
limit switches are functioning and correctly cabled.
INPUT OPENING LIMIT SWITCH
Connect the contact NORMALLY CLOSED of
the OPENING LIMIT SWITCH (L.S.CL.)
between the clamps 3 and 9 of the terminal
board.
Before activating the installation make sure that the
limit switches are functioning and correctly cabled.
.
PARTIAL OPENING INPUT
Connect the PARTIAL OPENING button (PED.)
between the clamps 3 and 10 of the terminal
board.
ATTENTION: leave it open if not used
Under the dead man mode the PARTIAL OPENING
button operates as CLOSE.
OPEN INPUT
Connect the button OPEN between the clamps
3 and 11 of the terminal board.
ATTENTION: leave it open if not used
CLOSE INPUT
Connect the button CLOSE between the clamps
3 and 12 of the terminal board.
ATTENTION: leave it open if not used
ENCODER INPUT
Connect the SIGNAL cable of the encoder to the
clamp 13 of the terminal board.
Connect the GND cable of the encoder to the
clamp 14 of the terminal board.
Connect the cable +Vdc of the encoder to the
clamp 15 of the terminal board.
ATTENTION: leave it open if not used
The activation/desactivation of the encoder function
is controlled in the MENU A
For the connection of the possible enco-
der we recommend to use a screened cable
3 x 0,75mm2 (type OLFLEX-110CH)

ITA ENG FRA ESP DEU POR 4 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
12
13
14
15
16
COURTESY LIGHT
Connect the courtesy light to the clamps 33 and
34, 230Vac 100W MAX.
It is possible to light up the action area of the
automatism during each motion.
The functioning of the auxiliary light is controlled by
the MENU A.
POWER SUPPLY
Connect the power supply cable to the clamps
26 and 27, connect the ground to one of the
clamps PE 28, 29 or 30.
Do not connect the card directly to the electric
network. Put a device which can ensure the
disconnection of each pole from the power supply of
the control unit
Use a cable with correct section according to the
current absorbed by the motor.
MOTOR OUTPUT
Connect the common of the motor to the clamp
23 of the control unit.
Connect the open of the motor to the clamp 22
of the control unit.
Connect close of the motor to the clamp 21 of
the control unit.
Before activating the automation make sure that all
the safey devices are correctly cabled and
functioning, refer to the preliminary checkings
section of chap.4
Cable the motor WITHOUT using the capacitor.
ACCESSORIES OUTPUTS
Accessories output 24Vdc 3W.
PHOTOCELLS POWER SUPPLY
Connect the clamp 16 of the control unit to the
clamp + of the power supply of the photocells
receiver.
Connect the clamp 17 of the control unit to the
power supply clamp - of the photocells receiver
and of the transmitter.
Connect the clamp 18 of the control unit to the
power supply clamp of the trasnmitter of the
photocells.
The photocells test test is activated by the MENU A.
ATTENTION: the control unit gives a voltage of 24
Vdc and can supply a maximum power of 3W.
For the safety edges test connect the test device of
the safety edge on the power supply pins of the TX
(test activated wiht low logic signal 0Vdc).
Please refer to the manual of the safety edge.
FLASHING LIGHT
Connect the flashing light to the clamps 31 and
32.
Use a flashing light without self flashing card
230Vac 60W MAX
!! Risk of electric shock !!
For the connection of the motor we recom-
mend to use a screened cables 3 poles +
earth 1.5 mm2 (type FD781CY)

ITA ENG FRA ESP DEU POR 5 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
3 Programming Menu
This procedure must be carried out ONLY by the installer and ONLY during the installation of the system.
WARNING: the motor must be still, preferably in closed position, in order to access the programming menu!
8888888888888888
8888888888888888
3.1 Activation and selection of the programming menu
The control unit CT INVERTER AM is equipped with THREE user menus (MENU A, MENU B, MENU C), by which it is possible to regulate, program
and modify all functional parameters. Follow the indications on the display during the programming phases.
MENU A - allows to activate the optional functions and to select the intervention modalities of the security systems.
