Amit RRU-WEM/1158 User manual

rru-wem1158_g_en_100
RRU-WEM/1158
WTB / Ethernet / MVB gateway
Operation manual
Version 1.00

RRU-WEM/1158
rru-wem1158_g_en_100 2/34
AMiT, spol. s r.o. does not provide any warranty concerning the contents of this
publication and reserves the right to change the documentation without
obligation to inform anyone or any authority about it.
This document can be copied and redistributed under following conditions:
1. The whole text (all pages) must be copied without any changes.
2. All redistributed copies must retain the AMiT, spol. s r.o. copyright notice
and any other notices contained in the documentation.
3. This document must not be distributed for purpose of making profit.
The names of products and companies used herein can be trademarks or
registered trademarks of their respective owners.
AMiT is a registered trademark.
Copyright (c) 2017, AMiT, spol. s r. o.
Producer: AMiT, spol. s r. o.
Naskové 1100/3, 150 00 Praha
www.amit-transportation.com
Technical support: [email protected]

RRU-WEM/1158
3/34 rru-wem1158_g_en_100
Contents History of revisions.........................................................................................4
Related documentation...................................................................................4
1Definition of used abbreviations ........................................................5
2Definition of used terms......................................................................6
3Introduction..........................................................................................7
4Technical parameters..........................................................................8
4.1 Dimensions...................................................................................................11
4.2 Recommended drawing symbol ...................................................................12
4.3 Block diagram...............................................................................................13
5Product marking ................................................................................14
6Conformity assessment ....................................................................16
6.1 Other tests....................................................................................................17
7Power supply......................................................................................18
7.1 Powering from DC network...........................................................................18
8Communication lines.........................................................................19
8.1 WTB .............................................................................................................19
8.1.1 WTB line state indication..............................................................................20
8.2 Ethernet........................................................................................................21
8.2.1 Ethernet line state indication ........................................................................22
8.3 MVB..............................................................................................................23
8.3.1 MVB line state indication..............................................................................24
9Indications and settings....................................................................25
9.1 System LEDs................................................................................................25
9.2 Service mode and factory setting .................................................................26
9.3 Commissioning.............................................................................................26
10 Mounting, installation rules ..............................................................27
10.1 Mounting instructions....................................................................................27
10.2 Holes for mounting into frame ......................................................................29
10.3 Installation rules............................................................................................29
11 Ordering information, package contents.........................................30
11.1 Ordering Information.....................................................................................30
11.2 Package contents.........................................................................................30
11.3 Connectors...................................................................................................30
12 Packing ...............................................................................................31
13 Storing.................................................................................................32
14 Maintenance .......................................................................................33
15 Waste disposal...................................................................................34

RRU-WEM/1158
rru-wem1158_g_en_100 4/34
History of revisions
Document name: rru-wem1158_g_en_100.pdf
Revision
Date
Author of change
Changes
100
1. 08. 2017
Škoch J.
New document
Related documentation
1. WTB / Ethernet / MVB Gateway Programming manual file: rru-wem1158_1_ms_en_xxx.pdf
2. Application Note AP0037  Principles of using Ethernet network
file: ap0037_en_xx.pdf

RRU-WEM/1158
5/34 rru-wem1158_g_en_100
1 Definition of used abbreviations
Bus Administrator
Electric Middle Distance
Medium Attachment Unit
Multifunction Vehicle Bus
Message Data
Process Data
To Be Defined
Train Communication Network
Wire Train Bus
BA
EMD
MAU
MVB
MD
PD
TBD
TCN
WTB

