Anova D1007 User manual

anovafurnishings.com
888.535.5005 tel
TOOLS NEEDED:
• 1/2" Open-end or box-end wrench
• Ratchet with 1/2" socket
• Level
• Rubber Mallet
Assembly Instructions
D1007
D1105
D2003
D2003COM
D2005
D2006
D2014
L2003
TABLE COMPONENTS:
ASSEMBLY HARDWARE: All hardware is stainless steel.
(2) Table Supports (1) Table Top (2) Seats (2) Cross Braces
ASSEMBLY:
Inspect the shipping container contents for damage and to determine that all components and hardware are present.1.
2. Place the tabletop upside down on the shipping packaging or
other so surface to avoid scratching the product. Locate one
of the supports and position it near the end of the tabletop.
3. Align the mounting holes in the support with the holes in
the bracket on one end of the tabletop. Install a washer onto
one of the provided bolts and insert the bolt through onto
one of the provided bolts and insert the bolt through one of
the mounting holes in both parts, with the bolt head on the
outside surface of the support. Install a washer and nylock
nut on the inside end of the bolt.
NOTE: Before assembling the nuts to the bolts, it is
recommended that a light oil or petroleum jelly be applied to
the screw threads.
NOTE: Installing the bolt in this direction reduces the risk of
scratching during use.
Leave the hardware nger tight so that adjustments can be
made during assembly and leveling.
Install a bolt and washer through the mounting hole in the
support and tabletop bracket, and install a washer and nylock
nut. Again, leave the hardware nger tight.
1
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
Picnic Table
F1038
F1105
F1149
F2003
F2014
F6420
(16) 5/16"-18 x 1 1/4"
Hex Head Bolts
(16) 5/16-18
Nylock Nuts
(32) 5/16
Flat Washers
(4) Rubber Feet
The assembly is a two-person operation.
Support
Support Washer
Washer
Bolt
Nylock
Nut
Tabletop
Bracket
Tabletop
packaging cardboard
or other so surface

Copyright 2018 ANOVA® Made in USA. 2
Note: Please contact Customer Care at 1-866-797-1761 when ordering replacement parts.
04/03/2018
4. Position the remaining support near the other end of the tabletop.
Align the mounting holes in the support with the holes in the bracket on
the end of the tabletop. Install a washer onto a bolt and insert the bolt
through one of the mounting holes in both parts, with the bolt head on the
outside surface of the support.
5. Locate the four rubber feet and place them in the outermost holes on the
bottom of the supports. Use the rubber mallet to set the feet into place.
7. Attach the other cross brace to the tabletop and other support bracket in
the same manner. Leave the hardware nger tight.
8. Locate one of the seats and position it up to the support seat brackets.
Line up the mounting holes in the seat with the mounting holes in the
support seat bracket. Insert a bolt with a washer through each of the sets
of mounting holes and tighten nger tight.
9. Turn the table right side up and tighten all hardware while checking with a
level.
10. Move the assembled table to desired location.
11. Retighten hardware two weeks aer initial assembly.
Repeat this step for the seat on the other side of the table.
6. Locate one of the cross braces and position it so that the mounting hole in
one end aligns with the mounting hole in the bracket in the center of the
support. Put a washer on one of the bolts and insert the bolt through the
cross brace and support bracket and put a washer and nylock nut on the
end of the bolt.
Leave the hardware nger tight so that adjustments can be made while
assembling and leveling.
Position the other end of the cross brace so the mounting hole aligns with
the hole closest to the center of the tabletop bracket. Install a bolt and
washer through the cross brace and the tabletop bracket and install a
washer and nylock nut on the end of the bolt. Again, leave hardware nger
tight.
Washer and
Nylock Nut
Washer and
Nylock Nut
Support
Bolt and
Washer
Tabletop
Rubber
Foot
Rubber
Foot
Bolt and
Washer
Bolt and
Washer
Cross Brace
Support Seat
Bracket
Washer and
Nylock Nut