MENU B - it is dedicated to the learning of the runs, to the operations related to the manual movement and to the regulation of the control
parameters of the motor
MENU C - menu for auxiliary configurations for user’s support
2
1 Stop the motor and get in safety conditions The display must not show any indications
The display shows the
first entry available
Select an entry of the menu (see following table); shortly press key
P3 to scroll down to the following index, or key P1 to go back to
the previous menu
3 The display shows the entry selected.
Some parts of the control unit are subject to dangerous voltages!
Pay attention during the phase of manual accessing to the control board
4 Confirm the entry selected by pressing key P2
The first line of the display shows the present setting for
the function selected.
The second line of the display shows the possible
modification settings according to the parameter
selected (see specific paragraphs)
5 Modify the status of the parameter by following the
indications written in the second line of the display by using
keys P1 e P3.
The first line of the display shows the present setting for
the function selected.
The second line of the display shows the possible
modification settings according to the parameter
selected (see specific paragraphs)
6 Confirm the setting selected by pressing key P2 The display indicates the correct storage of data and then
shows the entry selected
7 It is possible to modify other parameters (go back to point 3) or to
exit the programming menu by selecting the option EXIT
(confirm by pressing key P2)
Exit from the menu is confirmed by the absence of
indications on the display
AUTOMATIC EXIT FROM THE MENU: the menu exits automatically in case of long inactivity (longer than 15 seconds)
8888888888888888
8888888888888888
8888888888888888
8888888888888888
Press and keep pressed key P1 for 2 seconds in order to
activate MENU A
Press and keep pressed key P2 for 2 seconds in order to
activate MENU B
Press and keep pressed key P3 for 2 seconds in order to
activate MENU C
LANGUAGE SETTING
Press key P3 for 2 seconds. Confirm with key P2. Select the language by pressing either P1 or P3.
Confirm with key P2
It is suggested to select the language before any other operations

ITA ENG FRA ESP DEU POR 6 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
3.2 Programming menu A (key P1)- List of parameters
The following table lists the entries of menu A and reports a short description of the parameters that can be adjusted; refer to paragraph ADVANCED
FUNCTIONS for more details
Auto
ReclosingTim
Timed closure of the gate (only from total or partial opening)
OFF: disabled
HH:MM:SS: time of persistence in opening position
PhotoAuto
Reclose
Immediate closing after the intervention of the photocell (only from total or partial opening)
OFF: disabled
ON: the gate closes 3 seconds after the contact between photocell has restored
Brake
Brake operation (for motors with high inertia).
OFF: disabled
1: electronic brake
2: activation of the contact on the auxiliary card for an external brake, active with still motor
3: activation of the contact on the auxiliary card for an external brake, active when motor is moving
MENU A
Dead Man
“Dead Man” mode. The motor moves only by means of a permanent command
OFF: disabled
ON: enabled (WARNING: automatic motions are disabled)
Condominium
Condominium function. The commands S.S. and PED allow only the opening of the gate
OFF: disabled
ON: enabled (WARNING: enable the “Automatic Re-Closure” in order to close)
Photo Inv
Photocell intervention modality
OFF: the gate stays still until the obstacle is removed, and then opens completely
ON: the gate opens completely (this function does not apply in opening)
Photo Test
Functional test of the photocell; it is executed before the gate moves
OFF: disabled
ON: test activated (WARNING: supply the photocell with power as shown in the scheme)
Edge Inv
Modality of operation of the safety edge (sensible edge)
OFF: the gate stops
ON: the gate opens completely (this function does not apply in opening)
Edge Test
Functional test of the safety edge; it is executed before the gate moves
OFF: disabled
ON: test activated (WARNING: supply the safety edge with power as specified in the chap. 2.12)
Pre-Blink
Short flash before the motion of the gate
OFF: disabled
ON: enabled
Area light
Modality of functioning of the auxiliary output for lighting
OFF: courtesy light
ON: zone light (lit-off only when the gate is completely closed)
Aux Light Time
Auxiliary light’s switching-off delay for lighting
OFF: Auxiliary light’s output disabled
HH:MM:SS: switching-off delay - auxiliary light’s output enabled
Clock
Programmed opening function
OFF: disabled
ON: the gate opens and stays open until the OPEN input is active
Water Hammer
OP
Water hammer before the gate opens
OFF: disabled
XX,Xs: enabled. Adjustment of pressure time (in seconds) applied to the mechanical stop in closing
Encoder
Functioning with encoder (only for motors equipped with a suitable encoder)
OFF: disabled
ON: enabled (WARNING: the re-programming of the runs is needed)
Sensor level
Level of operation of the “motor still sensor” (with active encoder only)
OFF: sensor disabled
NNN : sensor enabled - adjustment of operation’s sensitivity
Sensor Inv
Modality of operation of the “motor still sensor” (with active encoder only)
OFF: the gate stops
ON : reverses shortly in opening; opens completely in closing
EXIT

ITA ENG FRA ESP DEU POR 7 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
3.3 Programming menu B (key P2) - List of parameters
The following table lists the entries of menu A and reports a short description of the parameters that can be adjusted; refer to paragraphs dedicated to
each function for more information
Manual Motion
Allows to move the gate at low speed by using the keys located on the control board.