RRU-WEM/1158
rru-wem1158_g_en_100 6/34
2 Definition of used terms
Bus Administrator
MVB device with Bus Administrator functionality is able to work as MVB bus
Master. This function supposes the device is able to transfer the process data
and reports as well as transmit and receive the Device Status type information.
Electric Middle Distance
This is a type of physical interface of MVB line, where a twisted pair of shielded
wires is used for interconnection with implementing of transformer coupling for
galvanic isolation. EMD medium is used for up to 32 nodes and for distances to
200 m.
End Setting
The node in this state is physically connected on the end of WTB line, or
between two independent segments. One of the MAU channels is connected in
direction 1 and the second in direction 2. The WTB line segments, connected in
direction 1 and 2 are disconnected. Terminating resistors are connected in both
directions.
Intermediate Setting
The node in this state is physically connected in the middle of WTB line. The
main MAU channel is connected in direction 1 or in direction 2, the auxiliary
MAU channel is deactivated. The WTB line segments, connected in direction 1
and 2 are interconnected. The terminating resistors are disconnected in both
directions.
Line gate (Line Unit)
All HW resources, providing the electrical connection of MAU to the WTB line.
Medium Attachment Unit
Part of node, which arranges the link to transmission medium.
Sleep Mode
In this mode the node goes to End Setting state. Only part of MAU is active.
The node detects valid frames on line.
To Be Defined
Information will be completed in document revision.
TCN Gateway
MVB device with TCN Gateway function is able to access to other buses. This
function supposes the device is able to transfer the process data and reports
as well as transmit and receive the Device Status type information.

RRU-WEM/1158
7/34 rru-wem1158_g_en_100
3 Introduction
RRU-WEM/1158 is a compact WTB / ethernet / MVB gateway. WTB gateway
is mounted into the 19” subrack, or it could be mounted into other suitable frame
structure. WTB gateway contains one doubled WTB interface and one doubled
MVB interface. WTB gateway RRU-WEM/1158 contains working Ethernet line
(connector M12).
▪1 × WTB interface (doubled line)
▪1 × MVB interface (double line)
▪1 × Ethernet 100 Mbps (connector M12)
▪Power supply 110 V DC
▪Mounting in to the 19" subrack, or in to the frame structure
▪Compact aluminium chassis
▪Rolling stock electronic device
▪Design according to EN 50155:2007
▪Approved according to UIC CODE 556:2010
Basic features

RRU-WEM/1158
rru-wem1158_g_en_100 8/34
4 Technical parameters
Number of WTB lines
1 (double line)
Operation indication
16 × LED
Galvanic isolation
Yes, 1000 V AC / 1 minute 1)
Fritting
No
Communication rate
1 Mbps 0.01 %
Max. number of devices
32
Max. segment length without repeater
860 m
Characteristic impedance
120 Ω 2)
Connection points
4 × D-sub DE-9,
according to IEC 61375-1:2007,
connector fixing by M3 bolt
Standards
IEC61375-1:2007 (Ed. 2.0)
UIC CODE 556:2010 (Ed. 5.0)
1) Galvanic isolation must not be used for dangerous voltage separation.
2) Terminator is included in unit. Connection of terminator at end node is
provided automatically by unit firmware.
Number of interfaces
1
Operation indication
2 × LED (LNK and ACT)
Galvanic isolation
Yes, 1000 V AC / 1 minute 1)
Data transmission rate
100 Mbps
Recommended cabling
STP CAT5
Maximum segment length
100 m
Operation indication
LED (LNK and ACT)
Connection point
M12 connector
according to IEC 61375-3-4:2012 (Ed.1.0)
D-coding
1) Galvanic isolation must not be used for dangerous voltage separation.
Number of interfaces
1 (double line)
Interface type
EMD
MVB class (according to IEC 61375-2
ed. 1)
Class 5 without BA
Operation indication
8 × LED
Galvanic isolation
Yes, 1000 V AC / 1 minute 1)
Data transmission rate
1.5 Mbps ± 0.01 %
Recommended cabling
Shielded cable
Max. number of devices
32
Max. segment length without repeater
200 m
Characteristic impedance
120 Ω 2)
Connection points
2 × connector D-sub DE-9 (concatenation)
dle normy IEC61375-3-1:2012 (Ed. 1.0),
connector fixing by M3 bolt
Standard
IEC61375-3-1:2012 (Ed. 1.0)
1) Galvanic isolation must not be used for dangerous voltage separation.
2) Terminators are not part of the delivery (see tab. Ordering information).
WTB
Ethernet
MVB

