Anova RCPWF6 User manual

anovafurnishings.com
888.535.5005 tel
TOOLS NEEDED:
• 9/16" Open-end or box-end wrench
• Ratchet with 9/16" socket
• 18 Volt (or higher) driver with No. 3
Phillips head bit
Assembly Instructions
Wainwright
RCPWF6 - Wainwright 6' Flat Bench
RCPWF4 - Wainwright 4' Flat Bench
BENCH COMPONENTS:
ASSEMBLY HARDWARE: All hardware is stainless steel.
(2) Bench Supports (1 or 2) Seat Braces (2) Seat End Caps (5) Seat Planks (1) Seat Support
(2) 3/8"-16 X 3"
Carriage Bolts
(5 or 10) Phillips
Head Screws
(8) 3/8"-16 X 2 1/2"
Carriage Bolts
(2) 3/8"-16 X 1 1/4"
Hex Head Bolts
(8) 3/8"Lock
Washers
(10) 3/8"-16
Hex Nuts
(2) 3/8"-16
Nylock Nuts
(14) 3/8" Flat
Washers
ASSEMBLY:
Inspect the shipping container contents for damage and to
determine that all components and hardware are present.
1.
2. Locate the two bench supports and place them the
approximate distance of the seat on the packaging
cardboard or other so surface to avoid scratching the
product.
3. Locate the seat support and position it between the two
bench supports. Orient the seat support with the open side
facing downward. Hold the seat support so that the side
mounting holes in the support match up with the mounting
holes in the bench support. Place a 3/8" at washer on one
of the 3/8"-16 X 1 1/4” hex head bolts and insert the bolt
through the bench support and the seat support. Put a
3/8" at washer and 3/8"-16 hex nut on the end of the bolt
and tighten nger tight. Repeat this step for both sides of
the seat. Leave the hardware nger tight so adjustments
can be made during assembly.
NOTE: Before assembling the nuts to the bolts, it is
recommended that a light oil or petroleum jelly be applied
to the screw threads.
1
The assembly is a two-person operation.
3/8"-16 X 1 1/4"
Hex Head Bolt
3/8" Flat Washer
3/8" Flat Washer
3/8"-16 Hex Nut
Seat Support
Bench Support
Wainwright 6' Flat BenchWainwright 4' Flat Bench

2
4. Place either one or two seat braces on the seat support depending
on whether you are assembling the 4' bench or 6' bench. Make sure
the center hole in the seat brace aligns with the mounting hole in the
seat channel.
5. Place the ve seat planks over the seat supports and seat braces.
NOTE: When laying out the planks, make sure the surface with the
pre-drilled pilot holes face downward. Place the seat end cap over
each end of the seat planks.
6. Secure the end caps and planks using a 3/8"-16 X 3” carriage bolt
through the center seat plank and a 3/8"-16 X 2 1/2” carriage bolt
through the remaining seat planks. Install a 3/8" at washer and
3/8" nylock nut to each of the 3” carriage bolts and install a 3/8" at
washer, 3/8" lock washer and 3/8"-16 hex nut to each of the 2 1/2”
carriage bolts. Tighten the hardware nger tight so adjustments can
be made while installing the Phillips head screws.
7. Using a driver with a No. 3 Phillips head bit, drive a Phillips head
screw through each of the holes in the seat braces, seat supports and
into the matching pre-drilled holes in the seat planks.
3/8"-16 X 2 1/2"
Carriage Bolt
Seat End Cap
3/8" Flat Washer
3/8" Flat Washer
3/8" Lock Washer
3/8"-16 Hex Nut
3/8"-16 Nylock Nut
3/8"-16 X 3"
Carriage Bolt
Aer the Phillips head screws are installed in the seat planks, tighten
the hardware on the carriage bolts on the ends of the seat planks.
Tighten all of the hardware throughout the seat. Move the assembled
seat to the desired location.
8.
Aer two weeks, retighten all of the hardware.9.
Seat Brace
Seat Plank
Phillips Head Screw

Copyright 2018 ANOVA® Made in USA. 3
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
02/06/2018
A A B B
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET 1 OF 1
DRAWN
CHECKED
QA
MFG
APPROVED
dmetz 1/25/2018
DWG NO
TITLE
SIZE
D
SCALE
REV
.12:1
19.57"
44.00"
 .50"
19.57"
68.00"
 .50"
6' BENCH FOOT MOUNT
Assembly and Replacement Parts
Seat Support
Bench Support
Seat Brace
Seat Plank
Seat End Cap
A A B B
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
SHEET 1 OF 1
DRAWN
CHECKED
QA
MFG
APPROVED
dmetz 1/25/2018
DWG NO
TITLE
SIZE
D
SCALE
REV
.12:1
19.57"
44.00"
 .50"
19.57"
68.00"
 .50"
4' BENCH FOOT MOUNT
