Amico Mira LED Exam Light Manual

Operating and Maintenance Instructions
Mira LED Exam Light
Wall Mount
www.amico.com

2Amico Lights Corporation
Contents
Introduction 3
Symbols Used in This Manual 4
Safety Instructions 5-7
Scope of Delivery 8
Installing Wall Mount 9-10
Installing Wall Arm 11
Installing The Lighthead 12
Operation 13
Disinfecting, Cleaning and Sterilization 14
Maintenance 15
Notes On The Arm Systems 16-17
Spare Parts 18
Disassembly 19
Technical Data of the Lighthead 20
Technical Data of the Arm System 21
Service And Maintenance Notes 22
Warranty 23

www.amico.com 3
Introduction
Thank you for your purchase of the Mira LED Minor Surgery Light.
This installation manual gives you instructions on how to install the Mira LED Light for a Wall Mounted, Ceiling
Mounted or Floorstand version of your purchase. For instructions on operation, maintenance and further description
of the product please refer to the Operation and Maintenance Manual included.
Please read the following instructions very carefully and follow the safety instructions and requirements.

4Amico Lights Corporation
DANGER Can lead to death or serious injury.
WARNING Can lead to injury.
3
1 SYMBOLS
The warning symbols indicate all instructions that are important for safety. Failure to comply with them can lead to injury,
damage to the luminaire or the equipment. In combination with the following signal words the warning symbols means:
DANGER
Can lead to death or serious injury.
WARNING
Can lead to injury
Comply with operating instructions
CE conformity mark
Protective conductor
Neutral conductor/return conductor for the electrical current
Live conductor
Storage humidity
Storage temperature
Disposal
Manufacturer
Trademarks: All trade names mentioned in these instructions are the exclusive property of the relevant manufacturers.
Publication Revision: 02/17/13
Comply with operating instructions
3
1 SYMBOLS
The warning symbols indicate all instructions that are important for safety. Failure to comply with them can lead to injury,
damage to the luminaire or the equipment. In combination with the following signal words the warning symbols means:
DANGER
Can lead to death or serious injury.
WARNING
Can lead to injury
Comply with operating instructions
CE conformity mark
Protective conductor
Neutral conductor/return conductor for the electrical current
Live conductor
Storage humidity
Storage temperature
Disposal
Manufacturer
Trademarks: All trade names mentioned in these instructions are the exclusive property of the relevant manufacturers.
Publication Revision: 02/17/13
CE conformity mark
Protective conductor
ENG
SYMBOLS
4
1 SYMBOLS
The warning symbol is used for all instructions that are important for safety. If warnings are ignored, users may be injured or
the light or surroundings may be damaged. The warning symbol is used with the following signal words as follows:
WARNING
May cause death or serious injury.
CAUTION
May cause minor injury.
Protective earth
Neutral conductor return line for current
Live conductor
Disposal
Manufacturer
Neutral conductor/return conductor for the electrical current
ENG
SYMBOLS
4
1 SYMBOLS
The warning symbol is used for all instructions that are important for safety. If warnings are ignored, users may be injured or
the light or surroundings may be damaged. The warning symbol is used with the following signal words as follows:
WARNING
May cause death or serious injury.
CAUTION
May cause minor injury.
Protective earth
Neutral conductor return line for current
Live conductor
Disposal
Manufacturer
Live conductor
3
1 SYMBOLS
The warning symbols indicate all instructions that are important for safety. Failure to comply with them can lead to injury,
damage to the luminaire or the equipment. In combination with the following signal words the warning symbols means:
DANGER
Can lead to death or serious injury.
WARNING
Can lead to injury
Comply with operating instructions
CE conformity mark
Protective conductor
Neutral conductor/return conductor for the electrical current
Live conductor
Storage humidity
Storage temperature
Disposal
Manufacturer
Trademarks: All trade names mentioned in these instructions are the exclusive property of the relevant manufacturers.
Publication Revision: 02/17/13
Storage humidity
3
1 SYMBOLS
The warning symbols indicate all instructions that are important for safety. Failure to comply with them can lead to injury,
damage to the luminaire or the equipment. In combination with the following signal words the warning symbols means:
DANGER
Can lead to death or serious injury.
WARNING
Can lead to injury
Comply with operating instructions
CE conformity mark
Protective conductor
Neutral conductor/return conductor for the electrical current
Live conductor
Storage humidity
Storage temperature
Disposal
Manufacturer
Trademarks: All trade names mentioned in these instructions are the exclusive property of the relevant manufacturers.
Publication Revision: 02/17/13
Storage temperature
ENG
SYMBOLS
4
1 SYMBOLS
The warning symbol is used for all instructions that are important for safety. If warnings are ignored, users may be injured or
the light or surroundings may be damaged. The warning symbol is used with the following signal words as follows:
WARNING
May cause death or serious injury.
CAUTION
May cause minor injury.
Protective earth
Neutral conductor return line for current
Live conductor
Disposal
Manufacturer
Disposal
ENG
SYMBOLS
4
1 SYMBOLS
The warning symbol is used for all instructions that are important for safety. If warnings are ignored, users may be injured or
the light or surroundings may be damaged. The warning symbol is used with the following signal words as follows:
WARNING
May cause death or serious injury.
CAUTION
May cause minor injury.
Protective earth
Neutral conductor return line for current
Live conductor
Disposal
Manufacturer
Manufacturer
Symbols Used in This Manual
The warning symbols indicate all instructions that are important for safety. Failure to comply with them can lead
to injury, damage to the luminaire or the equipment. In combination with the following signal words the warning
symbols means:
Trademarks: All trade names mentioned in these instructions are the exclusive property of the relevant manufacturers.
Publication Revision: 02/17/13

