Amibot AG30 User manual

EN
Window cleaning robot
Instruction manual
AG30

EN
Instruction manual
Thank you for choosing AMIBOT! We hope you are fully satised
using your robot as part of your cleaning routine.
If you should encounter situations that have not been properly
addressed in this Instruction Manual or were to have any queries,
do not hesitate to contact us and a member of our Technical
Customer Service Department will be more than happy to answer
your questions.
For more information, you can visit the ocial AMIBOT website:
www.amibot.tech
We reserve the right to make technical alterations to the appliance
without prior notice with the objective of continually improving our
products and customer satisfaction.
Please carefully read all instructions in this manual before using this
appliance. AMIBOT will not be liable for damage due to incorrect use.

1
Contents
EN
Recommendations..........................................................3
Product overview............................................................4
Product contents..................................................................................... 4
Product diagram ..................................................................................... 5
Operating the robot........................................................... 6
Notes before use .................................................................................... 6
Connecting the appliance ...................................................................... 7
Installing the safety cord........................................................................ 8
Using the extension cord....................................................................... 9
Preparing and using the cleaning pads.............................................. 10
Starting the robot ................................................................................. 11
Pausing the robot ................................................................................. 13
Stopping the robot................................................................................ 13
Maintenance..................................................................14
Cleaning pads........................................................................................ 14
Fan .......................................................................................................... 14
Edge sensors ......................................................................................... 15
Continuous tracks............................................................................15
Indicator lights..............................................................16
Troubleshooting............................................................17
Table: Malfunctions and possible causes .......................................... 17
Warranty and after-sales service................................20
Technical specications ...............................................21

2
Contents
EN
Safety instructions and precautions ..........................22
Operating conditions............................................................................ 22
Recycling instructions ..................................................23

3
Recommendations
EN
• Do not use AMIBOT Glass on uneven surfaces, such as frosted,
textured, patterned or coated glass. AMIBOT will not be liable for
damage due to incorrect use of the robot on said surfaces.
• AMIBOT Glass is only appropriate for vertical, framed or framel-
ess glazed surfaces.
• Do not use AMIBOT Glass on a surface with frames less than
5mm thick.
• AMIBOT Glass can be used on a surface area of at least 50*70cm.
• Please ensure a clearance of at least 9cm between the glass and
any obstacles in the room (curtains or furniture).
• AMIBOT Glass can clean horizontally mounted glass or glass
mounted at an angle using the remote control. However, the de-
gree of the angle may aect the correct functioning of the appli-
ance. If this is the case, please ensure that someone is close to
the appliance in the event of a problem.
• Do not use AMIBOT Glass upside down.
• AMIBOT Glass is designed for routine cleaning. The appliance is
not intended to replace heavy-duty or rst-time cleaning.
• Do not use the appliance on damp or greasy windows.
• The appliance can be used to clean outside windows or windows
at a height if fastened with the safety rope, winds are calm and it
is not raining or snowing.
• Do not use the appliance on cracked glass.

4
Product overview
EN
Product contents
1
4
1. AMIBOT Glass
2. Cable and power adapter
3. Instruction manual
4. Safety rope
5. Remote control (batteries
included)
6. Two (2) yellow cleaning pads
and two (2) grey cleaning
pads
7. Extension cord
2 3
5 6 7

5
Product overview
EN
Product diagram
Robot
1. Speaker
2. Top indicator light
3. Handle
4. Power supply plug
5. Start/Pause button
6. Bottom indicator light
7. Edge sensors
8. Continuous tracks
9. Suction fan
10. Cleaning pads Velcro
fastening
Remote control
1. No use
2. No use
3. Direction control buttons
4. Start button
5. Cleaning mode Z
6. Cleaning mode N
7. Cleaning modes Z/N
8. Stop
9. Pause/Restart
1
2
3
4
5 6 7
8
9
10
1
5
8
2
3
4
6
7
9

