Alto-Shaam HALO HEAT EU2SYS-72/P User manual

ITEM NO. _______________________
The display case is constructed of 18 gauge, non-magnetic stainless steel. A curved, tempered glass front encloses the
display case and can be lifted to a 90 degree angle for easy cleaning. Removable, sliding glass doors on the operator side
are included. Sliding door tracks have a “clean sweep” cutout allowing for easy cleaning and crumb removal. Framed
end clear glass with rubber gasket material protects glass edges from chipping and breakage. The base is divided into
two (2) individually managed heat zones with each zone controlled by a separate thermostat with a range of 1 through 10
and heat-on indicator light. Overhead lights are controlled by ON/OFF switches in two (2) light
zones. Two (2) 125V plug outlets are available as an option on 120/208-240V units only.
■■EU2SYS-72 - 72" (1829mm) length, with BU2 base
■■EU2SYS-72/P - 72" (1829mm) length, with BU2 base, 71-5/16" (1811mm) self-service opening across full length of case front
■■EU2SYS-72/PL - 72" (1829mm) length, with BU2 base, 23-3/4" (603mm) self-service opening on left side of case front
■■EU2SYS-72/PR - 72" (1829mm) length, with BU2 base, 23-3/4" (603mm) self-service opening on right side of case front
W164 N9221 Water Street • P. . Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PH NE: 262.251.3800 800.558.8744 U.S.A./CANADA FAX: [phone].329.8744 U.S.A. NLY
www.alto-shaam.com
P R I N T E D I N U .S.A.D U E T O O N G O I N G P R O D U C T D E V E L O P E N T , S P E C I F I C AT I O N S A R E S U B J E C T TO C H A N G E W I T H O U T N O T I C E . #69A - 03/08
EU2SYS-72 SERIES
HEATED DISPLAY SYSTEMS
FACTORY INSTALLED O TIONS
●The system base is not sold as a separate
item. Order the full EU2SYS model to
receive the base.
●Panel Color Choices
➥Specify color choice:
■■Black, standard
■■Stainless Steel, optional
■■Custom Color, optional
● HALO HEAT … a controlled, uniform heat source that gently
holds and surrounds food for better appearance, taste, and longer
holding life.
● Holds and displays hot food fresh and moist for hours —
without adding water.
● Expandable system to meet your specific requirements.
● HOT DIS LAY CASE
— Curved glass styling.
— Displays hot food without condensation on glass.
— Tempered sliding glass doors reflect heat back into the products
and mirror the display to enhance merchandising effect.
— Holds a full range of standard (gastronorm) pan sizes, full-size
or half-size sheet pans.
— Standard stainless steel front and black painted end panels.
— Thermostatically controlled heat source radiates from the base
of the display case in multiple heat zones.
— Overhead light zones with shatterproof coated bulbs.
●DECORATOR BASE
— Designed to accommodate your choice of equipment (750-TH-II,
750-TH-II/D, 750-S, 500-2D) or optional shelf.
— Stainless steel, distinctively framed in black as standard, and
brushed stainless or custom color as alternate choices.
●SELF-SERVICE H T DISPLAY
— Customer self-service opening is available on right side, left side,
or across the full length of case.
— Front mounted heat-guard provides customer protection.
EU2SYS-72
FRONT VIEW SHOWN WITH
OPTIONAL CASTERS

O P T I O N S & A C C E S S O R I E S
■■BUTTING KIT 5008523
■■CARVING STATI N 5001874
CASTERS, PLATE
■■5" (127mm), RIGID (2 REQUIRED)CS-2025
■■5" (127mm), SWIVEL WITH BRAKE (4 REQUIRED)CS-2026
GAUGE, INTERI R AMBIENT TEMP.