www.amico.com 5
Intended use
The Mira LED Minor Surgery Light is intended to provide illumination for minor surgery, diagnosis, or examination. It
is to be used near the patient to support treatments, which pose no risk to the patient in the event of any interruption
caused by light failure. It is meant for continuous operation.
User proles
Medical sta
All persons with medical training who work in the eld for which they were trained.
Cleaning sta
All persons familiar with national and workplace hygiene requirements.
Electricians
All persons with training in electronics and electrical technology who are familiar with the relevant standards and
regulations.
Certied installers
Persons qualied by training, experience and knowledge of the regulations to install and remove the equipment.
Safety Instructions
Please note that certain duties must be carried out by people with the appropriate corresponding qualications. The
instructions are part of the product and must be kept so they are accessible for all subsequent users:
• These instructions are for the Amico Lights Mira Series LED lights. This includes ceiling, oorstand and wall
mounted equipment.
• Please carefully read these operating instructions before using the equipment. It will help protect you and
others from potential injuries that may occur.
• All work on the light (including repairs) must be done by qualied electricians only. The light must be installed
by a certied installer.
• The light must not be modied or manipulated. Use in any other manner than with the original parts may
result in dierent specications and life-threatening dangers.
• Only persons with medical training are permitted to operate the equipment.
• Only trained cleaning personnel are permitted to clean the equipment.
• The light must not be used in an explosive environment. The power supply to the light is a potential ignition
source.
• The light must be used in dry rooms only.
• The light must not be left on unattended.
• Keep all ammable equipment and objects away from the Lighthead and cone during use.
• Do not use a damaged light. Defective cables can also be a potential hazard. Do not position cables near heat
sources or sharp edges.
• Eye damage. Never look directly at the light cone.
• Replace damaged lenses before using the light again.
• The light must be connected to the mains with a protective earth to prevent electric shock.
Safety Instructions

