Ambu aView 2 Advance User manual

3. User Interface
Time/Date
Live View
Archive
Login
Settings
Wi-Fi Symbol
Battery Life Indicator
Current
Procedure Folder
Image Adjustment
Record Video
Take Picture
Ambu®aView™2 Advance Gen 2
Quick Start Guide
1. INTENDED USE
2. SYSTEM PREPARATION
3. USER INTERFACE
NOTE: When you are using two visualisation devices
simultaneously, please note the following:
1. Connect the two visualisation devices to the monitor
as described previously.
2. Turn on the monitor as described previously.
3. The live images of both visualisation devices are
displayed, and
i.
The roman numeral in the upper corner of the live
images correspond with the visualisation device it is
coming from, with I being the visualisation device
plugged into the top connection port, II being the
connection port underneath and III being the
connection port at the bottom.
ii. To swap the positions of the live images, tap .
The Ambu®aView™2 Advance is a non-sterile, reusable monitor for
displaying live imaging data from compatible Ambu visualisation
devices.
Press the power button to turn on the
monitor. It takes approximately 20 seconds
for the system to fully load, however a live
image can be displayed aer just a few
seconds.
Connect the Ambu visualisation device to the
aView 2 Advance monitor, making sure that
the arrow on the cable connector lines up
with the white triangle on the connection port.
Ensure that a live image is displayed on the
monitor by pointing the distal end of the
visualisation device at an object.
Refer to IFU for
full information

Ambu Ltd.
Incubator 2
Alconbury Weald Enterprise Campus
Cambridgeshire
PE28 4XA
T: [phone]
ambu.co.uk
The recordings from the current procedure can be viewed and managed by tapping in the lower le corner. To access
past recordings at a later time, tap . For more information on how to manage recordings, see the Quick Guide for
Managing Recordings.
6. FILE MANAGEMENT
5. BATTERY STATUS
4. IMAGE ADJUSTMENT
Tap to open the Image Adjustment menu. Move the sliders to adjust the
colour, contrast, sharpness and brightness as desired.
Tap to rotate the live image by 180°. When image rotation is activated, an
inverted “R” appears in the upper right hand corner of the live image.
Tap to adjust Advanced Red Contrast.*
*This icon is shown only when ARC is enabled and the connected endoscope supports the function.
The battery symbol in the lower le corner of the monitor shows the battery level and the battery life remaining.
When battery level changes to orange and red, a notication with an enlarged battery icon will appear in the lower le corner.
The notication will remain visible when the battery turns red until manually closed.
NOTE: The remaining battery life depends, among other things, on the visualisation devices used and the image
adjustments. If these conditions change, the battery life adjusts accordingly.
The battery status is also indicated by the illuminated power button. If it ashes orange, the battery is low and the monitor
should be charged.
3:00 0:45 0:25
Green
Remaining
battery life
> 40 %
Orange
Remaining
battery life
< 40 %
Red
Remaining
battery life
< 20 %
The battery is
charging