■■FULL-SERVICE & SELF-SERVICE FULL CASES 5004182
■■SELF-SERVICE LEFT-SIDE OF CASES 5004183
■■SELF-SERVICE RIGHT-SIDE OF CASES 5004184
■■GLASS, TEM ERED END ANE, BRONZE KIT 5001143
■■INDEPENDENT ELECTRICAL UTLET 5001781
■■LOW ROFILE BASE
OVERALL HEIGHT REDUCED BY 4-3/ 4" (121mm) 304342
PANEL KIT, C UNTER T P
■■BRUSHED STAINLESS STEEL 5001282
■■CUST M C L R P152
PANEL KIT, SYSTEM
■■BRUSHED STAINLESS STEEL 5001289
■■CUST M C L R 5005790
■■PAN INSERT, SELF-SERVICE 4" (102mm) DEE 1001991
PLATF RM SCALE
■■LEFT-HAND 5001308
■■RIGHT-HAND 5001307
SHEET PAN DIVIDER BAR PACKAGE
■■FULL-SERVICE & SELF-SERVICE FULL CASES 5002803
■■SELF-SERVICE LEFT-SIDE OR RIGHT-SIDE OF CASES 5002804
■■SHELF, STAINLESS STEEL 5005786
■■TEM ERATURE ROBE 5004917
■■THERMOSTAT GUARD COVER LATE 5007660
■■WORK SHELF WITH GRAVY LANE 5005639
W164 N9221 Water Street • P. . Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PH NE: 262.251.3800 800.558.8744 U.S.A./CANADA FAX: [phone].329.8744 U.S.A. NLY
www.alto-shaam.com
#69A - 03/08 D U E T O O N G O I N G P R O D U C T D E V E L O P E N T , S P E C I F I C AT I O N S A R E S U B J E C T TO C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A.
WEIGHT(EST.)
M DEL NET SHIP
EU2SYS-72 992 lb (450 kg) 1038 lb (471 kg)
EU2SYS-72/P 1003 lb (455 kg) 1053 lb (478 kg)
EU2SYS-72/PL/PR 1003 lb (455 kg) 1053 lb (478 kg)
CRATED DIMENSI NS: HXWXD
EU2SYS-72: NOT YET AVAILABLE
EU2SYS-72
EU2SYS Profile
EU2SYS-72 SERIES
HEATED DI SPLAY SYSTEMS
D I M E N S I O N S (HXWXD )
EXTERIOR, WITH BASE:
58-3/16" x 72" x 44-5/16" (1477mm x 1829mm x 1125mm)
WELL DIMENSIONS (WXLXD):
27-3/16" x 69-5/16" x 4-1/2" (690mm x 1760mm x 114mm)
48" (1219mm)
ELECTRICAL OUTLET
26-1/2" (673mm)
31-5/8" (804mm)
58-3/16" (1477mm)
ELECTRICAL PANEL
5-1/2"
(140mm)
72" (1829mm)
ELECTRICAL PANEL
26-1/2" (673mm)31-5/8" (804mm)
5-1/2"
(140mm)
Rigid
Caster
Swivel
Caster
Swivel
Caster
96" (2438mm)
ELECTRICAL PANEL
26-1/2" (673mm)
31-5/8" (804mm)
58-3/16" (1477mm)
5-1/2"
(140mm)
32-1/2" (824mm)
31-5/8" (804mm)
5-1/2"
(140mm)
44-5/16" (1125mm)
26-1/4" (666mm)
OPENING WIDTH
28-5/16" (719mm)
OPENING HEIGHT
58-3/16" (1477mm)
58-3/16" (1477mm)
Swivel
Caster
26-1/4" (666mm)
OPENING WIDTH
Swivel
Caster
26-1/4" (666mm)
OPENING WIDTH
Rigid
Caster
Swivel
Caster Swivel
Caster
26-1/4" (666mm)
OPENING WIDTH
26-1/4" (666mm)
OPENING WIDTH
26-1/4" (666mm)
OPENING WIDTH
28-5/16" (719mm)
OPENING HEIGHT
(Shown with optional shelf)
(Shown with optional shelf) (Shown with optional shelf)
(Shown with optional shelf) (Shown with optional shelf) (Shown with optional shelf)
13-5/8"
(346mm)
OPENING
13-5/8"
(346mm)
OPENING
28-5/16" (719mm)
OPENING HEIGHT
13-5/8"
(346mm)
OPENING
13-5/8"
(346mm)
OPENING
ELECTRICAL
OUTLET
ELECTRICAL
OUTLET
28-5/16" (719mm)
OPENING HEIGHT
13-5/8"
(346mm)
OPENING
13-5/8"
(346mm)
OPENING
48" (1219mm)