6Amico Lights Corporation
Safety Instructions
• Never apply additional loads to the Lighthead and spring arm.
• Do not cover the light with a cloth or similar material while operating.
• If problems are encountered that have not been addressed in these operating instructions, please contact
your supplier in the interest of your own safety.
Please keep these operating instructions in a secured place near the device. This ensures easy access to safety
instructions and important information should the need arise.
• The inspections and maintenance work, as described on page 30, should only be done by trained service
technicians. Anyone else is not authorized to perform inspections and maintenance work.
• The adjustment work should only be carried out by a hospital technician or someone with similar
qualications. Anyone else is not authorized to perform adjustment work.
• This equipment has been built accordingly and is operationally safe. Nonetheless, it may still present some
danger, especially if not used according to the operating instructions as specied in this manual.
• Modications are never to be made for any reason. This is to ensure safety for all persons involved. Any
modications made to the system void the warranty.
• The contents of the operating instructions are subjected to change without notice.
Specic tting instructions
Mira LED Ceiling Mount
• Mounting material not included in delivery.
• The ceiling mount may be tted to ceiling only with a concrete strength of B25 (C20/25) or greater.
• Contact with reinforcing elements of the solid slab ceiling must be avoided. In case of doubt, a structural
engineer should control the mounting on the respective surface.
• The drill holes should be made by a skilled person in accordance with the drill hole tolerances recommended
by the manufacturer of the fastening anchors.
• The screws must be carefully tightened using a torque wrench in accordance with the recommendations of
the manufacturer of the fastening anchors.
Mira LED Wall Mount
• Mounting Material not included in delivery.
The light may be mounted only on walls that guarantee sucient hold. The necessary technical information can be
found in the installation section of this manual.

