Amit TE1088 User guide

Networking Gateway
System Manual
S/W Version 2.0
August 2005
P/N 214196

About This Manual
This manual contains the following chapters:
Chapter 1 – Product Description: Describes the Networking Gateway
and its components.
Chapter 2 – Installation: Describes how to install the system and its
components.
Chapter 3 – Operation and Administration: Describes how to use the
web-based management application for configuring parameters and
managing the Networking Gateway.
Appendix A – Print Server: Describes how to configure the printer
server.
Appendix B – 802.1x Setting.

Contents
Chapter 1 - Product Description .......................................................1
1.1 Introducing the Networking Gateway IDU ......................................................2
1.2 Functions and Features ...................................................................................3
1.2.1 Basic Functions....................................................................................................3
1.2.2 Wireless Functions...............................................................................................4
1.2.3 Security Functions ...............................................................................................4
1.2.4 Advanced Functions ............................................................................................5
1.3 Specifications....................................................................................................6
1.3.1 Radio Specifications ............................................................................................6
1.3.2 Regulatory Standards Compliance ......................................................................6
1.3.3 Environmental ......................................................................................................7
1.3.4 Mechanical ...........................................................................................................7
1.3.5 Electrical...............................................................................................................7
Chapter 2 - Installation .....................................................................9
2.1 Installation Requirements ..............................................................................10
2.1.1 Packing List........................................................................................................10
2.1.2 Additional Installation Requirements .................................................................10
2.2 Panels Layout and Components ...................................................................11
2.2.1 Front Panel.........................................................................................................11
2.2.2 Rear Panel Components....................................................................................13
2.3 Installation.......................................................................................................14

Contents
Chapter 3 - Using the Web Configuration Server............................17
3.1 Introduction .................................................................................................... 18
3.2 Accessing the Web Configuration Server.................................................... 19
3.3 Log in and Log out ......................................................................................... 20
3.3.1 The Main Menu..................................................................................................21
3.3.2 Control Buttons .................................................................................................. 21
3.4 Status .............................................................................................................. 23
3.5 Wizard (Administrator only) .......................................................................... 25
3.6 Basic Setting................................................................................................... 33
3.6.1 WAN Setup ........................................................................................................33
3.6.2 LAN Setup..........................................................................................................42
3.6.3 Wireless Setting................................................................................................. 48
3.6.4 Change Password .............................................................................................54
3.7 Security Setting .............................................................................................. 55
3.7.1 MAC Control ......................................................................................................55
3.7.2 Packet Filters (Administrator only).....................................................................55
3.7.3 URL Blocking (Administrator only).....................................................................60
3.7.4 Domain Filter (Administrator only) ..................................................................... 62
3.7.5 Firewall (Administrator only) ..............................................................................64
3.7.6 Miscellaneous Items (Administrator only)..........................................................65
3.8 NAT Setting (Administrator only).................................................................. 67
3.8.1 Virtual Server .....................................................................................................67
3.8.2 Special AP .........................................................................................................68
3.8.3 DMZ Host........................................................................................................... 69
3.8.4 VPN Pass Through ............................................................................................70
3.9 Advanced Settings (Administrator only)...................................................... 72
3.9.1 System Time ...................................................................................................... 72

Introducing the Networking Gateway IDU
3.9.2 System Log ........................................................................................................73
3.9.3 Dynamic DNS.....................................................................................................75
3.9.4 SNMP Setting.....................................................................................................76
3.9.5 Routing Table.....................................................................................................77
3.9.6 Schedule Rule....................................................................................................80
3.9.7 UPnP Setting......................................................................................................83
3.10 Toolbox............................................................................................................84
3.10.1 View Log ............................................................................................................84
3.10.2 Firmware Upgrade (Administrator only).............................................................85
3.10.3 Backup Setting...................................................................................................86
3.10.4 Reset to Default .................................................................................................87
3.10.5 Reboot................................................................................................................87
3.10.6 DRAP .................................................................................................................88
3.10.7 Miscellaneous Items ..........................................................................................89
3.11 Web Configuration Server’s Parameters Summary.....................................91
Appendix A - Print Server..............................................................103
A.1 Configuring on Windows 2000 and XP Platforms......................................104
Appendix B - 802.1x Setting..........................................................111
Glossary.........................................................................................119
Manual Revision
vii

