Quick Installation and Maintenance Instructions
Worktop Light for Powered Hummingbird
(LCD & Laptop Models)
HMA-WT-LEDMNT
LCD Model Installation
INSTRUCTIONS:
1. Unlock the work surface using the provided key (lock is located on right side of work surface). Open
work surface by lifting surface from rear.
2. Open cord access door and remove cable management cover (Figure 1).
3. Raise display to its MAXIMUM height on the display post.
4. Clean desired mounting location on bottom of display.
5. Remove tape backing from LED accessory and mount to desired location on display. For ideal bonding
results, apply moderate pressure to adhesive section (unfold/open LED) for 15 seconds.
6. Run LED Accessory cable through cord access door (Figure 2).
7. Plug in connector and tie the LED cable to CAT5 cable using provided cable ties (Figure 3).
8. Replace cord management cover, close the cord access door (Figure 4).
9. Close and lock work surface.
10. Refer to Enable LED below.
WARNING: It is the responsibility of the end user to ensure all aspects of installation are covered by following the full manual and reviewing warnings/notes
found at: http://www.amico.com/products/workstations-wheels
Preventive maintenance checks must be performed regularly to maintain the quality and performance of this product. Any parts that may be broken, missing,
worn, distorted, or contaminated in any way should not be used and all affected parts should be replaced immediately. Should the necessity of any repair be
suspected; please contact your local distributor.
Figure 3 Figure 5Figure 4
Medical Facility Responsibility
Figure 2
Installation Tools Installation Reference
Scissors
Cable Tie x 3Accessory LED with
mounting adhesive
Figure 1

2
Laptop Model Installation
INSTRUCTIONS:
1. Unlock work surface using the provided key (lock is located on right side of work
surface). Open work surface by lifting surface from rear.
2. Plug in connector and tie LED cable to CAT5 cable using provided cable ties (Figure 6).
3. Place laptop inside the worktop.
4. Clean desired mounting location on laptop.
5. Remove tape backing from LED accessory and mount to desired position on back of
Laptop screen (Figure 7). For ideal bonding results, apply moderate pressure on LED
accessory for 15 seconds. Run excess cable beside/under Laptop.
6. Close and lock worktop.
7. Refer to Enable LED below.
Figure 6 Figure 7
Quick Installation and Maintenance Instructions
Worktop Light for Powered Hummingbird
(LCD & Laptop Models)
HMA-WT-LEDMNT
Enable LED
STANDARD CONTROL INTERFACE MODELS
1. Test light functionality by pressing the light bulb button on the Standard Control Interface.
2. Once LED Accessory illuminates, installation is complete.
3. Adjust the LED Accessory to desired angle.
ADVANCED CONTROL INTERFACE MODELS
1. Access login screen by pressing the top left corner of the home screen on the Advanced Control Interface (Figure 8).
2. Enter username and password and select“Log In”. Under“Settings”, select“Admin Setup”.
3. Select the checkbox for“Top” in the “Enable Light”section and press “Save”(Figure 9). The main ADMIN screen should display three (3) LED options: “Top”,
“Middle”, and “Bottom”.
4. Select “Top” to illuminate LED (Figure 10).
5. Once LED illuminates, installation is complete.
6. Adjust LED to desired angle.
Figure 8
Settings Notes
4:50 pm07/10/2014
Pulse
Timer
10h:50m
GUEST
Top Middle Bottom
Figure 9
4:50 pm
07/10/2014
10h:50m
ADMIN SETUP
Enable Light
Enable Buzzer
Allow login without password
Automatically Logout After
Allow new users
Units Metric
Imperial
Top Middle Bottom
SaveCancel
System
Users
Set Clock
ADMIN
Reset
Figure 10
Settings Notes
4:50 pm07/10/2014
Pulse
Timer
10h:50m
ADMIN
Top Middle Bottom

Amico Accessories Inc. 122 East Beaver Creek Road, Richmond Hill, ON L4B 1G6, Canada
Toll Free Tel: [phone] | Tel: [phone] | Fax: [phone]
www.amico.com 3
Troubleshooting Guide
Adjustments
The LED light has a hinge to allow for adjustment to lighting angle.
To adjust brightness on a standard interface, hold the lightbulb icon until desired lighting level is reached.
Maintenance
It is recommended that once every three (3) months, all locks, bolts and screws are visually inspected for signs of product wear and tear or damage. Check the
product for looseness in the mount or orientation, and ensure it is secure.
Warranty
During the term of warranty: Within the first twelve (12) months from the date of shipment, Amico Accessories will repair or replace any part which is proven to be
defective at no cost. After the twelve (12) month period, Amico Accessories will send the parts to the customer free of charge, however shipping and installation
will be borne by the customer.
The warranty is valid only when the product has been properly installed according to Amico Accessories specifications, used in a normal manner, and serviced
according to factory recommendations. It does not cover failures due to damage which occur in shipments or failures which resulted from accidents, misuse,
abuse, neglect, mishandling, alteration, misapplication or damage that may be attributable to Force Majeure.
AMICO ACCESSORIES DOES NOT HONOR VERBAL STATEMENTS CONCERNING THE WARRANTY.
The distributor and/or dealer are not sanctioned to create verbal warranties about the product described in this agreement. Any statements will not be honored or
be made part of the agreement of sale. This document is the final complete and exclusive terms of the agreement.
THIS WARRANTY IS INCLUSIVE AND REPLACES ALL OTHER WARRANTIES.
Amico Accessories shall not, under any circumstances be liable for incidental or consequential damages including, but not limited to, profit, loss of sales or injuries
to person(s) or property.
Correction of non-compliance as noted above will result in completion of all liabilities of Amico Accessories whether based on agreement, neglect or changed
materials, designs or specifications without notice.
All claims for warranty must first be approved by Amico Accessories Customer Service Department: ([email protected] or 1-877-264-2697). A valid
Return Goods Authorization number must be obtained from Amico Accessories prior to commencement of any warranty claim.
AAQMHMNGBRDWRKTPLIGHTPWD 09.14.2020
Symptom Possible Cause Solution
LED mounting tape is not secure Incorrect installation Call distributor to replace part
LED installed but does not illuminate Improper installation or incomplete software
administration setup
Refer to Enable LCD
