Allseating FOSTER Sleeper Installation instructions

Folding Back Seat
(Upholstered/Wood/Foam)
Upper Seat
(Upholstered/Wood/Foam)
Lower Seat
(Upholstered/Wood/Foam)
Side Panel Mechanism
(Wood / Foam) (Steel )
For material recycling information please refer to the Allseating End of Life Recovery
and List of Recycling Facilities, which is available at www.allseating.com
Disassembly Instructions
FOSTER Sleeper
Document: CAM-324
Revision: 01
Date: July 17, 2015
These disassembly instructions are also applicable to Foster Sleeper Wide.

Disassembly Instructions
FOSTER Sleeper
Document: CAM-324
Revision: 01
Date: July 17, 2015
Tools: #2 #3 Phillips Head, Rubber Mallet or Hammer, Allen Key
Skill Set: Good manual dexterity
Estimated Time: 15min per chair
Lower Seat –4min.
Flip the chair on its side so the bottom is visible. Pull out the lower seat. Locate the 2 fasteners
attached to the “top positioed at the ed of the slidig echais ad ufaste. Reoe
the “top. Pull the loer seat outards to reoe fro the frae.
Upper Seat –4min
Flip the chair on its side so the bottom is visible. Pull the upper seat outwards and position it an
agle approiatel degree. Locate the 2 fasteers attached to the “top positioed at the
ed of the slidig echais ad ufaste. Reoe the “top. Pull the upper seat outards to
remove from the frame.
Folding Back Seat- 4min
Flip the chair on its side so the bottom is visible. Unzip the upholstery zipper located at the
bottom of the folding back seat. Locate 2 fasteners attached to the mechanism located
underneath the folding back seat cover and unfasten. Pull folding back seat upwards to remove
from frame.
Side Panel- 3min
Flip the chair on its side so the bottom is visible. Locate 4 fasteners attached on each side of the
side panel and unfasten. Pull the side panels from the mechanism.
