Amico Gamma LED Series Manual

Operating and Maintenance Instructions
Gamma LED Exam Light
Floorstand
www.amico.com

Contents
Introduction 3
Symbols Used in This Manual 4
Safety Instructions 5-7
Scope of Delivery 8
Installing the Floorstand 9-10
Operation 11
Disinfecting, Cleaning and Sterilization 12
Maintenance 13
Notes on the Arm Systems 14
Spare Parts 15
Troubleshooting 15
Disassembly 15
Technical Data of the Lighthead 16
Technical Data of the Arm System 17
Warranty 18

www.amico.com 3
Introduction
Thank you for your purchase of the Gamma LED Light.
This installation manual gives you instructions on how to install the Gamma LED Light for the oorstand version of
your purchase. For instructions on operation, maintenance and further description of the product please refer to the
Operation and Maintenance Manual included.
Please read the following instructions very carefully and follow the safety instructions and requirements.

4Amico Lighting Solutions
Can lead to death or serious injury.
Can lead to injury.
Class II Electrical Equipment
Comply with operating instructions
CE conformity mark
Protective conductor
Neutral conductor/return conductor for the electrical current
Live conductor
Storage humidity
Storage temperature
Disposal
Manufacturer
Do not Lean
Read Manual
Do not Step On
Symbols Used in This Manual
The warning symbols indicate all instructions that are important for safety. Failure to comply with them can lead
to injury, damage to the luminaire or the equipment. In combination with the following signal words the warning
symbols means:
Trademarks: All trade names mentioned in these instructions are the exclusive property of the relevant manufacturers.

www.amico.com 5
Saftey Instructions
Intended use
The Gamma LED Light is intended to provide illumination for diagnosis or examination. It is to be used near the
patient to support treatments, which pose no risk to the patient in the event of any interruption caused by light
failure. It is meant for continuous operation.
User Proles
Medical sta
All persons with medical training who work in the field for which they were trained.
Cleaning sta
All persons familiar with national and workplace hygiene requirements.
Electricians
All persons with training in electronics and electrical technology who are familiar with the relevant standards and
regulations.
Certied installers
Persons qualified by training, experience and knowledge of the regulations to install and remove the equipment.
Safety Instructions
Please note that certain duties must be carried out by people with the appropriate corresponding qualifications. The
instructions are part of the product and must be kept so they are accessible for all subsequent users:
• These instructions are for the Amico Lights Gamma Series LED lights. This includes ceiling mount, rail mount
and wall mount equipment.
• Please carefully read these operating instructions before using the equipment. It will help protect you and
others from potential injuries that may occur.
• All work on the light (including repairs) must be done by qualified electricians only. The light must be installed
by a certified installer.
• The light must not be modified or manipulated. Use in any other manner than with the original parts may
result in different specifications and life-threatening dangers.
• Only persons with medical training are permitted to operate the equipment.
• Only trained cleaning personnel are permitted to clean the equipment.
• The light must not be used in an explosive environment. The power supply to the light is a potential ignition
source.
• The light must be used in dry rooms only.
• The light must not be left on unattended.
• Keep all flammable equipment and objects away from the lighthead and cone during use.
• Do not use a damaged light. Defective cables can also be a potential hazard. Do not position cables near heat
sources or sharp edges.
• Eye damage. Never look directly at the light cone.
• Replace damaged lenses before using the light again.
• The light must be connected to the mains with a protective earth to prevent electric shock.
• Never apply additional loads to the light head and spring arm.