www.amico.com 7
Warning levels
DANGER
Indication of hazards that can lead to death or serious injury if measures are disregarded.
WARNING
Indication of hazards that can lead to injury if measures are disregarded.
CAUTION
Indication of hazards that can lead to damage to property if measures are disregarded.
4
2 SAFETY INSTRUCTIONS
2.1 Intended use
The light duty equipment is intended for treatment lights
and other similar devices. It is to be used near the
patient to support diagnosis or treatment, which poses no
risk to the patient in the event of any interruption caused
by light failure. It is meant for continuous operation and is
not intended to be combined with other medical devices.
The system is NOT suitable for use in or near
combustible mixtures of aesthetic agents and air or
oxygen or nitrous oxide.
2.2 User profiles
Medical staff
All persons with medical training who work in the field for
which they were trained.
Cleaning staff
All persons familiar with national and workplace hygiene
requirements.
Electricians
All persons with training in electronics and electrical
technology who are familiar with the relevant standards
and regulations.
Certified installers
Persons qualified by training, experience and knowledge
of the regulations to install and remove the equipment.
2.3 Safety instructions
Please note that certain duties must be carried out by
people with the appropriate corresponding qualifications:
These operating instructions are for OASYS
Healthcare light duty series equipment. The end
devices are supplied by other manufacturers, and for
using such equipment refer to the manual of the
corresponding manufacturer.
These operating instructions become applicable only
after proper installation and assembly in accordance
with the assembly instructions provided.
Only persons with medical training are permitted to
operate the equipment.
Only trained cleaning personnel are permitted to
clean the equipment.
Please carefully read these operating instructions
before using the equipment. It will help protect you
and others from potential injuries that may occur.
If problems are encountered that have not been
addressed in these operating instructions, please
contact your supplier in the interest of your own
safety.
Please keep these operating instructions in a secured
place near the device. This ensures easy access to
safety instructions and important information should
the need arise.
The inspections and maintenance work, as described
in Section 6.0, should only be done by trained
service technicians. Anyone else is not authorized to
perform inspections and maintenance work.
The adjustment work should only be carried out by a
hospital technician or someone with similar
qualifications. Anyone else is not authorized to
perform adjustment work.
This equipment has been built accordingly and is
operationally safe. Nonetheless, it may still present
some danger, especially if not used according to the
operating instructions as specified in this manual.
Modifications are never to be made for any reason.
This is to ensure safety for all persons involved. Any
modifications made to the system void the warranty.
The contents of the operating instructions are
subjected to change without notice.
2.4 Warning levels
DANGER
Indication of hazards that can lead to death or serious
injury if measures are disregarded.
WARNING
Indication of hazards that can lead to injury if measures
are disregarded.
CAUTION
Indication of hazards that can lead to damage to
property if measures are disregarded.
EXPLOSION HAZARD
The above is an explosion hazard warning symbol. Non-
compliance with this symbol may result in damages or
injuries due to explosion.
ELECTRIC SHOCK
The above is an electric shock warning symbol. Non-
compliance with this symbol may result in damages or
injuries due to electric shock.
EXPLOSION HAZARD
The above is an explosion hazard warning symbol. Non-compliance with this symbol may result in damages or injuries
due to explosion.
4
2 SAFETY INSTRUCTIONS
2.1 Intended use
The light duty equipment is intended for treatment lights
and other similar devices. It is to be used near the
patient to support diagnosis or treatment, which poses no
risk to the patient in the event of any interruption caused
by light failure. It is meant for continuous operation and is
not intended to be combined with other medical devices.
The system is NOT suitable for use in or near
combustible mixtures of aesthetic agents and air or
oxygen or nitrous oxide.
2.2 User profiles
Medical staff
All persons with medical training who work in the field for
which they were trained.
Cleaning staff
All persons familiar with national and workplace hygiene
requirements.
Electricians
All persons with training in electronics and electrical
technology who are familiar with the relevant standards
and regulations.
Certified installers
Persons qualified by training, experience and knowledge
of the regulations to install and remove the equipment.
2.3 Safety instructions
Please note that certain duties must be carried out by
people with the appropriate corresponding qualifications:
These operating instructions are for OASYS
Healthcare light duty series equipment. The end
devices are supplied by other manufacturers, and for
using such equipment refer to the manual of the
corresponding manufacturer.
These operating instructions become applicable only
after proper installation and assembly in accordance
with the assembly instructions provided.
Only persons with medical training are permitted to
operate the equipment.
Only trained cleaning personnel are permitted to
clean the equipment.
Please carefully read these operating instructions
before using the equipment. It will help protect you
and others from potential injuries that may occur.
If problems are encountered that have not been
addressed in these operating instructions, please
contact your supplier in the interest of your own
safety.
Please keep these operating instructions in a secured
place near the device. This ensures easy access to
safety instructions and important information should
the need arise.
The inspections and maintenance work, as described
in Section 6.0, should only be done by trained
service technicians. Anyone else is not authorized to
perform inspections and maintenance work.
The adjustment work should only be carried out by a
hospital technician or someone with similar
qualifications. Anyone else is not authorized to
perform adjustment work.
This equipment has been built accordingly and is
operationally safe. Nonetheless, it may still present
some danger, especially if not used according to the
operating instructions as specified in this manual.
Modifications are never to be made for any reason.
This is to ensure safety for all persons involved. Any
modifications made to the system void the warranty.
The contents of the operating instructions are
subjected to change without notice.
2.4 Warning levels
DANGER
Indication of hazards that can lead to death or serious
injury if measures are disregarded.
WARNING
Indication of hazards that can lead to injury if measures
are disregarded.
CAUTION
Indication of hazards that can lead to damage to
property if measures are disregarded.
EXPLOSION HAZARD
The above is an explosion hazard warning symbol. Non-
compliance with this symbol may result in damages or
injuries due to explosion.
ELECTRIC SHOCK
The above is an electric shock warning symbol. Non-
compliance with this symbol may result in damages or
injuries due to electric shock.
ELECTRIC SHOCK
The above is an electric shock warning symbol. Non-compliance with this symbol may result in damages or injuries
due to electric shock.
Safety Instructions

8Amico Lights Corporation
Scope of Delivery
Wall Mount
Included:
1x Lighthead with sterilizable handle
1x wall arm
1x wall mount
1x main cover
1x small cover
1x plug cover
Scope of Delivery

www.amico.com 9
Load data
Bending moment MB max. 210 Nm
Vertical weight forces FG max. 205 N
• 1x load only. Regional safety factors to be considered.
• Maximum device load is assumed and included.
Installing wall mount
WARNING
To be tted only by qualied personnel
• Installation may be carried out by a state-certied tter. Insucient professional knowledge could cause life-
threatening injury.
WARNING
Danger of death from electric shock.
• All-pole disconnection of the light from the mains by an external switch must be possible.
Installing Wall Mount
1. Insert tubular dowels for the chosen screws and t the
wall mount.
2. Slide main cover over wall mount and into place.
3. Secure the cover with the four screws provided
WARNING
Danger of death from electric shock.
• Switch o circuit breaker before working on the mains connection.

