Allseating FLUID Installation instructions

Back
(Plastic/Mesh)
Arm
(Plastic/Steel )
Seat
(Plastic/Mesh or
Foam/Plywood)
Mechanism
(Steel ) Cylinder
(Steel )
Foot Rest
(Steel )
Base
Caster (Plastic or Aluminum)
(Plastic)
For material recycling information please refer to the End of Life Recovery Matrix
and List of Recycling Facilities, which is available at www.allseating.com.
Disassembly Instructions
FLUID
Document: CAM-306
Revision: 01
Date: June 7, 2012

Disassembly Instructions
FLUID
Document: CAM-306
Revision: 01
Date: June 7, 2012
Tools: #2 #3 Phillips Head, Rubber Mallet or Hammer, Allen Key
Skill Set: Good manual dexterity.
Estimated Time: 16min per chair.
Steps:
1. Armrest - 2min
Turn the chair upside down, so the bottom is visible. Locate the four fasteners locate on the
underside of the plastic seat frame and unfasten. If the chair is with width adjustable option,
loose the arm knob located underside of the plastic seat frame and remove the arm rest.
Remove the width adjustable bracket by unfastening screws located underside of the plastic
seat frame. Flip the chair to the opposing side and repeat the process.
2. Arm Cap - 1min
Turn the arm upside down so the bottom is visible. Locate the two fasteners and unfasten.
Remove the arm cap from the arm.
3. Back Bar - 1min
Locate the three fasteners located on the underside of plastic seat frame and unfasten.
Remove the backrest and back bar from the chair.
4. Back Rest - 2min
Separate the back rest from the back frame by unfastening four screws. Screws are visible on
the back frame, locate and unfasten.
5. Casters - 2min
Lay chair on back. Grasp and pull to remove casters from the base.
6. Base - 1min
Hold the base legs firmly and strike the bottom of cylinder with a hammer until base comes
loose, remove base.
7. Cylinder - 1min
Remove cylinder by placing one hand on can of cylinder and hit the bottom of the mechanism
with hammer until cylinder separates from mechanism.

Disassembly Instructions
FLUID
Document: CAM-306
Revision: 01
Date: June 7, 2012
8. Foot Rest - 1min
Remove footrest by placing one hand on cylinder and the other on footrest. Rotate the footrest
in a direction to loose. Read the instruction on footrest for direction.
9. Mechanism - 2min
Turn the chair upside down so the bottom is visible. Locate the four fasteners located on the
underside of the plastic seat frame or seat slider and unfasten. Remove mechanism from the
plastic seat frame or seat slider.
10. Seat - 2min
Mesh Seat: Turn the chair upside down so the bottom is visible. Locate the four fasteners
located on the underside of the plastic seat frame and unfasten. Remove seat from plastic
seat frame.
Upholstered Seat: Turn the chair upside down so the bottom is visible. Locate the four
fasteners located on the underside of the seat slider or seat pan and unfasten. Remove seat
from the mechanism or seat slider.
11. Seat Slider - 1min
Turn the chair upside down so the bottom is visible. Locate the four fasteners located on the
underside of the plastic seat frame and unfasten. Remove seat slider from plastic seat frame.