6Amico Lighting Solutions
Saftey Instructions
• Do not cover the light with a cloth or similar material while operating.
• If problems are encountered that have not been addressed in these operating instructions, please contact
your supplier in the interest of your own safety.
• Do not place the fixture such that it is difficult to remove the power cord.
Please keep these operating instructions in a secured place near the device. This ensures easy access
to safety instructions and important information should the need arise.
• The inspections and maintenance work, as described on page 13, should only be done by trained service
technicians. Anyone else is not authorized to perform inspections and maintenance work.
• The adjustment work should only be carried out by a hospital technician or someone with similar
qualifications. Anyone else is not authorized to perform adjustment work.
• This equipment has been built accordingly and is operationally safe. Nonetheless, it may still present some
danger, especially if not used according to the operating instructions as specified in this manual.
• Modifications are never to be made for any reason. This is to ensure safety for all persons involved. Any
modifications made to the system void the warranty.
• The contents of the operating instructions are subjected to change without notice.
Specic tting instructions for the Gamma LED Floorstand
• Mounting material not included in delivery.
• The floorstand may be fitted to wall only with a concrete strength of B25 (C20/25) or greater.
• Contact with reinforcing elements of the solid slab ceiling must be avoided. In case of doubt, a structural
engineer should control the mounting on the respective surface.
• The drill holes should be made by a skilled person in accordance with the drill hole tolerances recommended
by the manufacturer of the fastening anchors.
• The screws must be carefully tightened using a torque wrench in accordance with the recommendations of
the manufacturer of the fastening anchors.
Gamma LED Floorstand
• Mounting material not included in delivery.
• The necessary technical information can be found in the installation section of this manual.

www.amico.com 7
Saftey Instructions
Warning Levels
DANGER
Indication of hazards that can lead to death or serious injury if measures are disregarded.
WARNING
Indication of hazards that can lead to injury if measures are disregarded.
CAUTION
Indication of hazards that can lead to damage to property if measures are disregarded.
EXPLOSION HAZARD
The above is an explosion hazard warning symbol. Non-compliance with this symbol may result in damages or injuries
due to explosion.
ELECTRIC SHOCK
The above is an electric shock warning symbol. Non-compliance with this symbol may result in damages or injuries
due to electric shock.

8Amico Lighting Solutions
Scope of Delivery
Floorstand
Included
1 x Arm with a Lighthead
1 x 3" Screw
1 x Floor Stand Base
1 x Post with an Adaptor and a Cable holder
1 x Counter Weight
6 x Casters

www.amico.com 9
Installing the Floorstand
Installing the Floorstand
DANGER
Mounting by qualified personnel
• Mounting must be done by qualified personnel only. Lack of appropriate knowledge could be life-threatening.
DANGER
Life-threatening danger from falling luminaire.
• The ceiling must be made of solid concrete to guarantee a secure hold.
DANGER
Electric shocks are life-threatening.
• The electrical mains must be isolated from the by an external all-pole switch.
DANGER
Risk of injury from falling parts.
• Mounting must be performed by two people.
DANGER
Use protective equipment in line with tool manufacturer’s instructions.

10 Amico Lighting Solutions
Installing the Floorstand
WARNING
Danger of injury from unfolding spring arm.
1. Put the counter weight to the Floorstand base.
2. On the back side of the roll stand base, insert six (6) casters.
3. Insert the oor stand post in to
the counter weight, all the way
until the bottom, and secure the
bottom with a three inch (3) screw.
4. Insert the arm and secure the arm
and the post with the knob.

www.amico.com 11
Operation
Gamma LED Wall Mount
WARNING
Danger of death from electric shock
• Do not plug in a damaged power cable
• Replace damaged power cable before using light again
• The mains voltage and frequency must match the data on the name plate
• Connect to a mains connection with a protective earth only
NOTICE
• Wind the power cable to the cable retainers when it is not being used.
1. Plug in cable
2. Install the cable to the mains supply.
3. Switch on key pad.
Gamma LED Wall mount
Switch on the Light from control pad at lighthead.
Decrease Brightness Increase Brightness
Power (On/Off )
1
1

12 Amico Lighting Solutions
Disinfecting, Cleaning and Sterilization
NOTICE:
Damage due to improper cleaning authorized to perform inspections and maintenance work.
• Do not use alcohol, solvent or cleaning agents containing chlorine or scouring agents.
• Damage to lens by concentrated disinfectant or solvent.
• Follow the manufacturers recommended mixing ratio.
• Use of incorrect cloths may scratch lens.
NOTICE:
A dirty lens will reduce the illuminating power.
• Clean lens regularly
• Spray and wipe disinfection is permitted.
• Clean the lens with a leather cloth soaked in cleaner
• Spray disinfectant in horizontal position.
NOTICE:
The external components of the light can be disinfected with the following diluted products:
• Lysoformin
• Dismozon
• Hexaquart plus
• Sagrotan – fast disinfecting cleaner
• Tuffie5
NOTICE:
The local government regulations for disinfection must also be observed in addition to these instructions.

www.amico.com 13
Maintenance
DANGER
Electric shocks are life-threatening.
• Remove the connector from the power supply and put the switch in the “OFF” position.
• The connector cable must be checked for damage at least once per year.
NOTE: Maintenance and repairs must only be carried out by qualied electricians.
NOTE: Gamma is not serviceable or repairable by anyone other than the manufacturer.
NOTE: Locking mechanism should be provided by contractor as means of isolation.

