ASSEMBLY INSTRUCTIONS
L1360 6  Rendezvous Bench
L1361 4  Rendezvous Bench
L1504 4  Horizon Bench
L1506 6  Horizon Bench
Bench End
Screw
Washer
Nut
Contour
Bench Seat
Bench End
Screw Washer
Nut
Contour
Bench Seat
Packaging plastic and
cardboard to avoid
scratching the product
.50”
.66”
TOOLS NEEDED:
9/16” Open-end or Box-end Wrench•
Ratchet with 9/16” Socket•
#4 Phillips Screwdriver•
Level•
ASSEMBLY HARDWARE:
NOTE: Hardware arrives in two packages; one with each Bench End.
4 x
3/8”
Washer
4 x
3/8”
Flanged Hex Nut
4 x
3/8” X 1.5”
Phillips Head Screw
ASSEMBLY:
The assembly is a two-person operation.
1. Inspect the shipping container contents for damage and to determine that all components and hardware are present.
1 x Contour Bench Seat
BENCH COMPONENTS:
2 x Bench Ends
2. Place the Contour Bench Seat on the shipping
packaging or other so surface to avoid
scratching the product.
Note: Before assemblying the Nuts to the
Screws, it is recommended that a light oil
or petroleum jelly be applied to the screw
threads
3. Align the mounting holes in one of the
Bench Ends with the holes in the appropriate
end of the Bench Seat. Insert one of the
provided Screws through both parts, with
the screw head on the outside surface of the
Bench End. Install a Washer and Nut on the
inside end of the Screw.
Note: Always hold the screw head still and turn
the Nut. This protects the surface of the
Bench around the Screw from scratches (the
Washer protects the nut side of the Bench)
Leave the hardware nger tight so that
adjustments can be made to level the bench
seat.
Model L1360 shown.
Seat pattern may vary.

Do not drag the assembled unit across any surface.•
This product requires only periodic cleaning with a sponge and a solution of mild detergent and water to•
remove surface dirt. Do not clean with a solvent or petroleum based products.
Furniture must not be used other than for its intended purpose and should be inspected regularly for loose,•
missing, or broken hardware, and general instability.
Furniture that is damaged or appears to be unstable must be removed from service and be repaired or replaced.•
Repairs must be made using only factory authorized parts and methods.•
WARNING
CARE AND
MAINTENANCE
211 North Lindbergh Blvd.
St. Louis, MO 63141
tel: [phone]
web: anovafurnishings.com
11/2012
Bench End
Screw
Washer
Nut
Contour
Bench Seat
Bench End
Screw Washer
Nut
Contour
Bench Seat
Packaging plastic and
cardboard to avoid
scratching the product
.50”
.66”
Bench End
Screw
Washer
Nut
Contour
Bench Seat
Bench End
Screw Washer
Nut
Contour
Bench Seat
Packaging plastic and
cardboard to avoid
scratching the product
.50”
.66”
The feet of the Bench Ends
feature a surface mount cutout
for securing the Bench with
customer supplied surface
mount hardware.
Bench End
Screw
Washer
Nut
Contour
Bench Seat
Bench End
Screw Washer
Nut
Contour
Bench Seat
Packaging plastic and
cardboard to avoid
scratching the product
.50”
.66”
Surface mount cutout dimensions
Install a Screw, Washer, and Nut through the other set
of mounting holes in that end of the Bench Seat. Again,
leave the hardware nger tight.
4. Attach the other Bench End to the Bench Seat as shown.
Leave the hardware nger tight so adjustments can be
made to level the Bench Seat.
5. Tighten the Bench Seat hardware using the Screwdriver
and Ratchet Wrench while checking the seat surface
with a Level; minor adjustments can be made while
tightening the hardware to make the seat level.
6. Retighten all hardware two weeks aer initial assembly.
