Amino Amigo 7X User manual

4 123
5
6
READ
ME FIRST
1. Power/Activity LED and IR receiver.
Warning! Before connecting or disconnecting any cable, switch
off all system devices (TV, A/V Amplifier, etc.) and disconnect
from the main electrical supply.
Connect cable to STB + TV
The Amigo 7X provides options for connecting audio and video
to your TV:
HDMI (recommended): Best quality. Connect an HDMI cable
to the HDMI output of the Amigo 7X and to the HDMI input of
your TV.
Analogue A/V: Good quality. SD only composite with analogue
audio left/right.
Connecting via Wi-Fi
Internal dual band Wi-Fi is a feature for the Amigo 7X. Please
contact your service provider for detailed instructions about the
wireless network configuration.
1. DC power input 5V 2A.
2. HDMI port.
3. Analogue A/V output (adapter cable available).
4. Ethernet port.
5. 2X USB port. DO NOT use this port for Powered USB.
Use for external storage media such USB flash drive (external
storage media must be formatted as FAT32). You can also
update software and program lists using this connection.
6. MicroSD Slot (IP only).
Contents
The Amigo 7X is supplied with the correct power adapter for your
local system. The package may also contain optional accessories
shown below, depending on your service provider.
The Amigo 7X is protected with a clear plastic film. This should be
removed before use.
Overview of the Amigo 7X
1. Connecting the Amigo 7X to a TV
Optional accessories
Amigo 7X User Guide
Connect an HDMI cable to the HDMI output of the Amigo 7X and
to the HDMI input of your A/V receiver or home cinema system.
Warning! The Amigo 7X must only be used with the supplied
power adapter.
Connect the power adapter to the power input of the Amigo 7X,
then connect the power adapter to the mains supply. The power
adapter provided will be specific to your region. Ensure you have
the correct power adapter for your region. If you are unsure,
contact your service provider.
3. Connecting the Amigo 7X to the power supply
2. Connecting the Amigo 7X to an A/V receiver
Remote control
and batteries
HDMI cable
3.5 mm jack to
3 x RCA cable
Ethernet cable

Important - Safety instructions
Read these instructions carefully and keep for future reference. Note all warnings.
The product contains no user-serviceable parts. Refer all servicing to qualified
service personnel.
Handle the product with care and do not attempt to dismantle the product.
Do not expose the product or its accessories to any liquids, rain or moisture.
Do not locate the product near a heat source and do not block ventilation holes:
the product will become warm during operation. Allow at least 10 cm (4”) around
the product for air circulation.
Do not place the product where it may be subject to physical shock, vibration or
where the product may fall over.
Do not place the product on soft furnishings or carpets.
Only use the power supply provided by the manufacturer. The use of any other
type of power supply may invalidate any approval or warranty applying to the
product and may be dangerous. If the power supply does not match your local
system, contact your product supplier.
Protect the power supply cord from damage.
Before disconnecting the device from the power supply cord, first remove the
power cord from the main outlet.
Disconnect the product from the mains supply if left unused for long periods of
time or during electrical storms.
Disconnect the product before cleaning, and use a dry cloth only.
Only use attachments and accessories specified by the manufacturer.
The product is for indoor use only.
FCC statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that
may cause undesired operation of the device.
IMPORTANT NOTE:
RF exposure warning statement:
1. This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
2. This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with a minimum distance of 20 centimetres between the radiator and your body.
Operating information
Operating temperature: 5 °C to 40 °C (40 °F to 104 °F)
Frequency bands and maximum powers:
WLAN Bluetooth
2.4 GHz: EIRP < 20 dBm
5.18~5.24 GHz: EIRP < 23 dBm
5.26~5.32 GHz: EIRP < 23 dBm
5.50~5.70 GHz: EIRP < 23 dBm
BT-EDR: EIRP < 4 dBm
BT-LE: EIRP < 2 dBm
99-705106-01 AM-011263-DS v1
Hereby, Amino Communications Ltd. declares that the radio equipment type
IP Digital set-top box
is in compliance with Directive 2014/53/EU.
The full text of the EU Declaration of Conformity is available at the
following internet address: www.aminocom.com/support
Support and regulatory information
European Approvals
2014/53/EU (RED Directive)
2011/65/EU (RoHS Directive)
2012/19/EU (WEEE Directive)
2014/35/EU (Low Voltage Directive)
Manufactured under licence from Dolby Laboratories. Dolby, Dolby
Audio, and the double-D symbol are trademarks of Dolby Laboratories.
The country code selection feature is disabled for products marketed to the
US/Canada.
For support and further regulatory information about this product, go to:
www.aminocom.com/legal/docs
Manufacturer/importer: Amino Communications Ltd, 1010 Cambourne Business
Park, Cambourne, Cambridge, CB23 6DP, United Kingdom.
Declaration of Conformity
Conformity
EN60950-1: 2006
CAN/CSA-C22.2 No. EN60950-1