RRU-WEM/1158
9/34 rru-wem1158_g_en_100
Power supply voltage range
(permanent)
66 V DC to 154 V DC
Maximum power consumption
Max. 0.1 A at 110 V DC
Inrush current
Max. 2 A < 2 ms at 110 V DC
Galvanic isolation
Yes, 1000 V AC / 1 minute 1)
Connection point
Connector WAGO 769-663/003-000
Connector counterpart
Connector WAGO 769-103/021-000
Wire cross section
0.75 mm2to 2.5 mm2
1) Galvanic isolation must not be used for dangerous voltage separation.
Mechanical design
Compact aluminium tube, anodized black
Front and rear panel made of aluminium
alloy with anti-corrosion surface finish 1)
Mounting
Into 19“ subrack
Ingress protection rate
IP20 2)
Weight–netto
–brutto
1,56 kg ±5 %
2.00 kg ±5 %
Dimensions in standard units (w × h)
28 HP × 3 U 3)
Dimensions (w × h × d)
(142 × 129 × 204) mm 4)
1) Front panel is made from aluminium alloy without detail specifying of
additives composition. Surface is naturally anodized.
2) After all cable connectors are connected.
3) 1 HP (horizontal pitch) = 0.2 inch (5.08 mm),
1U (rack unit) = 1.75 inch (44.45 mm).
4) Depth, including inserted power supply connector.
Unit overall mass of plastics
212.73 g
Included mass of self-extinguishing
plastics
212.73 g
Device does not contain
PUR, PVC, Asbestos
Device conforms
2011/65/EU (ROHS)
1907/2006EU (REACH)
Operating temperature range
-40 °C to +70 °C
Operating temperature range
-40 °C to +70 °C
Maximum ambient humidity
< 95 % non-condensing
Reliability (MTBF) min
150 000, at 40 °C ambient temperature,
methodology acc. to MIL HDBK217F2 Part
Stress 1)
1) Contact manufacturer for updated values.
None
Unit is supplied with loader, which enables software downloading by application ADS
Manager via Ethernet line.
Power supply
Mechanics
Dangerous
materials
Temperatures
Others
Components
with reduced
lifetime
Software
equipment

RRU-WEM/1158
rru-wem1158_g_en_100 10/34
WTB gateway is intended to operate up to 1 400 m above the sea level.
WTB gateway is designed to meet the Temperature Class TX.
According to EN 61373 standard, WTB gateway is classified in terms of vibrations
into Category 1, Class A (mounting to vehicle body).
Permissible supplying voltage drop-outs duration: max. 10 ms (Class S2 according to
Chapter 3.1.1.2 of EN 50155:2007).
For supply voltage switching are permissible conditions of C1 and C2 Class.
The device is not classified according to EN 50128:2011 Railway applications –
Communications, signalling and processing systems –Software for railway control
and protection systems.
The device is not classified according to EN 50129:2003 Railway applications –
Communication, signalling and processing systems –Safety related electronic
systems for signalling.
Claims of EN
50155:2007
Safety
classification

RRU-WEM/1158
11/34 rru-wem1158_g_en_100
4.1 Dimensions
141,9
138,8
168,5
171,0
203,7
128,4
32,7 127,0
122,4
RRU-WEM/1158
+110 V
Fig. 1–Physical dimensions of WTB gateway

RRU-WEM/1158
rru-wem1158_g_en_100 12/34
4.2 Recommended drawing symbol
Following drawing symbol is recommended for RRU-WEM/1158 gateway.
RRU-WEM/1158
X2
Ethernet
M12
X3
WTB A1
D-sub DE-9 M
X4
WTB A2
D-sub DE-9 F
X5
WTB B1
D-sub DE-9 M
X7
MVB-M1
D-sub DE-9 M
X8
MVB-M2
D-sub DE-9 F
X6
WTB B2
D-sub DE-9 F
X1
1
2
WAGO769-103/021-000
PE
GND
Vcc
3
Fig. 2–Recommended drawing symbol