Figures
Figure 1: Front Panel .........................................................................................................................11
Figure 2: Rear Panel (without antenna).............................................................................................13
Figure 3: Log In Window....................................................................................................................20
Figure 4: Networking Gateway Main Window....................................................................................21
Figure 5: System Status ....................................................................................................................23
Figure 6: Setup Wizard ......................................................................................................................25
Figure 7: Setup Wizard - Select WAN Type ......................................................................................25
Figure 8: Setup Wizard – WAN Type - Static IP Address..................................................................26
Figure 9: Setup Wizard - Dynamic IP Address ..................................................................................27
Figure 10: Setup Wizard - Dynamic IP Address with Road Runner Session Management..............28
Figure 11: Setup Wizard – PPP over Ethernet ..................................................................................29
Figure 12: Setup Wizard – PPTP.......................................................................................................30
Figure 13: Setup Wizard - Configuration Completed.........................................................................32
Figure 14: Basic Setting.....................................................................................................................33
Figure 15: WAN Setup/Primary Setup...............................................................................................33
Figure 16: Virtual Computers.............................................................................................................34
Figure 17: Choose WAN Type...........................................................................................................35
Figure 18: Primary Setup - Static IP Address....................................................................................36
Figure 19: Primary Setup - Dynamic IP Address...............................................................................37
Figure 20: Primary Setup - Dynamic IP Address with Road Runner Session Management.............38
Figure 21: Primary Setup - PPPoE ....................................................................................................40
Figure 22: Primary Setup - PPTP ......................................................................................................41
Figure 23: LAN Setup ........................................................................................................................42
Figure 24: LAN Setup - DHCP Server Enabled.................................................................................44

Figures
Figure 25: DHCP Clients List.............................................................................................................45
Figure 26: MAC Address Control.......................................................................................................46
Figure 27: DHCP Clients Combo Box ...............................................................................................48
Figure 28: Wireless Setting ...............................................................................................................48
Figure 29: Wireless Clients List .........................................................................................................51
Figure 30: Advanced Wireless Setting ..............................................................................................52
Figure 31: Change Password ............................................................................................................54
Figure 32: Security Setting Window ..................................................................................................55
Figure 33: Packet Filter Initial Window ..............................................................................................56
Figure 34: Inbound Packet Filter – Example 1 ..................................................................................58
Figure 35: Inbound Packet Filter - Example 2 ...................................................................................58
Figure 36: Outbound Packet Filter - Example 1 ................................................................................59
Figure 37: Outbound Packet Filter - Example 2 ................................................................................60
Figure 38: URL Blocking....................................................................................................................60
Figure 39: URL Blocking Example.....................................................................................................61
Figure 40: Domain Filter ....................................................................................................................62
Figure 41: Firewall .............................................................................................................................64
Figure 42: Miscellaneous Items.........................................................................................................65
Figure 43: NAT Setting ......................................................................................................................67
Figure 44: Virtual Server....................................................................................................................67
Figure 45: Special Applications .........................................................................................................69
Figure 46: DMZ Host .........................................................................................................................70
Figure 47: VPN Pass Through...........................................................................................................70
Figure 48: Advanced Setting .............................................................................................................72
Figure 49: System Time ....................................................................................................................72
Figure 50: System Log ......................................................................................................................74
Figure 51: Dynamic DNS...................................................................................................................75
Figure 52: SNMP Setting...................................................................................................................76
Figure 53: Routing Table ...................................................................................................................78

Introducing the Networking Gateway IDU
Figure 54: Schedule Rule ..................................................................................................................80
Figure 55: Schedule rule Setting .......................................................................................................81
Figure 56: Schedule Rule Setting – Example Step 1 ........................................................................81
Figure 57: Schedule Rule Setting – Example Step 2 ........................................................................82
Figure 58: Virtual Server - Schedule Rule#1 .....................................................................................82
Figure 59: Packet Filter - Schedule Rule#1.......................................................................................83
Figure 60: UPnP Setting ....................................................................................................................83
Figure 61: Toolbox.............................................................................................................................84
Figure 62: View System Log..............................................................................................................85
Figure 63: Firmware Upgrade............................................................................................................86
Figure 64: Backup..............................................................................................................................87
Figure 65: Reset to Default................................................................................................................87
Figure 66: Reboot ..............................................................................................................................88
Figure 67: DRAP Protocol .................................................................................................................88
Figure 68: Toolbox - Miscellaneous Items.........................................................................................89
Manual Revision
xi