10 Amico Lights Corporation
4. Connect to the mains power supply.
5. Connect the lamp cable.
6. Clip plug cap into top of the wall mount main cover.
7. Clip small cover to the wall mount main cover.
Installing Wall Mount
ENG
SYMBOLS
4
1 SYMBOLS
The warning symbol is used for all instructions that are important for safety. If warnings are ignored, users may be injured or
the light or surroundings may be damaged. The warning symbol is used with the following signal words as follows:
WARNING
May cause death or serious injury.
CAUTION
May cause minor injury.
Protective earth
Neutral conductor return line for current
Live conductor
Disposal
Manufacturer
ENG
SYMBOLS
4
1 SYMBOLS
The warning symbol is used for all instructions that are important for safety. If warnings are ignored, users may be injured or
the light or surroundings may be damaged. The warning symbol is used with the following signal words as follows:
WARNING
May cause death or serious injury.
CAUTION
May cause minor injury.
Protective earth
Neutral conductor return line for current
Live conductor
Disposal
Manufacturer

www.amico.com 11
WARNING
Danger of injury from unfolding spring arm.
1. Gently pry the two halves of the cover apart and set
aside.
2. Remove two screws (1) from receptacle mount. Move
receptacle mount (2) to provide access for mounting.
3. Install ceiling arm.
CAUTION
Light may fall if inaccurately fastened.
• Locking rings must click into groove and be
evenly positioned all around.
4. First install washer (1), then safety washer (2), followed
by two locking rings (3). Ensure tooth on safety
washer aligns with the hole in the wall mount stem
(4).
5. Replace the receptacle mount (1). Reinstall two screws
(2), do not over tighten.
6. Gently replace covers and snap together
7. To continue with installing the Lighthead see
Installing the Lighthead section of this manual
Installing Wall Arm
1
1
2
4
1
2
3
2
2
1

12 Amico Lights Corporation
1. Remove screw
2. Rotate sleeve so the notch and slot are aligned.
3. Insert Lighthead.
4. Insert safety segment.
5. Turn back sleeve and install the screw. Tighten screw
according to requirements of the friction from the
Lighthead.
6. Clip handle on.
Installing The Lighthead
CAUTION
Damage can be caused by falling Lighthead.
• Danger of injury through incorrect tting of the Lighthead.

www.amico.com 13
Operation
Mira LED Floorstand
WARNING
Danger of death from electric shock
• Do not plug in a damaged power cable
• Replace damaged power cable before using light again
• The mains voltage and frequency must match the data on the name plate
• Connect to a mains connection with a protective earth only.
NOTICE:
• Wind the power cable to the cable retainers when it is not being used.
1. Plug in cable (1).
2. Install the cable to the mains supply.
3. Switch on (2).
1
2
Mira LED – All Models
Switch on Light from control pad at Lighthead.
Power (on/o)
Decrease brightness Increase brightness
Endo Light (on/o)

14 Amico Lights Corporation
Disinfecting, Cleaning and Sterilization
NOTICE:
Damage due to improper cleaning
• Do not use alcohol, solvent or cleaning agents containing chlorine or scouring agents.
• Damage to lens by concentrated disinfectant or solvent.
• Follow the manufacturers recommended mixing ratio.
• Use of incorrect cloths may scratch lens.
NOTICE
A dirty lens will reduce the illuminating power.
• Clean lens regularly
• Spray and wipe disinfection is permitted.
• Clean the lens with a leather cloth soaked in cleaner
• Spray disinfectant in horizontal position.
NOTICE
The external components of the light can be disinfected with the following diluted products:
• Lysoformin
• Dismozon
• Hexaquart plus
• Sagrotan – fast disinfecting cleaner
NOTICE
The local government regulations for disinfection must also be observed in addition to these instructions.
NOTICE
Sterilize handle at 120C and 1.05 bar for 30 minutes.

