ARB LINX LX100 User manual

OPERATION GUIDE
LX100 Vehicle Accessory Interface Kit | 03.08.18
LIN
VEHICLE ACCESSORY INTERFACE

PAGE 2
| LX100 VEHICLE ACCESSORY INTERFACE KITOPERATION GUIDE
WHAT IS
LINX?

| LX100 VEHICLE ACCESSORY INTERFACE KITOPERATION GUIDE
PAGE 3
WHAT IS
LINX?
INTRODUCING TOTAL CONTROL
LINX is a unique modern controller that declutters the dashboard and centralises the command of vehicle accessories by
replacing classic switches, gauges and monitors with one sleek and smart driver interface. Built on an expandable platform,
LINX will continue to evolve your on and off road driving experience both now and into the future.
The mobile touchscreen display integrates seamlessly into the vehicle cabin and mounts to a magnetic gimbal that’s
installed within easy reach of the driver. This connects to the LINX Controller which is the brains behind the system, and is
conveniently installed out-of-sight either underneath the dash or the seat.
STAY IN THE LOOP
For the latest details, updates and list of accessories, head over to:
www.linx.arb.com.au
LINX is a sleek touchscreen interface that enables total control of
both new and existing 4X4 Accessories. Gone are the days where
the only option for installing aftermarket switches meant drilling
multiple holes into the dashboard.

| LX100 VEHICLE ACCESSORY INTERFACE KITOPERATION GUIDE
PAGE 4
TABLE OF
CONTENTS
Get to know the basic in’s and out’s of your brand new LINX -
the next generation of 4x4 Accessories.
KIT CONTENTS
01. WHAT’S IN THE BOX? p.7
OVERVIEW
02. COMPATIBLE ARB ACCESSORIES p.9
03. OPTIONAL ACCESSORIES p.10
INITIAL SETUP
04. SETTING UP YOUR LINX p.13
05. GETTING STARTED p.14
SWITCHING ON/OFF p.15
UPDATING LINX SOFTWARE p.16
BLUETOOTH PAIRING THE DISPLAY WITH CONTROLLER p.18
OPERATING LINX
06. LINX DISPLAY p.21
07. HOME SCREEN p.22
08. SETTINGS MENUS p.24
QUICK SETTINGS MENU p.24
MAIN SETTINGS MENU p.24
09. LINX USER INTERFACE p.25
LINX DISPLAY SCREENS p.26
10. LINX MAIN ICON SCREEN p.27
ACCESSING EACH MODULE p.28
RETURNING TO LINX MAIN ICON SCREEN p.28
LINX SETTINGS SCREEN p.29
11. UPDATING LINX p.30
MODULES OVERVIEW
12. FRONT AND REAR TRACTION MODULES p.32
CONFIGURING TRACTION MODULES: AIR LOCKER SETUP p.33
13. COMPRESSOR MODULE p.35
SWITCHING ON COMPRESSOR p.35
CONFIGURING COMPRESSOR MODULE p.36
CONFIGURING PRESSURE CONTROL p.36
PRESSURE CONTROL MODE LIST p.38

| LX100 VEHICLE ACCESSORY INTERFACE KITOPERATION GUIDE
PAGE 5
14. SWITCHBOARD MODULE p.40
CONFIGURING SWITCHBOARD MODULE p.40
RENAMING ACCESSORIES p.41
AUTOMATING ACCESSORIES p.41
LOW BATTERY PROTECTION p.42
SWITCHING ON AN ACCESSORY p.42
15. BATTERY MODULE p.43
CONFIGURING BATTERY MODULE p.43
RENAMING BATTERIES p.44
LOW VOLTAGE ALARM LEVEL p.44
16. SPEEDOMETER MODULE p.46
CONFIGURING SPEEDOMETER p.46
SETTING SPEED LIMIT WARNING p.47
17. AIR SUSPENSION MODULE p.48
CONFIGURING AIR SUSPENSION p.48
RENAMING MODES p.50
ADJUSTING AIR PRESSURE p.51
18. INCLINOMETER MODULE p.52
CONFIGURING THE INCLINOMETER p.53
19. CLOCK MODULE p.54
COMPLIANCE INFORMATION
20. COMPLIANCE INFORMATION p.57
EUROPE - EU DECLARATION OF CONFORMITY p.57
USA - FCC STATEMENT p.58
ENVIRONMENTAL PROTECTION p.58

PAGE 6
| LX100 VEHICLE ACCESSORY INTERFACE KITOPERATION GUIDE
KIT CONTENTS
Each and every component to get your new LINX up and
running.
BACK TO TABLE OF CONTENTS

| LX100 VEHICLE ACCESSORY INTERFACE KITOPERATION GUIDE
PAGE 7
01.
WHAT’S IN
THE BOX?
Congratulations on the purchase of your brand new LINX. Inside the
box, you’ll nd each of the components required to get the system
up and running for your next 4x4 adventure.
NOTES
• The LINX Display 02 was specically designed to withstand the extremes of heat and cold. It has a metal coupling on the
back to connect it to the magnets on the LINX Display Gimbal Mount .
• The LINX Controller 01 and wiring looms 05 are normally mounted under the dash, however this may vary depending on
the vehicle.
• The DIN rail 06 comes assembled to the back of the LINX controller 01 and is used for securing the unit.
• The USB connection can be used to power and charge the LINX Display, and provide the communications channel between the
LINX Controller and LINX Display.
LINX CONTROLLER
LINX DISPLAY
LINX DISPLAY
GIMBAL MOUNT
USB CABLE
WIRING LOOMS (x3)
DIN RAIL 180MM
01
02
03
04
06
05
03

PAGE 8
| LX100 VEHICLE ACCESSORY INTERFACE KITOPERATION GUIDE
OVERVIEW
Out of the box, LINX offers total control of six pre-installed
modules: Front & Rear Traction, Compressor & Pressure
Control, Battery Monitoring, Speedometer, Air Suspension
Control and an Accessory Switchboard.
BACK TO TABLE OF CONTENTS

| LX100 VEHICLE ACCESSORY INTERFACE KITOPERATION GUIDE
PAGE 9
There’s a range of ARB accessories that can be
controlled and monitored by LINX.
ARB DRIVING LIGHTS
ARB offers a large range of LED, HID and Halogen driving
lights and light bars to suit your every driving need.
Designed to perform in the most extreme conditions,
they’ll keep the road ahead brightly lit and the rear visible
wherever you go.
AIR LOCKERS
Designed and manufactured in Australia, ARB Air
Lockers will enhance the traction of your 4×4 in just
about any terrain, whether it’s rock, clay, gravel, sand,
snow or mud.
ARB DUAL BATTERY SYSTEMS
Allowing you to power additional accessories without the
risk of attening the main battery, an ARB Dual Battery
System also provides peace of mind in the event of a main
battery failure.
ARB AIR COMPRESSORS
ARB Air Compressors provide many advantages;
including inating tyres and camping accessories,
running air tools, activating Air Lockers and even re-
seating a tyre onto a wheel.
0 2.
COMPATIBLE ARB
ACCESSORIES

| LX100 VEHICLE ACCESSORY INTERFACE KITOPERATION GUIDE
PAGE 10
03.
OPTIONAL
ACCESSORIES
A range of products are available to complement the
LINX Vehicle Accessory Interface.
Please refer to the LINX Installation Guide or your
nearest ARB Store or Stockist for further information.
A-PILLAR BRACKET
LINX A-Pillar Brackets are designed to provide a vehicle
specic mount that puts the LINX Display in safe and easy
reach of the driver. They are available for a large range of
popular 4WD vehicles.