This function is fundamental in order to check the motion during the installation
End position
Learning the full run of the gate, both in opening and in closing
WARNING: this operation must start when the gate is completely closed
Ped. Position
Learning of the opening partial run
WARNING: this operation must start when the gate is completely closed
High Speed OP
Regulation of the normal speed of the gate during the opening phase
NNN: speed expressed in Hz (frequency of the wave supplied to the motor)
Low Speed OP
Regulation of the speed of the gate during the opening phase when approaching the end of the run
NNN: speed expressed in Hz (frequency of the wave supplied to the motor)
High Speed CL
Regulation of the normal speed of the gate during the closing phase
NNN: speed expressed in Hz (frequency of the wave supplied to the motor)
Low Speed CL
Regulation of the speed of the gate during the closing phase when approaching the end of the run
NNN: speed expressed in Hz (frequency of the wave supplied to the motor)
High Torque OP
Torque supplied to the motor during the opening phase at normal speed
NNN: percentage of torque supplied to the motor
Low Torque OP
Torque supplied to the motor during the opening phase when approaching the end of the run
NNN: percentage of torque supplied to the motor
High Torque CL
Torque supplied to the motor during the closing phase at normal speed
NNN: percentage of torque supplied to the motor
Low Torque CL
Torque supplied to the motor during the closing phase when approaching the end of the run
NNN: percentage of torque supplied to the motor
EXIT
MENU B
3.4 Programming menu C (key P3) - List of parameters
The following table lists the entries of menu A and reports a short description of the parameters that can be adjusted; refer to paragraphs dedicated to
each function for more information
Language
Select the language (where applicable)
Backlight
Backlighting of the display
OFF: the light of the display is disabled
ON: the light of the display is enabled and its automatic switching-off is timed (Energy saving)
Reset
Total reset of factory settings of the control board.
WARNING: all programming operations and the setting of the control board must be repeated after this
operation
EXIT
MENU C

ITA ENG FRA ESP DEU POR 8 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
4. Preliminary checks
6
Manually bring the gate to a total opening position and
check the status of led LS.OP.
Once all above operations are successfully terminated, close
the automation and lock the motor.
2
1
The preliminary checks must be carried out only by professionals and by paying maximum attention. The correct wiring of the motor and the limit
switches is very important for the correct functioning of the automation.
Unlock the motor and supply the system with power only
after controlling the wiring connections and checking the
absence of short circuits
Check the status of the LEDs input by considering that all
normally closed (NC) inputs must have their corresponding
led alighted.
 Led LS.OP is off. Correct functioning
 Led LS.OP is on, but led LS.CL is off; check the
connection of the limit switches.
Manually bring the gate to a total closing position and
check the status of led LS.OP.
3
 Led LS.CL is off. Correct functioning.
 Led LS.CL is on, but led LS.OP is off; check the
connection of the limit switches
Manually bring the gate to the middle of the run and then
lock the motor.
Enter the parameter Manual Movement of MENU B and
command the closure of the gate.