14 Amico Lighting Solutions
Notes on the Arm Systems
Selection of Fastening Material
We recommend the use of (not included in the delivery) counter-plates for fastening to drywall.
Cleaning and Disinfection
DANGER
Electric shocks are life-threatening.
• The devices can conduct electricity and must be handled with care during cleaning and disinfection.
• If there is a power plug remove it from the socket.
• Do not use spraying methods for cleaning and/or disinfection.
• Do not spray liquid into the openings of electrical power sockets, gas sockets or devices, or allow liquid to
enter these.
Recommended cleaning agents
Use mild soap solutions or standard detergents as cleaning agents. Wipe down the surfaces of the equipment with
a dampened cloth. If necessary, use small quantities of mild soap solution as a cleaning agent. Then wipe the outer
surfaces with a soft, clean cloth until they are completely dry.
Disinfection procedure
Disinfection by wiping is intended to be the standard disinfection procedure for the support arm system. Hygiene
guidelines and corresponding safety measures must be determined by the operator for the disinfection procedures
that are applied.
• After the contamination by any potentially infectious material (such as blood, secretions or excrement), the
areas must be disinfected immediately in a targeted way.
• Comply with application concentrations.
• Wipe the area to be disinfected rather than spraying it.
• Do not use areas that have been wiped until the disinfectant is dry.
Testing
DANGER
Electric shocks are life-threatening.
• During all testing work, disconnect the device from the power supply/remove the plug from the power socket
and secure the device so that it cannot be switched on again.
Every six (6) months or 5000 arm movements check for:
• Paint damage
• Cracks in plastic parts
• Deformation of the support system
• Loosening of parts
Every two (2) years:
• The securing element of the cantilever arm must be checked and greased by a qualified professional.

www.amico.com 15
Spare Parts
Troubleshooting
Handle (L-P-HANDLE-ALU) Cable: US PLUG (L-X-MILED- FLS-PWR-CRD)
Malfunction Possible cause Remedy User proles
Light does not come on Contact fault Switch on again All
Light does not come on Illuminant defective Contact manufacturer’s
After- Sales Service
Only by manufacturer’s
After- Sales Service
Light does not come on No mains power Check power supply and all
connections
Qualied electrician
Disassembly
DANGER
Electric shocks are life-threatening
• Remove connector from the power supply and put the switch in the “OFF” position before disassembling.
Disposal
Do not dispose of this product with normal refuse. Dispose of the product at a recycling center or return it to
a dealer with a disposal service depending on local regulations. Cut o the cable ush with the housing.

16 Amico Lighting Solutions
Technical Data of the Lighthead
Units Gamma 40 LED Gamma 50 LED Gamma 60 LED
Lighthead Diameter in 88 8
Light Intensity (Central
Luminance)
lx (fc) 40,000 Lux (3,716 fc)
@ 0.5m (19.7”)
50,000 Lux (4,645 fc)
@ 0.5m (19.7”)
60,000 Lux (5,574 fc)
@ 0.5m (19.7”)
Brightness Control % 50-100 50-100 50-100
Light Field Diameter in 66 6
Color Rendering Index Ra 95 95 95
R9 in 90 90 90
Weight of Light lbs 66 6
Color Temperature (Standard) K4500 4500 4500
Number of LED's (Main) 77 7
LED Service Life hours 50,000 50,000 50,000
Electrical 100-240 VAC, 50/60 Hz,
0.77 amps
100-240 VAC, 50/60 Hz,
0.77 amps
100-240 VAC, 50/60 Hz,
0.77 amps
Power Supply ea Direct Power Supply Direct Power Supply Direct Power Supply
Mounting Options Ceiling, Wall, Floorstand, Rail Ceiling, Wall, Floorstand, Rail Ceiling, Wall, Floorstand, Rail
NOTE: Essential Performance Parameters:
- Delivery of minimum and adequate illumination on the diagnostic eld.
- Limitation of energy in the diagnostic eld.

