Allseating RAINBOW Installation instructions

These disassembly instructions are also applicable to TWIST Side Chair.
Back
(Foam/Plywood)
Arm
(Plastic)
Seat
(Foam/Plywood)
Frame
(Steel )
For material recycling information please refer to the End of Life Recovery Matrix
and List of Recycling Facilities, which is available at www.allseating.com.
Disassembly Instructions
RAINBOW
Document: CAM-311
Revision: 01
Date: June 7, 2012

Disassembly Instructions
RAINBOW
Document: CAM-311
Revision: 01
Date: June 7, 2012
These disassembly instructions are also applicable to TWIST Side Chair.
Tools: #2 #3 Phillips head, Hammer or
Rubber mallet, Pliers, Box cutter.
Skill Set: Good manual dexterity.
Estimated Time: 10min per chair.
Steps:
1. Armrest - 2min
With a rubber mallet or hammer, knock the underside of the arm rest. Continue to knock until
the arm rest is free from the chair frame. This process may require some force. Flip the chair
to the opposing side and repeat the process.
2. Seat - 3min
Turn the chair upside down so the bottom is visible. Locate the four fasteners located on the
underside of the seat pan and unfasten. Remove the seat panel from the chair frame.
3. Back Rest - 4min
In these chairs, the fasteners may be concealed between the back rest and back panel. In this
event, carefully insert the tip of screwdriver in between the back panel and back rest. Push
down on the handle of the screwdriver while also applying pressure into the back panel and
back rest to pry both apart. Continue to apply pressure in this way until the back panel is free
from the back rest. Once the fasteners are sufficiently exposed, remove the back rest by
unscrewing fasteners.
4. Feet Glides - 1min
Once both the seat and back are removed from the frame, re-position the chair upside down to
access glides. With pliers, firmly grasp the glide and wiggle upward until free. Repeat process
for all four feet.