WARNING: pay attention with the moving gate!
4
The motor starts to move. Watch its sense of rotation:
 If the gate opens, then stop the manual motion,
disconnect the system from the power and reverse the
motor connections. Then try again.
 If the gate closes, then stop the manual motion and go to
the following phase
Enter the parameter Manual Movement of MENU B and
command the opening of the gate.
WARNING: pay attention with the moving gate!
5
The motor starts to move. Watch its sense of rotation:
 If the gate closes, then stop the manual motion,
disconnect the system from the power and reverse the
motor connections. Then try again.
 If the gate opens, then stop the manual motion and go to
the following phase
5. Manual motion (Menu B - Manual movement)
This operation must be carried-out only by qualified personnel and by paying maximum attention.
The manual motion is an operation planned only for the phase of installation; it allows to move the gate at a limited speed in both directions.
WARNING: the photocells and the safety edge are not monitored during this phase!
Access to parameter Manual Mov. of MENU
B and confirm by pressing key P2
Move the gate by using keys P1 and P3.
Press key P2 or wait 15 sec. in order to exit the menu
6. Learning
Learning the run allows to define the parameters of the run of the gate, such as the width of the run at normal speed and at slowed speed.
Check that the adjustment of the torque and the speed of the gate are set before carrying out the learning phase.
Check that the gate is closed before starting the learning phase.
6.1 Learning the run of the gate (Menu B - Final position)
Enter the parameter Final Position of MENU
B and confirm by pushing key P2
Start moving the gate by pressing and releasing key P1 (START) or a Step-
by-Step key.
Push key P1 (START) or a Step-by-Step key when the gate reaches the
point where you want to start the slowdown in the opening phase
The gate continues its run at reduced speed as far as it hits the opening
limit.
Once the opening limit has been reached, the gate starts to close.
Push key P1 (START) or a Step-by-Step key when the gate reaches the
point where you want to start the slowdown in the closing phase
The gate continues its run at reduced speed as far as it hits the closing limit.
The programming is terminated once the closing limit is reached.
Note: in case no slowdown zones are set, then the control unit follows the
factory settings.
Exit the menu by scrolling the entries until you
find EXIT

ITA ENG FRA ESP DEU POR 9 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
Enter the parameter Ped. Position of MENU
B and confirm by pressing key P2
Start moving the gate by pressing and releasing key P1 (START) or a
Step-by-Step key.
When the gate reaches the position of partial opening, then push key
P1 (START) or a step-by-step key
The gate moves again in closing.
When the gate hits the limit in closing, then the programming is
terminated.
Exit the menu by scrolling the entries until you
find EXIT
6.2 Learning the partial run (Menu B – Ped. Position)
Learning the partial run allows to define the position of partial opening that allows the pedestrians accessing (PED command)
Check that the adjustment of the torque and the speed of the gate are set before carrying out the learning phase.
Check that the gate is closed before starting the learning phase.
The entries of menu B - Speed and torque - once the parameters themselves are entered allow to adjust the corresponding parameters from a
minimum up to a maximum value, according to the indications shown on the display.
The versatility of the control board allows an infinity of possible combinations: however it is recommended to adjust the settings by keeping into
account the dimensions and weight of the gate. High speeds may be dangerous, as well as high torques.
Such regulations must be carried out only by professionals.
It is recommended to check the correct functioning of the automation after any regulation.
It is highly recommended to learn the runs of the gate each time these parameters are changed.
8. Advanced functions
Photocell test
This control unit is equipped with a function which allows to control the proper functioning of photocells before any operation of the motor is made.
The security of the system is therefore higher in case the photo-device breaks down (for example, if the relay of exit is stuck) or there is a
undesired short circuit on the input of the photocells. The control board indicates a possible fault by flashing only once when any key is pressed
and also by not moving at all. This check is made after the control board receives a command to move, but before the control board itself gives
power to the motor.
Edge Test
Functional test of the safety edge. Connect the safety edge as shown in the instructions by using the photocell test’s clamp.