RRU-WEM/1158
13/34 rru-wem1158_g_en_100
4.3 Block diagram
FPGA
Power
supply
DDR2
WTB
interface
Ethrenet
interface
5 V ss.
X2 X3 X4 X5 X6 X7 X8
WTB A1 WTB A2 WTB B1 WTB B2 MVB-M1 MVB-M2Ethernet
2.5 V ss.
1.8 V ss.
1.2 V ss.
MVB
interface
X1
Power
Vcc Power
supply
5 V ss.
Fig. 3–Block diagram of RRU-WEM/1158 WTB gateway

RRU-WEM/1158
rru-wem1158_g_en_100 14/34
5 Product marking
Type label is located on the side of unit‘s mechanics.Contained data is
summarized in the table below (values are illustrative):
Description
Data
Note
–
Logo AMiT
Producer logo
–
QR code
Product QR code
TYPE
RRU-WEM/1158
Product type designation
S/N
AAddddd
Serial number
MAC
00-09-54-xx-xx-xx
MAC address
FW
APP x.xx / LDR x.xx
Version of FW from production
POWER
110 V DC / 0.1 A
Power supply voltage
WEIGHT
m.mm kg
Weight netto
TEST
OK-xx
Routine testing result
HiPot
HiPot-OK
HiPot test result
DATE
dd.mm.yyyy
Production date in day/month/year
format
–
Logo CE
Unit was assessed and complies with
EU legislative requirements
–
Crossed out dustbin logo with
a full stripe
The disposal of electronic equipment is
subject to the regulations on handling
electrical waste.
TYPE
S/N
MAC
FW
POWER
WEIGHT
TEST
HiPot
DATE
RRU-WEM/1158
AA00000
00-09-54-FF-FF-FF
APP 1.00 / LDR 1.00
110 V DC / 0.1A
1.56 kg
OK-AM
HiPot-OK
01.04.2015
Fig. 4 –Illustrative example of type label

RRU-WEM/1158
15/34 rru-wem1158_g_en_100
TYPE S/N MAC FW POWER WEIGHT TEST HiPot DATE
RRU-WEM/1158 AA00000 00-09-54-FF-FF-FF APP1.00 / LDR 1.00 110 VDC / 0.1 A 1.56 kg OK-AM HiPot-OK 01.04.2015
Fig. 5 –Location of type label (illustrative picture)

RRU-WEM/1158
rru-wem1158_g_en_100 16/34
6 Conformity assessment
Provided that the unit is correctly used, it conforms with requirements of Czech
governmental decree NV117/2016. The compliance assessment with
NV117/2016 has been performed in accordance with harmonized standard EN
50121-3-2:2006.
Tested in accordance
with standard
Type of test
Classificati
on
EN 61000-4-2:2009
Electromagnetic compatibility (EMC) –
Part 4-2:Testing and measurement
techniques –Electrostatic discharge
immunity test
Complies
EN 61000-4-3:2006
Electromagnetic compatibility (EMC) –
Part 4-3:Testing and measurement
techniques - Radiated, radio-frequency,
electromagnetic field immunity test
Complies
EN 61000-4-4:2012
Electromagnetic compatibility (EMC) –
Part 4-4:Testing and measurement
techniques - Electrical fast transient/burst
immunity test.
Complies
EN 61000-4-5:2006
Electromagnetic compatibility (EMC) –
Part 4-5:Testing and measurement
techniques –Surge immunity test
Complies
EN 61000-4-6:2009
Electromagnetic compatibility (EMC) –
Part 4-6:Testing and measurement
techniques –Immunity to conducted
disturbances, induced by radio-frequency
fields
Complies