Tables
Table 1: Radio Specifications ..............................................................................................................6
Table 2: Regulatory Standards Compliance........................................................................................6
Table 3: Environmental Specifications.................................................................................................7
Table 4: Mechanical Specifications .....................................................................................................7
Table 5: Electrical Specifications .........................................................................................................7
Table 6: Front Panel LEDs ................................................................................................................11
Table 7: Rear Panel Connectors .......................................................................................................13
Table 8: Status Window Parameters .................................................................................................23
Table 9: Setup Wizard – Static IP Address Parameters....................................................................27
Table 10: Setup Wizard – Dynamic IP Address Parameters.............................................................28
Table 11: Setup Wizard – Dynamic IP Address with Road Runner Session Management
Parameters ........................................................................................................................................29
Table 12: Setup Wizard – PPPoE Parameters..................................................................................30
Table 13: Setup Wizard – PPTP Parameters ....................................................................................31
Table 14: Virtual Computers Parameters ..........................................................................................34
Table 15: Static IP Address Parameters ...........................................................................................36
Table 16: Dynamic IP Address Parameters ......................................................................................38
Table 17: Dynamic IP Address with Road Runner Session Management Parameters ....................39
Table 18: PPP over Ethernet Parameters .........................................................................................40
Table 19: PPTP Parameters..............................................................................................................41
Table 20: LAN Setup Parameters......................................................................................................43
Table 21: DHCP Clients List Parameters ..........................................................................................45
Table 22: DHCP Clients List Parameters ..........................................................................................46
Table 23: Wireless Setting Parameters .............................................................................................49

Tables
Table 24: Wireless Clients List Parameters ......................................................................................51
Table 25: Advanced Wireless Setting Parameters............................................................................52
Table 26: Advanced Wireless Setting Parameters............................................................................56
Table 27: URL Blocking Parameters .................................................................................................61
Table 28: Domain Filter Parameters..................................................................................................63
Table 29: Firewall Parameters...........................................................................................................64
Table 30: Miscellaneous Items Parameters ......................................................................................65
Table 31: Virtual Server Parameters .................................................................................................68
Table 32: Special Applications Parameters.......................................................................................69
Table 33: VPN Pass Through Parameters ........................................................................................71
Table 34: System Time Parameters ..................................................................................................73
Table 35: System Log Parameters ....................................................................................................74
Table 36: Dynamic DNS Parameters ................................................................................................76
Table 37: SNMP Parameters.............................................................................................................77
Table 38: Routing Table Parameters.................................................................................................78
Table 39: Routing Table Parameters.................................................................................................80
Table 40: DRAP Protocol Parameters...............................................................................................88
Table 41: Miscellaneous Items Parameters ......................................................................................90
Table 42: Web Configuration Server’s Parameters Summary .......................................................... 91

1
1
Chapter 1 - Product Description
In This Chapter:
Introducing the Networking Gateway IDU, page 2
Functions and Features, page 3
Specifications, page 6

Chapter 1 - Product Description
1.1 Introducing the Networking Gateway
IDU
The Networking Gateway Indoor Unit (IDU) enables operators and service
providers using a Broadband Wireless Access system to provide subscribers
with a number of broadband services transparently.
The Networking Gateway IDU together with the SU-ODU comprises a
Subscriber Unit that provides data connections to the Base Station. The
four 10/100Base-T Ethernet ports connect to the user’s data equipment,
providing comprehensive routing functionality and supporting various
security features. User’s data equipment equipped with either IEEE
802.11b (11M) or IEEE 802.11g (54M) compatible wireless adapters can
connect to the unit via its built-in Wireless LAN port, functioning as an
Access Point.
The Networking Gateway IDU is powered from the mains. The Networking
Gateway IDU is connected to the ODU via a category 5E Ethernet cable.
This cable carries the Ethernet data between the two units as well as power
(54 VDC) and control signals to the ODU. It also carries status indications
from the ODU.
The Networking Gateway is designed for remote management and
supervision using either the built-in internal web server or SNMP.
The Networking Gateway is easily updated and upgraded as it supports
remote software and configuration file download.
Product Description
2