6
Operating the appliance
EN
Notes before using AMIBOT Glass
• Please ensure AMIBOT Glass is plugged in while it is cleaning.
• AMIBOT Glass has a back-up battery that charges during use.
The back-up battery powers the robot if it becomes unplugged
or the electricity fails.
• Using the back-up battery: the back-up battery must be charged
for around 2h before using the robot for the rst time.
• If the glazed surface is dirty, clean a small area before placing the
AMIBOT Glass there.
• Do not use the appliance if it is not securely attached to the
window or if it shows visible signs of deterioration.
• To reduce the risk of electrical shock, do not place the appliance
near water or other liquids.
• Do not touch the power plug or the appliance with wet hands.
• Do not pull on the appliance's power cord to avoid causing
possible damage.
• Keep the power cord away from sources of heat.
• Do not use the appliance if the power cord or plug are damaged.
• WARNING: Only use the power cable supplied by the manufacturer
to charge the battery.
• The robot batteries must only be replaced by qualied persons.
• The remote control uses two non-rechargeable AAA RO3
batteries.
• If the remote control is not used for a long period of time, the
batteries must be replaced.

7
Operating the appliance
EN
Connecting the appliance
The power plug and adapter must only be used indoors.
Assembling the power adapter
1
2
3
1. Power cable
2. Power adapter
3. Power plug
Connecting the power supply to the robot
Plug the power plug into the robot. Screw the power plug in a
clockwise direction.

8
Operating the appliance
EN
Installing the safety cord
A
B
C
A. Safety cord
B. Robot handle (End 1 of cord)
C. Karabiner (End 2 of cord)
Assembling the safety cord
The safety cord must be fastened to your appliance if you wish to
clean an outside window or a window at a height.
Fasten end 1 of the safety cord around the robot handle (B).
Fasten end 2 of the safety cord to a secure place (C) to stop the robot
from falling.
NOTE: The robot could fall due to a power outage of more than 30min (AMIBOT
Glass back-up battery life).
1 2

9
Operating the appliance
EN
Using the extension cord (4.5m)
If the power cable length restricts AMIBOT Glass's movements, the
extension cord can be used.
A B
A. End A of the extension cord
A. End B of the extension cord
Assembling the extension cord
A
B
B
A
1. Connect the power adapter and end B
of the extension cord.
2. Connect the robot's power plug and
end A of the extension cord.
2 1

10
Operating the appliance
EN
Preparing and using the cleaning pads
Cleaning pad types
1. Grey cleaning pad
2. Yellow cleaning pad
1 2
Grey microbre cleaning pad
The grey microbre cleaning pad is used for regular maintenance
cleaning of surfaces where dust accumulation is not signicant. This
cleaning pad is used with a cleaning product suitable for cleaning
glazed surfaces.
Yellow cleaning pad
The yellow cleaning pad is suitable for windows with a signicant
amount of dust. Use a dry cleaning pad to remove the maximum
amount of dirt.
NOTE:
• For particularly dirty surfaces, AMIBOT recommends using the yellow cleaning
pad before using the grey cleaning pad with window cleaner.
• Ensure that the cleaning pads do not cover the detection sensors at the edge of
the robot or the continuous tracks.

11
Operating the appliance
EN
Starting the robot
Product diagram
1
2
3
1. Robot Start/Pause button
2. Remote control Start button
3. Pause/Restart button
Plug the robot into the mains supply
The robot is charged when the indicator light is green.
NOTE: Do not unplug in the appliance while in use because it could fall.
8 cm
2 sec

Turn the robot on
Press the Start/Pause button (1) found
on the top of the robot for 2 seconds.
The blue indicator will illuminate and
AMIBOT'S suction fan will start. The robot
can be placed on the glazed surface.
Place the robot on the window
Place AMIBOT on the window at least
8cm from the window edges or any other
obstacle.