Condominium
All commands given via radio or by a step-by-step and/or a partial opening keys involve only the opening of the gate. The closing is related to the
function of automatic closing, which MUST BE ABSOLUTELY ACTIVATED since every command of closing is ignored.
PhotoAutoReclose
The gate closes 3 seconds after the photocell intervenes in case the gate is in a totally open or in a partial open position.
These are functions and/or functional modalities that can be activated by the user through the programming menu.
Automatic closing
Timed closing of the gate from totally open position or partial opening position. The “stop” command disables the automatic closing until a new
command given by the user is received (S.S., CLOSE, etc).
Motor brake
To be used with motors with a strong inertia and the necessity to quickly stop the automation. Pay attention as the mechanics must be sized
accordingly.
OFF: Brake disabled
1: Electronic braking function
2: Activation of the contact on the auxiliary card for an external brake, active with still motor
3: Activation of the contact on the auxiliary card for an external brake, active when motor is moving
Dead Man
The motor moves only with permanent a command and not with just impulses: the motor opens if the key “open” is kept pressed, and the opposite
operation applies with the key “close”. WARNING: this modality forbids all operations of automatic motion!
Inv. On photocells
Allows to set if, once the photocell beam is interrupted, the gate must reverse immediately (only in closing) or just after the removal of the obstacle
(it applies both in opening and in closing)
Edge Inv.
Allows to set if, once the safety edge alarms itself, the gate must stop or it must stop and then reverse (applies only in the phase of closing)
7 Adjustment of the speed and the torque (Menu B - Speed and torque)

ITA ENG FRA ESP DEU POR 10 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
Reset of the unit according to the display indications; this reset the control board to its factory settings
WARNING: all programming and personal settings must be repeated after the reset of the control board!
Clock function
Input OPEN becomes input clock in case it is possible to connect a timer for the programmed opening of the automation. The contact is
understood as a command to opening and to stay open as long as this status stays closed. When the contact is opened, then the unit reset its
normal functioning, waiting for a command given by the user (if the automatic closing is required, then it must be enabled from the menu).
Pre-flashing
This function commands a blinking BEFORE each movement in order to indicate the imminent movement itself.
Zone light
There is the possibility to use the auxiliary output as a courtesy light or as a light zone (always lit-on as long as the gate is open)
Auxiliary light timeout
There is the possibility to set the delay of switching-off of the auxiliary light after the automation stops
Water hammer in opening
If the automation is equipped with an electronic lock, then it is advisable that, when the gate is closed, the motor shortly operates in closing before
it starts the opening phase (water hammer). This function allows to unlock the electronic lock in any case, even when the weather conditions are
very bad (for example in case of ice). The activation of this function enables also the electronic lock’s output.
Sensor level
If it is enabled, it allows to modify the intervention sensitivity of the “stop motor” sensor. Decrease the value that is set in order to have higher
sensitivity. If the sensitivity is too high and the sensor operates without any apparent reason, then increase the value.
Encoder
If the motor is equipped with a suitable encoder, then it is possible to enable the functionalities of the encoder. In such way the control board does
not work any longer “by time” but “with encoder” instead. It is possible to detect the possible blocking of the motor.
Sensor inversion
Allows to define the reaction of the gate in case the “stop motor” sensor applies. If the reversing is not activated, then the gate stops and waits for
a new command. If the reversing is activated, then the gate reverses shortly in case the sensor applies during the opening; it open completely in
case the sensor applies during the closing phase of the gate.
10 Backlighting of the display (Menu C - Display light)
Enter MENU C and follow the instructions shown on the display in order to enable/disable the backlighting of the display itself.
The control board operates the function Energy saving which automatically switches off the display after the unit is inactive since some minutes.
The backlighting is automatically reactivated (if this function is enabled) when the user operates on the control board.
11 Housing for radio receiver
The unit disposes of a molex connector to house an ALLMATIC radio receiver. The first channel of the receiver is associated to the wired com-
mand S.S., whereas the second radio-channel (if it is present) is associated to wired command PED.
Follow the instructions of the receiver itself for learning the transmitters.