www.amico.com 17
Technical Data of the Arm System
Electrical:
Nominal input voltage 100-240 VAC
Frequency range 50 / 60Hz
Input current 0.77 A
Device Protection Class II Approval ETL/cETL
Any power supply with output less than or equal to 60V, current output less than or equal to 5A and a minimum of 2
MOOP can be used with the spring arm.
Environmental conditions for transport, storage and operation:
Storage and transport
After 15 weeks the conditions for operation apply.
-10°C to +34°C Ambient
20% to 90% humidity
70kPa to 94 kPa
Operation:
This product should be acclimatized to its operating conditions for 24 hours prior to its first use.
+10°C to +40°C
20% to 90% humidity
Weight:
Gamma LED Swing Floorstand 11 kg (24 lbs)
Gamma LED Swing Ceiling Mount 17.7kg (39.1 lbs)
Gamma LED Swing Rail Mount 2.7 kg (6 lbs)
Gamma LED Swing Wall Mount 2.7 kg (6 lbs)
Operating mode: Continuous Operation
Classication:
Gamma LED Swing Class II
Classification under 93/42 EEC – Annex IX Class II
Safety testing according to: CSA C22.2 #60601-1 IEC/EN 60601-1 2nd. UL 60601-1

18 Amico Lighting Solutions
www.amico.comwww.amico.com
Architectural Lighting Solutions (Solar Series, Skyline Series, Lunar Series,
LightMaster)
Amico Lights Corporation warrants its products against defective materials and workmanship for twelve (12) months from the
date of shipment. Within this period, Amico Lights Corporation will repair or replace any part on site or at the factory which is
proven to be defective at Amico Lights Corporation’s cost.
Furthermore, Amico Lights Corporation will warrant its material to be free from defect for an additional period of four (4) years
(five [5] years from the date of shipment). Within this period, Amico Lights Corporation will replace any part at no charge, which is
proven to be defective. Shipping and installation costs after the first twelve (12) months will be borne by the customer.
The warranty applies to normal usage and does not apply to any product that has been subject to alteration, abuse, negligence,
or use (including voltage and/or current) other than that for which the product was designed.
Medical Lighting Solutions (Mira Series, Gamma Series, Clarity Series, Magna
Series)
Amico Lights Corporation warrants its products against defective materials and workmanship for twelve (12) months from the
date of shipment. Within this period, Amico Lights Corporation will repair or replace any part on site or at the factory which is
proven to be defective at Amico Lights Corporation’s cost.
Furthermore, Amico Lights Corporation will warrant its material to be free from defect for an additional period of four (4) years
(five [5] years from the date of shipment). Within this period, Amico Lights Corporation will replace any part at no charge, which is
proven to be defective. Shipping and installation costs after the first twelve (12) months will be borne by the customer.
The spring arms for the above mentioned are warranted for a period of twelve (12) months. The warranty for the spring arms shall
include parts and labor and shall commence from the date of shipment.
The warranty applies to normal usage and does not apply to any product that has been subject to alteration, abuse, negligence,
or use (including voltage and/or current) other than that for which the product was designed.
Amico Lights Corporation shall not be liable for incidental or consequential damages resulting from the use of the equipment.
All claims for warranty must first be approved by Amico Lights Corporation. A valid Return Goods Authorization (RGA) number
must be obtained from Amico Lights Corporation prior to commencement of any service work. Warranty work which has not
been pre-authorized by Amico Lights Corporation will not be reimbursed.
Amico Lights Corporation 85 Fulton Way, Richmond Hill, ON L4B 2N4, Canada
600 Prime Place, Hauppauge, NY 11788, USA
Tel: [phone] | Fax: [phone]
Warranty Policy - Lighting Products

Notes

www.amico.com
LTINSTALINSTRGAMMAFLOORSTANDLED 07.24.20
Amico Lighting Solutions | 122-B East Beaver Creek Road, Richmond Hill, ON L4B 1G6, Canada
Toll Free Phone: [phone] | Toll Free Fax: [phone] | Tel: [phone] | Fax: [phone]
Email: [e-mail] | www.amico.com