RRU-WEM/1158
17/34 rru-wem1158_g_en_100
6.1 Other tests
The unit has been assessed and approved for use in railway applications
according to standards:
Tested in accordance
with standard
Type of test
Result
EN 50155:2007
Railway applications –Electronic
equipment used on rolling stock
Complies
EN 50121-3-2:2006
Railway applications –Electromagnetic
compatibility –Part 3-2:Rolling stock –
Apparatus
Complies
EN 61373:2010
Railway applications –Rolling stock
equipment –Shock and vibration tests
Category 1,
Class B
EN 61000-4-2:2009
Electromagnetic compatibility (EMC) –
Part 4-29:Testing and measurement
techniques –Voltage dips, short
interruptions and voltage variations on
d.c. input power port immunity tests
S2, C1, C2
EN 60068-2-1:2007
Environmental testing –Part 2-1:Tests –
Test A:Cold
Complies
EN 60068-2-2:2007
Environmental testing - Part 2-2:Tests –
Test B:Dry heat
Complies
EN 60068-2-30:2005
Environmental testing - Part 2-30:Tests –
Test Db:Damp heat, cyclic (12 + 12 hour
cycle).
Complies
IEC61375-1:2007 (Ed 2.0)
Electric railway equipment –Train bus –
Part 1:Train Communication Network
Complies
IEC61375-2:2007 (Ed 1.0)
Electric railway equipment –Train bus –
Part 2:Train communication network
conformance testing
Complies
UIC CODE 556:2010
(Ed 5.0)
Information transmission in the train (train
bus)
Complies
EN 45545-2:2013
Railway applications –Fire protection on
railway vehicles –Part 2: Requirements
for fire behaviour of materials and
components
HL3

RRU-WEM/1158
rru-wem1158_g_en_100 18/34
7 Power supply
WTB gateway RRU-WEM/1158 can be powered by 110 V DC from vehicle
onboard power network.
7.1 Powering from DC network
Power supply is connected to X1 WAGO 769-663 plug.
Fig. 6–Power supply connector location
Connector WAGO 769-663/003-000
PIN
Signal
Description
1
PE
Unit chassis.
2
GND
Power supply, ground
3
Vcc
Power supply, inpu
PWR X1
connector
wiring

RRU-WEM/1158
19/34 rru-wem1158_g_en_100
8 Communication lines
8.1 WTB
WTB gateway RRU-WEM/1158 has available a WTB interface with double line,
according to IEC61375-1:2007 standard.
Both lines are connected through D-sub DE-9 connectors. Connectors are fitted
with M3 threaded nuts, that prevents the cable falling off due to vibrations or to
be broken away.
Fig. 7–Location of WTB line connectors
Connector type: D-sub DE-9, plug
Connector
PIN
Description
X3, X5
1
WTB line positive wire
2
WTB line negative wire
3
Not connected
4
Not connected
5
Not connected
6
Not connected
7
Not connected
8
Not connected
9
Not connected
WTB line
connectors
wiring
54321
9876

RRU-WEM/1158
rru-wem1158_g_en_100 20/34
Connector type: D-sub DE-9, socket
Connector
PIN
Wiring signals on RRU-WEM/1158
X4, X6
1
WTB line positive wire
2
WTB line negative wire
3
Not connected
4
Not connected
5
Not connected
6
Not connected
7
Not connected
8
Not connected
9
Not connected
8.1.1 WTB line state indication
Indication of WTB line state is provided by 16 LEDs in the middle part of front
panel. Six of these LEDs in WTB A area indicate the state of line A. Six LEDs in
WTB B area indicate the state of line B and the remaining four LEDs indicate
the node state. Following table describes meaning of the individual LEDs:
Fig. 8–LEDs front panel detail (WTB)
LED
Colour
Description
TL1
Green
Trusted Line, direction 1
TL2
Green
Trusted Line, direction 2
RX1
Green
Data reception from direction 1
RX2
Green
Data reception from direction 2
D1
Yellow
Disturbance, direction 1
D2
Yellow
Disturbance, direction 2
WMS
Green
Node is in Master composition
SLP
Green
Node is in Sleep Mode
END
Green
Node is in End Setting state
INT
Green
Node is in Intermediate Setting state
Description of
LED
12345
6789