12
Operating the appliance
EN
Choose the cleaning mode
Automatic: Before starting its cleaning cycle, AMIBOT scans the
perimeter to analyse the shape of the glazed surface and dene its
cleaning route.
Cleaning modes available: Choose from three cleaning modes
using the remote control:
AMIBOT Glass can be started by:
• Pressing the Start/Pause (1)
button found on the top of
the robot.
• Pressing the Start button on
the remote control (2).
Start the robot
1. N Mode: is suitable for particularly long surfaces.
2. Z Mode: is suitable for particularly wide surfaces.
3. Z/N Mode: AMIBOT automatically alternates between Z and N
modes.
N Z

13
Operating the appliance
EN
Pause
To stop AMIBOT, press the Start/Pause button on the robot (1) or the
Pause/Restart button on the remote control (2).
Stop
When AMIBOT stops its cleaning cycle, it returns to the place it
started and beeps.
Remove the robot from the glazed surface
Take hold of the robot's handle and press the Start/Pause button (1)
for around 2 seconds so the suction fan stops. AMIBOT can then be
removed from the window safely.
Remove the safety cord
If the safety cord was installed beforehand, it can now be removed.
Switch o
Before performing maintenance,
switch o and unplug the
appliance, as a security measure.

14
Maintenance
EN
Cleaning pads
Remove the AMIBOT's cleaning
pad and rinse with clean water
and your choice of cleaning
product. Rub and rinse with
plenty of water.
AMIBOT grey and yellow cleaning
pads are machine washable at
30° maximum.
Allow cleaning pads to dry before reusing them on your AMIBOT.
Fan
Turn the AMIBOT over and wipe
any debris from the fan with a
dry cloth so the same level of
xation is maintained.

15
Maintenance
EN
Edge sensors
Turn the AMIBOT over and clean
the four edge sensors using
a dry cloth to maintain their
eectiveness.
Continuous tracks
Use a dry cloth to clean the
continuous tracks.

16
Indicator lights
EN
Robot status Indicator
Continuous BLUE AMIBOT is ready to be attached to the glazed
surface and start its cleaning cycle.
Flashes RED AMIBOT has encountered a problem.
Continuous GREEN Back-up battery is fully charged and AMIBOT is
ready to use.
Continuous ORANGE AMIBOT back-up battery is charging.

17
Troubleshooting
EN
Please contact AMIBOT technical department in the following cases:
• If the appliance has been dropped, damaged or come into contact
with water.
• If the power cord is damaged.
• If the back-up battery is defective.
Table: Malfunctions and possible causes
Malfunction Possible causes Solutions
The robot does not
move correctly, it skids
on the glazed surface.
1. The window is too
dirty or damp.
2. The cleaning pad is
too dirty or damp.
1. Dry the window.
2. Change the cleaning
pad.
3. Clean the continuous
tracks.
The robot stops and
the indicator ashes
RED.
The robot does not have
enough suction.
1. Check that the cleaning
pad is correctly
attached to the Velcro.
2. Check that the window
does not have any
faults.
3. The window frames
may be uneven,
however the robot can
be controlled using the
remote control.

18
Troubleshooting
EN
The robot does not
work correctly after
being switched on.
There is a problem
with the edge detection
sensors.
1. Check that the cleaning
pad is correctly
attached to the Velcro
and does not overlap
the edge sensors.
2. Contact the AMIBOT
after-sales service if
the edge sensors do
not work correctly.
The indicator ashes
RED and the robot
beeps.
The robot is not
connected to the power
adapter correctly.
Check that the robot is
connected to the power
cable or the extension
cord.
Indicators ash RED
and BLUE successively.
There is a problem with
the motherboard.
Contact AMIBOT after-sales
department.
The remote control
does not work.
1. The batteries are
not installed or need
to be replaced.
2. The remote control
is broken.
1. Change the batteries.
2. Replace the remote
control for a new one.
The robot freezes
at the edge of the
window.
1. There is a problem
with the edge
sensors.
2. The frames are less
than 5mm thick.
1. Switch the robot o
and then place it back
on the window.
2. The robot has not
adapted to the frame
of the surface.