www.amico.com 15
Maintenance
DANGER
Electric shocks are life-threatening.
• Remove the connector from the power supply and put the switch in the“OFF”position.
• The connector cable must be checked for damage at least once per year.
NOTE
• Maintenance and repairs must only be carried out by qualied electricians.
• The corresponding user prole is described in Chapter 2, Safety instructions
Setting Spring Force
NOTE
The spring force is set at the optimum setting in the factory
• Lift the spring arm to its highest position. • Insert a 6 mm Allen key through window and turn
the adjustment screw.
Setting spring force:
• Turn screw counter clockwise (+) to increase spring force (when spring arm lowers)
• Turn screw clockwise (-) to decrease spring force (when spring arm rises)

16 Amico Lights Corporation
Notes On The Arm Systems
Selection Of Fastening Material
We recommend the use of (not included in the delivery) counter-plates for fastening to drywall.
Cleaning and disinfection
DANGER
Electric shocks are life-threatening.
• The devices can conduct electricity and must be handled with care during cleaning and disinfection.
• If there is a power plug remove it from the socket.
• Do not use spraying methods for cleaning and/or disinfection.
• Do not spray liquid into the openings of electrical power sockets, gas sockets or devices, or allow liquid to
enter these.
Recommended cleaning agents
Use mild soap solutions or standard detergents as cleaning agents. Wipe down the surfaces of the equipment with
a dampened cloth. If necessary, use small quantities of mild soap solution as a cleaning agent. Then wipe the outer
surfaces with a soft, clean cloth until they are completely dry.
Disinfection procedure
Disinfection by wiping is intended to be the standard disinfection procedure for the support arm system. Hygiene
guidelines and corresponding safety measures must be determined by the operator for the disinfection procedures
that are applied.
• After the contamination by any potentially infectious material (such as blood, secretions or excrement), the
areas must be disinfected immediately in a targeted way.
• Comply with application concentrations.
• Wipe the area to be disinfected rather than spraying it.
• Do not use areas that have been wiped until the disinfectant is dry.
•
Testing
DANGER
Electric shocks are life-threatening.
• During all testing work, disconnect the device from the power supply/remove the plug from the power socket
and secure the device so that it cannot be switched on again.
Every 6 months or 5000 arm movements check for:
• Paint damage
• Cracks in plastic parts
• Deformation of the support system
• Loosening of parts
Every 2 years:
The securing element of the cantilever arm must be checked and greased by a qualied professional.

www.amico.com 17
Notes On The Arm Systems
Disassembling For Servicing
DANGER
Injury hazard
• The cantilever arm is under a high spring load. If the end device is not moved to the upper cantilever arm
position, the cantilever arm will spring up, possibly causing serious injury. Only remove the end device if the
cantilever arm is in the upper position.
• Disconnect the device from the power supply/remove the plug from the mains and ensure it cannot be
switched on again.
• Place cantilever arm in the upper position.
• Unscrew the brake screw 1 so that the sleeve 2 can be turned.
• Turn the sleeve 2 through 180 degrees until the securing segment 3 appears in the slot 4.
• Hold the end device head 5 rmly and remove the securing segment 3 using a narrow at-bladed screwdriver.
• Remove end device 5 from the connection.
• Put protective cap in place.
1. Brake screw
2. Sleeve
3. Securing segment
4. Slot
5. End device terminal
This system is designed to be equipped with end devices from other manufacturers. For end device operation
instructions please refer to the operating instructions of the related manufacturer.

