Allseating FOSTER Recliner Wide Installation instructions

(Upholstered /Foam /Wood)
Relax Cables
(Fabric / Steel ) SEAT
For material recycling information please refer to the Allseating End of Life Recovery
and List of Recycling Facilities, which is available at www.allseating.com
(Wood / Foam)
Back Rest
Disassembly Instructions
FOSTER Recliner
Document: CAM-323
Revision: 01
Date: July 17, 2015
(Wood / Foam)
Side Panels
Mechanism
( Steel )
Large Foot Rest
These disassembly instructions are also applicable to Foster Recliner Wide.
(Wood / Foam)
Small Foot Rest

Disassembly Instructions
FOSTER Recliner
Document: CAM-323
Revision: 01
Date: July 17, 2015
Tools: #2 #3 Phillips Head, Rubber Mallet or Hammer, Allen Key
Skill Set: Good manual dexterity
Estimated Time: 15min per chair
Back Rest- 3min
Pull the relax ales loated o the side of the relier. Loate the laps positioed
underneath the back rest and disengage. Pull back rest upward to remove from the frame.
Seat –4min
Flip the chair on its side so the bottom is visible. Locate 4 fasteners located underneath the seat
and unfasten. Pull the seat outwards to remove from the frame.
Side Panels- 4min
Flip the chair on its side so the bottom is visible. Locate 6 fasteners attached to the side panel
and unfasten. Pull the side panel outward to remove from the mechanism chassis. (Total 12
fasteners, 6 fasteners on each side panel)
Large Footrest –2min
Turn the chair on its side so the bottom is visible. Locate 4 multi-screws attached to the large
footrest and unfasten. Pull the large footrest outwards to remove from the mechanism.
Small Footrest –2min
Turn the chair on its side so the bottom is visible. Locate 4 multi-screws attached to the small
footrest and unfasten. Pull the small footrest outwards to remove from the mechanism.