Functions and Features
1.2 Functions and Features
1.2.1 Basic Functions
Auto-sensing Ethernet Switch
Equipped with a 4-port auto-sensing Ethernet switch.
Printer sharing
Embedded print server to allow all of the networked computers to share
one printer through the USB host port.
WAN Types
Support of several WAN types: Static, Dynamic, PPPoE, PPTP, and
Dynamic IP with Road Runner Session Management (e.g., Telstra,
BigPond).
Firewall
All unwanted packets from outside intruders can be blocked to protect
the Intranet.
DHCP Server Support
All of the networked computers can retrieve TCP/IP settings
automatically from the Networking Gateway.
Web-based configuring
Configurable through any networked computer’s web browser using
Netscape or Internet Explorer.
Virtual Server Support
Enables to expose WWW, FTP and other services on your LAN to other
Internet users.
User-Definable Application Sensing Tunnel
Users can define the attributes to support special applications requiring
multiple connections, such as Internet gaming, video conferencing,
Internet telephony and so on. The Networking Gateway can sense the
application type port as a trigger and open a multi-port tunnel for it.
DMZ Host Support
Lets one specific networked computer be fully exposed to the Internet.
This function is used when special application sensing tunnel feature is
insufficient to allow an application to function correctly. Use with
caution.
NG System Manual
3

Chapter 1 - Product Description
Statistics of WAN Support
Enables to monitor inbound and outbound packets.
1.2.2 Wireless Functions
High speed for wireless LAN connection
Up to 54 Mbps data rate by incorporating Orthogonal Frequency
Division Multiplexing (OFDM).
IEEE 802.11b compatible (11M)
Allowing inter-operation among multiple vendors.
IEEE 802.11g compatible (54M)
Allowing inter-operation among multiple vendors.
Auto fallback
54M, 48M, 36M, 24M, 18M, 12M, 6M data rates with auto fallback in
802.11g mode.
11M, 5.5M, 2M, 1M data rates with auto fallback in 802.11b mode.
1.2.3 Security Functions
Packet Filter
Packet Filter allows controlling access to a network by analyzing the
incoming and outgoing packets and letting them pass or blocking them
based on the source and destination IP addresses and ports.
Domain Filter Support
Enables preventing users from accessing specific domains.
URL Blocking Support
URL Blocking uses keywords to block hundreds of applicable websites
connections.
VPN Pass-through
The Networking Gateway can also support VPN pass-through.
802.1X Support
When the 802.1X function is enabled, the Wireless user must be
authenticated by the Networking Gateway before being allowed to use
the Network services.
Product Description
4

Functions and Features
SPI Mode Support
When SPI Mode is enabled, the Networking Gateway checks every
incoming packet and detects if this packet has changed its IP address
since initial negotiation.
DoS Attack Detection Support
When this feature is enabled, the Networking Gateway detects and logs
Denial of Service (DoS) attack arriving from the Internet.
1.2.4 Advanced Functions
System Time
Allows synchronizing system time with a network time server, with the
PC, or set the time manually.
E-mail Alert
The Networking Gateway can be configured to send its log file by mail.
Dynamic DNS
At present, the Networking Gateway supports 3 Dynamic DNSs:
DynDNS.org, TZO.com and dhs.org.
SNMP Support
The Networking Gateway supports SNMP V1 and V2c.
Routing Table
The Networking Gateway supports static routing and two kinds of
dynamic routing: RIP1 and RIP2.
Schedule Rule
Customers can control the schedule (when to allow and when to block)
for several functions, such as virtual server and packet filters.
NG System Manual
5

Chapter 1 - Product Description
1.3 Specifications
1.3.1 Radio Specifications
Table 1: Radio Specifications
Item Description
Frequency 2400-2483.5 MHz
Wireless LAN Standards Compliant with IEEE 802.11b and IEEE 802.11g
Output Power (Average) 10, 12, 15, 17 dBm
Data Rates IEEE 802.11g mode: 54M, 48M, 36M, 24M, 18M, 12M, 6M
with auto fallback in.
 IEEE 802.11b mode: 11M, 5.5M, 2M, 1M with auto fallback
in.
1.3.2 Regulatory Standards Compliance
Table 2: Regulatory Standards Compliance
Type Standard
EMC ETS EN 301 489-17
Safety EN 60950 (CE)
IEC 60 950 US/C UL
Radio ETSI 300 328
FCC Part 15
Immunity EN 55024:1998
Product Description
6