The functioning of the additional card depends on the setting of the parameter “Brake”:
Parameter “Brake” OFF-1: A normally open contact is available on the output for the activation of the electronic lock. The electronic lock can be acti-
vated by previously enabling the Water Hammer in opening (parameter Water Hammer OP).
Parameter “Brake” 2-3: A contact is available on the output for the activation of an external brake.
9 RESET of the control board (Menu C - Reset)
12 Auxiliary output (this output is available only with the additional card R1)
ELECTRICAL LOCK,
MOTOR BRAKE
Connection
with the
control unit

ITA ENG FRA ESP DEU POR 11 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
9 Tips for a successful installation
9.1 High speed movements
PROBLEM SOLUTION
 The motor stops for the effort during the movements
 It is easy to stop the automation during the movements
counteracting the movement
 The gate moves slowly despite having set an high speed
 Raise the torque supplied to the motor until problem is solved
High Torque OP, High Torque OP
 Lower the speed of the motor until problem is solved
High Speed OP, High Speed CL
 The motor stops and the control unit shows FAULT on the
display or 10 seconds of fast blinking
 Lower the torque supplied to the motor until problem is solved High Tor-
que OP, High Torque OP
 Lower the speed of the motor until problem is solved
High Speed OP, High Speed CL
9.1 Low speed movements (slowing down)
PROBLEM SOLUTION
 The motor stops for the effort during the movements
 It is easy to stop the automation during the movements
counteracting the movement
 The gate moves slowly despite having set an high speed
 Raise the torque supplied to the motor until problem is solved
Low Torque OP, Low Torque CL
 Lower the speed of the motor until problem is solved
Low Speed OP, Low Speed CL
9.3 Correct working
The correct setting of parameter is when you are not able to stop the automation when trying counteracting the movement.
The use of safety devices is absolutely necessary to ensure the safety of the automation.

ITA ENG FRA ESP DEU POR 12 / 12
6-1622595 rev.06 13/01/2017
Compatible from firmware version CSMAM02
WARNING AND ADVICES
Avoid putting the connection cables of buttons, security devices and inputs close to those of the power supply of the control unit and of the motor. Some
parts of the control unit are subject to dangerous voltage. The control unit must be installed and programmed only by qualified professionals. Always use
a device that ensures the disconnection of all poles of the control unit’s power supply .
This device can be a switch (connected directly to the power supply terminals) with a contact’s minimum distance of 3 mm for each pole, or it can be a
device connected to the power network.
For connecting the card and the motors we recommend to use cables with double isolation as in compliance to the laws in force; the minimum cross
section of the single conductor must not be less than 1,5 mm² and not more than 2.5mm².
TECHNICAL FEATURES - CT INVERTER AM
Power supply 230 Vac +15%, -15% ; 50Hz
Photocells power supply 24 Vdc 3W MAX
Accessories power supply 24Vac 3W MAX
Motor output 230Vac 1,5KW (current limited to 10A) MAX cos > 0.8
Flashing light output 230 Vac 60W MAX for fixed light, without self-blinking.
Courtesy light output 230Vac 100W MAX
Auxiliary output (only with card R1). Clean contact out-
put NOT supplied. 24Vac 0.5A MAX (12W MAX)
ALLMATIC S.r.l
32020 Lentiai - Belluno – Italy
Via dell’Artigiano, n°1 – Z.A.
Tel. [phone] – 751163 r.a. Fax [phone]
http://www.allmatic.com - E-mail: [email protected]
GUARANTEE - In compliance with legislation, the manufacturer’s guarantee is valid from the date stamped on the product and is restricted to the re-
pair or free replacement of the parts accepted by the manufacturer as being defective due to poor quality materials or manufacturing defects. The
guarantee does not cover damage or defects caused by external agents, faulty maintenance, overloading, natural wear and tear, choice of incorrect
product, assembly errors, or any other cause not imputable to the manufacturer. Products that have been misused will not be guaranteed or repaired.
Printed specifications are only indicative. The manufacturer does not accept any responsibility for range reductions or malfunctions caused by environ-
mental interference. The manufacturer’s responsibility for damage caused to persons resulting from accidents of any nature caused by our defective
products, are only those responsibilities that come under Italian law.