ELECTRICAL OUTLET
26-1/2" (673mm)
31-5/8" (804mm)
58-3/16" (1477mm)
ELECTRICAL PANEL
5-1/2"
(140mm)
72" (1829mm)
ELECTRICAL PANEL
26-1/2" (673mm)31-5/8" (804mm)
5-1/2"
(140mm)
Rigid
Caster
Swivel
Caster
Swivel
Caster
96" (2438mm)
ELECTRICAL PANEL
26-1/2" (673mm)
31-5/8" (804mm)
58-3/16" (1477mm)
5-1/2"
(140mm)
32-1/2" (824mm)
31-5/8" (804mm)
5-1/2"
(140mm)
44-5/16" (1125mm)
26-1/4" (666mm)
OPENING WIDTH
28-5/16" (719mm)
OPENING HEIGHT
58-3/16" (1477mm)
58-3/16" (1477mm)
Swivel
Caster
26-1/4" (666mm)
OPENING WIDTH
Swivel
Caster
26-1/4" (666mm)
OPENING WIDTH
Rigid
Caster
Swivel
Caster Swivel
Caster
26-1/4" (666mm)
OPENING WIDTH
26-1/4" (666mm)
OPENING WIDTH
26-1/4" (666mm)
OPENING WIDTH
28-5/16" (719mm)
OPENING HEIGHT
(Shown with optional shelf)
(Shown with optional shelf) (Shown with optional shelf)
(Shown with optional shelf) (Shown with optional shelf) (Shown with optional shelf)
13-5/8"
(346mm)
OPENING
13-5/8"
(346mm)
OPENING
28-5/16" (719mm)
OPENING HEIGHT
13-5/8"
(346mm)
OPENING
13-5/8"
(346mm)
OPENING
ELECTRICAL
OUTLET
ELECTRICAL
OUTLET
28-5/16" (719mm)
OPENING HEIGHT
13-5/8"
(346mm)
OPENING
13-5/8"
(346mm)
OPENING
S P E C I F I C AT I O N S
●Ten (10) overhead lights with two (2) light zones.
●Two (2) base heat zones with two (2) adjustable thermostats with
a range of 1 through 10, and two (2) heat-on indicator lights.
●Three (3) tinted, reflective, tempered glass sliding doors on
operator side.
●One (1) 10" x 60" (254mm x 1524mm) operator-side work shelf.
●Self-serve model EU2SYS-72/P has a self-serve pan insert
26-7/16" x 69-3/16" x 2" (672mm x 1757mm x 51mm) and
includes three (3) Wire Pan Grids.
●Self-serve models EU2SYS-72/PL and EU2SYS-72/PR have self-
serve pan insert 21-5/8" x 26-7/16" x 2" (549mm x 672mm x 51mm)
and includes one (1) Wire Pan Grid.
E L E C T R I C A L
VOLTAGE PHASE CYCLE/HZ AMPS kW
120/208-240 (UL)1 50/60 18.75 4.5
at 208 1 50/60 19.0 4.6
at 240 1 50/60 19.0 4.6
230 (CE)1 50/60 18.3 4.2
230 1 50/60 18.4 4.2 BARE END, NO PLUG
BARE END, NO PLUG
PA N C O N F I G U R AT I O N *
PAN SIZE DIMENSIONS QTY.
FULL-SIZE & ONE-HIRD**: 12" X20" X2-1/2" (GN 1/1) 5
12" X6" X2-1/2" (GN 1/3) 5
HALF-SIZE & ONE-HIRD**: 12" X10" X2-1/2" (GN 1/2) 10
12" X6" X2-1/2" (GN1/3) 5
FULL-SIZE SHEE PANS: 18" X26" X1" 3
MAX. CAPACITY/VOLUME:80 lbs (36 kg)
50 qts (60 L)
* Pans are not included with display case.
** Will also accept 4" (100mm) deep pans.
INSTALLATION REQUIREMENTS
Display case must be installed level. The display case must
not be installed in any area where it may be affected by steam,
grease, dripping water, high temperatures, or any other
severely adverse conditions.
Do not install a heated display case near a cold air source such
as a freezer, air conditioning vents, or in any area where
outside air fluctuation can affect performance.