18 Amico Lights Corporation
Spare Parts
Troubleshooting
Malfunction Possible cause Remedy User profiles
Light does not come on Contact fault Switch on again All
Light does not come on Illuminant defective Contact manufacturer’s After-
Sales Service
Only by manufacturer’s After-
Sales Service
Light does not come on No mains power Check power supply and all
connections Qualied electrician
Light does not come on 1A fuse defective
(Mira LED Floorstand only) Replace fuse Qualied electrician
Handle (Art.- Nr. D51.040.000)
Rotary knob (Art.- Nr. D51.050.000)
Cable:
• Schuko D70.017.000
• CH D70.018.000
• UK D70.019.000
• US HG D70.020.000
• Slow-blow 2A fuse
(Art.- Nr. D69.596.000) Mira LED Floorstand only
DISASSEMBLY / SPARE PARTS
ENG
19
12 DISASSEMBLY
WARNING
Danger of death from electric shock.
 Before installation disconnect plug from
mains and set switch to off position.
WARNING
Never unscrew the top cable retainer.
 If both cable retainers are unscrewed, the
connection will be loose and will fall, which
may cause injury and damage to the cables
and lamp.
12.1 Disposal
Do not dispose of the light with the
normal refuse. Dispose oft he light at a
recycling centre or return it to a dealer
with a disposal service debending on
local regulations. Cut off the cable flush
with the housing.
13 SPARE PARTS
Handle (Art.- Nr. D51.040.000)
Rotary knob (Art.- Nr. D51.050.000)
Cable:
 Schuko D70.017.000
 CH D70.018.000
 UK D70.019.000
 US HG D70.020.000
Fast-blow 1A fuse (Art.- Nr. D69.596.000)
triango 30 F only

www.amico.com 19
ENG
SYMBOLS
4
1 SYMBOLS
The warning symbol is used for all instructions that are important for safety. If warnings are ignored, users may be injured or
the light or surroundings may be damaged. The warning symbol is used with the following signal words as follows:
WARNING
May cause death or serious injury.
CAUTION
May cause minor injury.
Protective earth
Neutral conductor return line for current
Live conductor
Disposal
Manufacturer
DANGER
Electric shocks are life-threatening.
• Remove connector from the power supply and put the switch in the“OFF”position before disassembling.
DANGER
Never unscrew the upper cable holder - injury hazard.
• When both cable holders are unscrewed, the connecting piece is loose and falls downward, which could cause
injury and/or damage to the cable and/or the device
Disassembly
Disposal
Do not dispose of this product with normal refuse. Dispose of the product at a recycling center or return it to
a dealer with a disposal service depending on local regulations. Cut o the cable ush with the housing.

20 Amico Lights Corporation
Technical Data of the Lighthead
Units Mira 50 LED Mira 65 LED Mira 90 LED
Lighthead Diameter in 18 18 18
Light Intensity (Central Luminance) lx (fc) 50,000 Lux (4,762 fc)
@ 1m (39.37")
65,000 Lux (6,190 fc)
@ 1m (39.37")
90,000 Lux (8,571 fc)
@ 1m (39.37")
Brightness Control %50-100 50-100 50-100
Light Field Diameter in 6.5-12.0 6.5-12.0 6.5-12.0
Depth of Illumination in 94.5 94.5 94.5
Color Rendering Index Ra 95 95 95
R9 in 90 90 90
Weight of Lighthead lbs 11 11 11
Color Temperature (Standard) K 4500 4500 4500
Shadow Dilution
Single Mask %0.7 0.7 0.7
Double Mask %55.5 55.5 55.5
Cavity %100 100 100
Single Mask with Cavity %0.3 0.3 0.3
Double Mask with Cavity %55.3 55.3 55.3
Number of LED's (Main) 36 36 36
LED Service Life hours 50,000 50,000 50,000
Total Radiant Power at Max Intensity W/m² 178 231.4 317
Electrical 100-240 VAC, 50/60 Hz,
0.40 amps
100-240 VAC, 50/60 Hz,
0.55 amps
100-240 VAC, 50/60 Hz,
0.65 amps
Power Supply ea Direct Power Supply Direct Power Supply Direct Power Supply
Mounting Options Ceiling, Wall, Floorstand Ceiling, Wall, Floorstand Ceiling, Wall, Floorstand
Certicates
cETLus conform to
UL60601-1; UL60601-2-41;
UL certied IP54 per
IEC 60598
cETLus conform to
UL60601-1; UL60601-2-41;
UL certied IP54 per
IEC 60598
cETLus conform to
UL60601-1; UL60601-2-41;
UL certied IP54 per
IEC 60598
